BEJAX830Cellular/PCS CDMA Phone with Bluetooth

- 1 - User Manual AX830 Ver. 1.1 2007. 07. 09 Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. " Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. if this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help. LIMITED WARRANTY STATEMENT 1. WHAT THIS WARRANTY COVERS: LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and conditions: (1) The limited warranty for the product extends for ONE (1) year beginning on the data of purchase of the product. (2) The limited warranty extends on to the original purchaser of the product and is not assignable or transferable to any subsequent purchaser/end user. (3) This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the U.S., including Alaska, Hawaii, U.S. Territories and Canada. (4) The external housing and cosmetic parts shall not be covered under these limited warranty terms. (5) Upon request from LG, the consumer must provide information to reasonably prove the date of purchase. (6) The customer shall bear the cost of shipping the product to the Customer Service Department of LG. LG shall bear the cost of shipping the product back to the consumer after the completion of service under this limited warranty. 2. WHAT THIS WARRANTY DOES NOT COVER: (1) Defects or damages resulting from use of the product in other than its normal and customary manner. (2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair, misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused by shipping blown fuses spills of food or liquid. (3) Breakage or damage to antennas unless caused directly by defects in material or workmanship. (4) That the Customer Service Department at LG was net notified by consumer of the alleged defect or malfunction of the product during the applicable limited warranty period. (5) Products which have had the serial number removed or made illegible. (6) The limited warranty is in lieu of all other warranties, express or implied either in fact or by operations law, statutory or otherwise, including, but limited to any implied warranty of marketability or fitness for a particular use. (7) Damage resulting from use of non-LG approved accessories. (8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to normal customer use. (9) Products operated outside published maximum ratings. 3 (10) Products used or obtained in a rental program. (11) Consumables (such as fuses). 3. STATE LAW RIGHTS: No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, RISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of imitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 4. HOW TO GET WARRANTY SERVICE: To obtain warranty service, please call the following web address: www.lgeservice.com 8 For Your Safety Important Information This user guide contains important information on the use and operation of this phone. Please read all the information carefully for optimal performance and to prevent any damage to or misuse of the phone. Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Before You Start Safety Instructions WARNING!To reduce the possibility of electric shock, do not expose your phone to high humidity areas, such as the bathroom, swimming pool, etc. Always store your phone away from heat.Never store your phone in settings that may expose it to temperatures less than 32°F or greater than 104°F, such as outside during extreme weather conditions or in your car on a hot day. Exposure to excessive cold or heat will result in malfunction, damage and/or catastrophic failure. Be careful when using your phone near other electronic devices.RF emissions from your mobile phone may affect nearby in adequately shielded electronic equipment. You should consult with manufacturers of any personal medical devices such as pacemakers and hearing aides t…

Text truncated - open the document above for the full version.

LG Electronics Inc. 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: NOVEMBER 12, 2007 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJAX830 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Manager Mobile Handset R&D Center Mobile Communications Company LG Electronics Inc.

November 12, 2007 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 SUBJECT: LG Electronics Inc. FCC ID: BEJAX830 Part 20.19 Certification Gentlemen: We, LG Electronics, hereby declare the samples evaluated in this application are equivalent to production samples. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, E.S.Park Manager Mobile Handset R&D Center Mobile Communication Company LG Electronics Inc. Tel : 82-2-2033-1110 Fax : 82-2-2033-1222 [email protected] 60-39, Gasan-dong, Gumchon-gu Seoul 153-801, Korea LG Electronics Inc. LGE

Reviewed by: FCC ID: BEJAX830 FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0709121016.BEJ November 15 - 16, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 1 of 5 © 2007 PCTEST Engineering Laboratory, Inc. REV 7.1C 10/23/07 EXTERNAL PHOTOGRAPHS Reviewed by: FCC ID: BEJAX830 FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0709121016.BEJ November 15 - 16, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 2 of 5 © 2007 PCTEST Engineering Laboratory, Inc. REV 7.1C 10/23/07 Reviewed by: FCC ID: BEJAX830 FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0709121016.BEJ November 15 - 16, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 3 of 5 © 2007 PCTEST Engineering Laboratory, Inc. REV 7.1C 10/23/07 Reviewed by: FCC ID: BEJAX830 FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0709121016.BEJ November 15 - 16, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 4 of 5 © 2007 PCTEST Engineering Laboratory, Inc. REV 7.1C 10/23/07 Reviewed by: FCC ID: BEJAX830 FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0709121016.BEJ November 15 - 16, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 5 of 5 © 2007 PCTEST Engineering Laboratory, Inc. REV 7.1C 10/23/07

