BEJ42PC5DUCPlasma Monitor

P/NO : MFL34797004 (0612-REV00) As an ENERGY STARPartner LGE U. S. A.,Inc.has determined that thisproduct meets the ENERGYSTAR guidelines for energy efficiency.As an ENERGY STARPartner LGE U. S. A.,Inc.has determined that thisproduct meets the ENERGYSTAR guidelines for energy efficiency. LCD TV PLASMA TV 32LC7D37 LC 7 D42LC7D 42PC5D50PC5D LCD TV MODELS PLASMA TV MODELS WARNING / CAUTION 1 WARNING / CAUTION To prevent fire or shock hazards, do not expose this product to rain or moisture. FCC NOTICE Class B digital device This equipment has been tested and found to com- ply with the limits for a Class B digital device, pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio fre- quency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or televi- sion reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is con- nected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and main- tenance (servicing) instructions in the literature accompanying the appliance. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. WARNING / CAUTION 2 IMPORTANT SAFETY INSTRUCTIONS SAFETY INSTRUCTION Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)that produce heat. Do not defeat the safety purpose of the polar- ized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong, The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Only use attachments/accessories specified by the manufacturer. Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the apparatus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may be placed immediately adjacent to that safety instruction : O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l O w n e r M a n u a l Owner ManualO w n e r M a n u a l O w n e r M a n u a l 1 2 3 4 5 6 7 WARNING / CAUTION 3 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Unplug this apparatus during lightning storms or when unused for long periods of time. Refer all servicing to qualified service person- nel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has exposed to rain or moisture, does not operate normally, or has been dropped. CAUTION concerning the Power Cord : Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension…

Text truncated - open the document above for the full version.

