BEJA133Cellular/PCS GSM Phone with Bluetooth

LG-A133 User Guide — English This guide will help you understand your new mobile phone. It will provide you with useful explanations of features on your phone. Some of the contents in this manual may differ from your phone depending on the software of the phone or your service provider. Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. 2 Getting to know your phone Call key Dials a phone number and answers incoming calls. Main screen Soft keys Each of these keys performs the functions indicated by the text on the display immediately above them. OK key Selects menu options and confirms actions. Music key Go to Music function directly. Navigation keys Use for quick access to phone functions. Camera key Go to Camera function directly. End/Power key Ends or rejects a call. Turns the phone on/off. Returns to the home screen when you use the menu. 3 Installing a memory card Lift the memory card cover and insert a micro SD card with the golden contact area facing downwards. Close the memory card cover so that it clicks shut. To remove the memory card, gently push it as shown in the diagram. Note: A memory card is an optional accessory. Formatting the memory card From your home screen, press Menu and select Settings. Choose Memory Info, select External memory and press Format, and insert security code. WARNING: When you format your memory card, all the content will be wiped. If you do not want to lose the data on your memory card, back it up fi rst. Headset / Charger / USB Cable connector Volume key Memory card slot 4 Installing the SIM Card and Charging the Battery Installing the SIM Card When you subscribe to a cellular network, you are provided with a SIM card loaded with your subscription details, such as your PIN, any optional services available and many others. Important! › The SIM card can be easily damaged by scratches or bending, so be careful when handling, inserting or removing the card. Keep all SIM cards out of the reach of small children. Illustrations 1 Open battery cover 2 Remove the battery 3 Insert your SIM 4 Insert your battery 5 Close the battery cover 6 Charge your battery WARNING: Do not remove the battery when the phone is switched on, as this may damage the phone. 5 Menu map 1. Messaging 1.1 Create message 1.2 Inbox 1.3 My mailbox 1.4 Drafts 1.5 Outbox 1.6 Sent items 1.7 Saved items 1.8 Emoticons 1.9 Message settings 2. Contacts 2.1 Names 2.2 Settings 2.3 Groups 2.4 Speed dials 2.5 Service dial numbers 2.6 Own number 2.7 My business card 3. Call log 3.1 Call log 3.2 Missed calls 3.3 Received calls 3.4 Dialled numbers 3.5 Call duration 3.6 Packet data counter 3.7 Call costs 4. Settings 4.1 Profi les 4.2 Display 4.3 Date and time 4.4 Connectivity 4.5 Call 4.6 Phone 4.7 Network 4.8 Internet profi les 4.9 Access points 4.10 Packet data conn. 4.11 Security 4.12 Memory info. 4.13 Restore factory settings 5. Gallery 5.1 My memory card 5.2 My images 5.3 My sounds 5.4 My videos 5.5 My games & apps 5.6 Others 6 Menu map 6. Media 6.1 Camera 6.2 Video 6.3 Music 6.4 FM radio 6.5 Voice recorder 6.6 Ringtone creator 7. Organiser 7.1 Alarm clock 7.2 Calendar 7.3 To-do list 7.4 Notes 7.5 Secret notes 7.6 Cash Book 7.7 BMI Calculator 7.8 Calculator 7.9 Stopwatch 7.10 Date fi nder 7.11 Converter 7.12 World time 7.13 Go to 7.14 SIM Services 7.15 Settings 8. Applications 8.1 My games & apps 8.2 Settings 9. Web 9.1 Home 9.2 Bookmarks 9.3 Last web address 9.4 Settings 9.5 Go to address 9.6 Saved pages 7 Calls Making a call 1 Key in the number using the keypad. To delete a digit press CLR. 2 Press to initiate the call. 3 To end the call, press . TIP! To enter + when making an international call, press and hold 0. TIP! To control the volume during a call, press volume key. Making a call from your contacts 1 Select Names from the home screen. 2 Using the keypad, enter the first letter of the contact you want to call. For example, for Office, Press 6 three times to select the first character, “O”. 3 Select Make call from Options or press to initiate the call. Answering and rejecting a call When your phone rings, p…

Text truncated - open the document above for the full version.

Date: March 22, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Lab Manager Jim. Kim and of SGS Testing Korea Co., Ltd and hereafter referred to as SGS Testing Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Jim. Kim of SGS Testing Korea Co., Ltd on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Testing Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jae Cheon(J.C.) Lee General Manager LG Electronics USA

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: May 11, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJA133 Eq uipment Class: JBP: Part 15 Class B Computing Device Peripheral To Who m It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

Test Report No. : F690501/RF-EMG003287 Page : 12 of 17 3. Photographs of EUT  Front View  Rear View

Model No: LG-A133 FCC ID : BEJA133 S/N : Made in Korea LG Electronics Inc. LGE

Test Report No. : F690501/RF-EMG003287 Page : 13 of 17  Top View of Main Board  Bottom View of Main Board Test Report No. : F690501/RF-EMG003287 Page : 14 of 17  Top View of LCD Panel  Bottom View of LCD Panel Test Report No. : F690501/RF-EMG003287 Page : 15 of 17  Top View of Battery  Bottom View of Battery Test Report No. : F690501/RF-EMG003287 Page : 16 of 17  Camera Module  Inside

