BEJ42PC3DUUEPlasma Display Panel

Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service. ENERGYSTAR is a set of power-saving guidelines issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LGE U. S. A.,Inc. has determined that this product meets the ENER- GY STAR guidelines for energy efficiency. P/NO : 38289U0527F Printed in Korea OWNER’S MANUAL LCD TV MODELS: 32LC2DU 37LC2DU 42LC2DU PLASMA TV MODELS: 42PC3DU 42PC3DVU 50PC3DU 60PC1D Internet Home Page : http://www.lge.com http://www.lg.ca b - Applied models: 42PC3DU/3DVU/50PC3DU 32/37/42LC2DU 2 Warning WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suffi- cient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appli- ance. NOTE TO CABLE/TV INSTALLER: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as prac- tical. REGULATORY INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics Corporation. Unauthorized modification could void the user’s authority to operate this product. COMPLIANCE: The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc. 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 Phone: 1-800-243-0000 http://www.lgusa.com CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN W W arning arning 3 Safety Instructions WARNING : To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience recepta- cles, and the point where they exit from the apparatus. 11. Only use the attachments / accessories specified by the manufacturer. Safety Instructions Safety Instructions Owner's Manual 4 Safety Instructions 12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the appa- ratus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normal- ly, or has been dropped. 15. DISCONNECTING DEVICE FROM MAINS Main plug is the disconnecting device.The plug must remain redily operable. On Disposal a. The fluorescent lamp used in this product contains a small amount of mercury. b. Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority. Note - If the TV feels cold to the touch, there may be a small “flicker” when …

Text truncated - open the document above for the full version.

