BEJ60LA8600UCLED TV MONITOR

www.lg.comP/NO : MFL67652601 (1301-REV00) 55LA8600 60LA8600 Please read this manual carefully before operating your set and retain it for future reference. OWNER’S MANUAL LED TV * LG LED TV applies LCD screen with LED backlights. 47LA7900 55LA7900 ENGLISH 2 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product.  Do not use this apparatus near water.  Clean only with a dry cloth.  Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.  Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.  Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet (Can differ by country).  Do not press strongly upon the panel with a hand or a sharp object such as a nail, pencil or pen, or make a scratch on it. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING/CAUTION - TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death. CAUTION If you ignore the caution message, you may be slightly injured or the product may be damaged. NOTE The note helps you understand and use the product safely. Please read the note carefully before using the product. WARNING : This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. :DVKKDQGVDIWHUKDQGOLQJ ENGLISH 3 IMPORTANT SAFETY INSTRUCTIONS  Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.  Only use attachments/accessories specified by the manufacturer.  Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.  Unplug this apparatus during lightning storms or when unused for long periods of time.  Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.  Do not stick metal objects or any other conductive material into the power cord. Do not touch the end of the power cord while it is plugged in.  Keep the packing anti-moisture material or vinyl packing out of the reach of children. Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.  CAUTION concerning the Power Cord (Can differ by country): It is recommended that appliances be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner’s manual to be certain. Do not connect too many appliances to the same AC power outlet as this could result in fire or electric shock. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. Do not move the TV with the power cord plugged in. Do not use a damaged or loose power cord. Be sure do grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV.  Warning - To reduce the risk of fire or electrical shock, do not expose this product to rain, moisture or other liquids. Do not touch the TV with wet hands. Do not install this product near flammable objects such as gasoline or candles, or expose the TV to direct air conditioning.  Do not expose to dripping or splashing and do not place objects filled with liquids, such as vases, cups, etc. on or over the apparatus (e.g. on shelves above the unit). ENGLISH 4 IMPORTANT SAFETY INSTRUCTIONS  Grounding (Except for devices which are not grounded.) Ensure that you connect the earth ground wire to prevent poss…

Text truncated - open the document above for the full version.

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: Jan, 24 , 2013 C o m p lian ce C er tif icatio n Ser v ices C er tif icatio n Div is io n 4 7 1 7 3 B en icia Street Fremont, CA 94538, USA LETTER OF AUTHORIZATION To whom it may concern: We, the undersigned, hereby authorize Harvey Sung of DIGITAL EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization for FCC ID: B EJ60LA8600UC including signing of all documents relating to these matters. Any and all acts carried out by DIGITA L EMC Co., Ltd., on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from LG Electronics USA. Sincerely, Jacob Cho Director, Product Regulatory Compliance

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: Jan 24, 2013 Co mpliance Certifica t ion Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Mr. Harvey Sung of Digital EMC Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Mr. Harvey Sung of Digital EMC Co., Ltd. on our behalf shall have the same effect as acts of our own. In authorizing Digital EMC Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of a ll complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect t o such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jacob Cho Director, Product Regulatory Compliance REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

LG Electronics USA. 1000 Sylvan Avenue Englewood Cliffs, New Jersey, United States Date: Jan, 24, 2013 Compliance Certification Services Certif ication Division 47173 Benicia Street Fremont, CA 94538, USA RE: Request of Confidentiality for FCCID: BEJ60LA8600UC To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description File name PERMANENT 1 Block Diagram 60LA8600-UC Block Diagram.pdf SHORT-TERM 2 External Photos 60LA8600-UC _Ext Photo.pdf 3 Internal Photos 60LA8600-UC _Int Photo.pdf 4 Test-Setup Photos 60LA8600-UC _Test Photo.pdf 5 Users Manual 60LA8600-UC _User Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Jacob Cho Director, Product Regulatory Compliance

FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 1 FRONT REAR Label Location FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 2 LABEL REAR PORT FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 3 SIDE PORT

FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 1 REAR LABEL Label Location WIFI MODULE Label Product Label BT MODULE Label

FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 1 < Inside EUT > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 2 < LCD Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 3 < LCD Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 4 < LCD Label > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 5 < Main Board Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 6 < Main Board Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 7 < Power Board Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 8 < Power Board Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 9 < Power Board Label > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 10 < Button Board Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 11 < Button Board Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 12 < WIFI Module Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 13 < WIFI Module Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 14 < Sub Board1 Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 15 < Sub Board1 Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 16 < Sub Board2 Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 17 < Sub Board2 Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 18 < IR Board Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 19 < IR Board Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 20 < Remote Control Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 21 < Remote Control Rear > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 22 < BT Module Front > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. View 23 < BT Module Rear >

