BEJ50PX4DUBPDP Display

Please read this manual carefully and completely before operating your TV. Retain this manual for future reference. Record model number and serial number of the TV in the spaces provided below. See the label attached on the back cover and relate this information to your dealer if you require service. Model Number : Serial Number : MODELS: DU-50PX41S/51S LG Electronics U.S.A., Inc. TM R TruSurround XT PLASMA TV OWNER’S MANUAL 2 Plasma TV Warning/Caution WARNING/CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suffi- cient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appli- ance. WARNING/CAUTION: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. FCC NOTICE • A Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. • Any changes or modifications not expressly approved by the party responsible for compli- ance could void the user’s authority to operate the equipment. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized mod- ification could void the user’s authority to operate this product. COMPLIANCE: The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 1-201-816-2000 http://www.lgusa.com WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN /CAUTION WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. W W arning/Caution arning/Caution Owner’s Manual 3 TV Guide On Screen Notices for U.S.A. TV Guide On Screen Notices for U.S.A. In the United States, the TV Guide On Screen system and other related marks are registered marks of Gemstar-TV Guide On Screen system International, Inc. and/or one of its affiliates. In Canada,TV Guide On Screen system is a registered mark of Transcontinental Inc., and is used under license by Gemstar-TV Guide On Screen system International, Inc. The TV Guide On Screen system is protected by one or more of the following issued United States patents 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121. The TV Guide On Screen system is manufactured under license from Gemstar-TV Guide On Screen system International, Inc. and/or one of its affiliates. Digital Cable Compatibility Digital Cable Compatibility This digital television is capable of receiving basic analog, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced interactive digital cable services such as video-on-demand, cable operator enhanced program (For example, electronic program guide provided by the cable operator), and data enhanced television service may require the use of a set top box. For more information contact your local cable operator. Use of the CableCARD TM TradeMark. “CableCARD TM is a trademark of Cable Television Laboratories, Inc.” 4 Plasma TV Safety Instructions IMPORTANT SAFETY INSTRUCTIONS Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the appara- tus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety instructions shall be includ- ed where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or drawing that illus- trates the intent of a specific safety instruction may be placed immediately adjacent to that safety instruction : 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampli- fiers)that produce heat. 9. Do not defeat the safety purpose of the p…

Text truncated - open the document above for the full version.