PREPARATION 14 PREPARTION  To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment. 1. Antenna (Analog or Digital) Wall Antenna Socket or Outdoor Antenna without a Cable Box Connections. For optimum picture quality, adjust antenna direction if needed. 2. Cable R ( ) Wall Antenna Socket Outdoor Antenna (VHF, UHF) Cable TV Wall Jack Multi-family Dwellings/Apartments (Connect to wall antenna socket) RF Coaxial Wire (75 ohm) RF Coaxial Wire (75 ohm) Single-family Dwellings /Houses (Connect to wall jack for outdoor antenna) Be careful not to bend the bronze wire when connecting the antenna. Bronze Wire R ( ) ANTENNA/ CABLE IN R ( ) ANTENNA/ CABLE IN R ( ) ANTENNA/ CABLE IN GG The TV will let you know when the analog, cable, and digital channel scans are complete. NOTE !  To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.  If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.  If the antenna is not installed properly, contact your dealer for assistance. Antenna UHF Signal Amplifier VHF EXTERNAL EQUIPMENT SETUP 15 HD RECEIVER SETUP EXTERNAL EQUIPMENT SETUP This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive digital signals from a digital set-top box or other digital external device, refer to the figure as shown below. DIGITAL AUDIO OUT OPTICAL AV OUT AV IN 1 VIDEOAUDIO MONO ( ) S-VIDEO COMPONENT IN VIDEOAUDIO YLRPBPR When connecting Component cable 12 1. How to connect Connect the video outputs ( Y, PB, PR ) of the digital set top box to the CCOOMMPPOONNEENNTT IINN VVIIDDEEOO 11 jacks on the set. Match the jack colors (Y = green, P B= blue, and PR= red). Connect the audio output of the digital set-top box to the CCOOMMPPOONNEENNTT IINN AAUUDDIIOO 11 jacks on the set. 2 1 2. How to use  Turn on the digital set-top box. ( Refer to the owner’s manual for the digital set-top box. )  Select CCoommppoonneenntt 11 input source with using the IINNPPUUTT button on the remote control.  If connected to CCOOMMPPOONNEENNTT IINN22 input, select CCoommppoonneenntt 22 input source. Signal 480i 480p 720p 1080 i Component 1/2 Yes Yes Yes Yes HDMI1/DVI, HDMI2 No Yes Yes Yes EXTERNAL EQUIPMENT SETUP 16 EXTERNAL EQUIPMENT SETUP When connecting HDMI cable Connect the digital set-top box to HHDDMMII//DDVVII IINN 11 or 22 jack on the set. No separated audio connection is necessary. 1. How to connect 2. How to use  Turn on the digital set-top box. ( Refer to the owner’s manual for the digital set-top box. )  Select HHDDMMII11//DDVVII or HHDDMMII22 input source with using the IINNPPUUTT button on the remote control. 2 1 HDMI/DVI IN ANTENNA/ CABLE IN REMOTE CONTROL IN RS-232C IN (CONTROL & SERVICE) RGB IN (PC) AUDIO IN (RGB/DVI) 1 2 SERVICE HDMI-DTV OUTPUT 1 GG If the digital set-top box supports Auto HDMI function, the output resolution of the source device will be automatically set to 1280x720p. GG If the digital set-top box player does not support Auto HDMI, you need to set the output resolution appropriately. To get the best picture quality, adjust the output resolution of the source device to 1280x720p. NOTE ! EXTERNAL EQUIPMENT SETUP 17 HDMI/DVI IN ANTENNA/ CABLE IN REMOTE CONTROL IN RS-232C IN (CONTROL & SERVICE) RGB IN (PC) AUDIO IN (RGB/DVI) DIGITAL AUDIO OUT OPTICAL 1 2 SERVICE COMPONENT IN AV OUT AV IN 1 VIDEOAUDIO MONO ( ) S-VIDEO VIDEOAUDIO LR DVI-DTV OUTPUT Connect the DVI output of the digital set-top box to the HHDDMMII//DDVVII IINN 11 or 22 jack on the set. Connect the audio output of the digital set-top box to the AAUUDDIIOO IINN (( RRGGBB//DDVVII )) jack on the set. 1. How to connect  Turn on the digital set-top box. ( Refer to the owner’s manual for the digital set-top box. )  Select HHDDMMII11//DDVVII or HHDDMMII22 input source with using the IINNPPUUTT button on the remote control. 2. How to use 2 1 1 2 When connecting HDMI to DVI cable EXTERNAL EQUIPMENT SETUP 18 DVD SETUP EXTERNAL EQUIPMENT SETUP When connecting Component cable DIGITAL AUDIO OUT OPTICAL AV OUT AV IN 1 VIDEOAUDIO MONO ( ) S-VIDEO COMPONENT IN VIDEOAUDIO YLRPBPR AUDIO ( ) Component Input ports To get better picture quality, connect a DVD player to the component input ports as shown below. Component ports on the TV YPBPR Video output ports on DVD player Y Y Y Y P B B-Y Cb Pb P R R-Y Cr Pr Connect the video outputs ( Y, PB , PR ) of the DVD to the CCOOMMPPOONNEENNTT IINN VVIIDDEEOO11 jacks on the set. Match the jack colors ( Y = green, P B= blue, and PR= red ) . Connect the audio outputs of the DVD to the CCOOMMPPOONNEENNTT IINN AAUUDDIIOO11 jacks on the set. 1. How to connect 2. How to use  Turn on the DVD player, insert a DVD.  Select CCoommppoonneenntt 11 input source with using the IINNPPUUTT button on the remote control.  If connected to CCOOMMPPOONNEENNTT IINN 22 input, select CCoommppoonneenntt 22 input source.  Refer to the DVD player's manual for operating instructions. 2 1 12 EXTERNAL EQUIPMENT SETUP 19 When connecting with an S-Video cable DIGITAL AUDIO OUT OPTICAL COMPONENT IN AV OUT AV IN 1 VIDEO S-VIDEO VIDEOAUDIO AUDIOUDIO MONO ( ) LR S-VIDEO AUDIO 1 2 HDMI/DVI IN NTENNA/ CABLE IN REMOTE CONTROL IN RS-232C IN (CONTROL & SERVICE) RGB IN (PC) AUDIO IN (RGB/DVI) 1 2 SERVICE HDMI-DVD OUTPUT AUDIO ( ) 1 Connect the S-VIDEO output of the DVD to the SS--VVIIDDEEOO input on the set. Connect the audio outputs of the DVD to the AAUUDDIIOO input jacks on the set. 1. How to connect 2. How to use  Turn on the DVD player, insert a DVD.  Select AAVV11 input source with using the IINNPPUUTT button on the remote control.  If connected to AAVV IINN22 , select AAVV22 input source.  Refer to the DVD player's manual for operating instructions. When connecting HDMI cable Connect the HDMI output of the DVD to the HHDDMMII//DDVVII IINN 11 or 22 jack on the set. No separated audio connection is necessary. 1. How to c…

Text truncated - open the document above for the full version.

