  1. Home/
  2. LG Electronics USA, Inc./
  3. BEJD2743PB

BEJD2743PBLCD Monitor

LG Electronics USA, Inc.
LCD Monitor - FCC ID BEJD2743PB - LG Electronics USA, Inc.
Click to zoom

Application Details

Equipment Class
JBP - Part 15 Class B Computing Device Peripheral
Date of Grant
Apr 07, 2012
Application Purpose
Original Equipment
Date of Application
Apr 05, 2012
Equipment Note
LCD Monitor
Company
LG Electronics USA, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Block Diagram

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

www.lg.com D2343P D2743P ENGLISH OWNER’S MANUAL CINEMA 3D MONITOR Please read this manual carefully before operating your set and retain it for future reference. CINEMA 3D MONITOR MODEL 2 ENG ENGLISH TABLE OF CONTENTS CONTENTS 3 ASSEMBLING AND PREPAR- ING 3 Unpacking 4 Parts and buttons 5 Setting up the Monitor set 5 - Attaching the Stand Base 6 - Detaching the Stand Base 7 - Mounting on a table 7 - Using the cable holder 9 - Mounting on a wall 10 USING THE MONITOR SET 10 Connecting to a PC 10 - D-SUB connection 10 - DVI-D connection 10 - HDMI connection 12 CUSTOMIZING SETTINGS 13 Customizing Settings 13 - Menu Settings 14 - PICTURE 15 - COLOR 16 - DISPLAY 16 - VOLUME 17 - OTHERS 18 - FUNC.Settings 18 - 3D SETTINGS 19 - Setting Dual Play 20 PICTURE MODE 21 - SUPER+RESOLUTION 22 SUPER ENERGY SAVING 23 TROUBLESHOOTING 25 TROUBLESHOOTING WHEN USING 3D MODE 26 SPECIFICATIONS 26 D2343P 27 D2743P 28 Preset Modes (Resolution) 29 Indicator 30 SAFETY PRECAUTIONS 30 - Precautions to take when viewing 3D images 30 - When using 3D Glasses 31 PROPER POSTURE 31 Proper posture for using the Monitor set. 31 Precautions to take when viewing 3D im- ages 3 ENG ENGLISH ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.  Do not use any unapproved accessories to ensure the safety and product life span.  Any damages or injuries by using unapproved accessories are not covered by the warranty.  The accessories supplied with your product may vary depending on the model.  Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. CAUTION NOTE Stand BodyStand BodyStand Base CD(Owner's Manual) / Card D-SUB Cable DVI-D Cable (This cable is not included in all countries.) ( Depending on the country )( Depending on the country ) Power CordAC-DC AdapterAC-DC Adapter or Two Screws 3D Glasses (Normal type) 3D Glasses (Clip-on type) The number of 3D glasses may differ depending on the model of country. 4 ENG ENGLISH ASSEMBLING AND PREPARING Parts and buttons Power Indicator  Lighting On: Turned on  Lighting Off: Turned off Connection panel (See p.10) Button (See p.12) (Power Button) 5 ENG ENGLISH ASSEMBLING AND PREPARING Attach the Stand Body to the monitor set. Attach the Stand Base. Tighten the screw to the right with a coin. Attach the Stand Body to the monitor set. Use two screws to fix the Stand Body and monitor set. Attach the Stand Base. Tighten the screw to the right with a coin. Setting up the Monitor set Attaching the Stand Base 1 Place the Monitor set with the screen side down on a flat and cushioned surface. Lay a foam mat or soft protective cloth on the surface to protect the screen from damage. CAUTION 2 Stand Base Stand Body D2743P Stand Base Stand Body Stand Body 1 2 3 1 2 3 4 D2343P 6 ENG ENGLISH ASSEMBLING AND PREPARING  This illustration depicts the general model of connection. Your monitor may differ from the items shown in the picture.  Do not carry the product upside down holding only the stand base. The product may fall and get damaged or injure your foot. CAUTION Detaching the Stand Base 1 Place the Monitor set with the screen side down on a flat and cushioned surface. Stand Base Stand Base Stand Body Stand Body Stand Base Stand Body Stand Body Pull out the Stand Body and Stand Base from the monitor set. Turn the screw to the left with a coin. Pull out the Stand Base. 1 2 3 Turn the screw to the left with a coin. Pull out the Stand Base from the Stand Body. Remove two screws and pull out the Stand Body from the monitor set. 1 2 3 2 D2343P D2743P 7 ENG ENGLISH ASSEMBLING AND PREPARING Mounting on a table 1 Lift and tilt the Monitor set into its upright position on a table. Leave a 10 cm (minimum) space from the wall for proper ventilation. Using the cable holder 2 Connect the AC-DC Adapter and Power Cord to a wall outlet. 3 Press (Power) button on the bottom switch panel to turn the power on. 10 cm 10 cm 10 cm 10 cm Unplug the power cord before moving the Monitor to another location. Otherwise electric shock may occur. CAUTION Cable holder or 8 ENG ENGLISH ASSEMBLING AND PREPARING Using the Kensington security system The Kensington security system connector is located at the back of the Monitor set. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com. Connect the Kensington security system cable between the Monitor set and a table. The Kensington security system is optional. You can obtain it from most electronics stores. NOTE When you adjust the angle, do not hold the bottom of the Monitor set frame as shown on the following illustration, as may injure your fingers. Do not touch or press the screen when adjusting the angle of the monitor. Do not hold this set like below picture.Monitor screen can detach from stand base and injure your body. WARNING Tilt from +20 to -5 degrees up or down to adjust the angle of the Monitor set to suit your view. NOTE FrontRear 9 ENG ENGLISH ASSEMBLING AND PREPARING Mounting on a wall For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide. If you intend to mount the Monitor set to a wall, attach Wall mounting interface (optional parts) to the back of the set. When you install the Monitor set using a wall mounting interface (optional parts), attach it carefully so it will not drop. 1 Please, Use the screw and wall mount interface in accordance with VESA Standards. 2 If you use screw longer than standard, the monitor might be damaged internally. 3 If you use improper screw, the product might be damaged and drop …

