Oct 1, 2005 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: LG Electronics Inc. FCC ID: BEJCG300 Request for Short-Term Confidentiality To Whom It May Concern: In accordance with 0.457 and 0.459 of CFR 47, LG Electronics Inc. requests short-term confidentiality for the test setup photos, external photos, internal photos, and user’s manual of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which LG Electronics Inc. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely, E.S.Park Chief Research Engineer LG Electronics Inc. LG Electronics Inc. LGE Tel : 82-2-2033-3850 Fax : 82-2-2033-3103 [email protected] 459-9, Kasan-dong, Kemchun-ku Seoul 153-023, Korea

October 1. 2005 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 In re : LG Electronics Inc.. FCC ID: BEJCG300 Dual Band GSM Phone Part 22/24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Electronics, Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced Type Acceptance application. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, E.S.Park Chief esearch Engineer Mobile Handset Lab LG Electronics Inc. Tel : 82-2-2033-3850 Fax : 82-2-2033-3103 [email protected] 459-9, Kasan-dong, Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE LG Electronics Inc. LGE October 1. 2002 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Subject : LG Electronics Inc.. FCC ID: BEJCG300 User’s Manual RF Exposure Warning Statement Gentlemen: LG Electronics, Inc. hereby conforms that the attached RF exposure warning page will be ready visible to the user, and will be placed at a prominent location in the front of user’s manual. If you have any questions or comments concerned the above, please do not hesitate to contact PCTEST Lab. or me at (410)290-6652 Sincerely, E.S.Park Chief Research Engineer Mobile Handset Lab LG Electronics Inc. Tel : 82-2-2033-3850 Fax : 82-2-2033-3103 [email protected] 459-9, Kasan-dong, Kemchun-ku Seoul 153-023, Korea

FCC ID: BEJCG300 Applicant: LG Electronics USA Correspondence Reference Number: 25282 731 Confirmation Number: TC489918 Date of Original Email: 12/19/2005 Subject: Request for additional information Please detail all key GSM modes of operation i.e. GPRS, EDGE etc and how they are accounted for in this filing. Please provide full information. Please find full information in Page 4 of the Operational Description Exhibit. This device operates in voice mode under GSM mode only. This device is data capable in GPRS mode multislot class 10.

LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300

LG Electronics Inc. Model : CG300 FCC ID : BEJCG300 IMEI S/N LG Electronics Inc. Model : CG300 FCC ID : BEJCG300 IMEI S/N LG Electronics Inc. Model : CG300 FCC ID : BEJCG300 IMEI S/N

LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300 LG FCC ID: BEJCG300 EUT Photographs © 2005 PCTEST Lab. Dual-Band GSM Phone w/ Bluetooth Model: CG300

Reviewed by: PCTEST SAR REPORT SAR SUMMARY REPORT Quality Manager SAR Filename: Test Dates: EUT Type: Dual-Band FCC ID: 0510040686 10/25/2005 - 10/26/2005 GSM Phone with Bluetooth BEJCG300 Page 1 of 25 © 2005 PCTEST Engineering Laboratory, Inc. Applicant Name: Date of Testing: LG Electronics Inc. 10/25/2005 - 10/26/2005 1000 Sylvan Avenue Test Site/Location: Englewood Cliffs, NJ 07632 PCTEST Lab, Columbia, MD, USA Test Report Serial No.: 0510040686 FCC ID: BEJCG300 APPLICANT: LG ELECTRONICS Application Type: Certification FCC Rule Part(s): § 2.1093; FCC/OET Bulletin 65 Supplement C (July 2001) FCC Classification: Licensed Transmitter Held to Ear (PCE) EUT Type: Dual-Band GSM Phone with Bluetooth Model(s): CG300 Tx Frequency: 824.20MHz - 848.8MHz (Cellular GSM) 1850.20MHz - 1909.8MHz (PCS GSM) RF Output Power: 2.125 W ERP Cellular GSM (33.27 dBm) 1.126 W ERP PCS GSM (30.65 dBm) Max. SAR Measurement: Cellular GSM: 1.04 W/kg Head SAR, 1.40 W/kg Body SAR PCS GSM: 0.25 W/kg Head SAR, 0.62 W/kg Body SAR Test Device Serial No.: Pre-Production Sample [S/N: FCC #1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 2.2 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Reviewed by: PCTEST SAR REPORT SAR SUMMARY REPORT Quality Manager SAR Filename: Test Dates: EUT Type: Dual-Band FCC ID: 0510040686 10/25/2005 - 10/26/2005 GSM Phone with Bluetooth BEJCG300 Page 2 of 25 © 2005 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION....................................................................................................................3 2. TEST SITE LOCATION...........................................................................................................4 3. SAR MEASUREMENT SETUP................................................................................................5 4. ALIDX-500 E-FIELD PROBE SYSTEM....................................................................................6 5. PROBE CALIBRATION PROCESS.........................................................................................7 6. PHANTOM AND EQUIVALENT TISSUES............................................................................8-9 7. TEST SYSTEM SPECIFICATIONS.......................................................................................10 8. DOSIMETRIC ASSESSMENT AND PHANTOM SPECS.........................................................11 9. DEFINITION OF REFERENCE POINTS................................................................................12 10. TEST CONFIGURATION POSITION.....................................................................................13 11. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.................................................................14 12. MEASUREMENT UNCERTAINTIES......................................................................................15 13. SAR TEST EQUIPMENT......................................................................................................16 14. CONCLUSION.....................................................................................................................17 15. REFERENCES.....................................................................................................................18 EXHIBIT A. SYSTEM VERIFICATION...............................................................................................19 EXHIBIT B. SAR SETUP PROCEDURES..........................................................................................20 EXHIBIT C. SAR DATA SUMMARY...............................................................................................21-25 Reviewed by: PCTEST SAR REPORT SAR SUMMARY REPORT Quality Manager SAR Filename: Test Dates: EUT Type: Dual-Band FCC ID: 0510040686 10/25/2005 - 10/26/2005 GSM Phone with Bluetooth BEJCG300 Page 3 of 25 © 2005 PCTEST Engineering Laboratory, Inc. 1. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency (RF) radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Pr…

