BEJ50PY2DRUAPDP Display

Please read this manual carefully and completely before operating your TV. Retain this manual for future reference. Record model number and serial number of the TV in the spaces provided below. See the label attached on the back cover and relate this information to your dealer if you require service. Model Number : Serial Number : MODELS: TU-50PY22/TU-50PY2DR-UA TU-60PY22/TU-60PY2DR-UA LG Electronics U.S.A., Inc. TM R TruSurround XT PLASMA TV OWNER’S MANUAL 2 Plasma TV Warning/Caution WARNING/CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of suffi- cient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appli- ance. WARNING/CAUTION: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. FCC NOTICE • A Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. • Any changes or modifications not expressly approved by the party responsible for compli- ance could void the user’s authority to operate the equipment. CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized mod- ification could void the user’s authority to operate this product. COMPLIANCE: The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 1-201-816-2000 http://www.lgusa.com WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN /CAUTION WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. W W arning/Caution arning/Caution Owner’s Manual 3 TV Guide On Screen Notices for U.S.A. TV Guide On Screen Notices for U.S.A. In the United States, the TV Guide On Screen system and other related marks are registered marks of Gemstar-TV Guide On Screen system International, Inc. and/or one of its affiliates. In Canada,TV Guide On Screen system is a registered mark of Transcontinental Inc., and is used under license by Gemstar-TV Guide On Screen system International, Inc. The TV Guide On Screen system is protected by one or more of the following issued United States patents 6,498,895, 6,418,556, 6,331,877; 6,239,794; 6,154,203; 5,940,073; 4,908,713; 4,751,578; 4,706,121. The TV Guide On Screen system is manufactured under license from Gemstar-TV Guide On Screen system International, Inc. and/or one of its affiliates. Digital Cable Compatibility Digital Cable Compatibility This digital television is capable of receiving basic analog, digital basic and digital premium cable television programming by direct connection to a cable system providing such programming. A security card provided by your cable operator is required to view encrypted digital programming. Certain advanced interactive digital cable services such as video-on-demand, cable operator enhanced program (For example, electronic program guide provided by the cable operator), and data enhanced television service may require the use of a set top box. For more information contact your local cable operator. Use of the CableCARD TM TradeMark. “CableCARD TM is a trademark of Cable Television Laboratories, Inc.” 4 Plasma TV Warning/Caution IMPORTANT SAFETY INSTRUCTIONS Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the appa- ratus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may be placed immediately adjacent to that safety instruction : 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampli- fiers)that produce heat. 9. Do not defeat th…

Text truncated - open the document above for the full version.