WATCHING TV / CHANNEL CONTROL 29 ADJUST SAP SOUND PICTURE CC 123 456 78 0 9 BACK POWER TV INPUT INPUT Turns your TV or any other programmed equipment on or off, depending on the mode. In AV 1-2, Component 1-2, RGB-PC (or RGB-DTV), HDMI1/DVI, and HDMI2 input sources, screen returns to the last TV channel. External input modes rotate in regular sequence: Antenna, Cable, AV1-2, Component 1-2, RGB- PC (or RGB-DTV), HDMI1/DVI and HDMI2. (AV 1-2, Component 1-2, RGB-PC (or RGB-DTV), HDMI1/DVI, and HDMI2 input sources are linked automatically, only if these are connected.) PICTURE SOUND SAP CC ADJUST Adjust the factory preset picture depend on the viewing environment. GG pp..6699 Select the appropriate type of sound for type of program. GG pp..8800 Analog mode: Selects MTS sound (Mono, Stereo, and a SAP) DTV mode: Change the audio language. Select a closed caption. GG pp..9944 (*In DTV/CADTV mode GG pp..9955 ) Adjust the screen position, size and phase in PC mode. GG pp.. Inside the Sliding Cover  Open the battery compartment cover on the back side and install the batteries matching correct polarity ( +with +,-with - ) .  Install two 1.5V AA batteries. Don’t mix old or used batteries with new ones.  Close cover.  Use a remote control up to 7 meters distance and 30 degree (left/right) within the receiving unit scope.  Dispose of used batteries in a recycle bin to preserve environment. BRIGH T - MENU B R IG H T + POWER V C R T V DVD A U D I O CABLE S T B MODE TV INPUT INPUT R BRIGH T - MENU B R IG H T + POWER V C R T V DVD A U D I O CABLE S TB MODE TV INPUT INPUT Installing Batteries Remote control effective range WATCHING TV / CHANNEL CONTROL 30 TURNING ON TV WATCHING TV / CHANNEL CONTROL NOTE ! GG If you intend to be away on vacation, disconnect the power plug from the wall power outlet. GG When the TV is turned on, the indicator will blink green before the picture is seen. First, connect power cord correctly. At this moment, the TV switches to standby mode.  In standby mode to turn TV on, press the, IINNPPUUTT , CCHH (( DD or EE )) button on the TV or press the PPOOWWEERR , IINNPPUUTT , TTVV IINNPPUUTT , CCHH(( DD or EE )) , NNuummbbeerr ((00 ~ 99)) button on the remote control. Select the viewing source by using the TTVV IINNPPUUTT , IINNPPUUTT button on the remote control.  This TV is programmed to remember which power state it was last set to, even if the power cord is out. When finished using the TV, press the PPOOWWEERR button on the remote control. The TV reverts to standby mode. POWER VCR TV DVD MODE TV INPUT INPUT SAPSOUND PICTURE CC 12 3 45 6 78 0 9 BACK VOLCH MUTEFAV EXIT TIMER RATIO SIMPLINK 1 2 3 SAPSOUND PICTURE CC 12 3 45 6 78 0 9 BACK VOLCH MUTEFAV EXIT TIMER RATIO SIMPLINK Press the CCHH DD EE or NNUUMMBBEERR buttons to select a channel number. 1 VOLUME ADJUSTMENT CHANNEL SELECTION Press the VVOOLL DD or EE button to adjust the volume. If you want to switch the sound off, press the MMUUTTEE button. You can cancel the Mute function by pressing the MMUUTTEE or VVOOLL DD or EE button. 12 3 45 6 VOLCH MUTEFAV EXIT TIMER RATIO SIMPLINK Adjust the volume to suit your personal preference. 1 2 3 WATCHING TV / CHANNEL CONTROL 31 ON-SCREEN MENUS SELECTION Press the MMEENNUU button and then use DD or EE button to select the each menu. Press the GG button and then use DD EE FF GG button to display the available menus. Your TV's OSD ( On Screen Display ) may differ slightly from what is shown in this manual. SETUP VIDEO OPTION LOCK TIME EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID EZ Picture Color Temperature XD Advanced Video Reset Auto Clock Manual Clock Off Timer On Timer Sleep Timer Auto Off Aspect Ratio Caption/Text Caption Option Language ISM Method Low Power AUDIO Audio Language EZ Sound Balance TV Speaker Lock System Set Password Block Channel Movie Rating TV Rating-Children TV Rating-General Input Block 2 1 Lock System Set Password Block Channel TV Rating-English TV Rating-French Input Block For USA For Canada WATCHING TV / CHANNEL CONTROL 32 AUTO SCAN ( EZ SCAN ) WATCHING TV / CHANNEL CONTROL Press the MMEENNUU button and then use DD or EE button to select the SSEETTUUPP menu. Press the GG button and then use DD or EE button to select EEZZ SSccaann . Press the EENNTTEERR button to begin the channel search. Allow EEZZ SSccaann to complete the channel search cycle for AANNTTEENNNNAA and CCAABBLLEE . Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the channel list. Run EZ Scan again after any Antenna/Cable connection changes. A password is required to gain access to EZ Scan menu if the Lock System is turned on. EZ Scan Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID EZ Scan G Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID Selection ( G or ) leads you to the EZ scan screen. EZ Scan G Manual Scan Channel Edit DTV Signal Input Source Input Label Set ID Selection ( G or ) leads you to the EZ scan screen. 2 3 1 Processing EZ scan... ANTENNA Ch.20 0 channel(s) found Press to stop the current scan and start DIGITAL ANTENNA channel scan. MENU Previous Next 1 2 3 BRIGHT - BRIGHT + ENTER TIMER RATIO SIMPLINK POWER VCR TV DVD AUDIO CABLE STB MODE TV INPUT INPUT EXIT MENU WATCHING TV / CHANNEL CONTROL 33 ADD/DELETE CHANNEL (MANUAL SCAN ) A password is required to gain access to Manual Scan menu if the Lock System is turned on. Press the MMEENNUU button and then use DD or EE button to select the SSEETTUUPP menu. Press the GG button and then use DD or EE button to select MMaannuuaall SSccaann . Press the GG button and then use DD or EE button to select TTVV , DDTTVV , CCAATTVV , and CCAADDTTVV . Press the GG button and then use DD or EE button to select channel you want to add or delete. Press the EENNTTEERR button to add or delete the channel. Press the EEXXIITT button to return to TV viewing or press MMEENNUU button to return to the previous menu. BRIGHT - BRIGHT…

