BEJ50PX4DRUAPlasma Display Panel

Please read this manual carefully and completely before operating your TV. Retain this manual for future reference. Record model number and serial number of the TV in the spaces provided below. See the label attached on the back cover and relate this information to your dealer if you require service. Model Number : Serial Number : MODELS:50PY2DR 50PY2DR-UA 60PY2DR 60PY2DR-UA 50PX4DR 50PX4DR-UA LG Electronics U.S.A., Inc. TM R TruSurround XT PLASMA TV OWNER’S MANUAL 2 Plasma TV Warning/Caution WARNING/CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suffi- cient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appli- ance. WARNING/CAUTION: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. FCC NOTICE • A Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. • Any changes or modifications not expressly approved by the party responsible for compli- ance could void the user’s authority to operate the equipment. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized mod- ification could void the user’s authority to operate this product. COMPLIANCE: The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 1-800-243-0000 http://www.lgusa.com WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN /CAUTION WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. W W arning/Caution arning/Caution Owner’s Manual 3 TV Guide On Screen Notices for U.S.A. TV Guide On Screen Notices for U.S.A. Digital Cable Compatibility Digital Cable Compatibility This digital television is capable of receiving basic analog, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced interactive digital cable services such as video-on-demand, cable operator enhanced program (For example, electronic program guide provided by the cable operator), and data enhanced television service may require the use of a set top box. For more information contact your local cable operator. In the United States, TV GUIDE and other related marks are registered marks of Gemstar-TV Guide International, Inc. and/or one of its affiliates. In Canada, TV GUIDE is a registered mark of Transcontinental Inc., and is used under license by Gemstar-TV Guide International, Inc. The TV Guide On Screen system is protected by one or more of the following issued United States patents 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121. The TV Guide On Screen system is manufactured under license from Gemstar-TV Guide International, Inc. and/or one of its affiliates. Use of the CableCARD TM TradeMark. “CableCARD TM is a trademark of Cable Television Laboratories, Inc.” Trademark Notice Aux Etats Unis TV GUIDE et d’autres marques relatives sont des marques déposées de Gemstar-TV Guide International, Inc. et/ou d’une de ses sociétés affiliées. Au Canada TV GUIDE est une marque déposée de Transcontinental Inc., utilisée sous licence de Gemstar-TV Guide International, Inc. Le système TV Guide On Screen est fabriqués sous licence de Gemstar-TV Guide International, Inc. et/ou d’une de ses sociétés affiliées. Le système TV Guide On Screen est protégés par un ou plusieurs brevets émis aux Etats Unis, comme le 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121. License Notice Patent Notice 4 Plasma TV Warning/Caution IMPORTANT SAFETY INSTRUCTIONS Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the appa- ratus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option…

Text truncated - open the document above for the full version.

60 Plasma TV Operation Recorded TV Recorded TV On playing the recorded program, edit a section On playing the recorded program, edit a section - You can save the desired screen in the recorded program list after editing the recorded program.. 1. At the point of desired start , press the button. • The progress bar which be editied will be showed the red color. • It can be possible as search ( FForGG), pause while editing the section. 2. At the point of desired finish , press the button. • Stop editing the section. 3. Repeatedly play the above 1,2 phase, it can be possible to edit some programs. 4. If you press the button to stop the recorded program playback, this message is displayed as shown below. •Save: Save contents of editing the section and finish the playback of recorded program. • Undo: Don’t save contents of editing the section and finish the playback of recorded program. • Cancel: The screen is disappeared and the playback is continued. Notes: • It can be possible to play on the recording / reserved recording • It can be possible to occur a noise by a hard-disk on playing the recorded program. The noise is irrelevant the profi- ciency and creditability of product, the noise occurred more than adequate is the same as good product. • In case saving the content of editing the section, delete the portion not to select. • When power off on editing, It can be possible not to save the content of editing. You do press the STOP (