17 Place the set with the screen facing down on a cushion or soft cloth as shown. Before unfolding the stand, please make sure two locks (A) on the bottom of the stand push outward. Pull the stand out as shown. After unfolding the stand, please insert and tighten the screws (provided as parts of the product) in the holes (B) on the bottom of the stand. 1 2 When connecting cables to the set, Do not disengage the lock (C). This may cause the set to fall, causing serious bodily injury and serious damage to the set. 3 Basic Connection Basic Connection (C) Hold the CABLE MANAGEMENT with both hands and push it as shown. Connect the cables as necessary. To connect an additional equipment, see the External equipment Connections section. Reinstall the CABLE MANAGEMENTas shown. 1 2 3 * Image shown here may be slightly different from your set. When closing the stand for storage - First remove the screws in the holes (B) on the bottom of the stand. And then pull two Hooks (D) of the stand bottom and fold the stand into the back of the set. - After folding, push the two Locks (A) of the stand bottom outward. (A) (B) (D) (A) (B) How to use stand (For 42PC3DU/3DVU) How to arrange the cable (For 50PC3DU) For 60PC1D, 42PC3DU/3DVU Arrange the cable as shown. 18 Installation Antenna Or Cable Connection Multi-family Dwellings/Apartments (Connect to wall antenna socket) Single-family Dwellings /Houses (Connect to wall jack for outdoor antenna) Outdoor Antenna Wall Antenna Socket VHF Antenna UHF Antenna RF Coaxial Wire (75 ohm) Turn clockwise to tighten. VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T ANTENNA/ CABLE IN C O M P O N E N T I N DIGITAL AUDIO OUT OPTICAL VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T C O M P O N E N T I N Bronze Wire Be careful not to bend the bronze wire when connecting the antenna. Analog and Digital TV signals provided on antenna - Antenna or Cable Service without a Cable Box Connection. - For optimum picture quality, adjust antenna direction if needed. Analog and DTV signals provided on two separate antennas Cable TV Wall Jack RF Coaxial Wire (75 ohm) Bronze Wire Bronze Wire Turn clockwise to tighten. Antenna RF Coaxial Wire (75 ohm) •In a poor signal area to improve picture quality, purchase and install a sig- nal amplifier. •If the antenna needs to be split for two TV’s, install a “2-Way Signal Splitter” in the connections. •If the antenna is not installed properly, contact your dealer for assistance. VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T ANTENNA/ CABLE IN C O M P O N E N T I N DIGITAL AUDIO OUT OPTICAL VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T C O M P O N E N T I N External Equipment Connections External Equipment Connections signal amplifier VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T ANTENNA/ CABLE IN C O M P O N E N T I N DIGITAL AUDIO OUT OPTICAL VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T C O M P O N E N T I N NOTE: All cables shown are not included with the TV Cable TV Wall Jack RF Coaxial Wire (75 ohm) Turn clockwise to tighten. Analog and Digital TV signals provided on cable VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T ANTENNA/ CABLE IN C O M P O N E N T I N DIGITAL AUDIO OUT OPTICAL VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO A V I N 1 A V O U T C O M P O N E N T I N 19 Installation - To avoid picture noise (interference), leave an adequate distance between the VCR and TV. - Typically a frozen still picture from a VCR. If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible on the screen. VCR Setup When connecting with an antenna VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO AV IN 1 AV OUT COMPONENT IN DIGITAL AUDIO OUT OPTICAL S-VIDEO OUT IN (R) AUDIO (L) VIDEO 34 OUTPUT SWITCH ANT OUT ANT IN ANTENNA/ANTENNA/ CABLE INCABLE IN REMOTEREMOTE CONTROL INCONTROL IN RS-232C INRS-232C IN (CONTROL(CONTROL & SER & SERVICE)VICE) RGB IN (PC)(PC) AUDIO INAUDIO IN (RGB/DVI)(RGB/DVI) VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO AV IN 1 AV OUT COMPONENT IN DIGITAL AUDIO OUT OPTICAL SERVICESERVICE HDMI IN 1(DVI)1(DVI) 2 When connecting with a RCA cable VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO AV IN 1 AV OUT COMPONENT IN DIGITAL AUDIO OUT OPTICAL S-VIDEO OUT IN (R) AUDIO (L) VIDEO 34 OUTPUT SWITCH ANT OUT ANT IN HDMI / DVI IN ANTENNA/ CABLE IN REMOTE CONTROL IN RS-232C IN (CONTROL & SERVICE) RGB IN (PC) AUDIO IN (RGB/DVI) VIDEOVIDEO AUDIOAUDIO VIDEOVIDEOAUDIOAUDIO MONO ( ) S-VIDEOS-VIDEO A V IN 1 A V OUT COMPONENTCOMPONENT IN DIGITAL AUDIO OUTOUT OPTICALPTICAL SERVICE VCR 1 2 3 Connect the AUDIO/VIDEOjacks between TV and VCR. Match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red) Insert a video tape into the VCR and press PLAY on the VCR. (Refer to the VCR owner’s manual.) Select AV1input source using the INPUTbutton on the remote control. - If connected to AV IN2, select AV2 input source. •If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONOjack of the set. 1 1 2 3 4 Connect the RF antenna out socket of the VCR to the Antennasocket on the set. Connect the antenna cable to the RF antenna in socket of the VCR. Set VCR output switch to 3 or 4 and then tune TV to the same channel number. Insert a video tape into the VCR and press PLAY on the VCR. (Refer to the VCR owner’s manual.) VCR 1 2 20 Installation When connecting with an S-Video cable VIDEO AUDIOAUDIO VIDEOAUDIOAUDIO MONO ( ) S-VIDEOS-VIDEO A V IN 1 A V OUT COMPONENTCOMPONENT IN IN DIGITDIGITALAL AUDIO AUDIO OUT OPTICALPTICAL S-VIDEO OUT IN (R) AUDIO (L) VIDEO 34 OUTPUT SWITCH ANT OUT ANT IN HDMI / DVI IN ANTENNA/ CABLE IN REMOTE CONTROL IN RS-232C IN (CONTROL & SERVICE) RGB IN (PC) AUDIO IN (RGB/DVI) VIDEO AUDIO VIDEOAUDIO ( ) S-VIDEO AV IN 1 AV OUT COMPONENT IN DIGITAL AUDIO OUT OPTICAL SERVICE VCR 1 1 2 2 3 4 Connect the S-VIDEO output of the VCR to the S- VIDEOinput on the set. The picture quality is improved; compared to normal composite (RCA cable) input. Connect the audio outputs of th…

Text truncated - open the document above for the full version.

