BEJ42PC3DVUDPLASMA MONITOR

Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service. P/NO : 38289U0527A (0511-REV00) Printed in Korea OWNER’S MANUAL LCD TV MODELS: 32LC2D 37LC2D 42LC2D PLASMA TV MODELS: 42PC3D42PC3D-UD 42PC3DV42PC3DV-UD 50PC3D50PC3D-UD Internet Home Page : http://www.lge.com http://www.lg.ca 2 Warning WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suffi- cient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appli- ance. NOTE TO CABLE/TV INSTALLER: This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as prac- tical. REGULATORY INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics Corporation. Unauthorized modification could void the user’s authority to operate this product. U.S.A. only ----------------------------------------------- COMPLIANCE: The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc. 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 Phone: 1-201-816-2000 http://www.lgusa.com --------------------------------------------------------------- CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN W W arning arning 3 Safety Instructions WARNING : To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture. Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus. IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience recepta- cles, and the point where they exit from the apparatus. 11. Only use the attachments / accessories specified by the manufacturer. Safety Instructions Safety Instructions O w n e r's M a n u a l 4 Safety Instructions 12. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the appa- ratus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normal- ly, or has been dropped. On Disposal a. The fluorescent lamp used in this product contains a small amount of mercury. b. Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local authority. Note - If the TV feels cold to the touch, there may be a small “flicker” when when it is turned on. This is normal, there is noth- ing wrong with TV. - Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they have no adverse effect on the monitor's performance. - Avo…

Text truncated - open the document above for the full version.

26 Installation When connecting with a D-sub 15 pin cable 1 2 3 4 Connect the RGB output of the digital set-top box to the RGB IN (PC/DTV) ( 32/37/42LC2D Model)/ RGB (PC/DTV) (42PC3D/3DV/50PC3D Model) jack on the set. Connect the audio outputs of the set-top box to the AUDIO IN (RGB/DVI) ( 32/37/42LC2D Model) /AUDIO (RGB/DVI) (42PC3D/3DV/50PC3D Model) jack on the set. Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.) Select RGB-DTVinput source with using the INPUTbutton on the remote control. - This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below. VIDEOAUDIO ( ) VIDEOAUDIO COMPONENT IN S-VIDEO AV IN 1 AV OUT HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C IN (CONTROL & SERVICE) HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C IN (CONTROL & SERVICE) REMOTE CONTROL RGB IN (PC/DTV) AUDIO IN (RGB/DVI) ANTENNA IN CABLE IN (R) AUDIO (L) RGB-DTV OUTPUT REMOTEREMOTE CONTROLCONTROL RGB IN (PC/DTV) AUDIO INAUDIO IN (RGB/DVI)(RGB/DVI) Digital Set-top Box HDSTB Setup 1 2 When connecting with a HDMI cable 1 2 3 Connect the HDMI output of the digital set-top box to the HDMI/DVI INjack on the set. Select HDMI/DVIinput source with using the INPUTbutton on the remote control. Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.) Digital Set-top Box •TV can receive the video and audio signal simultaneously with using a HDMI cable. •If the digital set-top box supports Auto HDMI function, output resolution of the digital set-top box will be automatically set to 1280x720p. •If the digital set-top box does not support Auto HDMI, you need to set the output resolution appro- priately. To get the best picture quality, adjust the output resolution of the digital set-top box to 1280x720p. VIDEOAUDIO ( ) VIDEOAUDIO COMPONENT IN S-VIDEO AV IN 1 AV OUT HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C INRS-232C IN (CONTROL & SERVICE) HDMI-DTV OUTPUT HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C IN (CONTROL & SERVICE) REMOTE CONTROL RGB IN (PC/DTV) AUDIO IN (RGB/DVI) ANTENNA IN CABLE IN REMOTE CONTROL RGB IN (PC/DTV) AUDIO IN (RGB/DVI) 1 27 Installation When connecting with a Component cable 1 2 3 4 Connect the video outputs (Y, PB, PR) of the digi- tal set-top box to the COMPONENT IN VIDEO jacks on the set. Connect the audio output of the digital set-top box to the COMPONENT IN AUDIO jacks on the set. Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.) Select Component 1input source with using the INPUTbutton on the remote control. B R (R) AUDIO (L) VIDEOVIDEOAUDIOUDIO MONO ( ) VIDEOVIDEOAUDIOUDIO COMPONENT INCOMPONENT IN S-VIDEOS-VIDEO AV IN 1V IN 1 AV OUTV OUT HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C IN (CONTROL & SERVICE) HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C IN (CONTROL & SERVICE) REMOTE CONTROL RGB IN (PC/DTV) AUDIO IN (RGB/DVI) ANTENNA IN CABLE IN REMOTE CONTROL RGB IN (PC/DTV) AUDIO IN (RGB/DVI) Signal 480i 480p/720p/1080i Component1/2 Ye s Ye s RGB-DTV, HDMI/DVI No Ye s 21 Digital Set-top Box When connecting with a HDMI to DVI cable 1 2 3 4 Connect the DVI output of the digital set-top box to the HDMI/DVI IN jack on the set. Connect the audio outputs of the set-top box to the AUDIO IN (RGB/DVI) ( 32/37/42LC2D Model)/AUDIO (RGB/DVI) (42PC3D/3DV/50PC3D Model) jack on the set. Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.) Select HDMI/DVI input source with using the INPUTbutton on the remote control. (R) AUDIO (L) DVI-DTV OUTPUT VIDEOAUDIO ( ) VIDEOAUDIO COMPONENT IN S-VIDEO AV IN 1 AV OUT HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C IN (CONTROL & SERVICE) HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C INRS-232C IN (CONTROL & SERVICE) REMOTEREMOTE CONTROLCONTROL RGB IN (PC/DTV) AUDIO INAUDIO IN (RGB/DVI)(RGB/DVI) ANTENNA IN CABLE IN REMOTE CONTROL RGB IN (PC/DTV) AUDIO IN (RGB/DVI) Digital Set-top Box 1 2 • If the digital set-top box has a DVI output and no HDMI output, a separated audio connection is nec- essary. •If the digital set-top box supports Auto DVI function, the output resolution of the digital set-top box will be automatically set to 1280x720p. •If the digital set-top box does not support Auto DVI, you need to set the output resolution appropri- ately. To get the best picture quality, adjust the output resolution of the digital set-top box to 1280x720p. 28 Installation Digital Audio Output 1 2 3 Connect one end of an optical cable to the TV Digital Audio Optical Output port. Connect the other end of the optical cable to the digital audio optical input on the audio equipment. See the external audio equipment instruction manual for operation. When connecting with external audio equip- ments, such as amplifiers or speakers, please turn the TV speakers off. (Refer to p.43) HDMI/DVI IN DIGITAL AUDIO OUT OPTICAL RS-232C INRS-232C IN (CONTROL & SERVICE) - Send the TV’s audio to external audio equipment (stereo system) via the Digital Audio Output Optical port. CAUTION Do not look into the optical output port. Looking at the laser beam may damage your vision. 1/2 Monitor Out Setup 1 2 Connect the second TV or monitor to the TV’s AV OUTPUT jacks. See the Operating Manual of the second TV or monitor for further details regarding that device’s input settings. S-VIDEO IN (R) AUDIO (L) VIDEO VIDEOVIDEOAUDIOUDIO MONO ( ) VIDEOVIDEOAUDIOUDIO COMPONENT INCOMPONENT IN S-VIDEOS-VIDEO AV IN 1V IN 1 AV OUTV OUT - The TV has a special signal output capability which allows you to hook up a second TV or monitor. 1/2 •Component 1-2, RGB-PC/RGB-DTV, HDMI/DVI, DTV input sources cannot be used for Monitor out. •When connecting with external audio equip- ments, such as amplifiers or speakers, please turn the TV speakers off. (Refer to p.43) • We recommend to use the video and audio o…