LG Electronics Inc. LGE Model No: AX830 FCC ID : BEJ AX830 S/N :Made in Korea Note: The FCC ID label shown will be r eadily visible at the time of purchase. ※ FCC ID label form

LG FCC ID: BEJAX830 EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with Bluetooth and EvDO Model: AX830 LG FCC ID: BEJAX830 EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with Bluetooth and EvDO Model: AX830 LG FCC ID: BEJAX830 EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with Bluetooth and EvDO Model: AX830 LG FCC ID: BEJAX830 EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with Bluetooth and EvDO Model: AX830 LG FCC ID: BEJAX830 EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with Bluetooth and EvDO Model: AX830 LG FCC ID: BEJAX830 EUT Photographs © 2007 PCTEST Lab. Cellular/PCS CDMA Phone with Bluetooth and EvDO Model: AX830

Reviewed by: FCC ID:BEJAX830CERTIFICATION REPORT Quality Manager SAR Filename:Test Dates:EUT Type: 0709121017.BEJ11/08/07 - 11/12/07Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 1 o f 25 © 2007 PCTEST Engineering Laboratory, Inc.REV 4.6C 10/25/07 Applicant Name:Date of Testing: LG Electronics USA11/08/07 - 11/12/07 1000 Sylvan AvenueTest Site/Location: Englewood Cliffs, NJ 07632PCTEST Lab, Columbia, MD, USA United StatesTest Report Serial No.: 0709121017.BEJ FCC ID:BEJAX830 APPLICANT:LG ELECTRONICS USA EUT Type:Cellular/PCS CDMA Phone with Bluetooth and EvDO Application Type:Certification FCC Rule Part(s):§2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] FCC Classification:Licensed Transmitter Held to Ear (PCE) Model(s):AX830 Additional Model(s)CX830, UX830, LG830 Tx Frequency:824.70 - 848.31 MHz (Cellular CDMA) 1851.25 - 1908.75 MHz (PCS CDMA) Conducted Power:24.78 dBm Cellular CDMA 24.61 dBm PCS CDMA Max. SAR Measurement:0.746 W/kg CDMA Head SAR 0.364 W/kg CDMA Body SAR 1.03 W/kg PCS Head SAR 0.209 W/kg PCS Body SAR EUT Serial No.:Pre-Production[S/N: A0000003A2E401] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std.C95.1-2005 and has been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003 and in applicable Industry Canada Radio Standards Specifications (RSS) . I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions:Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 2.0 cm between the back of the unit and the body of the user. End-users must be informed of the body -worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not specified in this filing may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: FCC ID:BEJAX830CERTIFICATION REPORT Quality Manager SAR Filename:Test Dates:EUT Type: 0709121017.BEJ11/08/07 - 11/12/07Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 2 o f 25 © 2007 PCTEST Engineering Laboratory, Inc.REV 4.6C 10/25/07 TABLE OF CONTENTS 1INTRODUCTION....................................................................................................................3 2TEST SITE LOCATION...........................................................................................................4 3SAR MEASUREMENT SETUP................................................................................................5 4DASY E-FIELD PROBE SYSTEM............................................................................................7 5PROBE CALIBRATION PROCESS..........................................................................................8 6PHANTOM AND EQUIVALE NT TISSUES................................................................................9 7DOSIMETRIC ASSESSMENT & PHANTOM SPECS..............................................................10 8DEFINITION OF REFERENCE POINTS................................................................................11 9TEST CONFIGURATION POSITIONS...................................................................................12 10RF EXPOSURE LIMITS........................................................................................................14 11MEASUREMENT UNCERTAINTIES......................................................................................15 12SYSTEM VERIFICATION......................................................................................................16 13FCC 3G MEASUREMENT PROCEDURES............................................................................17 14SAR DATA SUMMARY.........................................................................................................19 15EQUIPMENT LIST................................................................................................................22 16CONCLUSION.....................................................................................................................23 17REFERENCES.....................................................................................................................24 Reviewed by: FCC ID:BEJAX830CERTIFICATION REPORT Quality Manager SAR Filename:Test Dates:EUT Type: 0709121017.BEJ11/08/07 - 11/12/07Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 3 o f 25 © 2007 PCTEST Engineering Laboratory, Inc.REV 4.6C 10/25/07 1INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSIC95.1-2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz[2]and Health Canada RF Exposure Guidelines Safety Code 6 [26]. The measurement procedure described in IEEE/ANSI C95. 