www.lg.com P/NO : MFL67701716 (1301-REV00) 60PN5700 Please read this manual carefully before operating your set and retain it for future reference. OWNER’S MANUAL PLASMA TV 2 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING/CAUTION - TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. yy Do not use this apparatus near water. Short-circuit Breaker Power Supply yy Clean only with a dry cloth. Short-circuit Breaker Power Supply yy Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Short-circuit Breaker Power Supply yy Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. Short-circuit Breaker Power Supply yy Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet (Can differ by country). Short-circuit Breaker Power Supply yy Do not press strongly upon the panel with a hand or a sharp object such as a nail, pencil or pen, or make a scratch on it Short-circuit Breaker Power Supply IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Short-circuit Breaker Power Supply WARNING : This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death. CAUTION If you ignore the caution message, you may be slightly injured or the product may be damaged. NOTE The note helps you understand and use the product safely. Please read the note carefully before using the product. 3 ENG ENGLISH IMPORTANT SAFETY INSTRUCTIONS yy Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Short-circuit Breaker Power Supply yy Only use attachments/accessories specified by the manufacturer. Short-circuit Breaker Power Supply yy Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Short-circuit Breaker Power Supply yy Unplug this apparatus during lightning storms or when unused for long periods of time. Short-circuit Breaker Power Supply yy Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Short-circuit Breaker Power Supply yy Do not stick metal objects or any other conductive material into the power cord. Do not touch the end of the power cord while it is plugged in. yy Keep the packing anti-moisture material or vinyl packing out of the reach of children. Anti- moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children. yy CAUTION concerning the Power Cord (Can differ by country): It is recommended that appliances be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner’s manual to be certain. Do not connect too many appliances to the same AC power outlet as this could result in fire or electric shock. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized service. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance. Do not move the TV with the power cord plugged in. Do not use a damaged or loose power cord. Be sure do grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV. Short-circuit Breaker Power Supply yy Warning - To reduce the risk of fire or electrical shock, do not expose this product to rain, moisture or other liquids. Do …

Text truncated - open the document above for the full version.

16 ENG ENGLISH ASSEMBLING AND PREPARING CAUTION yy Disconnect the power before moving or installing the TV. yy If you install the TV on a ceiling or slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. yy Do not over tighten the screws as this may cause damage to the TV and void your warranty. yy Use only screws and wall mounts that meet the VESA standard. Any damages or injuries by misuse or using an improper accessory are not covered by the warranty. NOTE yy A wall mount bracket is optional. You can obtain additional accessories from your local dealer. yy Use only screws that are listed on the VESA standard screw specifications. yy The wall mount kit includes an installation manual and necessary parts. yy The length of screws may differ depending on the wall mount. Make sure to use the proper length. yy For more information, refer to the manual supplied with the wall mount. Securing the TV to a wall (optional) (Depending on model) 1 Insert and tighten the eye-bolts, or TV brackets and bolts on the back of the TV. - If there are bolts inserted at the eye-bolts position, remove the bolts first. 2 Mount the wall brackets with the bolts to the wall. Match the location of the wall bracket and the eye-bolts on the rear of the TV. 3 Connect the eye-bolts and wall brackets tightly with a sturdy rope. Make sure to keep the rope horizontal with the flat surface. CAUTION yy Make sure that children do not climb on or hang on the TV. NOTE yy Use a platform or cabinet that is strong and large enough to support the TV securely. yy Brackets, bolts and ropes are optional. You can obtain additional accessories from your local dealer. 17 ENG ENGLISH ASSEMBLING AND PREPARING Tidying cables 1 Install the power cord holder and power cord. It will help prevent the power cable from being removed by accident.removed by accident. Power Cord Holder 2 Gather and bind the cables with the cable holder. Cable Holder CAUTION yy Do not move the TV by holding the cable holder and power cord holder, as the cable holders may break, and injuries and damage to the TV may occur. 18 ENG ENGLISH MAKING CONNECTIONS MAKING CONNECTIONS You can connect various external devices to the TV. Supported external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. For more information on external device’s connection, refer to the manual provided with each device. NOTE yy If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input cable to the TV through a DVD recorder or VCR. For more information on recording, refer to the manual provided with the connected device. yy The external device connections shown may differ slightly from illustrations in this manual. yy Connect external devices to the TV regardless of the order of the TV port. yy If you connect a gaming device to the TV, use the cable supplied with the gaming device. yy Refer to the external equipment’s manual for operating instructions. Connecting to an antenna or cable Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations may differ from the actual items and a RF cable is optional. CAUTION yy Make sure not to bend the copper wire of the RF cable. Copper wire yy Complete all connections between devices, and then connect the power cord to the power outlet to prevent damage to your TV. NOTE yy Use a signal splitter to use more than 2 TVs. yy Visit http://lgknowledgebase.com for more information about the antenna and cable connection. Search for antenna. yy DTV Audio Supported Codec: MPEG, Dolby Digital ANTENNA/ CABLE IN VHF Antenna UHF Antenna Antenna Terminal Coaxial (75Ω) (*Not Provided) 19 ENG ENGLISH MAKING CONNECTIONS Connecting to a HD receiver, DVD Player or VCR Connect a HD receiver, DVD Player or VCR to the TV and select an appropriate input mode. HDMI Connection HDMI is the best way to connect a device. Transmits digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown in the following illustration. NOTE yy Use the latest High Speed HDMI™ Cable that supports CEC (Customer Electronics Control) function. yy High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher. yy HDMI Audio Supported Format: DTS, Dolby Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/88k/96k/176 k/192k) IN 3 (MHL) IN 2 (PC) HDMI 1 I N (ARC) (*Not Provided) DVD / Blu-Ray / HD Cable Box / HD STB Choose any HDMI IN input port to connect. It does not matter which port you use. ARC (Audio Return Channel) yy When connected with a high-speed HDMI cable, digital audio can be sent to a compactible device without an additional optical audio cable. yy ARC is only supported on the HDMI IN 1 (ARC) port. An external audio device that supports ARC should be connected to HDMI 1 if you wish to use ARC. 20 ENG ENGLISH MAKING CONNECTIONS DVI to HDMI Connection Transmits digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an audio cable. C OMPONENT IN L PB PR R Y VIDEO AUDIO R L/MONO AV IN AUDIO IN (PC) $8',2287 '9,287 IN 2 (PC) AUDIO (*Not Provided) (*Not Provided) DVD / Blu-Ray / HD Cable Box RED WHITE 21 ENG ENGLISH MAKING CONNECTIONS Connecting to a mobile phone Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from mobile phones to television sets. yy Connect the mobile phone to the HDMI IN 3 (MHL) port to view the phone screen on the TV. yy This only works for the MHL-enabled phone. yy With some MHL supporting mobile phones, you can use the TV remote to control the phone. yy The MHL passive cable is needed to connect the TV and a mobile phone. NOTE (*Not Provided) MHL Cable Mobile phone IN…

