BEJC570FCellular/PCS GSM/EDGE and Cellular WCDMA Phone with WLAN and Bluetooth

C570 User Guide ELECTRONICS INC. Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation This device has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components. Introduction 6 Congratulations on your purchase of this LG C570 Windows Mobile Smartphone. This user guide contains information on the use and operation of this phone. Please read all the information carefully for optimal performance and to prevent damage or misuse of the phone. Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Phone Components C570 Features 7 1. Earphone jack 2. Display screen 3. Home key 4. Left soft key 5. Call key 6. Optical joystick 7. Function key 8 Microphone 10. Earpiece/Speakers 11. Camera 12. Right soft key 13. Power/End key 14. Back key 15. Enter key 16. My Social key 17. Smart Contacts key 18. Smart Applications key 9. SIM Card slot 20. Camera 21. Battery Compartment 19. microSD Card slot C570 Features 8 Keys and Parts Functions 1. Earphone jack: Plug the headset for handsfree conversation or listening to music. 2. Display screen 3. Home key: Press to return to the Today screen. 4. Left soft key: Press to perform the function indicated by the text on the display above it. 5. Send key: Press to place or answer incoming calls. In standby mode, press to access the dialer and view the most recent incoming, outgoing and missed calls. 6. Optical joystick: Use as directional keys to move up, down, left, or right. Press to confirm a selection. 7. Function key: Press to toggle between number/symbol and letter input. 8. Microphone 9. SIM Card slot 10. Earpiece/Speakers 11. Camera: Use for video calls. 12. Right soft key: Press to perform the function indicated by the text on the display above it. 13. Power/End key b Long press to turn the phone on or off. b During a call, press to end or reject a call. 14. Back key: Press to go back to the previous screen or back out of menus one level at a time. When entering text, press to delete single characters; press and hold to delete entire words. 15. Enter key 16. My Social key: Press to access Good Email and SN. Good Email and SN is a shortcut application to send and receive e-mails. 17. Smart Contacts key: Press to access Smart Contacts. Smart Contacts allows you to add your favorite contacts or phone numbers to the Smart Contacts list. 18. Smart Applications key: Press to access Smart Applications. Smart Application allows you to add your favorite applications to the Smart Applications list for easy access. 19. microSD Card slot 20. Camera: Use to take photos or videos. 21. Battery Compartment micro SD C570 Features 9 How to hold your phone In order to allow better RF antenna sensitivity, LG suggests that you hold the handset as depicted in the figure below. Please do not cover the RF antenna area with your hand during a call and using a bluetooth connection. It may degrade speech quality. Volume Keys bWhen the screen is idle, press to adjust system volume. bDuring a call, press to adjust the in-call volume. USB Connector Use to connect the charger, earphone, or USB cable to synchronize with a computer. Camera Key Press to activate the camera and take photos or videos. microSD slot Remove the cover and insert the memory card. Multi key Press to switch multi world clock with single clock, Task Manager. Getting Started 10 Installing the SIM card and Battery Always turn off your phone and disconnect it from the charger and other accessories before installing or replacing the SIM card, microSD card, and battery. To remove the back cover 1. Place three fingers on the back cover and your thumb on the front panel. 2. Push the front panel with your thumb and slide the back cover off with the three fingers. Battery Your phone comes with a rechargeable Li-ion battery. To remove the battery 1. Turn the phone off. 2. Remove the back cover. 3. Insert your finger in the battery’s finger grip, then gently push down the battery towards the direction of the arrow to release and remove the battery. Getting Started SIM Card Your SIM card contains your phone number, subscription details, and contacts and must be…

Text truncated - open the document above for the full version.

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: June 7, 2010 Federal Communications Commission Autho rization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Re quest of Confidentiality for FCC ID: BEJC570F Eq uipment Class: JBP: Part 15 Class B Computing Device Peripheral To Whom It May Conce rn: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

