BEJC710HCellular/PCS GSM/WCDMA/EDGE Phone with WLAN and Bluetooth

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: May 10, 2010
Application Purpose: Original Equipment
Date of Application: May 10, 2010
Equipment Note: Cellular/PCS GSM/WCDMA/EDGE Phone with WLAN and Bluetooth
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. This device is not intended for sale in the USA. Part 15 Class B Compliance This device and its accessories comply with part15 of FCC rules and ICES-003 Class B digital apparatus requirements for Industry Canada. Operation is subject to the following two conditions: (1) This device & its accessories may not cause harmful interference. (2) This device & its accessories must accept any interference received, including interference that may cause undesired operation. Body-worn Operation Thisdevice has been tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.79inches(2.0cm) must be maintained from the user's body. Additionally, Belt clips, holsters & other body-worn accessories may not contain metallic components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tWZSMGI[LIRMR WTIEOIVTLSRIQSHI 6IEV:MI[ 8LI&EWMGW :SPYQI/I]WEPPS[W]SYXSEHNYWXXLIQEWXIVZSPYQISVXSEHNYWXXLI-RGEPPZSPYQI HYVMRKEGEPP %GGIWWSV]'LEVKIV4SVXEPPS[W]SYXSGSRRIGXXLITLSRIGLEVKIV97&GEFPISVSXLIV GSQTEXMFPIEGGIWWSVMIW QMGVS7(7PSXEGGSQQSHEXIWERSTXMSREPQMGVS7(v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…

Text truncated - open the document above for the full version.

Cover Letter(s)

From: 임지영 Sent: Tuesday, May 11, 2010 1:11 AM To: 'PCTEST TCB/CB' Subject: RE: Question s Regarding FCC ID: BEJC710H Dear PCTEST, 1.There are rounding errors in the GFSK occupied bandwidth test results in the table on page 14 of the Bluetooth test report. The values do not match the values in the corresponding plots when the plot values are rounded properly. Please revise.  We send the revised BT test report. Please check attachment file. Best Regards, Ji-Young Lim From: 한봉효 Sent: Tuesday, May 11, 2010 10:10 AM To: PCTEST TCB/CB; HCT - Ji-Young Lim Subject: Re: Q uestions Regarding FCC ID: BEJC710H Importance: High Hello PCTEST TCB, Thank you for your e-mail. Please see below and find the attachments. Regarding User Manual, I added the IC standard's name. For details, please find the attachment. Thank you! Best regards Han. ----- Original Message ----- From: PCTEST TCB/CB To: HCT - Ji-Young Lim Sent: Tuesday, May 11, 2010 9:03 AM Subject: Questions Regarding FCC ID: BEJC710H To: Ms. Ji-Young Lim / HCT From: Mr. Mark Czumak / PCTEST TCB RE: FCC ID: BEJC710H Applicant: LG Electronics USA Correspondence Reference Number: BEJ100547 Confirmation Number: 1Y1005070547-49 Date of Original Email: May 10, 2010 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 2.The Operational Description document details EUT UMTS 1700 transmit capability on pages 4 and 7. The schematic diagrams also show WCDMA triple-band, including AWS band on page 1 of the document. Please verify that this capability is not operational in the EUT. 3. → I confirm AWS capability is not operational in the EUT. 4.There are two W850 target power ranges listed in the Tune-up procedure document. Please verify that the second range is for W1900 and revise the document accordingly. 5. → Please find the attachment. 6. 3. The Antenna location document provides the distance between the Bluetooth and main antennas only. Please update to include the WLAN antenna. 7. → Please find the attachment. 8. 4. The distance between the Bluetooth and licensed antennas listed on pa ge 24 of the SAR report has a rounding error when compared to the Antenna location document. Please revise. 9. → Please find the attachment. 10. 5. The Tissue Verification table in section 10 of the SAR report only provides muscle data. Please revise to include brain data or correct the typographical errors in the tables. 11. → Please find the attachment. 12. 6. The value listed for Cell WCDMA right tilt SAR in Table 10 on page 30 of the SAR report does not match the corresponding plot on page 58. Please address. 13. → Please find the attachment. 14. 7. The end output power listed in section 13 on page 31 of the SAR report is greater than the start power by more than 5%. This is not permitted by IEEE 1528 section 6.2.2. Please address. 15. → Please find the attachment. 16. 8. There are rounding errors in the GFSK occupied bandwidth test results in the table on page 14 of the Bluetooth test report. The values do not match the values in the corresponding plots 17. when the plot values are rounded properly. Please revise. 18. → Miss Lim will send you the response. The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Mark Czumak Certification Engineer PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notif y the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

