BEJ42PX5DUBPlasma Display Panel

Please read this manual carefully and completely before operating your TV. Retain this manual for future reference. Record model number and serial number of the TV in the spaces provided below. See the label attached on the back cover and relate this information to your dealer if you require service. Model Number : Serial Number : MODELS:42PX4D/42PX5D 42PX4D-UB/42PX5D-UB LG Electronics U.S.A., Inc. TM R TruSurround XT PLASMA TV OWNER’S MANUAL 2 Plasma TV Warning/Caution WARNING/CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suffi- cient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appli- ance. WARNING/CAUTION: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. FCC NOTICE • A Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. • Any changes or modifications not expressly approved by the party responsible for compli- ance could void the user’s authority to operate the equipment. . CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized mod- ification could void the user’s authority to operate this product. COMPLIANCE: The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 1-800-243-0000 http://www.lgusa.com WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN /CAUTION WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. W W arning/Caution arning/Caution Owner’s Manual 3 TV Guide On Screen Notices for U.S.A. TV Guide On Screen Notices for U.S.A. In the United States, TV GUIDE and other related marks are registered marks of Gemstar-TV Guide International, Inc. and/or one of its affiliates. In Canada, TV GUIDE is a registered mark of Transcontinental Inc., and is used under license by Gemstar-TV Guide International, Inc. The TV Guide On Screen system is protected by one or more of the following issued United States patents 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121. The TV Guide On Screen system is manufactured under license from Gemstar-TV Guide International, Inc. and/or one of its affiliates. Digital Cable Compatibility Digital Cable Compatibility This digital television is capable of receiving basic analog, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced interactive digital cable services such as video-on-demand, cable operator enhanced program (For example, electronic program guide provided by the cable operator), and data enhanced television service may require the use of a set top box. For more information contact your local cable operator. Use of the CableCARD TM TradeMark. “CableCARD TM is a trademark of Cable Television Laboratories, Inc.” Trademark Notice Aux Etats Unis TV GUIDE et d’autres marques relatives sont des marques déposées de Gemstar-TV Guide International, Inc. et/ou d’une de ses sociétés affiliées. Au Canada TV GUIDE est une marque déposée de Transcontinental Inc., utilisée sous licence de Gemstar-TV Guide International, Inc. Le système TV Guide On Screen est fabriqués sous licence de Gemstar-TV Guide International, Inc. et/ou d’une de ses sociétés affiliées. Le système TV Guide On Screen est protégés par un ou plusieurs brevets émis aux Etats Unis, comme le 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121. License Notice Patent Notice 4 Plasma TV Safety Instructions IMPORTANT SAFETY INSTRUCTIONS Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the appara- tus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety instructions shall be includ- ed where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or …

Text truncated - open the document above for the full version.

Owner’s Manual 55 Operation When finished, press ENTERto highlight Schedule Recording. PressENTERagain to close the menu. You see a Record icon for the selected frequency next to the show title. Highlight Cancel to close the menu, change no information, and return to the highlighted show. 3) Manual Recording • Highlight the Schedule Service label, and press Menu to display the Schedule Options menu. • Use the D/E /F/G buttons to move through the options. Use the number or the D/E /F/G buttons to change the informa- tion, as necessary. • Highlight New Manual Recording and press ENTERto display the Record Options menu. • Current information (i.e., date, start and end times, channel, input) is displayed. • Recorder choice: Please choose the VCR only. This TV does not provide other devices with a recording feature. 56 Plasma TV Operation TV Guide On Screen TV Guide On Screen TM TM System System • Use the left and right arrows to choose between Once, Daily, Weekly, and Off, as follows. WOnce —records the time, channel, input, recorder combi nation one time. WDaily —records the time, channel, input,recorder combi nation Monday through Friday. WWeekly —records the time, channel, input, recorder combination once a week on this selected day of the week WOff (not cancel) —keeps the time, channel, input, recorder combination in the list without recording until the frequency is changed. Record Conflict A conflict message appears for the following reasons: • a show set to Record overlaps with any part of another show pre- viously set to Record, • a show set to Record overlaps with a show previously set to auto- tune Select one of these options: Wrecord anyway - this show will override an existing show set to Record or auto-tune Wdon't record this show - cancel the Recording Before a recording begins, a notification screen appears if your TV is On. At that time, you can choose to start or cancel recording. If the TV is not On, the recording occurs as scheduled. If there is no activity for 3 minutes, the notification screen automatically closes and com- pletes the highlighted item. When finished, press ENTERto highlight Schedule Recording. PressENTERagain to close the menu. You see a Record icon for the selected frequency next to the show title. Note: Manual recording is listed by channel number. Highlight Cancel to close the menu, change no informa- tion, and return to the highlighted show. Owner’s Manual 57 Operation You can set a show to Reminder in Listings, Search, and Schedule or change Reminder settings for a show in Schedule. There are 2 ways to set a show to Reminder: 1) From a Panel Menu • Highlight a show, and press Menu to display the Episode Options menu. • Highlight Set Reminder, and press ENTERto display the Remind Options menu. • Highlight the Frequency option, and use the left and right arrows to choose between: WOnce —sets a show reminder one time WRegularly —sets a show reminder every time the show airs on the same channel and starts at the same time WWeekly —sets a show reminder each time the show airs on the same day of the week, on the same channel and starts at the same time WOff —keeps the show in the list but will not remind until the frequency is changed • Power On the TV, if Off, when a Reminder is scheduled. Choices are Yes and No. (Default = No) • Automatically tune the TV to the channel (TV must be On), when a Reminder is scheduled. Choices are Yes and No. (Default = No) • When to display the reminder screen. Choices are 30 seconds to 15 minutes early, to 30 seconds to 15 minutes late, to On time. (Default = 1 min early) When finished, press ENTERto highlight Schedule Reminder. PressENTERagain to close the menu. You see a Remind icon for the selected frequency next to the show title. Highlight Cancel to close the menu, change no information, and return to the highlighted show. Remind Remind 58 Plasma TV Operation TV Guide On Screen TV Guide On Screen TM TM System System 2) Manual Reminder • Highlight the Schedule Service label, and press the Menu key to display the Schedule Options menu. • Use the D/E /F/G buttons to move through the options. Use the number or D/E /F/G buttons to change the information, as necessary. • Highlight New Manual Reminder and press the ENTERkey to dis- play the Remind Options menu. • Current information (i.e., date, start and end times, channel, input, frequency, etc.) is displayed. • Highlight the Frequency option, and use the F/Gbuttons to choose among Once, Daily, Weekly, and Off, as follows. WOnce —sets a show reminder for the time, channel, input, recorder combination one time WDaily —reminds for the time, channel, input, recorder com- bination Monday through Friday WWeekly —sets a show reminder for the time, channel, input, recorder combination once a week on this selected day of the week WOff (not cancel) —keeps the time, channel, input, destina- tion combination in the list without reminding until the frequency is changed • Power On the TV, if Off, when a Reminder is scheduled. Choices are Yes and No (Default =No). • Automatically tune the TV to the channel (TV must be On), when a Reminder is scheduled. Choices are Yes and No (Default = No). When finished, press ENTERto highlight Schedule Reminder. PressENTERagain to close the menu. You see a Remind icon for the selected frequency next to the show title. Note: Manual reminder is listed by channel number. Highlight Cancel to close the menu, change no information, and return to the highlighted show. Owner’s Manual 59 Operation Based on your option settings, a notification screen will appear, if your TV is On at the reminder time. You can then choose to hide the reminder, or highlight the show, and press ENTERto tune to the show. If there is no activ- ity for 3 minutes, the notification screen automatically closes and completes the highlighted item (hide reminders). If you choose Hide Reminders, the window closes for the show or shows, but does not affect other Reminders you set. Note:If mor…