Owner’s Manual 51 TV Guide On Screen System < Record Defaults> • Record Default Options lets you set defaults for the following: • When to start the record event. Choices are 120 minutes early to 120 minutes late, to On time. (Default = On time) • When to end the record event. Choices are 120 minutes early to 120 minutes late, to On time. (Default = On time) • Recorder choice: Please choose the VCR only. This TV does not provide other devices with a recording feature. Highlight Record Defaults, and press the Menu key to display the Record Default Options menu. Highlight Go to Service Bar to close the menu, change no infor- mation, and return to the Setup Service Bar. TV Guide On Screen TV Guide On Screen TM System continued System continued < Remind Defaults> Remind Default Options lets you set defaults for the following: • Power On the TV, if Off, when a Reminder is scheduled. Choices are Yes and No. (Default = No) • Automatically tune the TV to the channel (TV must be On), when a Reminder is scheduled. Choices are Yes and No. (Default = No) • When to display the reminder screen. Choices are 30 seconds to 15 minutes early, to 30 seconds to 15 minutes late, to On time. (Default = 1 min early) Highlight Remind Defaults, and press the Menu key to display the Remind Default Options menu. Highlight Go to Service Bar to close the menu, change no infor- mation, and return to the Setup Service Bar. When finished, press ENTERto highlight Done. Press ENTER again to close the menu and accept the changes. Highlight Cancel to close the menu, change no information, and return to the highlighted option. 52 Plasma TV TV Guide On Screen System W Once—records the show one time W Regularly—records the show every time the show airs on the same channel and starts at the same time W Weekly—records the show each time the show airs on the same day of the week, on the same channel and starts at the same time W Off (not cancel)—keeps the show in the list but will not record this show until the frequency is changed. W Cancel (no icon displayed)—does not record TV Guide On Screen TV Guide On Screen TM System continued System continued Record Record And Remind Features And Remind Features V < Record > 2) From a Panel Menu •Highlight a show, and press Menu to display the Episode Options menu. •Highlight Set Recording, and press ENTERto display the Record Options menu. •Highlight the Frequency option, and use the left and right arrows to choose among Once, Regularly, Weekly, and Off, as previously described. • Recorder choice: Please choose the VCR only. This TV does not provide other devices with a recording feature. Note: Video Window Lock is operated to on or off using PIP button in Listings mode. You can set a show to Record in Listings, Search, and Schedule or change Record settings for a show in Schedule. There are 3 ways to set a show to Record: 1) Using the Record Button on the Remote • Press the Record button on the remote to record the show Once with current default settings (Start and End recording On Time). Each time you press the Record button, you change the record frequency (but not the default settings) among Once (default), Regularly, Off, Weekly and then Cancel. Note: The proper Record icon appears on the show tile, as the Record button is pressed. Owner’s Manual 53 TV Guide On Screen System When finished, press ENTERto highlight Schedule Recording. Press ENTERagain to close the menu. You see a Record icon for the selected frequency next to the show title. Highlight Cancel to close the menu, change no information, and return to the highlighted show. TV Guide On Screen TV Guide On Screen TM System continued System continued 3) Manual Recording • Highlight the Schedule Service label, and press Menu to display the Schedule Options menu. • Use the D / E / F / G buttons to move through the options. Use the number or the D / E / F / G buttons to change the informa- tion, as necessary. • Highlight New Manual Recording and press ENTER to display the Record Options menu. • Current information (i.e., date, start and end times, channel, input) is displayed. • Recorder choice: Please choose the VCR only. This TV does not provide other devices with a recording feature. 54 Plasma TV TV Guide On Screen System • Use the left and right arrows to choose between Once, Daily, Weekly, and Off, as follows. W Once —records the time, channel, input, recorder combi nation one time. W Daily —records the time, channel, input,recorder combi nation Monday through Friday. W Weekly —records the time, channel, input, recorder combination once a week on this selected day of the week W Off (not cancel) —keeps the time, channel, input, recorder combination in the list without recording until the frequency is changed. TV Guide On Screen TV Guide On Screen TM System continued System continued Record Conflict A conflict message appears for the following reasons: • a show set to Record overlaps with any part of another show pre- viously set to Record, • a show set to Record overlaps with a show previously set to auto- tune Select one of these options: W record anyway - this show will override an existing show set to Record or auto-tune W don't record this show - cancel the Recording Before a recording begins, a notification screen appears if your TV is On. At that time, you can choose to start or cancel recording. If the TV is not On, the recording occurs as scheduled. If there is no activity for 3 minutes, the notification screen automatically closes and com- pletes the highlighted item. When finished, press ENTERto highlight Schedule Recording. Press ENTERagain to close the menu. You see a Record icon for the selected frequency next to the show title. Note: Manual recording is listed by channel number. Highlight Cancel to close the menu, change no informa- tion, and return to the highlighted show. Owner’s Manual 55 TV Guide On Screen System TV Guide On Screen TV Guide On Screen TM System continued System continued V < Remind > You can …

Text truncated - open the document above for the full version.