3-200 2 Recommended Practice for the Measurement of Potentia…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: BEJAX830 FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0709121016.BEJ November 15 - 16, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 1 of 35 © 2007 PCTEST Engineering Laboratory, Inc. REV 7.1C 10/23/07 Applicant Name: Date of Testing: LG Electronics USA November 15 - 16, 2007 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab., Columbia, MD, USA United States Test Report Serial No.: 0709121016.BEJ FCC ID: BEJAX830 APPLICANT: LG ELECTRONICS USA Application Type: Certification FCC Classification: PCS Licensed Transmitter Held to Ear (PCE) FCC Rule Part(s): §2; §22(H), §24(E) EUT Type: Cellular/PCS CDMA Phone with Bluetooth and EvDO Model(s): AX830, CX830, UX830, LG830 Tx Frequency Range: 824.70 - 848.31MHz (Cell. CDMA) / 1851.25 - 1908.75MHz (PCS CDMA) Max. RF Output Power: 0.204 W ERP Cell. CDMA (23.09 dBm) 0.237 W EIRP PCS CDMA (23.75 dBm) Emission Designator(s): 1M26F9W (CDMA) / 1M27F9W (PCS) Test Device Serial No.: identical prototype [S/N: N/A] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 & 24 Certification Reviewed by: FCC ID: BEJAX830 FCC Pt. 22/24 CDMA / EvDO MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0709121016.BEJ November 15 - 16, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 2 of 35 © 2007 PCTEST Engineering Laboratory, Inc. REV 7.1C 10/23/07 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT...........................................................................3 1.0 INTRODUCTION ..............................................................................................................................4 1.1 SCOPE ................................................................................................................................................ 4 1.2 TESTING FACILITY............................................................................................................................. 4 2.0 PRODUCT INFORMATION..............................................................................................................5 2.1 EQUIPMENT DESCRIPTION .............................................................................................................. 5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS ........................................................................... 5 2.3 LABELING REQUIREMENTS.............................................................................................................. 5 3.0 DESCRIPTION OF TESTS ..............................................................................................................6 3.1 MEASUREMENT PROCEDURE......................................................................................................... 6 3.2 OCCUPIED BANDWIDTH EMISSION LIMITS .................................................................................... 6 3.3 CELLULAR - BASE FREQUENCY BLOCKS....................................................................................... 6 3.4 CELLULAR - MOBILE FREQUENCY BLOCKS ................................................................................... 7 3.5 PCS - BASE FREQUENCY BLOCKS .................................................................................................. 7 3.6 PCS - MOBILE FREQUENCY BLOCKS .............................................................................................. 7 3.7 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL.............................................. 7 3.8 RADIATED SPURIOUS AND HARMONIC EMISSIONS ..................................................................... 8 3.9 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................. 8 4.0 TEST EQUIPMENT CALIBRATION DATA ......................................................................................9 5.0 SAMPLE CALCULATIONS ............................................................................................................10 6.0 TEST RESULTS .............................................................................................................................11 6.1 SUMMARY......................................................................................................................................... 11 6.2 EFFECTIVE RADIATED POWER OUTPUT DATA ........................................................................... 12 6.3 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA .................................................... 13 6.4 CELLULAR CDMA RADIATED MEASUREMENTS........................................................................... 14 6.5 PCS CDMA RADIATED MEASUREMENTS...................................................................................... 17 6.6 CELLULAR CDMA FREQUENCY STABILITY MEASUREMENTS ................................................... 20 6.7 PCS CDMA FREQUENCY STABILITY MEASUREMENTS............................................................... 22 7.0 PLOT(S) OF EMISSIONS ....…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: BEJAX830 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0709121020.BEJ Nov. 13 - 15, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 1 of 70 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.2 11/23/07 Applicant Name: Date of Testing: LG Electronics USA Nov. 13 - 15, 2007 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0709121020.BEJ FCC ID: BEJAX830 APPLICANT: LG ELECTRONICS USA Application Type: Certification FCC Rule Part(s): § 20.19(b), §6.3(v), §7.3(v) HAC Standard: ANSI C63.19-2006 v3.12; FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: Cellular/PCS CDMA Phone with Bluetooth and EvDO Model: AX830 Additional Model(s): CX830, UX830, LG830 Tx Frequency: 824.70 - 848.31 MHz (Cellular CDMA) 1851.25 - 1908.75 MHz (PCS CDMA) Test Device Serial No.: Pre-Production Sample [S/N: HAC1] C63.19-2006 HAC Category: M4 (RF EMISSIONS CATEGORY) This wireless portable device has been shown to be hearing-aid compatible under the above rated category, specified in ANSI/IEEE Std. C63.19-2006 and had been tested in accordance with the specified measurement procedures. Hearing-Aid Compatibility is based on the assumption that all production units will be designed electrically identical to the device tested in this report. