BEJ60PK550UDPLASMA TV/MONITOR

P/NO : SAC33575901(0905-REV06) www.lgusa.com / www.lg.ca / www.lgcommercial.com This product qualifies for ENERGY STAR in the “fac- tory default (Home Use mode)” setting. Changing the factory default picture setting or enabling other features will increase power consumption that could exceed the limits necessary to quality for Energy Star rating. Please read this manual carefully before operating your set and retain it for future reference. The model and serial number of the TV is located on the back and one side of the TV. Record it below should you ever need service. PLASMA TV OWNER’S MANUAL 42PJ350 50PJ350 50PJ340 50PK250 60PK250 50PK540 60PK540 50PK550 60PK550 www.lgusa.com / www.lg.ca 1-800-243-0000 USA, Consumer User 1-888-865-3026 USA, Commercial User 1-888-542-2623 CANADA LG Customer Information Center Model: Serial: 2 WARNING / CAUTION WARNING / CAUTION To prevent fire or shock hazards, do not expose this product to rain or moisture. FCC NOTICE Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two condi- tions: (1) This device may not cause (harmful) interference, and (2) this device must accept any interference received, including interference that may cause undesired operation (of the device). Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the litera- ture accompanying the appliance. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. NOTE TO CABLE/TV INSTALLER This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical. 3 IMPORTANT SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)that produce heat. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong, The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Only use attachments/accessories specified by the manufacturer. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus com- bination to avoid injury from tip-over. Unplug this apparatus during lighting storms or when unused for long periods of time. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power- supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 1 2 3 4 5 7 8 6 9 10 4 SAFETY INSTRUCTIONS Never touch this apparatus or antenna during a thunder or lighting storm. When mounting a TV on the wall, make sure not to install the TV by the hanging power and signal cables on the back of the TV. Do not allow an impact shock or any objects to fall into the product, and do not drop onto the screen with something. CAUTION concerning the Power Cord: It is recommend that appliances be placed upon a dedicated circuit; that is, a single outlet circuit …

Text truncated - open the document above for the full version.