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-360,Korea TEL : +82-54-470-4537 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ50PX4DUB Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Min-hwan OH / Senior Engineer LG Electronics Inc. TEL : +82-54-470-4537 FAX : 82-54-470-4534

FCC ID : BEJ50PX4DUB POWER OF ATTORNEY To whom it may concern: We the undersigned LG Electronics Inc. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign: Min-hwan OH/ Senior Engineer Tel:82-54-470-4537 Fax: 82-54-470-4534

Dear Timothy R. Johnson, 1)I uploaded revised manuals for BEJ50PX4DUB,BEJ50PY2DRUA. -See 2 page manual-1(new),There is cables statement for DVI/RGB. 2)Maxium resolution is 1024*768(BEJ50PX4DUB,BEJ50PY2DRUA) 3)1024*768 resolution is worse case data((BEJ50PX4DUB,BEJ50PY2DRUA) 4) We tested using emi test receiver(BEJ50PX4DUB,BEJ50PY2DRUA) 5) I uploaded revised 731 form for BEJ50PX4DUB,BEJ50PY2DRUA. 6) DVI(HDMI) PORT in circuit diagram is 8 page of Circuit -Digital_1 for BEJ50PX4DUB,BEJ50PY2DRUA-It is same DVI and HDMI. It is very urgent. Thank you, Yang. >From: Timothy R. Johnson [mailto:[email protected] ] >Sent: Friday, January 21, 2005 3:55 AM >To: [email protected] ...snip... >NARTE Certified EMC Engineer >No. EMC-002205-NE > >email: [email protected] >alternate email: [email protected] ATCB Comments_0120051.pdf From: =?ks_c_5601-1987?B?vufB+Ljw?= <[email protected]> To: <[email protected]> Subject: FCC ID: BEJ50PX4DUB//FCC ID: BEJ50PY2DRUA

Dear Timothy R. Johnson, 1)I uploaded revised manuals for BEJ50PX4DUB. -See 12 page manuals-1,There is cables statement for RGB. 2) We tested HDMI(DVI) port without ferrite bead. -Please see Photos of the test reports. Thank you Yang. Page 1 of 1=?ks_c_5601-1987?B?vufB+Ljw?=, 09:54 AM 2/4/2005 +0900, FW: FCC ID: BEJ50PX4DUB 2/7/2005Printed for "Timothy R. Johnson" <[email protected]>

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 20, 2005 RE: LG Electronics Inc. FCC ID: BEJ50PX4DUB After a review of the submitted information, I have a few comments on the above referenced Application. 1) The DVI input could not be found easily in the schematics. Please provide information as to where this may be found, or provide if not previously provided. Additionally if not previously provided, please be sure to provide for both this application and BEJ50PY2DRUA. 2) For connection to a PC, please explain the maximum resolution. Page 18 & 19 of the users manual implies 1024x768 while page 96 suggests 1366 x 768. Please confirm. 3) The device is capable of many different resolutions and refresh rates. These different resolutions and rates must be investigated to determine worse case (Page 16 of the users manual shows various resolutions possible). Worse case does not always occur at the highest resolution. Was this investigation performed? If not, how can worse case data be assured? 4) Please comment on the RBW/VBW used during radiated testing. 5) It appears that ferrites were present on the RGB and DVI cables. Therefore these are expected to be supplied to the end user with the device. However the information on page 12 and 21 suggest these cables will not be provided. Additionally this same information applies to application BEJ50PY2DRUA as well. Please address. 6) FYI....This application only covered the PC peripheral portion of the device. Please note that the manufacturer is still responsible for making sure that the technical requirements for TV receivers have been verified per the FCC rules (these may be found in Sections 15.31(n), 15.107, 109, 111, 117, 118, 119,120, and 122 as applicable). Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 28, 2005 RE: LG Electronics Inc. FCC ID: BEJ50PY2DRUA and BEJ50PX4DUB After a review of the submitted information, I have a few comments on the above referenced Application. 1) Regarding the previous comment: It appears that ferrites were present on the RGB and DVI cables. Therefore these are expected to be supplied to the end user with the device. However the information on page 12 and 21 suggest these cables will not be provided. Additionally this same information applies to application BEJ50PY2DRUA as well. Please address. You responded with: I uploaded revised manuals for BEJ50PX4DUB,BEJ50PY2DRUA. -See 2 page manual-1(new),There is cables statement for DVI/RGB. Placing the statement in the manual is not sufficient. The manufacturer must provide these cables since they required ferrites. The FCC’s concern is that these are common cables which the user can simply buy from any store, and typically the cable will not include ferrites, and if it does, likely is not the same ferrite as tested. The FCC has always felt that the burden of compliance is not that of the consumer/buyer/reseller, but instead the manufacturer (applicant issued grant). Since these cables are different than the consumer will buy and require ferrites for compliance, the manufacturer is responsible for providing to the buyer with the device. Additionally, please note that pages in the manual (12 and 23 of the new manual provided) clearly show they cables are not included. Optionally, the device may be tested/modified to comply without requiring external cables with ferrites. In this case, since no special cables are required for compliance (no ferrites present, etc.), the cables do not need to be provided to the consumer with the device. For further details of this, please consult Part 15.27. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2 January 28, 2005 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