Cover Letter(s)

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: April 22, 2010 Federal Communicatio ns Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columb ia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJC710H Equipment Class: JBP: P art 15 Class B Computing Device Periphe ral To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

External Photos

ID Label/Location Info

Model No: LG-C710h FCC ID : BEJC710H S/N : Made in Korea LG Electronics Inc. LGE

Internal Photos

Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 12 INTERNAL PHOTOGRAPHS Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ８ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ９ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １０ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １１ of 12 ■ INTERNAL PHOTO Report No.: HCTR1005FR01 FCC ID: BEJC710H/ IC: 2703C-C710H DATE: May 04, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １２ of 12 ■ INTERNAL PHOTO

Test Report

FCC ID: BEJC710H, IC: 2703C-C710H Report No.: HCTE1004FE18 Date: April 08, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 2 of 17 TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION 1.1 Product description 3 1.2 Related submittal(s)/Grant(s) 3 1.3 Tested system details 4 1.4 Cable description 5 1.5 Noise suppression parts on cable. (I/O cable) 5 1.6 Test methodology 6 1.7 Test facility 6 1.8 Frequency Range of Radiated Measurements 6 2. SYSTEM TEST CONFIGURATION 2.1 Configuration of tested system 7 3. PRELIMINARY TEST 3.1 Conducted Emission test 8 3.2 Radiated Emission test 8 4. CONDUCTED AND RADIATED EMISSION TESTS SUMMARY 4.1 Conducted Emission test 9 4.2 Radiated Emission test 14 5. FIELD STRENGTH CALCULATION 15 6. TEST EQUIPMENT 16 7. CONCLUSION 17 ATTACHMENT: TEST SETUP PHOTOGRAPHS FCC ID: BEJC710H, IC: 2703C-C710H Report No.: HCTE1004FE18 Date: April 08, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 3 of 17 1. GENERAL INFORMATION 1.1 Product Description Equipment Under Test (E.U.T) is Cellular/PCS GSM/EDGE/WCDMA Phone with Bluetooth &WLAN, Model: LG-C710h, C710h manufactured by LG Electronics Inc. Its basic purpose is used for communications. FCC/IC Model LG-C710h, C710h FCC ID / IC BEJC710H / 2703C-C710H E.U.T Type Cellular/PCS GSM/EDGE/WCDMA Phone with Bluetooth &WLAN TX Frequency 824.20 ㎒ to 848.80 ㎒ (GSM 850) 1 850.20 ㎒ to 1 909.80 ㎒ (GSM 1 900) 826.40 ㎒ to 846.60 ㎒ (WCDMA 850) 1 852.4 ㎒ to 1 907.6 ㎒ (WCDMA 1 900) RX Frequency 869.20 ㎒ to 893.80 ㎒ (GSM 850) 1 930.20 ㎒ to 1 989.80 ㎒ (GSM 1 900) 871.40 ㎒ to 891.60 ㎒ (WCDMA 850) 1 932.4 ㎒ to 1 987.6 ㎒ (WCDMA 1 900) 1.2 Related Submittal(s) / Grant(s) Original submittal only. FCC ID: BEJC710H, IC: 2703C-C710H Report No.: HCTE1004FE18 Date: April 08, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 4 of 17 1.3 Tested System Details All equipment descriptions used in the tested system (including inserted cards) are: Device Type Manufacturer Model Number/ Part Number FCC ID / DoC Connected To Cellular/PCS GSM/ EDGE/WCDMA Phone with Bluetooth &WLAN LG LG-C710h BEJC710H Notebook PC Notebook PC SAMSUNG NT-R519 DoC E.U.T Notebook PC adaptor DELTA ADP-60ZH D AD-6019R - Notebook PC Mouse Microsoft Intellimouse optical USB and PS/2 compatible DoC Notebook PC USB Cable - - - Notebook PC E.U.T Headset - - - E.U.T FCC ID: BEJC710H, IC: 2703C-C710H Report No.: HCTE1004FE18 Date: April 08, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 5 of 17 1.4 Cable Description * The marked "(D)" means the data cable and "(P)" means the power cable. 