BEJC320ICellular/PCS GSM/EDGE Phone with Bluetooth & WLAN

LG-C320i User Guide — English This guide will help you understand your new mobile phone. It will provide you with useful explanations of features on your phone. Some of the content of this manual may differ from your phone depending on the software of the phone or your service provider. Disposal of your old appliance 1 When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2 All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. 3 The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. 4 For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. 6 Getting to Know Your Phone Earpiece Send key • Dials a phone number and answers a call. • In standby mode: Shows the history of calls. Alpha numeric keys • In standby mode: Input numbers to dial Hold down - International calls - Connect voice mail centre to - Speed dials - Hold the key dow n to go Silent mode • In editing mode: Enter numbers & characters Soft keys (Left soft key / Right soft key) • These keys perform the function Indicated in the bottom of the display. Main LCD End key • Switch on/off (hold down) • End or reject a call. Confirm key / OK key • Selects menu options and confirms actions. Navigation key In standby mode: Briefly: Mp3 player Briefly: Camera Briefly: Toolbar when it was set. (Menu>Settings>Displa y>Homescreen>Display Items) • In menu: Scroll up & down. 7 Side keys • In standby mode: Controls the ring volume. • During a call: Earpiece volume adjustment • During playing MP3 music: Audio volume adjustment Charger/USB cable connector TIP: Please ensure the phone is powered on , external memory card is inserted and in idle mode before connecting the USB cable for Mass Storage. Battery pack Camera lens Battery cover SIM card holder Headset 8 1 Remove the battery cover Press the battery cover release latch. 2 Remove the battery Lever the bottom edge of the battery and remove it carefully from the battery compartment. WARNING: Do not remove the battery when the phone is switched on, as this may damage the phone. 3 Install the SIM card Slide the SIM card into the SIM card holder. Make sure that the gold contact area on the card is facing downwards. To remove the SIM card, pull it gently in the reverse direction. WARNING: Do not replace or remove the SIM card while your phone is being used or turned on, or data may be lost or the SIM card might be damaged. 4 Install the battery Insert the top of the battery first into the top edge of the battery compartment. Ensure that the battery contacts align with the terminals on the phone. Press down the bottom of the battery until it clips into place. Installing the SIM and battery 9 5 Replace the battery cover 6 Charging your phone Pull open the cover of the charger socket on the top of your LG-C320i. Insert the charger and plug into a mains electricity socket. Your LG-C320i will need to be charged until a message reading “Battery full” appears on screen. 10 Memory card Installing a memory card You can expand the memory available on your phone using a memory card. Note: A memory card is an optional accessory. Slide the memory card into the slot until it clicks into place. Make sure that the gold contact area is facing downwards. Removing a memory card Carefully remove the memory card by gently pushing it in to the phone and quickly releasing it. Formatting the memory card Your memory card may already be formatted. If your memory card isn’t formatted, you will need to format it before you can begin using it. 1 From the home screen press Menu then select Settings. 2 Choose Device and Memory info. and select External memory. 3 Press Format and enter the pas…

Text truncated - open the document above for the full version.

Date: March 22, 2010 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Lab Manager Jim. Kim and of SGS Testing Korea Co., Ltd and hereafter referred to as SGS Testing Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Lab Manager Jim. Kim of SGS Testing Korea Co., Ltd on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Testing Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jae Cheon(J.C.) Lee General Manager LG Electronics USA

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: July 15, 2010 Federal Communications Commission Authorization and Evaluation Division 7435 Oaklan d Mills Road, Columbia, MD 21046 RE: Request of Co nfidentiality for FCC ID: BEJC320 I Equipment Class: JBP: Part 15 Class B Computing Device Peripheral To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

