BEJ9QK-CU1511Wireless Adapter Card

DO5303 Squeak 1.5 5.8GHz WHAM2 1CHARACTERISTICS AND SPECIFICATIONS 1.1ABSOLUTE MAXIMUM RATINGS All Min/Max characteristics and specifications are guaranteed over the specified operating conditions. Typical performance characteristics and specifications are derived from measurements taken at typical supply voltages. T A =25ºC. GND = 0 V, all voltages with respect to 0 V. Transmitter ParameterSymbol ValueUnitNote Input PowerVCC5.5V Digital Input Pin Absolute Maximum Input Voltage 3.63VIO Inputs are not 5 V Tolerant. Operating TemperatureTA50C Storage TemperatureTS90C Table 1 – HT-821/CU1511 Tx Module Absolute Maximum Ratings 1.2TRANSMITTER OPERATING CONDITIONS ParameterConditionsMinTypicalMaxUnit POWER CONSUMPTIONPOWER CONSUMPTION Input Power Supply (Vin)4.555.5V CurrentVin = 5.0 VTBDmA LOGIC THRESHOLDSLOGIC THRESHOLDS Input Low Voltage ThresholdVin = 5.0 V0.8V Input High Voltage ThresholdVin = 5.0 V2.0V Output Low Voltage ThresholdVin = 5.0 V0.4V Output High Voltage ThresholdVin = 5.0 V2.4V Input Leakage CurrentVin = 5.0 V-10± 110μA TEMPERATURETEMPERATURE Operating Temperature050C Storage Temperature-2090C Table 2 – HT-821/CU1511 Tx Module Operating Conditions DO5711 HT-821/CU1511 Transmit Module Datasheet LG2010 Wireless Audio Home Theatre Solution HT-821/CU1511 Tx Module Datasheet (version 1.1) 2009-12-03 Page 1 of 5 Copyright © 2009 Eleven Engineering Inc. (all rights reserved) DO5303 Squeak 1.5 5.8GHz WHAM2 1.3HT-821/CU1511 TX MODULE PIN DESCRIPTION Connector OptionsConnector OptionsConnector OptionsConnector Options Pin # Pin Function DescriptionTxRxTx + XPDRx + XPD 1SCK0XPD ClockNot UsedNot UsedXPD ClockXPD Clock 2MISO0XPD DATANot UsedNot UsedXPD DataXPD Data 3MOSI0XPD DATANot UsedNot UsedXPD DataXPD Data 4PB1XInC2 Chip SelectNot UsedNot UsedXInC2 Chip SelectXInC2 Chip Select 5PB0FLASH Chip SelectNot UsedNot UsedFLASH Chip SelectFLASH Chip Select 6VinUnregulated 5 V Input5 V Input5 V Input5 V Input5 V Input 7VinUnregulated 5 V Input5 V Input5 V Input5 V Input5 V Input 8GNDGroundGNDGNDGNDGND 9ResetSIP Reset 3.3 V MAXResetResetResetReset 10MCLKI2S Master ClockNot UsedOutput to PulsusNot UsedOutput to Pulsus 11GNDGroundGNDGNDGNDGND 12BCLKI2S BitClockInput from DVDOutput to PulsusInput from DVDOutput to Pulsus 13LRCKI2S LRCK Input from DVDOutput to PulsusInput from DVDOutput to Pulsus 14SDIO0I2S Data InputInput from DVDOutput to PulsusInput from DVDOutput to Pulsus 15SDIO1I2S Data InputInput from DVDOutput to PulsusInput from DVDOutput to Pulsus 16PC2GPIOI2S SCLI2S SCLI2S SCLI2S SCL 17PC3GPIOI2S SDAI2S SDAI2S SDAI2S SDA 18AN3Analog Input 1.8 V MAXNot UsedNode ConfigNot UsedNode Config 19PF1GPIONot UsedNot UsedNot UsedNot Used 20PI2GPIONot UsedSMPS Power ControlNot UsedSMPS Power Control 21PI1GPIONot UsedSMPS Power SenseNot UsedSMPS Power Sense 22PD2GPIONot UsedRed LEDNot UsedRed LED 23PD3GPIONot UsedBlue LEDNot UsedBlue LED 24PD5GPIONot UsedPulsus ResetNot UsedPulsus Reset 25PD1GPIONot UsedTAS Power DownNot UsedTAS Power Down 