1.5 Noise Suppression Parts on Cable. (I/O cable) Product Name Port Ferrite Bead (Y/N) Location Metal Hood (Y/N) Location Headset jack N - Y E.U.T End Cellular/PCS GSM/ EDGE/WCDMA Phone with Bluetooth &WLAN USB data N - Y Both End Notebook PC USB (Mouse) Y Notebook PC End Y Notebook PC End Product Name Port Power Cord Shielded (Y/N) I/O Cable Shielded (Y/N) Length (M) Headset jack - N (D)1.0 Cellular/PCS GSM/ EDGE/WCDMA Phone with Bluetooth &WLAN USB data Y Y (P,D)1.2 Notebook PC USB (Mouse) - Y (D)1.8 FCC ID: BEJC710H, IC: 2703C-C710H Report No.: HCTE1004FE18 Date: April 08, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 6 of 17 1.6 Test Methodology Both Conducted and Radiated testing was performed according to the procedures in ANSI C63.4/2003. Radiated testing was performed at an antenna to E.U.T distance of 3 m 1.7 Test Facility The open area test site and conducted measurement facility used to collect the radiated data are located at the 254-1, Maekok-ri, Hobup-myun, Ichon-si, Kyoungki-do, 467-701, KOREA. The site is constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test facility was submitted to the Commission and accepted dated June 10, 2009. (Registration Number: 90661) 1.8 Frequency Range of Radiated Measurements An unintentional radiator, including a digital device, the spectrum shall be investigated from the lowest radio frequency signal generated or used in the device, without going below the lowest frequency for which a Radiated Emission limit is specified, up to the frequency shown in the following table Highest frequency generated or used in the device or on which the device operates or tunes (㎒) Upper frequency of measurement range (㎒) Below 1.705 30 1.705 to 108 1 000 108 to 500 2 000 500 to 1 000 5 000 Above 1 000 5 th harmonic of the highest frequency or 40 ㎓, whichever is lower FCC ID: BEJC710H, IC: 2703C-C710H Report No.: HCTE1004FE18 Date: April 08, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 7 of 17 2. SYSTEM TEST CONFIGURATION 2.1 Configuration of Test System Power Line Conducted test : E.U.T was connected to LISN via Notebook PC adaptor. Preliminary Power Line Conducted Emission tests were performed by using the procedure in ANSI C63.4/2003 7.2.3 to determine the worst operating conditions. Radiated Emission test : Preliminary Radiated Emission tests were performed by using the procedure in ANSI C63.4/2003 8.3.1.1 to determine the worst operating condition. Final Radiated Emission tests were performed at 3 m open area test site. [Configuration of Tested System] Power Line: 110VAC Non-Conductive Table Notebook PC adaptor Mouse Notebook PC Headset E.U.T FCC ID: BEJC710H, IC: 2703C-C710H Report No.: HCTE1004FE18 Date: April 08, 2010 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539…