WATCHING TV / CHANNEL CONTROL 51 ■ DDiirreecctt PPllaayy:: After connecting AV devices to the TV, you can directly control the devices and play media with- out additional settings. ■ SSeelleecctt AAVV ddeevviiccee:: Enables you to select one of the AV devices connected to TV. ■ DDiisscc ppllaayybbaacckk:: Control connected AV devices by pressing the , ENTER, G , A , ll ll , FF and GG buttons. ■ PPoowweerr ooffff aallll ddeevviicceess:: When you power off the TV, all connected devices are turned off. ■ SSwwiittcchh aauuddiioo--oouutt:: Offers an easy way to switch audio-out. ■ SSyynncc PPoowweerr oonn:: When the equipment with Simplink function connected HDMI terminal starts to play, The TV will change automatically to turn on mode. (A device, which is connected to the TV through a HDMI cable but does not support SIMPLINK, does not provide this function) Note: To operate SIMPLINK, an HDMI cable over Version 1.3 with *CEC function should be used. (*CEC: Consumer Electronics Control). SIMPLINK Menu TTVV vviieewwiinngg : Switch to the previous TV channel regardless of the current mode. DDIISSCC ppllaayybbaacckk : Select and play discs. When multiple discs are available, the titles of discs are conveniently displayed at the bottom of the screen. VVCCRR ppllaayybbaacckk : Control the connected VCR. HHDDDD RReeccoorrddiinnggss ppllaayybbaacckk : Control recordings stored in HDD. AAuuddiioo OOuutt ttoo HHoommee TThheeaatteerr ssppeea akk-- eerr//AAuuddiioo OOuutt ttoo TTVV : Select Home Theater speaker or TV speaker for Audio Out. SIMPLINK Functions 1 2 3 4 5 GG When no device is con- nected (displayed in gray) GG Selected Device GG When a device is connected (displayed in bright color) 1 2 3 4 5 Display SSIIMMPPLLIINNKK menu. Select the desired device. Control connected AV devices. 1 3 2 ENTER FREEZE ENTER ENTER FF GG Move FFGG Change Device Select FF GG Move FFGG Change Device Select FF GG Move FFGG Change Device Select USB 52 USB - Only 50/60PK550, 42/50PJ350 models ENTRY MODES When you connect a USB device, this screen is displayed automatically. In USB device, you can not add a new folder or delete the existing folder. Precautions when using the USB device GG Only a USB storage device is recognizable. GG If the USB storage device is connected through a USB hub, the device is not recognizable. GG A USB storage device using an automatic recognition program may not be recognized. GG A USB storage device which uses its own driver may not be recognized. GG In case of a card reader, up to four memory cards are concurrently recognizable. GG The recognition speed of a USB storage device may depend on each device. GG Please do not turn off the TV or unplug the USB device when the connected USB storage device is working. When such device is suddenly separated or unplugged, the stored files or the USB storage device may be damaged. GG Only use a USB storage device which has normal music files or image files. GG Please use only a USB storage device which was for- matted as a FAT16, FAT32 or NTFS file system pro- vided with the Windows operating system. In case of a storage device formatted as a different utility pro- gram which is not supported by Windows, it may not be recognized. GG Please connect power to a USB storage device which requires an external power supply. If not, the device may not be recognized. GG Please connect a USB storage device with cable is offered by USB maker. If connected with cable is not offered by USB maker or an excessively long cable, the device may not be recognized. GG Some USB storage devices may not be supported or operate properly. GG The TV will display up to 128 characters of a files name. GG Please backup important files because data on USB device may be damaged. Data management is con- sumer's responsibility and as a result, the manufactur- er does not cover data damage. GG The recommended capacity is 1TB or less for a USB external hard disk and 32GB or less for USB memory. Any device with more than the recommended capacity may not work properly. When removing the USB device Connect the USB device to the UUSSBB IINN jacks on the side of TV. 3 Select PPhhoottoo LLiisstt,, MMuussiicc LLiisstt or MMoovviiee LLiisstt . 1 MI IN 3 USB IN Select EEjjeecctt UUSSBB . Select the EEjjeecctt UUSSBB menu before removing the USB device. 2 ENTER 1 Q.MENU 2 ENTER ■ It doesn’t support USB HDD. ■ This TV supports JPG and MP3 files. Select EEjjeecctt . GG In order to avoid losing the USB memory stick, use the USB connector to fix the USB memory stick to the USB connector holder of the TV. NOTE ! USB Input Port USB Connector (sold separately) - Fix the one end of the USB connector to the USB memory stick and the other end to the USB connector holder. USB connector holder Photo ListMusic List PHOTO LIST USB 53 You can view ( * .JPG) files from USB storage devices. The On Screen Display on your model may be slightly different. Screen Components Moves to upper level file Preview: Display the thumbnail/folder name of the photo in the selected folder Current page/Total pages Total number of marked photos Usable USB memory Corresponding buttons on the remote control Supported photo file: * .JPG ■ You can play JPG files only. ■ Only baseline scan is supported among JPG. USB Device Page 1/1 No Marked PHOTO LIST Up Folder Free Space 150MB MovePopUp MenuMove PageMark 0 folder, 4 file(s) 34 5 1 1 2 Select UUSSBB . Select PPhhoottoo LLiisstt . 2 Top Folder DriveA 1 MENU ENTER ENTER 1 2 3 4 5 6 DriveA CH MARK 6 Exit USB 54 USB Photo Selection and Popup Menu USB Device Page 1/1 No Marked PHOTO LIST Up Folder Free Space 150MB 0 folder, 4 file(s) USB Device Page 1/1 No Marked PHOTO LIST Up Folder Free Space 150MB 1366 x 768 125KB Select the target folder or drive. Select the desired photos. 2 Show the Popup menu. 3 1 ■ Use the CCHH button to navigation in the photo page. ■ Use the MMAARRKK button to mark or unmark a photo. When one or more photos are marked, you can view individual photos or a slide…

Text truncated - open the document above for the full version.

