BEJA180ACellular/PCS GSM Phone

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Jan 16, 2011
Application Purpose: Original Equipment
Date of Application: Jan 16, 2011
Equipment Note: Cellular/PCS GSM Phone
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Part 15.21 statement Part 15.105 statement - Part 15 Class B Compliance Body-worn Operation HIZMGI

Cover Letter(s)

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: January 3, 2011 Fe dera l Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Ro ad, Columbia, MD 21046 RE: Request of Confid entiality for FCC ID: BEJA180A Equipment Class: JBP: Pa rt 15 Class B Computing Device Peripheral To Whom It May Concern: Pursuant to S ections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

External Photos

ID Label/Location Info

Model No: LG-A180a FCC ID : BEJA180A S/N : Made in Korea LG Electronics Inc. LGE

Internal Photos

FCCID: BEJA180A Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 1 FCCID: BEJA180A Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 2 FCCID: BEJA180A Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 3 FCCID: BEJA180A Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 4 FCCID: BEJA180A Copyright Ⓒ 2011, Digital EMC Co., Ltd. View 5

Test Report

DEMC#DREFCC1101-0045 (1012-01328) TRF-EM-003(00)081218 Copyright ○ c 2011, DIGITAL EMC CO., LTD. Page 2 of 13 CONTENTS 1. General Remarks........................................................................................................................ 3 2. Test Laboratory........................................................................................................................... 3 3. General Information of EUT....................................................................................................... 4 3.1 Product Description............................................................................................................... 4 3.2 Product Information............................................................................................................... 4 4. Test Summary............................................................................................................................. 5 4.1 Summary of tests .................................................................................................................. 5 5. Test Set-up and operation mode............................................................................................... 5 5.1 Principle of Configuration Selection ...................................................................................... 5 5.2 Test Operation Mode ............................................................................................................. 5 5.3 Support Equipment Used ......................................................................................................5 6. Test Results : Emission.............................................................................................................. 5 6.1 Conducted Emission ............................................................................................................. 5 6.2 Radiated Emission ................................................................................................................ 5 DEMC#DREFCC1101-0045 (1012-01328) TRF-EM-003(00)081218 Copyright ○ c 2011, DIGITAL EMC CO., LTD. Page 3 of 13 1. General Remarks This Report describes the emission characteristics of the tested product. If the product will be used with additional equipment other than those mentioned in this report or if the tested product will be used against the manufacture's specifications, the compliance with the relevant standards for the system has to be ensured. 2. Test Laboratory Digital EMC Co., Ltd. has been accredited / filed / authorized by the agencies listed in the following table; Certificate Nation Agency Code Mark Accreditation Korea KOLAS 393 ISO/IEC 17025 USA FCC 101842 Test Facility list & NSA Data Site Filing Japan VCCI C-1427 R-1364, R-3385 T-1442 Test Facility list & NSA Data Korea KCC KR0034 Test Facility list & NSA Data Certification Germany TUV ROK0924C ISO/IEC 17025 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. DIGITAL EMC CO., LTD. Address: 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 http://www.digitalemc.com Tel: +82-31-321-2664 Fax: +82-31-321-1664 DEMC#DREFCC1101-0045 (1012-01328) TRF-EM-003(00)081218 Copyright ○ c 2011, DIGITAL EMC CO., LTD. Page 4 of 13 3. General Information of EUT 3.1 Product Description Equipment Under Test (E.U.T) is Cellular/PCS GSM Phone Model: LG-A180a manufactured by LG Electronics Inc. Its basic purpose is used for communications. 3.2 Product Information Model No. LG-A180a Add Model No. A180a EUT Type Cellular/PCS GSM Phone Serial No NONE FCC ID BEJA180A Type of Sample Tested Pre-Production High Frequency 26MHz Supplied Power for Test AC120V, 60Hz Applicant LG Electronics Inc. 60-39, Gasan-dong, Gumchon-gu, Seoul, 153-023, Korea TX Frequency 824.20 MHz to 848.80 MHz (GSM850) 1850.20 MHz to 1909.80 MHz (GSM1900) RX Frequency 869.20 MHz to 893.80 MHz (GSM850) 1930.20 MHz to 1989.80 MHz (GSM1900) Date of Receipt of Sample 2010-12-02 Related Submittal(s) / Grant(s) Original submittal only. DEMC#DREFCC1101-0045 (1012-01328) TRF-EM-003(00)081218 Copyright ○ c 2011, DIGITAL EMC CO., LTD. Page 5 of 13 4. Test Summary 4.1 Summary of tests The applied standards to evaluate the compliance of requirements is 47CFR Part 15, Subpart B and the measurement procedures specified in ANSI C63.4 are performed. Test Items Applied Standards Status Emission Conducted Emission FCC Part 15 Subpart B C Radiated Emission FCC Part 15 Subpart B C Note 1: C=Conform NC=Not Conform NT=Not Tested NA=Not Applicable DEMC#DREFCC1101-0045 (1012-01328) TRF-EM-003(00)081218 Copyright ○ c 2011, DIGITAL EMC CO., LTD. Page 6 of 13 5. Test Set-up and operation mode 5.1 Principle of Configuration Selection Emission : The equipment under test (EUT) was configured to measure its highest possible radiation level. The test modes were adapted accordingly in reference to the instructions for use. 5.2 Test Operation Mode - PC link mode(Charging mode) 5.3 Support Equipment Used CABLE Unit Model No. Serial No. Manufacturer Connect type Length (m) shield BackshellFCC ID NOTE PC LGX14 F022040 LG USB DC POWER USB 1.0 1.6 1.4 Shield Shield Shield Plastic Plastic Plastic DOC MOUSE MS111-L 44751-091- 0K7V DELL. USB 1.4 Shield Plastic DOC ADAPTER ADP-40PH 6T1094 DELTA ELECTRONICS,INC. AC POWER1.2 Shield Plastic - EARMIC N/A N/A I-SOUND Stereo 1.2 Shield Plastic - (Configuration of Tested System) DEMC#DREFCC1101-0045 (1012-01328) TRF-EM-003(00)081218 Copyright ○ c 2011, DIGITAL EMC CO., LTD. Page 7 of 13 6. Test Results : Emission 6.1 Conducted Emission RESULT : COMPLY 6.1.1 Measurement Procedure In the range of 0.15MHz to 30MHz, the conducted emission was measured and set-up was made accordance with ANSI C63.4:2003. If the EUT is table top equipment, it was placed on a wooden table with a height of 0.8m above the reference ground plane and 0.4m from the conducting wall of the …

Text truncated - open the document above for the full version.

Test Setup Photos