From: 임지영 Sent: Thursday, July 08, 2010 5:13 AM To: 'PCTEST TCB/CB' Subject: FW : Questions Regarding FCC ID: BEJC570F Dear PCTEST, Please find the revised files and replies are embeded below your questions. Should you have any questions, please let me know. Best Regards, HCT CO.,LTD Ms. Ji-Young Lim(Sales Team)   *--- Discretion policies for e-mail message ---* In case you are an unintended recipient of this email message, be aware this message may contain confidential and classified information that is critical for conducting businesses. If this message and its attachment files are not directed to you, you are not authorized to reveal, use, publish, distribute, copy or trust this message or attachment without intended recipient’s authorization. In case you received this message by chance or in error, please return by forwarding the message and its attachments to the sender. HCT does not recognize liability for any error, omission, corruption or virus in the contents of this message or any attachment that occur as a result of e-mail transmission. ----- Original Message ----- From: PCTEST TCB/CB To: 'HCT - Hyun-A Jang' Sent: Wednesday, July 07, 2010 7:25 AM Subject: Questions Regarding FCC ID: BEJC570F To: Ms. Hyun-A Jang / HCT From: Mr. Mark Czumak / PCTEST TCB RE: FCC ID: BEJC570F Applicant: LG Electronics USA Correspondence Reference Number: BEJ100809 Confirmation Number: 1Y1007010809-812 Date of Original Email: July 6, 2010 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1.The test reports do not include “EDGE” and “phone” in the EUT description. Please revise the description to include this information. → Please find the attachment. 2.The test reports do not include “Cellular” WCDMA in the EUT description. Please revise the description to include this information. → Please find the attachment. 3.The operational description document lists UMTS AWS 1700 EUT capability. Please verify that this band is not operational for the EUT. → UMTS AWS 1700 capability is not implemented in this EUT. 4.The WCDMA Band II channel list is included in the table on page 3 of the tune-up procedure document. Please remove if not applicable to the EUT. → Please find the attachment. 5.According to the conducted power levels provided on page 20 of the SAR test report EDGE SAR data is required for GSM 850 four slot. Please provide the SAR data. → Please find the attachment. 6.The WCDMA conducted powers provided in Table 10.2 on page 21 of the SAR report is missing the HSDPA Active AMR data. Please address. → Please find the attachment. 7.More than half of the SAR plots starting on page 36 of the SAR report do not have the actual SAR plot. There seems to be a formatting issue. Please address. → Please find the attachment. The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Mark Czumak Certification Engineer PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 7 EXTERNAL PHOTOGRAPHS FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 7 ■ EXTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 7 ■ EXTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 7 ■ EXTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 7 ■ EXTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 7 ■ EXTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 7 ■ EXTERNAL PHOTO

Model No: LG-C570f FCC ID : BEJC570F S/N : Made in Korea LG Electronics Inc. LGE

FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 18 INTERNAL PHOTOGRAPHS FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ８ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ９ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １０ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １１ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １２ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １３ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １４ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １５ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １６ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １７ of 18 ■ INTERNAL PHOTO FCC ID: BEJC570F HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １８ of 18 ■ INTERNAL PHOTO