Chris Harvey From: Jo, Jenny (Gunpo) [[email protected]] Sent: Tuesday, July 20, 2010 1:25 AM To: [email protected]; Jeong, Feel (Gunpo) Cc: [email protected]; [email protected] Subject: RE: LG Electronics Inc., FCC ID: BEJC320I, Assessment NO.: AN10T0630 & AN10T0631 & AN10T0632 & AN10T0633, Notice#1 Attachments: LG-C320i_Test Report (BT)_Rev.1.pdf Page 1 of 3 7/21/2010 Dear Chris Thank you for your email. As for your inquiry, Please find attachment and see the below comment in blue. Many thanks, Jenny Jo(Ms)/조찬화 GSM Lab/Wireless Division Assistant Section Chief -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Tuesday, July 20, 2010 5:45 AM To: Jo, Jenny (Gunpo); Jeong, Feel (Gunpo) Cc: [email protected]; [email protected] Subject: LG Electronics Inc., FCC ID: BEJC320I, Assessment NO.: AN10T0630 & AN10T0631 & AN10T0632 & AN10T0633, Notice#1 Dear Jenny Jo and Feel Jeong, You are listed as the Technical Contacts for the above referenced TCB application. The following items need to be resolved before the review can be continued: 1. The internal Antenna Distance photo seems to show a Bluetooth/WiFi PCB Trace antenna but the Bluetooth & WLAN RF Test Report indicates that this device uses an internal -2.5dBi Chip Type antenna (the application for FCC ID: BEJC320 appears to have identical PCB trace antenna with stated - 5.82dBi). The Schematic exhibit seems to show a PCB trace type antenna. Please confirm the Bluetooth/WiFi antenna used in this device, update any exhibits that need correcting and provide a Bluetooth/WiFi Antenna Specification exhibit. Æ Radio Test report's revised. Please find attachment. 2. The SAR test report data tables note 6 state: This model supports GPRS (Class 12) and EDGE. The power in GPRS mode is higher than in EDGE mode and all Tx (1Tx ~ 4Tx) cases were investigated. The worst-case (GPRS 1 Tx) results are reported. (Please refer to the conduction power table Page 15) Please provide the test data for the investigation of SAR in 2Tx, 3Tx and 4Tx . Æ All Tx slot cases were investigated with conducted power that is reported on the report. As you see the conducted power table, this EUT has the highest power when it is operated in GPRS 1Tx slot mode. So I just tested in the mode during body SAR testing. 3. There are 2 versions of the SAR report # F690501/RF-SAR001878 submitted in the WLAN-DTS portion of this application. One version is a total of 120 pages, and the other is 130 pages. The difference appears to be that the larger report contains EUT Photographs in Appendix A. Since only one version of the SAR report will be uploaded to the FCC I would like you to confirm that I should use the 120 page version and the separate SAR EUT photos exhibit. Æ Please disregard the SAR report of 130 pages. As I found that it includes EUT photos which should not be opened to public, I re‐uploaded SAR test report of 120 pages and EUT photo seperately. The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Best regards, Chris Harvey [email protected] Information in this email and any attachments is confidential and intended solely for the use of the individual(s) to whom it is addressed or otherwise directed. Please note that any views or opinions presented in this email are solely those of the author and do not necessarily represent those of the Company. Finally, the recipient should check this email and an y attachments for the presence of viruses. The Company accepts no liability for any damage caused by any virus transmitted by this email. All SGS services are Page 2 of 3 7/21/2010 rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/terms_and_conditions.htm Page 3 of 3 7/21/2010

Front Rear Left Right

Model No: LG-C320i FCC ID : BEJC320I S/N : Made in Korea LG Electronics Inc. LGE

Battery Front Battery Rear Key Pad Front Key Pan Rear LCD Panel Front LCD Panel Rear Lcd Panel Label Main board Front Mainboard Rear Micro SD Card Slot Front Micro SD Card Slot Rear Ear-MIC Phone