LG Electronics USA Date: Dec 3, 2009 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Jin-Mo Yang,Engineering Manager of ESTECH Co., Ltd. and hereafter referred to as ESTECH, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jin-Mo Yang,Engineering Manager of ESTECH Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ESTECH as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Mr. Jae Cheon Lee,General Manager LG Electronics USA. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

LG Electronics USA Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: BEJ60PK550UD To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until (please enter the product announcement date here): 45days Internal Photos It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Mr Jae Cheon Lee,General Manager LG Electronics USA. 2009-12-3

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. Power 2.1 Front 2.2 Rear 3. PDP 3.1 Front 3.2 Rear 4. CTRL 4.1 Front 4.2 Rear 5. YSUS 5.1 Front 5.2 Rear 6. ZSUS 6.1 Front 6.2 Rear 7. IR 7.1 Front 7.2 Rear 8. TUNER(See main board)

LG Electronics USA FCC ID:BEJ60PK550UD -Operational description- A plasma display panel is the latest display technology. It is currently the best way to achieve flat panel displays with excellent image quality and large screen sizes, that are easily viewable. The PDP can be thought of as a descendant of the neon lamp an dit can be also be viewed as a series of fluorescent lamps. PDP is an array of cells, known as pixels, which are comprised of 3 sub pixels, corresponding to the colors red, green, and blue. Gas in a plasma state is used to react with phosphors in each sub-pixel to produce colored light (red, green, or blue). These phos-phors are the same types used in Cathode Ray Tube (CRT) devices such as televisions and common computer monitors. You get the rich, dynamic colors that you expect. Each sub-pixel is individually controlled by advanced electronics to produce over16 million different colors. All of this means that you get perfect images that are easily viewable in a display that is less than 5inches thick.

Test Report for FCC FCC ID:BEJ60PK550UD Company name Address Telephone Product name Model name Serial number Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - Basic model: 60PK550-UD Additional model: 60PK250-UA are same product, only model name is different. - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned Report Number : ESTF150912-002 , Web : www. estech. co. kr Page 1 of 15 Report NumberESTF150912-002 Manufacturer Country of origin Applicant Product 3-Dec-09 PLASMA TV/MONITOR 60PK550-UD NONE LG Electronics Inc. KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 (2008) & ICES-003 , ANSI C 63.4 2003 1-Dec-09 OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 847-941-8373 Measurement facility registration number Senior Engineer J.H.Kim Engineering Manager J.M.Yang 94696 (Signature) (Signature) EST-QP-20-01(0)-(F15) 3 4 5 6 8 8 8 9 10 11 11 11 12 13 15 Appendix 1. Spectral diagram Report Number : ESTF150912-002 , Web : www. estech. co. kr Page 2 of 15 5. Measurement of radiated emission ..................................................................... 5.1 Measurement equipment .............................................................................. Contents 1. Laboratory Information .................................................................................... 2. Descri ption of EUT .......................................................................................... 3. Test Standards ................................................................................................ 4. Measurement condition .................................................................................... 5.2 Environmental conditions .............................................................................. 5.4 Test data ................................................................................................... 5.3 Test data ................................................................................................... 7. Photographs of test setup ................................................................................. 8. Photographs of EUT .......................................................................................... 6. Measurement of conducted emission .................................................................. 6.1 Measurement equipment .............................................................................. 6.2 Environmental conditions .............................................................................. 6.3 Test data ................................................................................................... EST-QP-20-01(0)-(F15) 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co., Ltd. Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Korea (Safety & Telecom. Test Lab) EMC Test Lab : 97-1, Hoeok-ri, Majang-myun, Ichion-city, Kyonggi-do, South Korea 1.3 Official Qualification(s) KCC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report.ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150912-002 , Web : www. estech. co. kr Page 3 of 15 EST-QP-20-01(0)-(F15) 2. Description of EUT 2.1 Summary of Equipment Under Test Product Name : Model Number : 60PK550-UD Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : X-tal list(s): 2.2 General descriptions of EUT Report Number : ESTF150912-002 , Web : www. estech. co. kr Page 4 of 15 PLASMA TV/MONITOR NONE LG Electronics Inc. KOREA INPUT: AC100-240 V ~ 50 /60 Hz 6-Nov-09 31.88 MHz, 25 MHz, 12 MHz EST-QP-20-01(0)-(F15) 3. Test Standards Test Standard : FCC PART 15 (2008) & ICES-003 Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units TThis Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150912-002 , Web : www. estech. co. kr Page…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