32 Operation - There are two different ways in order to add or delete scanned channels. One is "Custom List" and the other is "Favorite List" in the channel list. Both of them are available after EZ Scanon the SETUPmenu. - A Custom List can be created by toggling each channel on or off with ENTERbutton. The chan- nels in the Custom List are dis- played in black color, and the channels deleted from the Custom List are displayed in gray color. Once a channel is high- lighted you can add or delete the channel by referring to the small window at the top-left corner of the screen.You can create your own Favorite List. Use the FAV button on the remote control when a channel is highlighted and then you can add or delete the channel to/from the Favorite List. Channel Edit Press the MENUbutton and then use DD / EE button to select the SETUPmenu. Press theGGbutton and then use DD / EE button to select Channel Edit. Press the GGbutton. You will now see a screen filled with channel num- bers and a preview picture. Use DD / EE / FF / GG button to select a channel and then use the ENTER button to add or delete it. Press FAV button to add the channel to the Favorite List. The heart-mark will appear in front of that channel num- ber. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. 1 2 3 4 5 * Custom List EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID EZ Scan Manual Scan Channel Edit G DTV Signal Input Source Input Label Set ID Selection ( G or ) leads you to the channel edit screen. 33 Operation DTV Signal Strength - Shows how strong your DTV sig- nal is and whether you need to adjust your antenna or digital cable input. The higher the signal strength, the less likely you are to experience picture degrada- tion. - DTV Signals: Only when the input signal is DTV or CADTV, this function is available. Press the MENUbutton and then use DD / EE button to select the SETUPmenu. Press theGGbutton and then use DD / EE button to select DTV Signal. View the on-screen signal strength monitor to see the quality of the signal being received. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. 1 2 3 4 - Changes the picture source so you can watch your TV, cable TV, VCR, DVD, or any other devices that are connected to your TV. Input Source Press the MENUbutton and then use DD / EE button to select the SETUPmenu. Press the GGbutton and then use DD / EE button to select Input Source. Press the GGbutton and then use DD / EE button to select the source: TV, AV1, AV2, Component1, Component2, RGB-PC, HDMI1/DVI, or HDMI2. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. 1 2 3 4 Setup Menu Options continued Setup Menu Options continued EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID BadNormalGood EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID EZ Scan Manual Scan Channel Edit DTV Signal Input Source G Input Label Set ID TV AV1 AV2 Component1 Component2 RGB-PC HDMI1/DVI HDMI2 34 Operation - Sets a label to each input source or lets you skip the input source which is not in use when you press INPUTbutton. Input Label Press the MENUbutton and then use DD / EE button to select the SETUPmenu. Press the GGbutton and then use DD / EE button to select Input Label. Press the GGbutton and then use DD / EE button to select the source: AV1- 2, Component1-2, RGB-PC, HDMI1/DVI or HDMI2. Press the FF / GGbutton to select the label. Press EXITbutton to return to TV viewing or press MENUbutton to return to the previous menu. 1 2 3 4 5 EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label G Set ID AV1Cable Box AV2VCR Component1DVD Component2Set Top Box RGB-PCPC HDMI1/DVIGame HDMI2 Satellite 35 Operation V V ideo Menu Options ideo Menu Options Auto Picture Control Auto Picture Control ( (EZ Picture) - EZ Picture adjusts the TV for the best picture appearance. Select the preset value in the EZ Picture menu based on the program category. - Daylight, Normal, Night Timeset- tings are preset for optimum picture quality at the factory and are not adjustable. - In the User 1,and User 2modes only, user can directly adjust the contrast, brightness, color, sharpness, tint. Press the EZ PIC button repeatedly to select the picture appear- ance setup option as shown below: Daylight, Normal, Night Time, User 1and User 2(your own set- tings). • You can also use the VIDEOmenu to adjust EZ Picture. Press the EXIT button to save and return to TV viewing . 1 2 Color Temperature Control - Choose one of three automatic color adjustments. Set to warm to enhance hotter colors such as red, or set to cool to see less intense colors with more blue. Press the MENUbutton and then use DD / EE button to select the VIDEOmenu. Press the GGbutton and then use DD / EE button to select Color Temperature. Press the GGbutton and then use DD / EE button to select either Cool, Medium, Warm, or User. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. 1 2 3 4 EZ Picture Color Temperature G XD Advanced Video Reset EZ Picture Color Temperature XD Advanced Video Reset Cool Medium Warm User 36 Operation Manual Color Temperature Control - You can also adjust the detailed set tings(Red, Green, Blue) by selecting the Usermenu. EZ Picture Color Temperature XD Advanced Video Reset Red0 EE EZ Picture Color Temperature XD Advanced Video Reset Press to confirm. MENU Selection ( G or ) leads you to the detailed setting screen. Cool Medium Warm User G User Red0 G Green0 Blue0 Press the MENUbutton and then use DD / EE button to select the VIDEOmenu. Press the GGbutton and then use DD / EE button to select Color Temperature . Press the GGbutton and then use DD / EE button to select …

Text truncated - open the document above for the full version.