 )button after checking the recording list. • Editing the section can be possible to the maxium of 10. • You can not save editing of less than 10 seconds. Owner’s Manual 61 v On playing the recorded program, repeat a section On playing the recorded program, repeat a section - You can set the section and repeatedly view on playig the recorded program. 1. At the point of desired start, press the button. • At start points, it is showed as marking . 2. At the point of desired finish, press the button. • At finiah points, it is showed as marking . • Repeatedly play the marked section. • You can not make sections of less than 5 seconds. • The progress bar which be repeated will be showed the blue color. 3. Press the button to move the position of the start point. • Return to the start point of marked section and then start the playback. 4. If you press the or button to stop playing the repeat section. Notes: •It can be possible a function as search (Rew / FF), Pause, edit a section while repeating a section. • When setting the section of start and finish, it can be possible both of Rew and FF. 62 Plasma TV Operation What is Memory Card What is Memory Card Precaution for Using the Memory Card Precaution for Using the Memory Card Notes on Memory Card Notes on Memory Card This is a device equipment to communicate the data between AV external equipment. It’s used to a digital cam- era, camcorder, MP3 player, notebook or PDA. - Insert the memory card correctly. - Don’t insert the metal substances into the slots of the memory card. - Do not bend, drop or apply strong shock to memory card. - After pulling the memory card out from the TV, please keep the memory stick in a appropriate case to prevent static shock. - The stored data may be changed or lost as a result of misuse, static electricity. - Do not turn the power off while using the memory card (loading or erasing). - Don’t eject the memory card while using the it. Otherwise, it may cause a data loss or card damage. - Only Insert one card to each slot. - To prevent a change or loss for stored data, don’t misuse the TV or don’t let static electricity or electrical noise for TV. - This Company takes no responsibility for problems such as the damage or malfunction that occurs while using the TV set, inappropriate TV settings, or any other reasons, except for defects or malfunctions intrinsic to the product. - Ensure to use a memory card that lists the manufacturers name and serial number. - The manufacturer shall not be responsible for damaged data. Be careful to avoid data damage, and back up your files. - Make sure to comply with the following steps when ejecting a memory card. - Each Memory Card is complied with standard. Owner’s Manual 63 Operation W W Inserting a Card 1. Insert the Memory Card to Memory card slots of TV side panel. 2. Two slots support defferent types of the Memory Cards. 3. If Memory Card is not inserted, each slot is disable. W W Ejecting a card 1. Press the M/C EJECTbutton on the remote control. 2. Select the Slot 1orSlot 2based on the inserted card location. If selecting Cancel, OSD is disappeared. 3. Eject the card with the hand. Note:If you insert or eject a card in one slot while the card in another slot (slot 1 or slot 2) is in use, the product can run abnormally. A. A. 1.Using the Memory Card Entry Modes- 1.Using the Memory Card / 2. Enter the HOME Menu Caution: Before you remove the memory card from the slot, do not forget to press the M/C EJECTbutton on the remote control and make it safe to eject the memory card, or the memory card may be damaged. How to insert and eject the Memory Card How to insert and eject the Memory Card label-side upward 50/60PY2DR 50PX4DR 64 Plasma TV Operation Memory Card type and Memory Card capacity Memory Card type and Memory Card capacity - 9 types of Memory Card can be used for this Plasma TV. - Playback speed can vary dependent on the card type. -Unsupported or damaged photo or music files can cause errors. Do not try to change the file extension of unsupported file -- -types to the file extension of supported file types. Slot 1Slot 2 •CF (CompactFlash) : 4GB •MD (Microdrive) : 4GB •CF+|| (MagicStor) :2.2GB *MagicStor Plus card is not is complied with the TV. •SD (Secure Digital) : 1GB •MMC (MultiMedia Card) : 1GB •MS (Memory Stick) :128MB •MS Pro (Memory Stick Pro) : 1GB •SMC (Smart Media Card) : 128MB •xD (xD-Picture Card) : 512MB CompactFlash Microdrive magicstor SmartMedía M EMORY S TICK PRO Secure Digtal TM xD-Picture Card MultiMediaCard TM M EMORY S…

Text truncated - open the document above for the full version.