Text truncated - open the document above for the full version.

LG Electronics Inc. Date:Sep 19,2006 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize <ESTECH CO.,Ltd.>, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by <ESTECH CO., Ltd.> on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing <ESTECH CO.,Ltd.> as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang-Wook Lee/Manager Engineer Tel:82-54-470-4532 REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-727,Korea TEL : +82-54-470-5639 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ42PC5DUC Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Curcuit Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Sang-Wook Lee/ Manager Engineer LG Electronics Inc. TEL : +82-54-470-5639 FAX : 82-54-470-4534

1. FRONT 2. REAR 3. PORT

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. Y_SUS 2.1 Front 2.2 Rear 3.Z_SUS 3.1 Front 3.2 Rear 4.CTRL 4.1 Front 4.2 Rear 5. PDP 5.1 Front 5.2 Rear 6. IN SIDE 1 7. IN SIDE 2

Test Report for FCC Company name Address Telephone Product name Basic Model Additional Models Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - Basic Model : 42PC5D-UC - Additional Models : 42PC5D, Z42PC5D - Basic Model and Additional Models are same product,only model name is different. - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned Report Number : ESTF150612-005 , Web : www. estech. co. kr Page 1 of 15 Report NumberESTF150612-005 Manufacturer Country of origin Applicant Product 19-Dec-06 Plasma Monitor 42PC5D-UC 42PC5D, Z42PC5D LG Electronics Inc. KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2006 , ANSI C 63.4 2003 , ICES-003 13-Dec-06 OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 847-941-8373 Measurement facility registration number Engineer J.H.Kim Manager Engineer J.M.Yang 94696 (Signature) (Signature) 3 4 5 6 8 8 8 9 10 11 11 11 12 13 15 Appendix 1. Spectral diagram Report Number : ESTF150612-005 , Web : www. estech. co. kr Page 2 of 15 5. Measurement of radiated emission ..................................................................... 5.1 Measurement equipment .............................................................................. Contents 1. Laboratory Information .................................................................................... 2. Descri ption of EUT .......................................................................................... 3. Test Standards ................................................................................................ 4. Measurement condition .................................................................................... 5.2 Environmental conditions .............................................................................. 5.4 Test data ................................................................................................... 5.3 Test data ................................................................................................... 7. Photographs of test setup ................................................................................. 8. Photographs of EUT .......................................................................................... 6. Measurement of conducted emission .................................................................. 6.1 Measurement equipment .............................................................................. 6.2 Environmental conditions .............................................................................. 6.3 Test data ................................................................................................... 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Korea (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report.ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150612-005 , Web : www. estech. co. kr Page 3 of 15 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : 42PC5D-UC Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : X-tal lists: 50MHz, 54MHz, 14.3MHz, 24MHz, 4MHz 2.2 General descriptions of EUT Report Number : ESTF150612-005 , Web : www. estech. co. kr Page 4 of 15 Plasma Monitor NONE LG Electronics Inc. KOREA INPUT:AC120V / 60Hz 2006-12-11 3. Test Standards Test Standard : FCC PART 15 (2006) & ICES-003 Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150612-005 , Web : www. estech. co. kr Page 5 of 15 4. Measurement Conditio…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
