www.lg.com OWNER’S MANUAL PLASMA TV Please read this manual carefully before operating your set and retain it for future reference. P/NO : MFL67701711 (1211-REV00) 50PH4700 60PH6700 2 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING/CAUTION - TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. y Do not use this apparatus near water. Short-circuit Breaker Power Supply y Clean only with a dry cloth. Short-circuit Breaker Power Supply y Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Short-circuit Breaker Power Supply y Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Short-circuit Breaker Power Supply y Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet (Can differ by country). Short-circuit Breaker Power Supply IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Short-circuit Breaker Power Supply WARNING : This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death. CAUTION If you ignore the caution message, you may be slightly injured or the product may be damaged. NOTE The note helps you understand and use the product safely. Please read the note carefully before using the product. 3 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS y Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Short-circuit Breaker Power Supply y Only use attachments/accessories specified by the manufacturer. Short-circuit Breaker Power Supply y Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Short-circuit Breaker Power Supply y Unplug this apparatus during lightning storms or when unused for long periods of time. Short-circuit Breaker Power Supply y Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Short-circuit Breaker Power Supply y Do not stick metal objects or any other conductive material into the power cord. Do not touch the end of the power cord while it is plugged in. y Keep the packing anti-moisture material or vinyl packing out of the reach of children. Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children. y CAUTION concerning the Power Cord (Can differ by country): It is recommended that appliances be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner’s manual to be certain. Do not connect too many appliances to the same AC power outlet as this could result in fire or electric shock. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. Do not move the TV with the power cord plugged in. Do not use a damaged or loose power cord. Be sure do grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV. Short-circuit Breaker Power Supply 4 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS y Warning - To reduce the risk of fire or electrical shock, do not expose this product to rain, moisture or other liquids. Do not touch the TV with wet hands. Do not install this product near flammable objects such as gasoline or candles, or expose…

Text truncated - open the document above for the full version.

21 ENG ENGLISH MAKING CONNECTIONS MAKING CONNECTIONS y This part of MAKING CONNECTIONS mainly uses picture for 60PH6700. You can connect various external devices to the TV. Supported external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. For more information on external device’s connection, refer to the manual provided with each device. NOTE y If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable to the TV through a DVD recorder or VCR. For more information on recording, refer to the manual provided with the connected device. y The external device connections show may differ from your model. y Connect external devices to the TV regardless of the order of the TV port. y If you connect a gaming device to the TV, use the cable supplied with the gaming device. y Refer to the external equipment’s manual for operating instructions. Connecting to an antenna or cable Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations may differ from the actual items and a RF cable is optional. CAUTION y Make sure not to bend the copper wire of the RF cable. Copper wire y Complete all connections between devices, and then connect the power cord to the power outlet to prevent damage to your TV. NOTE y Use a signal splitter to use more than 2 TVs. y Visit http://lgknowledgebase.com for more information about the antenna and cable connection. Search for antenna. ANTENNA/ CABLE IN VHF Antenna UHF Antenna Antenna Terminal Coaxial (75Ω) 22 ENG ENGLISH MAKING CONNECTIONS Connecting to a HD receiver, DVD Player or VCR Connect a HD receiver, DVD Player or VCR to the TV and select an appropriate input mode. HDMI Connection HDMI is the best way to connect a device. Transmits digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown in the following illustration. NOTE y Use the latest High Speed HDMI™ Cable that supports CEC (Customer Electronics Control) function. y High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher. IN 3 (MHL) IN 2 (PC) HDMI 1 I N (ARC) (*Not Provided) DVD/ Blu-Ray / HD Cable Box / HD STB Choose any HDMI IN input port to connect. It does not matter which port you use. ARC (Audio Return Channel) y When connected with a high-speed HDMI cable, digital audio can be sent to a compactible device without an additional optical audio cable. y ARC is only supported on the HDMI input 1 (ARC) port. An external audio device that supports ARC should be connected to HDMI 1 if you wish to use ARC. NOTE y DTV Audio Supported Codec: MPEG, Dolby Digital y HDMI Audio Supporeted Format: Dolby Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/ 88k/96k/176k/192k) -> Not supported DTS. 23 ENG ENGLISH MAKING CONNECTIONS DVI to HDMI Connection Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an audio cable. COMPONENT IN L PB PR R Y VID EO AUDIO R L/MONO AV IN AUDIO IN (PC) $8',2287 '9,287 IN 2 (PC) (*Not Provided) (*Not Provided) DVD/ Blu-Ray / HD Cable Box RED WHITE 24 ENG ENGLISH MAKING CONNECTIONS Connecting to a mobile phone Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from mobile phones to television sets. y Connect the mobile phone to the HDMI IN 3 (MHL) port to view the phone screen on the TV. y This only works for the MHL-enabled phone. y Some applications can be operated by the remote control. y For some mobile phones supporting MHL, you can control with the Magic Remote Control. y The MHL passive cable is needed to connect the TV and a mobile phone. NOTE (*Not Provided) MHL Cable Mobile phone IN 3 (MHL) 25 ENG ENGLISH MAKING CONNECTIONS Component Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with a component cable as shown in the following illustration. NOTE y If cables are installed incorrectly, it could case the image to display in black and white or with distorted color. y Check to ensure each cable is matched with the corresponding color connection. AUDIO VIDEO LR COMPONENT IN VIDEO AUDIO LP B PR R Y VIDEO AUDIO R L/MONO AV IN AUDIO IN (PC) (*Not Provided)(*Not Provided) DVD / Blu-Ray / HD Cable Box GREEN GREEN BLUE BLUE RED REDRED WHITE WHITE RED 26 ENG ENGLISH MAKING CONNECTIONS Composite Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown in the following illustration. NOTE y If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the TV. COMPONENT IN VIDEO AUDIO L PB PR R Y VIDEO AUDIO R L/MONO AV IN AUDIO IN (PC) VIDEO MONO () AUDIOLR VCR / DVD / Blu-Ray / HD Cable Box YELLOW WHITE RED YELLOW WHITE RED (*Not Provided) 27 ENG ENGLISH MAKING CONNECTIONS Connecting to a PC NOTE y It is recommended to use the HDMI connection for the best image quality. y Depending on the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use. y In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. If noise is present, change the PC output to another resolution, change the refresh rate to another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear. y The synchronization input form for Horizontal and Vertical frequencies is separate. y Depending on the graphics card, some resolution settings may not allow the image to be positioned on the screen properly. HDMI Connection or DVI to HDMI Connection Choose method A or B to make connection. Method A: HdMI Connection 5*%287 3& $8',228 7 HDMI AUDIO IN (RGB/DVI) RGB IN (PC) 1 IN …