FCC ID : BEJ50PX4DRUA POWER OF ATTORNEY To whom it may concern: We the undersigned LG Electronics Inc. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign: Sang-Wook Lee/Manager Engineer Tel:82-54-470-4537 Fax: 82-54-470-4534

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-360,Korea TEL : +82-54-470-4537 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ50PX4DRUA Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Sang-Wook Lee/ Manager Engineer LG Electronics Inc. TEL : +82-54-470-4537 FAX : 82-54-470-4534

1. FRONT 2. REAR 3. PORT 4. PORT 4. INTERNAL

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. POWER 2.1 Front 2.2 Rear 3. CTRL_LVDS 3.1 Front 3.2 Rear 4.PDP 4.1 Front 4.2 Rear 5. RGB 5.1 Front 5.2 Rear 6. YSUS 6.1 Front 6.2 Rear 7.MEMORY CARD READER 7.1 Front 7.2 Rear 8. Z SUS 8.1 Front 8.2 Rear 9. LED 9.1 FRONT 9.2 Rear 10. HDD 10.1 FRONT 10.2 Rear

LG Electronics Inc. FCC ID BEJ50PX4DRUA -Operational description- A plasma display panel is the latest display technology. It is currently the best way to achieve flat panel displays with excellent image quality and large screen sizes, that are easily viewable. The PDP can be thought of as a descendant of the neon lamp an dit can be also be viewed as a series of fluorescent lamps. PDP is an array of cells, known as pixels, which are comprised of 3 sub pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phos-phors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors. You get the rich, dynamic colors that you expect. Each sub-pixel is individually controlled by advanced electronics to produce over16 million different colors. All of this means that you get perfect images that are easily viewable in a display that is less than 5inches thick.

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 2000 Millbrook Dr Lincolnshire, IL 60069 United states 847-941-8373 Measurement facility registration number Senior Engineer J.M. Yang Director T.K. Lee 94696 (Signature) (Signature) Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2002 , ANSI C 63.4 2001 2005-03-05 ~2005-03-11 50PX4DR-UA NONE LG Electronics Inc. KOREA Report Number : ESTF150503-002 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150503-002 Manufacturer Country of origin Applicant Product 2005-03-11 PLASMA MONITOR 3 4 5 6 8 8 8 9 10 10 10 11 12 14 Appendix 1. Spectral diagram Appendix 2. Phorographs of EUT in side PCB Appendix 3. Block diagram of EUT Appendix 4. Circuit Diagram 7. Photogra phs of test setup ........................................................................... 8. Photogra phs of EUT .................................................................................... 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ Report Number : ESTF150503-002 , Web : www. estech. co. kr Page 2 of 14 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.3 Test data ............................................................................................. ... 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150503-002 , Web : www. estech. co. kr Page 3 of 14 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : 50PX4DR-UA Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 2.2 General descriptions of EUT Using Freq. :4.0Mhz(3EA)/18.43Mhz(2EA)/24.57Mhz(3ea)/8.0MHz/27MHz(2EA)/83.33MHz/13.5MHz 33.33MHz /25.0MHz(2ea)/14.0MHz/10.0MHz/12.00MHz Report Number : ESTF150503-002 , Web : www. estech. co. kr Page 4 of 14 PLASMA MONITOR NONE LG Electronics Inc. KOREA INPUT:AC120V / 60Hz 2005-03-05 3. Test Standards Test Standard : FCC PART 15 (2002) Test Method : ANSI C 63.4 (2001) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150503-002 , Web : www. estech. co. kr Page 5 of 14 4. Measurement Condition 4.1 EUT Operation. 4.2 Configuration and Peripherals * The EUT was in the following operation mode during all testing * The ope…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