FCC ID : BEJ42PC3DUUE POWER OF ATTORNEY To whom it may concern: We the undersigned LG Electronics Inc. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign: Sang-Wook Lee/Manager Engineer Tel:82-54-470-5639

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-360,Korea TEL : +82-54-470-5639 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ42PC3DUUE Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Sang-Wook Lee/ Manager Engineer LG Electronics Inc. TEL : +82-54-470-5639 FAX : 82-54-470-4534

1. FRONT 2. REAR 3. PORT

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. POWER 2.1 Front 2.2 Rear 3. Y_SUS 3.1 Front 3.2 Rear 4.Z_SUS 4.1 Front 4.2 Rear 5.CTRL_LVDS 5.1 Front 5.2 Rear 6. PDP 6.1 Front 6.2 Rear

LG Electronics Inc. FCC ID BEJ42PC3DUUE -Operational description- A plasma display panel is the latest display technology. It is currently the best way to achieve flat panel displays with excellent image quality and large screen sizes, that are easily viewable. The PDP can be thought of as a descendant of the neon lamp an dit can be also be viewed as a series of fluorescent lamps. PDP is an array of cells, known as pixels, which are comprised of 3 sub pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phos-phors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors. You get the rich, dynamic colors that you expect. Each sub-pixel is individually controlled by advanced electronics to produce over16 million different colors. All of this means that you get perfect images that are easily viewable in a display that is less than 5inches thick.

Test Report for FCC Company name Address Telephone Product name Basic Model Additional Models Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - Basic Model : 42PC3DVU-UE Additional Models : 42PC3D-UE,Z42PC3DU,Z42PC3D - Basic Model and Addition Models are same product,only model name is different. - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned Report Number : ESTF150608-005 , Web : www. estech. co. kr Page 1 of 15 Report NumberESTF150608-005 Manufacturer Country of origin Applicant Product 14-Aug-06 PLASMA MONITOR 42PC3DVU-UE 42PC3D-UE, Z42PC3DU,Z42PC3D LG Electronics Inc. KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2006 , ANSI C 63.4 2003 , ICES-003 2006-8-8~2006-8-9 OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 847-941-8373 Measurement facility registration number Engineer J.H.Kim Manager Engineer J.M.Yang 94696 (Signature) (Signature) 3 4 5 6 8 8 8 9 10 11 11 11 12 13 15 Appendix 1. Spectral diagram Report Number : ESTF150608-005 , Web : www. estech. co. kr Page 2 of 15 5. Measurement of radiated emission ..................................................................... 5.1 Measurement equipment .............................................................................. Contents 1. Laboratory Information .................................................................................... 2. Descri ption of EUT .......................................................................................... 3. Test Standards ................................................................................................ 4. Measurement condition .................................................................................... 5.2 Environmental conditions .............................................................................. 5.4 Test data ................................................................................................... 5.3 Test data ................................................................................................... 7. Photographs of test setup ................................................................................. 8. Photographs of EUT .......................................................................................... 6. Measurement of conducted emission .................................................................. 6.1 Measurement equipment .............................................................................. 6.2 Environmental conditions .............................................................................. 6.3 Test data ................................................................................................... 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Korea (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report.ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150608-005 , Web : www. estech. co. kr Page 3 of 15 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : 42PC3DVU-UE Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 2.2 General descriptions of EUT Using Freq. : 4MHz, 50MHz, 24MHz. 14.3MHz, 54MHz Report Number : ESTF150608-005 , Web : www. estech. co. kr Page 4 of 15 PLASMA MONITOR NONE LG Electronics Inc. KOREA INPUT:AC120V / 60Hz 2006-08-08 3. Test Standards Test Standard : FCC PART 15 (2006) & ICES-003 Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150608-005 , Web : www. estech. co. kr Pa…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