TRF-EM-003(00)081218 Copyright ○ c 2013, DIGITAL EMC CO., LTD. Page 2 of 28 FCC ID: BEJ60LA8600UC Report No.: DREFCC1301-0023 To t a l 2 8 pages CONTENTS 1. General Remarks ........................................................................................................................ 3 2. Test Laboratory ........................................................................................................................... 3 3. General Information of EUT ....................................................................................................... 4 4. Test Summary ............................................................................................................................. 5 4.1 Applied standards and test results ........................................................................................... 5 4.2 Test environment and conditions ............................................................................................. 5 4.3 Test result Summary ................................................................................................................ 5 5. Test Set-up and operation mode ............................................................................................... 6 5.1 Principle of Configuration Selection ......................................................................................... 6 5.2 Test Operation Mode ............................................................................................................... 6 5.3 Support Equipment Used ......................................................................................................... 6 6. Test Results : Emission .............................................................................................................. 7 6.1 Conducted Disturbance ........................................................................................................... 7 6.2 Radiated Disturbance ............................................................................................................ 12 Appendix 1 ..................................................................................................................................... 26 List of Test and Measurement Instruments ............................................................................. 26 Appendix 2 ..................................................................................................................................... 28 Report Revision History ............................................................................................................ 28 TRF-EM-003(00)081218 Copyright ○ c 2013, DIGITAL EMC CO., LTD. Page 3 of 28 FCC ID: BEJ60LA8600UC Report No.: DREFCC1301-0023 To t a l 2 8 pages 1. General Remarks This report contains the result of tests performed by: DIGITAL EMC CO., LTD. Address : 683-3, Yubang-Dong, Cheoin-Gu, Yongin-Si, Gyeonggi-Do, 449-080, Korea http://www.digitalemc.com Tel: +82-31-321-2664 Fax: +82-31-321-1664 2. Test Laboratory Digital EMC Co., Ltd. has been accredited / filed / authorized by the agencies listed in the following table; Certificate Nation Agency Code Mark Accreditation Korea KOLAS 393 ISO/IEC 17025 Site Filing USA FCC 101842 678747 Test Facility list & NSA Data Canada IC 5740A-1 5740A-2 Test Facility list & NSA Data Japan VCCI C-1427 R-1364, R-3385 T-1442, G-338 Test Facility list & NSA Data Certification Korea KC KR0034 Test Facility list & NSA Data Germany TUV ROK1221C ISO/IEC 17025 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competent of calibration and testing laboratory”. TRF-EM-003(00)081218 Copyright ○ c 2013, DIGITAL EMC CO., LTD. Page 4 of 28 FCC ID: BEJ60LA8600UC Report No.: DREFCC1301-0023 To t a l 2 8 pages 3. General Information of EUT Model No. 60LA8600-UC EUT Type LED TV Monitor Serial No NONE FCC ID BEJ60LA8600UC Type of Sample Tested Pre-Production High Frequency Max 1.2 GHz Rating AC 100-240 V~ 50/60 Hz Supplied Power for Test AC 120 V, 60 Hz Applicant LG Electronics Inc. 19-1, Cheongho-ri, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do, 451-713, Korea Manufacturer LG Electronics Inc. 19-1, Cheongho-ri, Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do, 451-713, Korea HDMI (PC) supported mode Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 640 x 350 31.468 70.09 720 x 400 31.469 70.08 640 x 480 31.469 59.94 800 x 600 37.879 60.31 1024 x 768 48.363 60.00 1152 x 864 54.348 60.053 1280 x 1024 63.981 60.02 1360 x 768 47.712 60.015 1920 x 1080 67.50 60.00 TRF-EM-003(00)081218 Copyright ○ c 2013, DIGITAL EMC CO., LTD. Page 5 of 28 FCC ID: BEJ60LA8600UC Report No.: DREFCC1301-0023 To t a l 2 8 pages 4. Test Summary 4.1 Applied standards and test results Test Items Applied Standards Results Conducted Disturbance ANSI C63.4:2003 C Radiated Disturbance ANSI C63.4:2003 C C=Comply N/C=Not Comply N/T=Not Tested N/A=Not Applicable The data in this test report are traceable to the national or international standards. 4.2 Test environment and conditions Test Items Test date (MM-DD) Temp ()°C Humidity (% R.H.) Conducted Disturbance 01-11 23 31 Radiated Disturbance 01-17 20 37 4.3 Test result Summary (1) Conducted Emission (USB MODE) Frequency [MHz] Phase Result [dBμV] Detector Limit [dBμV] Margin [dB] 0.15043 N 60.3 Quasi-Peak 66.0 5.7 (2) Radiated Emission (HDMI MODE) Frequency [MHz] Pol. Result [dB(μV/m)] Detector Limit [dB(μV/m)] Margin [dB] 891.026 H 40.2 Quasi-Peak 46.0 5.8 TRF-EM-003(00)081218 Copyright ○ c 2013, DIGITAL EMC CO., LTD. Page 6 of 28 FCC ID: BEJ60LA8600UC Report No.: DREFCC1301-0023 To t a l 2 8 pages 5. Test Set-up and operation mode 5.1 Principle of Configuration Selection Emission : The equipment under test (EUT) was configured to measure its highest possible radiation level. The test modes were adapted accordingly in reference to the instructions for use. 5.2 Test Operation Mode - HDMI MODE : ‘H’ Pattern mode, 1920x1080…

Text truncated - open the document above for the full version.

FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. Conducted Emission FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. Radiated Emission < 30 MHz ~ 1 GHz > FCC ID: BEJ60LA8600UC Copyright © 2013, DIGITAL EMC Co., Ltd. Radiated Emission < (1 ~ 6) GHz >
