BEJ42LM6200UELED LCD TV monitor

www.lg.com OWNER’S MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. 32LS5700 42LS5700 47LS5700 55LS5700 P/NO : MFL67468101 (1111-REV00) 32LS5750 42LS5750 47LS5750 55LS5750 42LM6200 47LM6200 55LM6200 65LM6200 42LM6250 47LM6250 55LM6250 42LM6700 47LM6700 55LM6700 47LM7600 55LM7600 2 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. - TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. WARNING/CAUTION Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.  Do not use this apparatus near water.  Clean only with a dry cloth.  Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.  Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.  Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet (Can differ by country). 3 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS  Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.  Only use attachments/accessories specified by the manufacturer.  Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.  Unplug this apparatus during lightning storms or when unused for long periods of time.  Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.  Never touch this apparatus or antenna during a thunder or lightning storm.  When mounting a TV on the wall, make sure not to install the TV by hanging the power and signal cables on the back of the TV.  Do not allow an impact shock or any objects to fall into the product, and do not drop anything onto the screen.  CAUTION concerning the Power Cord (Can differ by country): It is recommended that appliances be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner’s manual to be certain. Do not connect too many appliances to the same AC power outlet as this could result in fire or electric shock. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. Do not move the TV with the power cord plugged in. Do not use a damaged or loose power cord. Be sure do grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV.  Warning - To reduce the risk of fire or electrical shock, do not expose this product to rain, moisture or other liquids. Do not touch the TV with wet hands. Do not install this product near flammable objects such as gasoline or candles, or expose the TV to direct air conditioning. 4 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS  Do not expose to dripping or splashing and do not place objects filled with liquids, such as vases, cups, etc. on or over the apparatus (e.g. on shelves above the unit).  Grounding Ensure that you connect the earth ground wire to prevent possible electric shock (i.e. a TV with a three-prong grounded AC plug must be connected to a three-prong grounded AC outlet). If grounding methods are not possible, have a qualified electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes. Short-circuit Breaker Power Supply  DISCONNECTING DEVICE FROM THE MAIN POWER The power outlet must remain readily accessed in the event the device needs to be unplugged.  As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the unit is turned off.  Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized mo…

Text truncated - open the document above for the full version.

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: Dec 14, 2011 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Mr. Harvey Sung of Digital EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. Harvey Sung of Digital EMC Co., Ltd. on our behalf shall have the same effect as acts of our own. In authorizing Digital EMC Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Christopher Johnson Sr. Manager, Standards & Compliance REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: Dec 14, 2011 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: BEJ42LM6200UE To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description File name PERMANENT 1 Block Diagram 42LM6200-UE _Block Diagram.pdf SHORT-TERM 2 External Photos 42LM6200-UE _Ext Photo.pdf 3 Internal Photos 42LM6200-UE _Int Photo.pdf 4 Test-Setup Photos 42LM6200-UE _Test Photo.pdf 5 Users Manual 42LM6200-UE _User Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Christopher Johnson Sr. Manager, Standards & Compliance

FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 1 FRONT REAR Label Location FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 2 LABEL REAR PORT FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 3 SIDE PORT

FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 1 Rear side of the EUT LABEL Label Location Wi-Fi Module Label Bluetooth Module Label Product Label

FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 1 < Inside EUT > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 2 < LCD Front > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 3 < LCD Rear > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 4 < LCD Label > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 5 < Main Board Front > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 6 < Main Board Rear > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 7 < Main Board Label > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 8 < Power Board Front > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 9 < Power Board Rear > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 10 < Power Board Label > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 11 < FHD Board Front > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 12 < FHD Board Rear > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 13 < FHD Board Label > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 14 < IR Board Front > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 15 < IR Board Rear > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 16 < IR Board Label > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 17 < BT Module Front > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 18 < BT Module Rear > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 19 < WIFI Module Front > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 20 < WIFI Module Rear > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. View 21 < CPU >