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com HEARING AID COMPATIBILITY CERTIFICATE Reviewed by: FCC ID: BEJAX830 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0709121020.BEJ Nov. 13 - 15, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 2 of 70 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.2 11/23/07 TABLE OF CONTENTS 1. INTRODUCTION ........................................................................................................................ 3 2. TEST SITE LOCATION............................................................................................................... 4 3. EUT DESCRIPTION ................................................................................................................... 5 4. ANSI/IEEE C63.19 PERFORMANCE CATEGORIES .................................................................. 6 5. SYSTEM SPECIFICATIONS....................................................................................................... 7 6. TEST PROCEDURE................................................................................................................. 13 7. SYSTEM CHECK ..................................................................................................................... 15 8. MODULATION FACTOR .......................................................................................................... 18 9. FCC 3G MEASUREMENTS...................................................................................................... 20 10. OVERALL MEASUREMENT SUMMARY .................................................................................. 21 11. EQUIPMENT LIST.................................................................................................................... 24 12. MEASUREMENT UNCERTAINTY............................................................................................ 25 13. TEST DATA.............................................................................................................................. 26 14. CALIBRATION CERTIFICATES................................................................................................ 35 15. CONCLUSION.......................................................................................................................... 65 16. REFERENCES ......................................................................................................................... 66 17. TEST PHOTOGRAPHS ............................................................................................................ 68 Reviewed by: FCC ID: BEJAX830 HAC (RF EMISSIONS) TEST REPORT Quality Manager HAC Filename: Test Dates: EUT Type: 0709121020.BEJ Nov. 13 - 15, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 3 of 70 © 2007 PCTEST Engineering Laboratory, Inc. REV 6.2 11/23/07 1. INTRODUCTION On July 10, 2003, the Federal Communications Commission (FCC) adopted new rules requiring wireless manufacturers and service providers to provide digital wireless phones that are compatible with hearing aids. The FCC has modified the exemption for wireless phones under the Hearing Aid Compatibility Act of 1998 (HAC Act) in WT Docket 01-309 RM-8658 1 to extend the benefits of wireless telecommunications to individuals with hearing disabilities. These benefits encompass business, social and emergency communications, which increase the value of the wireless network for everyone. An estimated more than 10% of the population in the United States show signs of hearing impairment and of that fraction, almost 80% use hearing aids. Approximately 500 million people worldwide suffer from hearing loss. Compatibility Tests Involved: The standard calls for wireless communications devices to be measured for: ƒ RF Electric-field emissions ƒ RF Magnetic-field emissions ƒ T-coil mode, magnetic-signal strength in the audio band ƒ T-coil mode, magnetic-signal frequency response through the audio band ƒ T-coil mode, magnetic-signal and noise…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: BEJAX830 HAC (T-COIL) TEST REPORT Quality Manager Filename: Test Dates: EUT Type: 0709121021.BEJ Sept. 25 - 26 & Dec. 18, 2007 Cellular/PCS CDMA Phone with Bluetooth and EvDO Page 1 of 37 © 2007 PCTEST Engineering Laboratory, Inc. REV 3.2C 03/19/07 Applicant Name: Date of Testing: LG Electronics USA Sept. 25 - 26 & Dec. 18, 2007 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA United States Test Report Serial No.: 0709121021.BEJ FCC ID: BEJAX830 APPLICANT: LG ELECTRONICS USA Scope of Test: Audio Band Magnetic Testing (T-Coil) Application Type: Certification FCC Rule Part(s): § 20.19(b), §6.3(v), §7.3(v) HAC Standard: ANSI C63.19-2006 v3.12 FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: Cellular/PCS CDMA Phone with Bluetooth and EvDO Model(s): AX830 (Additional Models: CX830, UX830, LG830) Tx Frequency: 824.70 - 848.31 MHz (Cellular CDMA) 1851.25 - 1908.75 MHz (PCS CDMA) Test Device Serial No.: Pre-Production Sample [S/N: (MEID)A0000003A2E43C, A0000003EDAF41] HAC RF Emissions Category: M4 (ANSI C63.19-2006 v3.12) C63.19-2006 HAC Category: T4 (SIGNAL TO NOISE CATEGORY) This wireless portable device has been shown to be hearing-aid compatib…

Text truncated - open the document above for the full version.