Text truncated - open the document above for the full version.

LG Electronics USA 1000 Sylvan AvenueEnglewood Cliffs, NJ 07632, United States TEL: 201-266-2534 FAX: 201-816-2003 EMCCert DR. RAŠEK GmbH Date: February 15, 2013 Stoernhofer Berg 15 91364 Unterleinleiter GERMANY This authorization is valid until further written notice from the applicant. Sincerely Yours, ________________________________________________ Jacob Cho/Director LG Electronics USA [email protected]

LG Electronics USA 1000 Sylvan AvenueEnglewood Cliffs, NJ 07632, United States TEL: 201-266-2534 FAX: 201-816-2003 EMCCert DR. RAŠEK GmbH Date: February 15, 2013 Stoernhofer Berg 15 91364 Unterleinleiter GERMANY Attention : Application Examiner / Reviewing Engineer Subject : Request for confidentiality per Section 0.459 of FCC Rules Applicant : LG Electronics USA. FCC ID : BEJ60PN5700UA To whom it may concern, Request is hereby submitted, LG Electronics USA. to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are requested to be kept confidential: Block Diagram Rationale for request for confidentiality: LG Electronics USA. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. If you have questions or need further information, please contact the undersigned. Sincerely Yours, ________________________________________________ Jacob Cho/Director LG Electronics USA [email protected]

FCC ID. : BEJ60PN5700UA Page 1 of 5 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 2 of 5 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 3 of 5 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 4 of 5 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 5 of 5 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904)

Page 1 of 1 Report No.: E132R-009 It should not be reproduced except in full, without the written approval of ONETECH. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Dept : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) IDENTIFICATION LABEL: PROPOSED FCC ID LABEL The FCC ID shall be permanently affixed to the back side of the equipment FCC ID AREA FCC ID : BEJ60PN5700UA

FCC ID. : BEJ60PN5700UA Page 1 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 2 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 3 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 4 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 5 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 6 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 7 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 8 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 9 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 10 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 11 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 12 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 13 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div. : 307-51 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-765-8289, FAX: 82-31-766-2904) FCC ID. : BEJ60PN5700UA Page 14 of 21 Report No. : E132R-009 It should not be reproduced except in full, without the written approval of ONETECH Corp. EMC-002 (Rev.2) HEAD OFFICE : 301-14 Daessangnyeong-ri, Chowol-eup, Gwangju-si, Gyeonggi-do 464-862 Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMC Testing Div…

Text truncated - open the document above for the full version.