Test Report No. : F690501/RF-EMG003426 Page : 2 of 9 Contents 1. General Information...................................................................................................3 1.1 Client Information................................................................................................3 1.2 Test Laboratory...................................................................................................3 1.3 General Information of E.U.T. .............................................................................3 1.4 Operating Modes and Conditions........................................................................3 1.5 Peripheral Equipments........................................................................................3 1.6 Cable List ............................................................................................................4 1.7 System Configurations ........................................................................................4 1.8 Test System Layout ............................................................................................5 1.9 Applicable Standards for Testing ........................................................................5 1.10 Summary of Test Results..................................................................................5 2. Emission Test............................................................................................................6 2.1 Test Results ........................................................................................................6 2.2 Test Equipments .................................................................................................6 2.3 Test Site..............................................................................................................6 2.4 Conducted Emission Test Data...........................................................................6 2.5 Radiated Emission Test Data..............................................................................7 2.6 Modifications.......................................................................................................8 Appendix A : Conducted Emission ................................................................................9 Test Report No. : F690501/RF-EMG003426 Page : 3 of 9 1. General Information 1.1 Client Information Applicant : LG Electronics Inc. Address of Applicant : 60-39, Gasan-dong, Gumchon-gu, Seoul, 153-023, Korea Manufacturer : LG Electronics Inc. Address of Manufacturer : 60-39, Gasan-dong, Gumchon-gu, Seoul, 153-023, Korea 1.2 Test Laboratory Name and Address : SGS Testing Korea Co., Ltd. 18-34, Sanbon-dong, Gunpo, Gyeonggi-do, Korea 435-041 1.3 General Information of E.U.T. Product Name : Cellular/PCS GSM/EDGE Phone with Bluetooth & WLAN Model Name : C320i Alt. Model Name : LG-C320i Model Difference : Only model names are different. Serial No. : 005KPVH0774271 Highest Internal Frequency : Max. 208 MHz Test Voltage : AC 120V, 60Hz(Notebook Computer) 1.4 Operating Modes and Conditions Operating mode Operating condition USB Mode USB Data Communication Note: EUT was exercised through Software(Dell Program) during testing. 1.5 Peripheral Equipments Description Model Serial No. Manufacturer Notebook Computer PCG-3AHP 28272287 7000053Sony Corporation LCD Monitor CR22KS N843H1KP902165L Samsung Electronics USB Keyboard KU-0459 7691402003981 Microsoft USB MOUSE Optical Mouse HCA52704350 SUZHOU LOGITECH ELECTRONICS CO., LTD. Micro SD Card Mobile Ultra 2GB N/A SanDisk Note: Peripherals are DoC. Test Report No. : F690501/RF-EMG003426 Page : 4 of 9 1.6 Cable List Start END Cable Spec. Name I/O PortName I/O PortLength Shield USB Notebook Computer USB 1.2 Shielded MicroSD Micro SD Card - - - Cellular/PCS GSM/EDGE Phone with Bluetooth & WLAN I/O Ear-MIC Phone - 1.1 Unshielded DC IN AC Adapter DC OUT 1.8 Unshielded RGB LCD Monitor RGB 1.8 Shielded USB USB Keyboard - 1.5 Shielded Notebook Computer USB USB Mouse - 1.8 Shielded AC Adapter AC IN AC Source- 1.0 Unshielded 1.7 System Configurations Description Model Serial No. Manufacturer Battery LGIP-430N DC100504 LG Main board C320_MAIN SPFY0235601-C(2) N/A LCD Panel DM24- DSM04_V05 LK1019 LG Innotek co.,Ltd. Ear-MIC Phone N/A N/A LG Micro SD Card Slot N/A N/A N/A Key Pad C320_KEY_C SPEY0068201(3) N/A Test Report No. : F690501/RF-EMG003426 Page : 5 of 9 1.8 Test System Layout 1.9 Applicable Standards for Testing 1.10 Summary of Test Results Test Item Standards Results Conducted Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied Radiated Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied Standards Status Deviation FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Applicable No Deviation AC Adapter Notebook Computer Cellular/PCS GSM/EDGE Phone with Bluetooth & WLAN Micro SD Card LCD Monitor USB Mouse USB Keyboard Ear-MIC Phone Test Report No. : F690501/RF-EMG003426 Page : 6 of 9 EMISSION 2. Emission Test 2.1 Test Results Test Items Standards Test Results Conducted Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied Radiated Emission FCC Part 15 : 2009, Subpart B ANSI C63.4 : 2003 CISPR 22 : 2006 Complied 2.2 Test Equipments Equipment Model Manufacturer Last Cal. Date Two-Line V-Network ENV216 R&S 2010.01.06 Test Receiver ESHS10 R&S 2009.07.13 LISN L3-25 PMM 2009.07.02 Test Receiver ESU26 R&S 2010.04.08 Amplifier 8447F HP 2009.07.02 Bi-Log Antenna VULB9163 SCHWARZBECK MESS- ELEKTRONIK 2009.07.22 Preamplifier 8449B Agilent 2010.03.31 Horn Antenna HF906 R&S 2009.10.08 Note : Only the calibration period of Antennas is 2 years but the period of every equipment is 1 year. 2.3 Test Site Conducted Emission: Shield Room in Gunpo Laboratory Radiated Emission: 3m Semi-Anechoic chamber in Gunpo Laboratory 2.4 Conducted Emission Test Data The initial preliminary exploratory scans were performed using a max hold mode incorpora…

Text truncated - open the document above for the full version.

CE Front CE Rear RE Front RE Rear RE Front(GHz) RE Rear(GHz)