Owner’s Manual 41 Operation SETUP VIDEO AUDIO TIME OPTION LOCK Previous Audio Language EZ SoundRite EZ Sound Balance Treble Bass Front SurroundG TV Speaker BBE Off 3D EchoSound System SRS TruSurround XT MENU 1.Press the MENUbutton and then use D / E button to select the AUDIOmenu. 2. Press the Gbutton and then use D / E button to select Front Surround. 3. Press the Gbutton and then use D / E button to select Off, 3D EchoSound System orSRS (Sound Retrieval System)TruSurround XT.. • 3D EchoSound System Creates a stunning simulated stereo effects from any mono sound and a real- istic three-dimensional sound with a very wide and deep sound stage into stereo sound. • SRS TruSurround XT Takes advantage of any multi-channel format without needing to add extra speakers or equipment. Dialog clarity, bass enrichment, and the addition of stereo audio enhancement that produces an immersive sound experience from standard stereo material. 4. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. Front Surround Front Surround -is a trademark of SRS Labs, Inc. - TruSurround XT technology is incorporated under license from SRS Labs, Inc. - Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories. CABLE 1. Press the MENUbutton and then use D / E button to select the AUDIOmenu. 2. Press theGbutton and then use D / E button to select the desired sound option ( Balance,Treble, or Bass). 3. Press the Gbutton and then use F / Gbutton to make appropriate adjustments. 4. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. Manual Sound Control ( Manual Sound Control (Custom option) option) SETUP VIDEO AUDIO TIME OPTION LOCK Previous Audio Language EZ SoundRite EZ Sound Balance0G Treble50 Bass50 Front Surround TV Speaker BBE MENU LR - Adjust the sound to suit your taste and room situations. CABLE 42 Plasma TV Operation 1. Use the SAPbutton to select your desired MTS mode in analog signal. Each time you press the SAPbutton, Mono, Stereo, or SAPappear in turn. • If other languages available on the digital signal, select them with the SAPbutton. 2. Press EXIT button to save and return to TV viewing. Stereo/SAP Stereo/SAP Broadcasts Setup Broadcasts Setup - This TV can receive MTS stereo programs and any SAP (Secondary Audio Program) that accompanies the stereo program; if the station transmits an additional sound signal as well as the original one. - When having selected Stereo or SAP button on the remote control, this TV can only receive the signal in case that the TV sta- tion transmits the proper signals. - Mono sound is automatically received if the broadcast is only in Mono; even though Stereo or SAP has been selected. - Select Mono if you want to listen to the mono sound in remote fringe areas during stereo/SAP broadcasting. - Stereo or SAP can be received in Analog channel. BBE BBE - BBE High Definition Sound restores clarity and presence for better speech intelligibility and musical realism. Manufactured under license from BBE Sound, Inc. SETUP VIDEO AUDIO TIME OPTION LOCK Audio Language EZ SoundRite EZ Sound Balance Treble Bass Front Surround TV SpeakerG BBE Off On Prev. MENU CABLE 1.Press the MENUbutton and then use D / E button to select the AUDIOmenu. 2. Press the Gbutton and then use D / E button to select TV Speaker. 3. Press the Gbutton and then use D / E button to select OnorOff. 4. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. TV Speakers On/Of TV Speakers On/Of f Setup f Setup - Turn TV speakers off if using external audio equipment. Feature turns the TV Speakers option On or Off. 1.Press the MENUbutton and then use D / E button to select the AUDIOmenu. 2. Press the Gbutton and then use D / E button to select BBE. 3. Press the Gbutton and then use D / E button to select OnorOff. 4. Press EXIT button to return to TV viewing or press ENTERbutton to return to the previous menu. SETUP VIDEO AUDIO TIME OPTION LOCK Audio Language EZ SoundRite EZ Sound Balance Treble Bass Front Surround TV Speaker BBE G Off On Previous MENU CABLE Audio Menu Options Audio Menu Options Owner’s Manual 43 Operation SETUP VIDEO AUDIO TIME OPTION LOCK Previous Auto ClockG Manual Clock Off Timer On Timer Sleep Timer Auto Off Off On Time Zone Eastern Daylight Auto Saving MENU SETUP VIDEO AUDIO TIME OPTION LOCK Previous Auto Clock Manual Clock Off Timer On TimerG Sleep Timer Auto Off Off On Time 6 : 30 AM Ch. TV 2-0 Vol 17 MENU SETUP VIDEO AUDIO TIME OPTION LOCK Previous Auto Clock Manual ClockG Off Timer On Timer Sleep Timer Auto Off Year - - - - Date - - / - - Time - - : - - - - MENU - Timer function operates only if current time has been set. - Off-Timer function overrides On-Timer function if they are set both set to the same time. - The TV must be in standby mode for the On-Timer to work. - If you do not press any button within 2 hours after the TV turns on with the On Timer function, the TV will automatically revert to standby mode. On/Of On/Of f f T T imer Setup imer Setup 1. Press the MENUbutton and then use D / E button to select the TIMEmenu. 2. Press the Gbutton and then use D / E button to select Off Timeror On Timer. 3. Press the Gbutton and then use D / E button to selectOn. • To cancel On/Off timerfunction, select Off. 4. Press the Gbutton and then use D / E button to set the hour. 5. Press the Gbutton and then use D / E button to set the minutes. 6.For only On timerfunction Press the Gbutton and then use D / E button to select the channel at turn-on. Press the Gbutton and then use D / E button to set the sound level at turn-on. 7. Press EXIT button to return to TV viewing or press MENUbutton to return to the previous menu. Auto Clock Setup Auto Clock Setup - The time is set automatically from a digital channel signal. - The digital channel signal includes information for the current time provided by the broadcasting station. -…

Text truncated - open the document above for the full version.