1. FRONT 2. REAR 3. PORT 4.1 INTERNAL

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. POWER 2.1 Front 2.2 Rear 3. CTRL_LVDS 3.1 Front 3.2 Rear 4.PDP 4.1 Front 4.2 Rear 5. RGB 5.1 Front 5.2 Rear 6. YSUS 6.1 Front 6.2 Rear 7.MEMORY CARD READER 7.1 Front 7.2 Rear 8. Z SUS 8.1 Front 8.2 Rear

LG Electronics Inc. FCC ID BEJ50PX4DUB -Operational description- A plasma display panel is the latest display technology. It is currently the best way to achieve flat panel displays with excellent image quality and large screen sizes, that are easily viewable. The PDP can be thought of as a descendant of the neon lamp an dit can be also be viewed as a series of fluorescent lamps. PDP is an array of cells, known as pixels, which are comprised of 3 sub pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phos-phors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors. You get the rich, dynamic colors that you expect. Each sub-pixel is individually controlled by advanced electronics to produce over16 million different colors. All of this means that you get perfect images that are easily viewable in a display that is less than 5inches thick.

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned - 50PX4D-UB,DU-50PX41, DU-50PX41S, 50PX4D are same product. ONLY Model name is different OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 2000 Millbrook Dr Lincolnshire, IL 60069 United states 847-841-8373 Measurement facility registration number Senior Engineer J.M. Yang Director T.K. Lee 94696 (Signature) (Signature) Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2002 , ANSI C 63.4 2001 2005-01-10 ~2005-01-19 50PX4D-UB,DU-50PX41, DU-50PX41S, 50PX4D NONE LG Electronics Inc. KOREA Report Number : ESTF150501-003 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150501-003 Manufacturer Country of origin Applicant Product 2005-01-19 PLASMA MONITOR 3 4 5 6 8 8 8 9 10 10 10 11 12 14 Appendix 1. Spectral diagram Appendix 2. Phorographs of EUT in side PCB Appendix 3. Block diagram of EUT Appendix 4. Circuit Diagram Report Number : ESTF150501-003 , Web : www. estech. co. kr Page 2 of 14 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.3 Test data ............................................................................................. ... 7. Photographs of test setup ........................................................................... 8. Photogra phs of EUT .................................................................................... 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150501-003 , Web : www. estech. co. kr Page 3 of 14 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : 50PX4D-UB,DU-50PX41, DU-50PX41S, 50PX4D Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 2.2 General descriptions of EUT Using Freq. :24.57Mhz(2ea)/18.43Mhz/8Mhz/4MHz(4ea)/25MHz(2ea)/12MHz Report Number : ESTF150501-003 , Web : www. estech. co. kr Page 4 of 14 PLASMA MONITOR NONE LG Electronics Inc. KOREA INPUT:AC120V / 60Hz 2005-01-10 3. Test Standards Test Standard : FCC PART 15 (2002) Test Method : ANSI C 63.4 (2001) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150501-003 , Web : www. estech. co. kr Page 5 of 14 4. Measurement Condition 4.1 EUT Operation. 4.2 Configuration and Peripher…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