Text truncated - open the document above for the full version.

FCC ID : BEJ42PC3DVUD POWER OF ATTORNEY To whom it may concern: We the undersigned LG Electronics Inc. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign: Sang-Wook Lee/Manager Engineer Tel:82-54-470-5639

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-360,Korea TEL : +82-54-470-5639 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ42PC3DVUD Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Sang-Wook Lee/ Manager Engineer LG Electronics Inc. TEL : +82-54-470-5639 FAX : 82-54-470-4534

1. FRONT 2. REAR 3. PORT 4. IN

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. POWER 2.1 Front 2.2 Rear 3. CTRL_LVDS 3.1 Front 3.2 Rear 4.PDP 4.1 Front 4.2 Rear 5. YSUS 5.1 Front 5.2 Rear 6. Z SUS 6.1 Front 6.2 Rear 7. RGB BOARD 7.1 Front 7.2 Rear

LG Electronics Inc. FCC ID BEJ42PC3DVUD -Operational description- A plasma display panel is the latest display technology. It is currently the best way to achieve flat panel displays with excellent image quality and large screen sizes, that are easily viewable. The PDP can be thought of as a descendant of the neon lamp an dit can be also be viewed as a series of fluorescent lamps. PDP is an array of cells, known as pixels, which are comprised of 3 sub pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phos-phors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors. You get the rich, dynamic colors that you expect. Each sub-pixel is individually controlled by advanced electronics to produce over16 million different colors. All of this means that you get perfect images that are easily viewable in a display that is less than 5inches thick.

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned Report Number : ESTF150601-003 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150601-003 Manufacturer Country of origin Applicant Product 11-Jan-06 PLASMA MONITOR 42PC3DV-UD NONE LG Electronics Inc. KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2005 , ANSI C 63.4 2003 2006-01-04 ~ 2006-01-11 OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 201-266-2420 Measurement facility registration number Engineer J.H.Kim Manager Engineer J.M.Yang 94696 (Signature) (Signature) 3 4 5 6 8 8 8 9-1 9-2 10 10 10 11 12 14 Appendix 1. Spectral diagram Appendix 2. Phorographs of EUT in side PCB Appendix 3. Block diagram of EUT Appendix 4. Circuit Diagram Report Number : ESTF150601-003 , Web : www. estech. co. kr Page 2 of 14 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.4 Test data(2) .......................................................................................... 5.3 Test data(1) .......................................................................................... 7. Photogra phs of test setup ........................................................................... 8. Photogra phs of EUT .................................................................................... 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150601-003 , Web : www. estech. co. kr Page 3 of 14 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : 42PC3DV-UD Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 2.2 General descriptions of EUT Using Freq. : 50MHz, 4MHz(2EA), 10MHz, 27MHz(2EA), 8MHz, 24.57MHz, 18.43MHz Report Number : ESTF150601-003 , Web : www. estech. co. kr Page 4 of 14 PLASMA MONITOR NONE LG Electronics Inc. KOREA INPUT:AC120V / 60Hz 2006-01-04 3. Test Standards Test Standard : FCC PART 15 (2005) Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150601-003 , Web : www. estech. co. kr Page 5 of 14 4. Measurement Condition 4.1 EUT Operation. 4.2 Configuration and Peripherals * The EUT was in the following ope…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