Owner’s Manual 81 TV Guide On Screen System General Default Options lets you set defaults for the following: •The initial Info Box size when the TV guide on screen system is entered. Choices are No, Small, Large, and Last Used (Default = Last Used). •The Info Box size rotation when the Info key is pressed while in the TV guide on screen system. Choices are No only, Small only, Large only, No & Small, No & Large, Small & Large, All (Default = All) •Automatic entry into the TV guide on screen system (Auto-Guide) when the TV is powered On. Choices are On and Off (Default = On). Highlight General Default Options, and press the Menu key to dis- play the General Default Options menu. Highlight Go to Service Bar to close the menu, change no infor- mation, and return to the Setup Service Bar. When finished, press ENTERto highlight Done. Press ENTER again to close the menu and accept the changes. Highlight Cancel to close the menu, change no information, and return to the highlighted option. • Change Default Options Change Default Options lets you change default settings in the following categories: •General Default Options •Record Defaults •Remind Defaults Highlight Change Default Options, and press ENTER. <General Default Options> TV Guide On Screen TV Guide On Screen ® System continued System continued 82 Plasma TV TV Guide On Screen System < Record Defaults> Record Default Options lets you set defaults for the following: • When to start the record event. Choices are 120 minutes early to 120 minutes late, to On time. (Default = On time) • When to end the record event. Choices are 120 minutes early to 120 minutes late, to On time. (Default = On time) • Recorder choice: Please choose the HDD only. This TV does not provide other devices with a recording feature. Highlight Record Defaults, and press the Menu key to display the Record Default Options menu. Highlight Go to Service Bar to close the menu, change no infor- mation, and return to the Setup Service Bar. TV Guide On Screen TV Guide On Screen ® System continued System continued < Remind Defaults> Remind Default Options lets you set defaults for the following: •Power On the TV, if Off, when a Reminder is scheduled. Choices are Yes and No. (Default = No) •Automatically tune the TV to the channel (TV must be On), when a Reminder is scheduled. Choices are Yes and No. (Default = No) •When to display the reminder screen. Choices are 30 seconds to 15 minutes early, to 30 seconds to 15 minutes late, to On time. (Default = 1 min early) Highlight Remind Defaults, and press the Menu key to display the Remind Default Options menu. Highlight Go to Service Bar to close the menu, change no information, and return to the Setup Service Bar. When finished, press ENTERto highlight Done. Press ENTER again to close the menu and accept the changes. Highlight Cancel to close the menu, change no information, and return to the highlighted option. Owner’s Manual 83 W Once—records the show one time W Regularly—records the show every time the show airs on the same channel and starts at the same time W Weekly—records the show each time the show airs on the same day of the week, on the same channel and starts at the same time W Off (not cancel)—keeps the show in the list but will not record this show until the frequency is changed W Cancel (no icon displayed)—does not record TV Guide On Screen System TV Guide On Screen TV Guide On Screen ® System continued System continued Record Record And Remind Features And Remind Features V < Record > You can set a show to Record in Listings, Search, and Schedule or change Record settings for a show in Schedule. There are 3 ways to set a show to Record: 1) Using the Record Button on the Remote • Press the Record button on the remote to record the show Once with current default settings (Start and End recording On Time). Each time you press the Record button, you change the record frequency (but not the default settings) among Once (default), Regularly, Daily, Weekly and then Cancel. Note: The proper Record icon appears on the show tile, as the Record button is pressed. 2) From a Panel Menu •Highlight a show, and press Menu to display the Episode Options menu. •Highlight Set Recording, and press ENTERto display the Record Options menu. •Highlight the Frequency option, and use the left and right arrows to choose among Once, Regularly, Weekly, and Off, as previously described. • Recorder choice: Please choose the HDD only. This TV does not provide other devices with a recording feature. •Note: Video Window Lock is operated to on or off using PIP button in Listings mode. 84 Plasma TV TV Guide On Screen System When finished, press ENTERto highlight Schedule Recording. Press ENTERagain to close the menu. You see a Record icon for the selected frequency next to the show title. Highlight Cancel to close the menu, change no information, and return to the highlighted show. TV Guide On Screen TV Guide On Screen ® System continued System continued 3) Manual Recording •Highlight the Schedule Service label, and press Menu to display the Schedule Options menu. •Use the D / E / F / G buttons to move through the options. Use the number or Use the D / E / F / G buttons to change the infor- mation, as necessary. •Highlight New Manual Recording and press ENTER to display the Record Options menu. •Current information (i.e., date, start and end times, channel, input) is displayed. • Recorder choice: Please choose the HDD only. This TV does not provide other devices with a recording feature. Owner’s Manual 85 •Use the left and right arrows to choose between Once, Daily, Weekly, and Off, as follows. W Once —records the time, channel, input, recorder combi- nation one time. W Daily —records the time, channel, input, recorder combi- nation Monday through Friday. W Weekly —records the time, channel, input, recorder com- bination once a week on this selected day of the week W Off (not cancel) —keeps the time, channel, input, recorder combination in the list wi…