Text truncated - open the document above for the full version.

FCC ID : BEJ42PX5DUB POWER OF ATTORNEY To whom it may concern: We the undersigned LG Electronics Inc. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign: Sang-Wook Lee/Manager Engineer Tel:82-54-470-4537 Fax: 82-54-470-4534

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-360,Korea TEL : +82-54-470-4537 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ42PX5DUB Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Sang-Wook Lee/ Manager Engineer LG Electronics Inc. TEL : +82-54-470-4537 FAX : 82-54-470-4534

1. FRONT 2. REAR 3. PORT 4. PORT 4. INTERNAL

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. POWER 2.1 Front 2.2 Rear 3. CTRL_LVDS 3.1 Front 3.2 Rear 4.PDP 4.1 Front 4.2 Rear 5. RGB 5.1 Front 5.2 Rear 6. YSUS 6.1 Front 6.2 Rear 7.MEMORY CARD READER 7.1 Front 7.2 Rear 8. Z SUS 8.1 Front 8.2 Rear 9. LED 9.1 FRONT 9.2 Rear

LG Electronics Inc. FCC ID BEJ42PX5DUB -Operational description- A plasma display panel is the latest display technology. It is currently the best way to achieve flat panel displays with excellent image quality and large screen sizes, that are easily viewable. The PDP can be thought of as a descendant of the neon lamp an dit can be also be viewed as a series of fluorescent lamps. PDP is an array of cells, known as pixels, which are comprised of 3 sub pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phos-phors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors. You get the rich, dynamic colors that you expect. Each sub-pixel is individually controlled by advanced electronics to produce over16 million different colors. All of this means that you get perfect images that are easily viewable in a display that is less than 5inches thick.

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned - DU-42PX51X are same product. ONLY Model name is different Report Number : ESTF150503-001 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150503-001 Manufacturer Country of origin Applicant Product 2005-03-10 PLASMA MONITOR 42PX5D-UB,DU-42PX51X NONE LG Electronics Inc. KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2002 , ANSI C 63.4 2001 2005-03-06 ~2005-03-10 OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 2000 Millbrook Dr Lincolnshire, IL 60069 United states 847-941-8373 Measurement facility registration number Senior Engineer J.M. Yang Director T.K. Lee 94696 (Signature) (Signature) 3 4 5 6 8 8 8 9 10 10 10 11 12 14 Appendix 1. Spectral diagram Appendix 2. Phorographs of EUT in side PCB Appendix 3. Block diagram of EUT Appendix 4. Circuit Diagram Report Number : ESTF150503-001 , Web : www. estech. co. kr Page 2 of 14 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.3 Test data ............................................................................................. ... 7. Photographs of test setup ........................................................................... 8. Photogra phs of EUT .................................................................................... 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150503-001 , Web : www. estech. co. kr Page 3 of 14 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : 42PX5D-UB, DU-42PX51X Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 2.2 General descriptions of EUT Using Freq. :4.0Mhz(3EA)/8.0Mhz/24.57Mhz(3ea)/18.43MHz/27MHz(2EA)/10MHz/13.5MHz 33.33MHz(2ea) /25.0MHz/14.0MHz Report Number : ESTF150503-001 , Web : www. estech. co. kr Page 4 of 14 PLASMA MONITOR NONE LG Electronics Inc. KOREA INPUT:AC120V / 60Hz 2005-03-06 3. Test Standards Test Standard : FCC PART 15 (2002) Test Method : ANSI C 63.4 (2001) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150503-001 , Web : www. estech. co. kr Page 5 of 14 4. Measurement Condition 4.1 EUT Operation. 4.2 Configuration and Peripherals * The EUT was in th…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