Text truncated - open the document above for the full version.

PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0510040685 Test Dates: October 24-26, 2005 Phone Type: Dual-Band GSM FCC ID: BEJCG300 Page 1 of 25 © 2005 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 & 22 Certification LG ELECTRONICS, INC. Dates of Tests: October 24-26, 2005 1000 Sylvan Avenue Test Report S/N: 0510040685 Englewood Cliffs, NJ 07632 Test Site: PCTEST Lab, Columbia MD FCC ID BEJCG300 APPLICANT LG ELECTRONICS, INC. Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §24(E), §22(H); §2 EUT Type: Dual-Band GSM Phone Model: CG300 Tx Frequency Range: 824.20 – 848.80MHz (GSM850) / 1850.20MHz – 1909.80MHz (GSM1900) Rx Frequency Range: 869.20 – 893.80MHz (GSM850) / 1930.20MHz – 1989.80MHz (GSM1900) Max. RF Output Power: 2.125 W ERP GSM850 (33.27 dBm) / 1.162 W EIRP GSM1900 (30.65 dBm) Max. SAR Measurement: 1.04 W/kg GSM850 Head SAR; 1.40 W/kg GSM850 Body SAR; 0.25 W/kg GSM1900 Head SAR/ Slide Out; 0.62 W/kg GSM1900 Body SAR Emission Designator(s): 250KGXW Test Device Serial No. Identical Prototype [S/N: FCC #1] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 2.2 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0510040685 Test Dates: October 24-26, 2005 Phone Type: Dual-Band GSM FCC ID: BEJCG300 Page 2 of 25 © 2005 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-8 5.1 EFFECTIVE RADIATED POWER OUTPUT 9-10 6.1 EQUIVALENT ISOTROPIC RADIATED POWER 11 7.1 RADIATED MEASUREMENTS 12-17 8.1 FREQUENCY STABILITY 18-21 9.1 PLOTS OF EMISSIONS 22 10.1 LIST OF TEST EQUIPMENT 23 11.1 SAMPLE CALCULATIONS 24 12.1 CONCLUSION 25 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0510040685 Test Dates: October 24-26, 2005 Phone Type: Dual-Band GSM FCC ID: BEJCG300 Page 3 of 25 © 2005 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: LG ELECTRONICS, INC. Address: 2000 Milbrook Drive Lincolnshire, IL 60069 • FCC ID: BEJCG300 • Quantity: Quantity production is planned • Emission Designators: 250KGXW • Tx Freq. Range: 824.20 – 848.80 MHz (GSM850) 1850.20 – 1909.80 MHz (GSM1900) • Rx Freq. Range: 869.20 – 893.80 MHz (GSM850) 1930.20 – 1989.80 MHz (GSM1900) • Max. Power Rating: 2.125 W ERP GSM850 (33.27 dBm) 1.162 W EIRP GSM1900 (30.65 dBm) • FCC Classification(s): Licensed Portable Tx Held to Ear (PCE) • Equipment (EUT) Type: Dual-Band GSM Phone • Modulation(s): GSM • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E), §22(H) • Dates of Tests: October 24-26, 2005 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 0510040685 • Deviation from measurement procedure - None PCTEST PT. 22/24 REPORT FCC MEASUREMENT REPORT Reviewed By: Quality Manager Test Report S/N: 0510040685 Test Dates: October 24-26, 2005 Phone Type: Dual-Band GSM FCC ID: BEJCG300 Page 4 of 25 © 2005 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and …