Text truncated - open the document above for the full version.

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-360,Korea TEL : +82-54-470-4537 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ50PY2DRUA Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Min-hwan OH / Senior Engineer LG Electronics Inc. TEL : +82-54-470-4537 FAX : 82-54-470-4534

FCC ID : BEJ50PY2DRUA POWER OF ATTORNEY To whom it may concern: We the undersigned LG Electronics Inc. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign: Min-hwan OH/ Senior Engineer Tel:82-54-470-4537 Fax: 82-54-470-4534

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 20, 2005 RE: LG Electronics Inc. FCC ID: BEJ50PY2DRUA or BEJTU50PY2DRUA After a review of the submitted information, I have a few comments on the above referenced Application. 1) The FCC ID on the label does not match the FCC listed on all other documents in the application. It contains additional characters “TU” What is correct? Please review and correct all exhibits as necessary. a 2) For connection to a PC, please explain the maximum resolution. Page 19 & 20 of the users manual implies 1025x768 while page 107 suggests 1366 x 768. Please confirm. 3) The device is capable of many different resolutions and refresh rates. These different resolutions and rates must be investigated to determine worse case (Page 16 of the users manual shows various resolutions possible). Worse case does not always occur at the highest resolution. Was this investigation performed? If not, how can worse case data be assured? 4) Please comment on the RBW/VBW used during radiated testing. 5) FYI....This application only covered the PC peripheral portion of the device. Please note that the manufacturer is still responsible for making sure that the technical requirements for TV receivers have been verified per the FCC rules (these may be found in Sections 15.31(n), 15.107, 109, 111, 117, 118, 119,120, and 122 as applicable). Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 28, 2005 RE: LG Electronics Inc. FCC ID: BEJ50PY2DRUA and BEJ50PX4DUB After a review of the submitted information, I have a few comments on the above referenced Application. 1) Regarding the previous comment: It appears that ferrites were present on the RGB and DVI cables. Therefore these are expected to be supplied to the end user with the device. However the information on page 12 and 21 suggest these cables will not be provided. Additionally this same information applies to application BEJ50PY2DRUA as well. Please address. You responded with: I uploaded revised manuals for BEJ50PX4DUB,BEJ50PY2DRUA. -See 2 page manual-1(new),There is cables statement for DVI/RGB. Placing the statement in the manual is not sufficient. The manufacturer must provide these cables since they required ferrites. The FCC’s concern is that these are common cables which the user can simply buy from any store, and typically the cable will not include ferrites, and if it does, likely is not the same ferrite as tested. The FCC has always felt that the burden of compliance is not that of the consumer/buyer/reseller, but instead the manufacturer (applicant issued grant). Since these cables are different than the consumer will buy and require ferrites for compliance, the manufacturer is responsible for providing to the buyer with the device. Additionally, please note that pages in the manual (12 and 23 of the new manual provided) clearly show they cables are not included. Optionally, the device may be tested/modified to comply without requiring external cables with ferrites. In this case, since no special cables are required for compliance (no ferrites present, etc.), the cables do not need to be provided to the consumer with the device. For further details of this, please consult Part 15.27. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2 January 28, 2005 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Dear Timothy R. Johnson, I'm sorry 1)I uploaded revised label from. 2)Maxium resolution is 1024*768. 3)1024*768 resolution is worse case data 4) We tested using emi test receiver Thank you, Yang.