TRF-EM-003(00)081218 Copyright c 2011, DIGITAL EMC CO., LTD. Page 2 of 35 FCC ID: BEJ42LM6200UE Report No.: DREFCC1112-1906 To t a l 3 5pages CONTENTS 1. General Remarks ........................................................................................................................ 3 2. Test Laboratory ........................................................................................................................... 3 3. General Information of EUT ....................................................................................................... 4 3.1 Product Information ................................................................................................................. 4 4. Test Summary ............................................................................................................................. 5 4.1 Applied standards and test results ........................................................................................... 5 4.2 Test environment and conditions ............................................................................................. 5 4.3 Test result Summary ................................................................................................................ 5 5. Test Set-up and operation mode ............................................................................................... 6 5.1 Principle of Configuration Selection ......................................................................................... 6 5.2 Test Operation Mode ............................................................................................................... 6 5.3 Support Equipment Used ......................................................................................................... 6 6. Test Results : Emission .............................................................................................................. 7 6.1 Conducted Disturbance ........................................................................................................... 7 6.2 Radiated Disturbance ............................................................................................................ 14 Appendix 1 ..................................................................................................................................... 34 List of Test and Measurement Instruments ............................................................................. 34 TRF-EM-003(00)081218 Copyright c 2011, DIGITAL EMC CO., LTD. Page 3 of 35 FCC ID: BEJ42LM6200UE Report No.: DREFCC1112-1906 To t a l 3 5pages 1. General Remarks This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Cheoin-Gu, Yongin-Si, Gyeonggi-Do, 449-080, Korea http://www.digitalemc.com Tel: +82-31-321-2664 Fax: +82-31-321-1664 2. Test Laboratory Digital EMC Co., Ltd. has been accredited / filed / authorized by the agencies listed in the following table; Certificate Nation Agency Code Mark Accreditation Korea KOLAS 393 ISO/IEC 17025 Site Filing USA FCC 101842 678747 Test Facility list & NSA Data Japan VCCI C-1427 R-1364, R-3385 T-1442, G-338 Test Facility list & NSA Data Certification Korea KC KR0034 Test Facility list & NSA Data Germany TUV ROK1028C ISO/IEC 17025 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competent of calibration and testing laboratory”. TRF-EM-003(00)081218 Copyright c 2011, DIGITAL EMC CO., LTD. Page 4 of 35 FCC ID: BEJ42LM6200UE Report No.: DREFCC1112-1906 To t a l 3 5pages 3. General Information of EUT 3.1 Product Information Model No. 42LM6200-UE EUT Type LED LCD TV Monitor Serial No NONE FCC ID BEJ42LM6200UE Type of Sample Tested Pre-Production High Frequency 756 MHz Rating AC100-240 V~, 50/60 Hz, 1.0 A, 100 W Supplied Power for Test AC120V, 60Hz Applicant LG Electronics Inc. 19-1, Cheongho-ri, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do, 451- 713, Korea Manufacturer LG Electronics Inc. 19-1, Cheongho-ri, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do, 451-713, Korea TRF-EM-003(00)081218 Copyright c 2011, DIGITAL EMC CO., LTD. Page 5 of 35 FCC ID: BEJ42LM6200UE Report No.: DREFCC1112-1906 To t a l 3 5pages 4. Test Summary 4.1 Applied standards and test results Test Items Applied Standards Results Conducted Disturbance ANSI C63.4:2003 Comply Radiated Disturbance ANSI C63.4:2003 Comply The data in this test report are traceable to the national or international standards. 4.2 Test environment and conditions Test Items Test date (MM-DD) Temp () Humidity (% R.H.) Pressure (hPa) Conducted Disturbance 12-13 21 38 - Radiated Disturbance 12-10 12-12 23 22 36 35 4.3 Test result Summary (1) Conducted Emission(HDMI + LAN MODE) Frequency [MHz] Result [dB] Phase Detector Limit [dB] Margin [dB] 2.04200 32.4 N Average 46.0 13.6 (2) Radiated Emission(HDMI + LAN MODE) Frequency [MHz] Pol. Reading [dB] C.F. [dB/m] Result [dB(/m)] Limit [dB(/m)] Margin [dB] 675.048 H 37.9 -1.1 36.8 46.0 9.2 Note) 1. Emission Level = Reading Value + Correction Factor. 2. Correction Factor = Cable loss - Amp gain + Antenna Factor 3. Margin = Limit - Emission level TRF-EM-003(00)081218 Copyright c 2011, DIGITAL EMC CO., LTD. Page 6 of 35 FCC ID: BEJ42LM6200UE Report No.: DREFCC1112-1906 To t a l 3 5pages 5. Test Set-up and operation mode 5.1 Principle of Configuration Selection Emission : The equipment under test (EUT) was configured to measure its highest possible radiation level. The test modes were adapted accordingly in reference to the instructions for use. 5.2 Test Operation Mode - DSUB+LAN MODE - Worst Case Resolution : 1920 x 1080 Resolution - HDMI+LAN MODE - Worst Case Resolution : 1920 x 1080 Resolution - USB MODE 5.3 Support Equipment Used Unit Model No. Serial No. Manufacturer CABLE BackshellFCC ID Connect type Length (m) shield PC VOSTRO430 9K77SBX DELL POWER DSUB HDMI STEREO USB PS/2 PS/2 LAN 1.8 1.5 1.8 1.6 - 1.6 1.8 2.5 Non-shield S…

Text truncated - open the document above for the full version.

FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. Conducted Emission FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. Radiated Emission < 30 MHz ~ 1 GHz > FCC ID: BEJ42LM6200UE Copyright © 2011, DIGITAL EMC Co., Ltd. Radiated Emission < 1 GHz ~ 6 GHz >