26PD0GPIONot UsedTAS OTWNot UsedTAS OTW 27GNDGroundNot UsedGNDNot UsedGND 28GNDGroundNot UsedGNDNot UsedGND Table 3 – HT-821/CU1511 Tx Module Pinout DO5711 HT-821/CU1511 Transmit Module Datasheet LG2010 Wireless Audio Home Theatre Solution HT-821/CU1511 Tx Module Datasheet (version 1.1) 2009-12-03 Page 2 of 5 Copyright © 2009 Eleven Engineering Inc. (all rights reserved) DO5303 Squeak 1.5 5.8GHz WHAM2 1.4RF CHARACTERISTICS AND BEHAVIOR The HT-821/CU1511 Transmit module RF characteristics are described below paying special attention to include information pertinent to FCC and ETSI regulations. Module firmware operates by selecting a palette (or group) of random channels out of the total 37. Any channels with poor transmission rates are replaced with better channels from the remaining unused channels. The switching pattern from channel to channel is a random pattern. The table below describes some important aspects of the channel-hopping algorithm: ParameterConditionsMinTypicalMaxUnit RF CHARACTERISTICSRF CHARACTERISTICS Transmission MethodARQ with Adaptive FHSSARQ with Adaptive FHSSARQ with Adaptive FHSS Raw Data Rate1.536Mbps Channel Width<2MHz Total Channels37Ch Hopping Channels8Ch RF Coexistence In Specified Radius4sets TX Output PowerPreliminary81114dBm DETAILED BANDWIDTH CHARACTERISTICSDETAILED BANDWIDTH CHARACTERISTICSDETAILED BANDWIDTH CHARACTERISTICSDETAILED BANDWIDTH CHARACTERISTICSDETAILED BANDWIDTH CHARACTERISTICSDETAILED BANDWIDTH CHARACTERISTICS Hopping Rate187.5Hz Frequency Dwell Time5.333ms Audio TX: RF Transmit TimeTx Node4.594ms Audio RX: RF Transmit TimePer Each Rx Node0.219ms Frequency Range5.7255.825GHz Frequency Range (Total)78.057MHz 20 dB Channel BW1.94MHz RF RANGERF RANGERF RANGERF RANGERF RANGERF RANGE Indoor Range (Note 1)15m Open Field Range (Note 2)200m Table 4 – RF Characteristics Notes: 1.Typical home/office environment (estimated) 2.Estimated open field line of sight testing results. DO5711 HT-821/CU1511 Transmit Module Datasheet LG2010 Wireless Audio Home Theatre Solution HT-821/CU1511 Tx Module Datasheet (version 1.1) 2009-12-03 Page 3 of 5 Copyright © 2009 Eleven Engineering Inc. (all rights reserved) DO5303 Squeak 1.5 5.8GHz WHAM2 2PACKAGE DIMENSIONS CO2 PAC101 PAC102 COC1 PAC202PAC201 COC2 PAC301PAC302 COC3 PAC401 PAC402 COC4 PAC502 PAC501 COC5 PAC602 PAC601 COC6 PAC701 PAC702 COC7 PAC802PAC801 COC8 PAC901PAC902 COC9 PAC1002PAC1001 COC10 PAC1102PAC1101 COC11 PAC1201 PAC1202 COC12 PAC1301 PAC1302 COC13 PAC1402 PAC1401 COC14 PAC1502 PAC1501 COC15 PAC1702PAC1701 COC17 PAC1802 PAC1801 COC18 PAC1901PAC1902COC19 PAC2002 PAC2001 COC20 PAC2102 PAC2101 COC21 PAC2202 PAC2201 COC22 PAC2302 PAC2301 COC23 PAC2401PAC2402 COC24 PAC2502 PAC2501 COC25 PAC2602 PAC2601 COC26 PAC2702 PAC2701 COC27 PAC2802 PAC2801 COC28 PAC2902 PAC2901 COC29 PAC3002 PAC3001 COC30 PAC3102 PAC3101 COC31 PAC3202 PAC3201 COC32 PAC3302 PAC3301 COC33 PAC3402PAC3401COC34 PAC3502PAC3501 COC35 PAC3602PAC3601 COC36 PAC3701 PAC3702 COC37 PAC3801 PAC3802 COC38 PAC3901PAC3902COC39…