FCC ID: BEJC570F Report No.: HCTE1006FE10-1 Date: July 07, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 2 of 17 TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION 1.1 Product description 3 1.2 Related submittal(s)/Grant(s) 3 1.3 Tested system details 4 1.4 Cable description 5 1.5 Noise suppression parts on cable. (I/O cable) 5 1.6 Test methodology 6 1.7 Test facility 6 1.8 Frequency Range of Radiated Measurements 6 2. SYSTEM TEST CONFIGURATION 2.1 Configuration of tested system 7 3. PRELIMINARY TEST 3.1 Conducted Emission test 8 3.2 Radiated Emission test 8 4. CONDUCTED AND RADIATED EMISSION TESTS SUMMARY 4.1 Conducted Emission test 9 4.2 Radiated Emission test 14 5. FIELD STRENGTH CALCULATION 15 6. TEST EQUIPMENT 16 7. CONCLUSION 17 ATTACHMENT: TEST SETUP PHOTOGRAPHS FCC ID: BEJC570F Report No.: HCTE1006FE10-1 Date: July 07, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 3 of 17 1. GENERAL INFORMATION 1.1 Product Description Equipment Under Test (E.U.T) is Cellular/PCS GSM/EDGE/WCDMA Phone with Bluetooth & WLAN, Model: LG-C570f, C570f manufactured by LG Electronics Inc. Its basic purpose is used for communications. Model (s) LG-C570f, C570f FCC ID BEJC570F E.U.T Type Cellular/PCS GSM/EDGE/WCDMA Phone with Bluetooth & WLAN TX Frequency 824.20 ㎒ to 848.80 ㎒ (GSM 850) 1 850.20 ㎒ to 1 909.80 ㎒ (GSM 1 900) 826.40 ㎒ to 846.60 ㎒ (WCDMA 850) RX Frequency 869.20 ㎒ to 893.80 ㎒ (GSM 850) 1 930.20 ㎒ to 1 989.80 ㎒ (GSM 1 900) 871.40 ㎒ to 891.60 ㎒ (WCDMA 850) 1.2 Related Submittal(s) / Grant(s) Original submittal only. FCC ID: BEJC570F Report No.: HCTE1006FE10-1 Date: July 07, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 4 of 17 1.3 Tested System Details All equipment descriptions used in the tested system (including inserted cards) are: Device Type Manufacturer Model Number/ Part Number FCC ID / DoC Connected To Cellular/PCS GSM/ EDGE/WCDMA Phone with Bluetooth & WLAN LG LG-C570f BEJC570F Notebook PC Notebook PC HP Compaq6730b DoC E.U.T Notebook PC adaptor Hipro Electronics PPP014Y-S - Notebook PC Mouse Microsoft Intellimouse optical USB and PS/2 compatible DoC Notebook PC Headset - - - - USB Cable - - - Notebook PC E.U.T FCC ID: BEJC570F Report No.: HCTE1006FE10-1 Date: July 07, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 5 of 17 1.4 Cable Description * The marked "(D)" means the data cable and "(P)" means the power cable. 1.5 Noise Suppression Parts on Cable. (I/O cable) Product Name Port Ferrite Bead (Y/N) Location Metal Hood (Y/N) Location Headset jack N - Y E.U.T End Cellular/PCS GSM/ EDGE/WCDMA Phone with Bluetooth & WLAN USB data N - Y Both End Notebook PC USB (Mouse) Y Notebook PC End Y Notebook PC End Product Name Port Power Cord Shielded (Y/N) I/O Cable Shielded (Y/N) Length (M) Headset jack - N (D)1.2 Cellular/PCS GSM/ EDGE/WCDMA Phone with Bluetooth & WLAN USB data Y Y (P,D)1.2 Notebook PC USB (Mouse) - Y (D)1.8 FCC ID: BEJC570F Report No.: HCTE1006FE10-1 Date: July 07, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 6 of 17 1.6 Test Methodology Both Conducted and Radiated testing was performed according to the procedures in ANSI C63.4/2003. Radiated testing was performed at an antenna to E.U.T distance of 3 m 1.7 Test Facility The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1, Maekok-ri, Hobup-myun, Ichon-si, Kyoungki-do, 467-701, KOREA. The site is constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated June 10, 2009. (Registration Number: 90661) 1.8 Frequency Range of Radiated Measurements An unintentional radiator, including a digital device, the spectrum shall be investigated from the lowest radio frequency signal generated or used in the device, without going below the lowest frequency for which a Radiated Emission limit is specified, up to the frequency shown in the following table Highest frequency generated or used in the device or on which the device operates or tunes (㎒) Upper frequency of measurement range (㎒) Below 1.705 30 1.705 to 108 1 000 108 to 500 2 000 500 to 1 000 5 000 Above 1 000 5 th harmonic of the highest frequency or 40 ㎓, whichever is lower FCC ID: BEJC570F Report No.: HCTE1006FE10-1 Date: July 07, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 7 of 17 2. SYSTEM TEST CONFIGURATION 2.1 Configuration of Test System Power Line Conducted test : E.U.T was connected to LISN via Notebook PC adaptor. Preliminary Power Line Conducted Emission tests were performed by using the procedure in ANSI C63.4/2003 7.2.3 to determine the worst operating conditions. Radiated Emission test : Preliminary Radiated Emission tests were performed by using the procedure in ANSI C63.4/2003 8.3.1.1 to determine the worst operating condition. Final Radiated Emission tests were performed at 3 m open area test site. [Configuration of Tested System] Power Line: 110VAC Non-Conductive Table Notebook PC adaptor Mouse Notebook PC Headset E.U.T FCC ID: BEJC570F Report No.: HCTE1006FE10-1 Date: July 07, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 8 of 17 3. PRELIMINARY TEST 3.1 Conducted Emission Test ■ Test E.U.T with Data Communication mode, after connecting all peripheral devices. During preliminary tests,…