Dear Timothy R. Johnson, I talked about video cable with LG Electronics person in charge. As a result, concluded that offer video cable for RGB in LG Electronics. But, HDMI(DVI) cable is not offered Because We tested HDMI(DVI) port without ferrite bead. -Please see Photos of the test reports. 1)I uploaded revised manuals for BEJ50PY2DRUA. -See 12 page manuals-1,There is cables statement for RGB. Thank you Yang.

1. FRONT 2. REAR 3. PORT 4.1 INTERNAL

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. POWER 2.1 Front 2.2 Rear 3. CTRL_LVDS 3.1 Front 3.2 Rear 4.PDP 4.1 Front 4.2 Rear 5. RGB 5.1 Front 5.2 Rear 6. YSUS 6.1 Front 6.2 Rear 7.MEMORY CARD READER 7.1 Front 7.2 Rear 8. Z SUS 8.1 Front 8.2 Rear 9. LED 9.1 FRONT 9.2 Rear

LG Electronics Inc. FCC ID BEJ50PY2DRUA -Operational description- A plasma display panel is the latest display technology. It is currently the best way to achieve flat panel displays with excellent image quality and large screen sizes, that are easily viewable. The PDP can be thought of as a descendant of the neon lamp an dit can be also be viewed as a series of fluorescent lamps. PDP is an array of cells, known as pixels, which are comprised of 3 sub pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phos-phors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors. You get the rich, dynamic colors that you expect. Each sub-pixel is individually controlled by advanced electronics to produce over16 million different colors. All of this means that you get perfect images that are easily viewable in a display that is less than 5inches thick.

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned - 50PY2DR-UA,TU-50PY22, 50PY2DR are same product. ONLY Model name is different OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 2000 Millbrook Dr Lincolnshire, IL 60069 United states 847-841-8373 Measurement facility registration number Senior Engineer J.M. Yang Director T.K. Lee 94696 (Signature) (Signature) Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2002 , ANSI C 63.4 2001 2005-01-10 ~2005-01-19 50PY2DR-UA,TU-50PY22, 50PY2DR NONE LG Electronics Inc. KOREA Report Number : ESTF150501-002 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150501-002 Manufacturer Country of origin Applicant Product 2005-01-19 PLASMA MONITOR 3 4 5 6 8 8 8 9 10 10 10 11 12 14 Appendix 1. Spectral diagram Appendix 2. Phorographs of EUT in side PCB Appendix 3. Block diagram of EUT Appendix 4. Circuit Diagram Report Number : ESTF150501-002 , Web : www. estech. co. kr Page 2 of 14 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.3 Test data ............................................................................................. ... 7. Photographs of test setup ........................................................................... 8. Photogra phs of EUT .................................................................................... 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC require…

Text truncated - open the document above for the full version.