Test Report No. : F690501/RF-EMG003287 Page : 2 of 17 Contents 1. General Information...................................................................................................3 1.1 Client Information................................................................................................3 1.2 Test Laboratory...................................................................................................3 1.3 General Information of E.U.T. .............................................................................3 1.4 Operating Modes and Conditions........................................................................3 1.5 Peripheral Equipments........................................................................................3 1.6 Cable List ............................................................................................................4 1.7 System Configurations ........................................................................................4 1.8 Test System Layout ............................................................................................4 1.9 Applicable Standards for Testing ........................................................................5 1.10 Summary of Test Results..................................................................................5 2. Emission Test............................................................................................................6 2.1 Test Results ........................................................................................................6 2.2 Test Equipments .................................................................................................6 2.3 Test Site..............................................................................................................6 2.4 Conducted Emission Test Data...........................................................................6 2.5 Radiated Emission Test Data..............................................................................8 2.6 Modifications.......................................................................................................8 2.7 Photograph of Conducted Emission....................................................................9 2.8 Photographs of Radiated Emission (Below 1GHz)............................................10 2.9 Photographs of Radiated Emission (Above 1GHz) ...........................................11 3. Photographs of EUT ................................................................................................12 Appendix A : Conducted Emission ..............................................................................17 Test Report No. : F690501/RF-EMG003287 Page : 3 of 17 1. General Information 1.1 Client Information Applicant : LG Electronics Inc. Address of Applicant : 60-39, Gasan-dong, Gumchon-gu, Seoul, 153-023, Korea Manufacturer : LG Electronics Inc. Address of Manufacturer : 60-39, Gasan-dong, Gumchon-gu, Seoul, 153-023, Korea 1.2 Test Laboratory Name and Address : SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo, Gyeonggi-do, Korea 435-041 1.3 General Information of E.U.T. Product Name : Cellular/PCS GSM Phone with Bluetooth Model Name : LG-A133 Alt. Mode Name : A133 Model Difference : Only model name is different. Serial No. : 003KPSL0738334 Highest Internal Frequency : Max. 208 MHz Test Voltage : AC 120V, 60Hz 1.4 Operating Modes and Conditions Operating mode Operating condition USB Mode USB Data Communication 1.5 Peripheral Equipments Description Model Serial No. Manufacturer Notebook Computer PCG-3AHP 28272287 7000053Sony Corporation LCD Monitor CR22KS N843H1KP902165L Samsung Electronics USB Keyboard KU-0459 7691402003981 Microsoft USB MOUSE Basic Optical Mouse 1.0A USB/PS2 Compatible N/A MICROSOFT CORPORATION Micro SD Card Mobile Ultra 2GBN/A SanDisk Test Report No. : F690501/RF-EMG003287 Page : 4 of 17 1.6 Cable List Start END Cable Spec. Name I/O PortName I/O PortLength Shield USB Notebook Computer USB 1.2 Shielded Cellular/PCS GSM Phone with Bluetooth MicroSD Micro SD Card - - - DC IN AC AdapterDC OUT1.8 Unshielded RGB LCD Monitor RGB 1.8 Shielded USB USB Keyboard - 2.0 Shielded Notebook Computer USB USB Mouse- 1.8 Shielded AC Adapter AC IN AC Source- 1.0 Unshielded 1.7 System Configurations 1.8 Test System Layout Description Model Serial No. Manufacturer Battery LGIP-430N DC100314 LG Main Board A130-MAIN(2) SPFY0220301-C N/A LCD PANEL N/A N/A N/A Camera Module N/A N/A N/A AC Adapter Notebook Computer Cellular/PCS GSM Phone with Bluetooth Micro SD Card LCD Monitor USB Mouse USB Keyboard Test Report No. : F690501/RF-EMG003287 Page : 5 of 17 1.9 Applicable Standards for Testing 1.10 Summary of Test Results Test Item Standards Results Conducted Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied Radiated Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied Standards Status Deviation FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Applicable No Deviation Test Report No. : F690501/RF-EMG003287 Page : 6 of 17 EMISSION 2. Emission Test 2.1 Test Results Test Items Standards Test Results Conducted Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied Radiated Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied 2.2 Test Equipments Equipment Model Manufacturer Last Cal. Date Two-Line V-Network ENV216 R&S 2010.01.06 Test Receiver ESHS10 R&S 2009.07.13 LISN L3-25 PMM 2009.07.02 Test Receiver ESU26 R&S 2010.04.08 Amplifier 8447F HP 2009.07.02 Bi-Log Antenna VULB9163 SCHWARZBECK MESS- ELEKTRONIK 2009.07.22 Preamplifier 8449B Agilent 2010.03.31 Horn Antenna HF906 R&S 2009.10.08 Note : Only the calibration period of Antennas is 2 years but the period of every equipment is 1 year. 2.3 Test Site Conducted Emission: Shield Room in Gunpo Laboratory Radiated Emission: 3m Semi-Anechoic chamber in Gunpo Laboratory 2.…

Text truncated - open the document above for the full version.

Test Report No. : F690501/RF-EMG003287 Page : 9 of 17 2.7 Photograph of Conducted Emission Test Report No. : F690501/RF-EMG003287 Page : 10 of 17 2.8 Photographs of Radiated Emission (Below 1GHz) Test Report No. : F690501/RF-EMG003287 Page : 11 of 17 2.9 Photographs of Radiated Emission (Above 1GHz)