30 ENG ENGLISH WATCHING TV yy To display images in the best quality for your home environment, select Home Use. yy Store Demo is suitable for the retail environment. yy If you select Store Demo, any customized settings will switch back to the default settings of Store Demo in 5 minutes. NOTE 4 When the basic settings are complete, press the Wheel (OK) button. yy If you do not complete the Initial setting, it will appear whenever the TV turns on. yy Disconnect the power cord from the power outlet when you do not use the TV for a long period of time. NOTE 5 To turn the TV off, press the power button on the remote control. WATCHING TV Turning the TV on for the first time When you turn the TV on for the first time, the Initial setting screen appears. Select a language and customize the basic settings. 1 Connect the power cord to a power outlet. 2 In Standby mode, press the power button on the remote control to turn the TV on. The Initial setting screen appears when you turn the TV on for the first time. yy You can also access Initial Setting by accessing OPTION in the main menu. NOTE 3 Follow the on-screen instructions to customize your TV settings according to your preferences. Language Selection Select a language to display.  Enviroment Selection Select Home for the home environment.  Picture Mode Setting Select Picture Mode to use as default. (Depending on country)  Time Zone Setting Select the time zone and daylight saving options. (Depending on country)  Network Connection Set your network to enable network-related features on the TV.  ZIP Code Input your Zip Code.  Wireless Touch Pen Setting Connect wireless touch pen dongle to the USB port of the TV.  Select TV Watching Type Select a type to watch TV.  Auto Tuning Scans and saves available channels automatically.  Setting is complete Confirms the setting options.  Experience Magic Remote Control Simple guide of Magic Remote Control (Depending on model) 31 ENG ENGLISH USING THE USER GUIDE USING THE USER GUIdE User Guide allows you to more easily access the detailed TV information . 1 Press the SMART() button to access the Smart Home menu . 2 Select User Guide and press the OK button . User Guide  To use input device To set time options To set language To set caption To set other options To set TV lock options User Guide Index View on the Internet OPTION PROGRAMME Setting PICTURE, SOUND Setting LG SMART Function Advanced Function Information 1 23 4 5 1 Shows the video you were watching. 2 Guide categories. 3 List of topics in the current category. You can use / button to move between pages. 4 An index of key words present in the User Guide. 5 Provides the detailed information on the functions of LG Smart TV when the Internet is connected. (It may not be available depending on the country/language.) OPTION > To set language SMART  Settings  OPTION  Language Selects Menu Language and Audio Language displayed on the screen. Menu Language Audio Language Selects a screen menu language. [In Digital Mode Only] When watching a digital broadcast containing several audio languages, you can select the language you want. Subtitle Language [In Digital mode Only] Use the Subtitle function when two or more subtitle languages are broadcast. ✎ If subtitle data in a selected language is not broadcast, the default language subtitle will be displayed. Try Now Close 1 2 1 Shows the description of the selected menu. You can use / to move between pages. 2 Moves to the selected menu directly from the User Guide. (Depending on country) 32 ENG ENGLISH SPECIFICATIONS SPECIFICATIONS Power requirementAC 100 - 240 V ~ 50 / 60 Hz Television SystemNTSC-M, ATSC, 64 & 256 QAM Program CoverageVHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135 External Antenna Impedance 75 Ω Environment condition Operating Temperature 0 - 40 °C Operating HumidityLess than 80 % Storage Temperature-20 - 60 °C Storage HumidityLess than 85 % Product specifications may be changed without prior notice due to upgrade of product functions. MODELS 60N5700 (60PN5700-UA) Dimensions (Width x Height x Depth) With stand 1,386.8 x 874 x 340 (mm) 54.5 x 34.4 x 13.3 (inch) Without stand1,386.8 x 821.7 x 57 (mm) 54.5 x 32.3 x 2.2 (inch) WeightWith stand37.7 Kg (83.1 lbs) Without stand34.5 Kg (76.0 lbs) Current Value / Power consumption3.9 A / 390 W 33 ENG ENGLISH SPECIFICATIONS HDMI/DVI-DTV supported mode Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 720x480 31.469 31.5 59.94 60 1280x720 44.96 45 59.94 60 1920x1080 33.72 33.75 26.97 27 33.716 33.75 67.43 67.5 59.94 60 23.97 24 29.976 30.00 59.94 60 Component port connecting information Component ports on the TV YP B P R Video output ports on DVD player YP B P R YB-YR-Y YCbCr YPbPr SignalComponent 480iO 480pO 720p/1080iO 1080p O (60 Hz only) Wireless LAN module (WN8122E1) specification Standard IEEE802.11a/b/g/n Frequency Range 2400 to 2483.5 MHz 5150 to 5250 MHz 5725 to 5850 MHz Output Power (Max.) 802.11a: 16.5 dBm 802.11b: 16 dBm 802.11g: 15.5 dBm 802.11n - 2.4GHz: 15.5 dBm 802.11n - 5GHz: 16.5 dBm yy Because band channel used by the country could be different, the user can not change or adjust the operating frequency and this product is set for the regional frequency table. yy Contains FCC ID: BEJWN8122E1 yy Contains IC: 2703H-WN8122E1
