BEJAN110BJDDLP Projector

P/NO : 3828VA0577A a AN110B-JDAN110W-JD OWNER’S MANUAL LG DLP PROJECTOR LG DLP PROJECTOR Please read this manual carefully before operatingyour set. Retain it for future reference.Record model number and serial number of the setbelow.See the label attached on the bottom of the set andquote this information to your dealer if you requireservice.Model number : Serial number : DLP PROJECTOR DLP PROJECTOR FCC NOTICE • A Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. • Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Warning This is a class B product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures. Contents 3 Contents Introduction Safety Instructions ..........................................4 Part Descriptions Main Body .......................................................7 Control Panel ..................................................8 Remote Control ...............................................9 Installing Batteries...........................................9 Projector Status Indicators ..............................10 Accessories.....................................................11 Optional Extras ...............................................11 Installing and Composition Installation Instructions ...................................12 Basic Operation of the Projector.....................13 Installing the projector to the wall ...................14 Turning on the Projector .................................20 Turning off the Projector .................................20 Selecting source mode ...................................20 Focus, Zoom, Position of the Screen Image ..21 Connection Connecting to a Desktop PC ..........................22 Connecting to a Notebook PC ........................22 Connecting to a Video Source ........................23 Connecting to a DVD ......................................23 Connecting to a D-TV Set-Top Box ................24 HDMI ...............................................................25 Function Video Menu Options Adjusting Video ...............................................26 APC (Auto Picture Control) .............................26 Auto Color Temperature Control .....................27 Gamma Function ............................................27 White peaking Function ..................................28 Color Temperature Control..............................28 Color enhancement Control ............................28 Special Menu Options Selecting Language ........................................29 Using ARC Function........................................29 Flip horizontal Function...................................30 XD Demo ........................................................30 Auto sleep Function ........................................30 Using Keystone function .................................31 Using Blank function .......................................31 Selecting Blank image color ...........................32 Lamp mode Function ......................................32 Checking Lamp time .......................................32 Tilt function ......................................................33 Using Still function ..........................................33 Screen Menu Options Auto configure Function ..................................34 Manual configure ............................................34 Using ZOOM function .....................................35 Screen Position ...............................................35 RS-232C External Control Device Setup........................36 Information Supported Monitor Display..............................41 Maintenance....................................................42 Replacing the Lamp ........................................43 Memo ..............................................................45 Specifications ..................................................47 Disposal of your old appliance 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. 3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. 4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. Safety Instructions 4 Safety Instructions Please take note of the safety instructions to prevent any potential accident or misuse of the projector. ➟Safety Instructions are given in two forms as detailed below. WARNING: The violat…

Text truncated - open the document above for the full version.

FCC ID : BEJAN110BJD POWER OF ATTORNEY To whom it may concern: We the undersigned LG Electronics Inc. hereby authorize ESTECH Co., Ltd.(EST) of Korea to act on our behalf in all matters relating to all processes required in the FCC Part 15C approval and any communication needed with the national authority. Any and all acts carried out by EST on our behalf shall have the same effects as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, Sign: Sang-Wook Lee/Manager Engineer Tel:82-54-470-5639

LG Electronics Inc. 642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-360,Korea TEL : +82-54-470-5639 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJAN110BJD Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Sang-Wook Lee/ Manager Engineer LG Electronics Inc. TEL : +82-54-470-5639 FAX : 82-54-470-4534

1. FRONT 2. REAR 3. INSIDE 4. PORT

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. POWER 2.1 Front 2.2 Rear 3. POWER SUB 3.1 Front 3.2 Rear 4.DC DC CONVERTER 4.1 Front 4.2 Rear 5. DLP 5.1 Front 5.2 Rear

LG Electronics Inc. FCC ID BEJAN110BJD -Operational description-

Compliance Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - AN110B-JD and AN110W-JD are same product,only model name is different. - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned Report Number : ESTF150601-005 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150601-005 Manufacturer Country of origin Applicant Product 16-Jan-06 DLP Projector AN110B-JD,AN110W-JD NONE LG Electronics Inc. KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2005 , ANSI C 63.4 2003 2006-01-10 ~ 2006-01-16 OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 201-266-2420 Measurement facility registration number Engineer J.H.Kim Manager Engineer J.M.Yang 94696 (Signature) (Signature) 3 4 5 6 8 8 8 9-1 9-2 10 10 10 11 12 14 Appendix 1. Spectral diagram Appendix 2. Phorographs of EUT in side PCB Appendix 3. Block diagram of EUT Appendix 4. Circuit Diagram Report Number : ESTF150601-005 , Web : www. estech. co. kr Page 2 of 14 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.4 Test data(2) .......................................................................................... 5.3 Test data(1) .......................................................................................... 7. Photogra phs of test setup ........................................................................... 8. Photogra phs of EUT .................................................................................... 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150601-005 , Web : www. estech. co. kr Page 3 of 14 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : AN110B-JD,AN110W-JD Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 2.2 General descriptions of EUT Using Freq. : 48MHz, 14.31818MHz(2EA), 100MHz Report Number : ESTF150601-005 , Web : www. estech. co. kr Page 4 of 14 DLP Projector NONE LG Electronics Inc. KOREA INPUT:AC120V / 60Hz 2006-01-10 3. Test Standards Test Standard : FCC PART 15 (2005) Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150601-005 , Web : www. estech. co. kr Page 5 of 14 4. Measurement Condition 4.1 EUT Operation. 4.2 Confi…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