Text truncated - open the document above for the full version.

Users Manual

Regulatory Information cont. FCC Compliance Statement This equipment has been tested and found to comply within the limits of a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception (which can be determined by turning the equipment on and off), the user is encouraged to try to correct the interference by using one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and the receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's (or your) authority to operate the equipment. Only peripherals (digital input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to this monitor. Operation with non-certified peripherals is likely to result in interference to radio and TV reception. Only shielded signal cables may be used with this System. Canadian DOC Notice This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. TCO Displays 5.0 Congratulations, Your display is designed for both you and the planet! This display carries the TCO Certified label. This ensures that the display is designed for minimal impact on the climate and natural environment, while offering all the performance expected from top of the line electronic products. TCO Certified is a third party verified program, where every product model is tested by an accredited independent test laboratory. TCO Certified represents one of the toughest certifications for displays worldwide. Some of the Usability features of the TCO Displays 5.0 requirements: Visual Ergonomics Good visual ergonomics in order to improve the working environment for the user and to reduce sight and strain problems. Important parameters are: • Light levels without color tint, Uniform color and luminance, Wide color gamut • Calibrated color temperature and gamma curve • Wide luminance level, Dark black levels, Low motion blur Electrical Safety • Product fulfills rigorous safety standards 1 NOTICE The regulations are applied only to the products with the ID LABEL indicating specific requirements. NOTICE The regulations are applied only to the products with the ID LABEL indicating specific requirements. NOTICE The following information is for the models certified by TCO. If you want to know the specification of the purchased product, see the label attached on the back of the product. Regulatory Information cont. 2 Emissions • Low alternating electric and magnetic fields emissions • Low acoustic noise emissions Some of the environmental features of the TCO Displays 5.0 requirements: • The brand owner demonstrates corporate social responsibility and has a certified environmental management system (EMAS or ISO 14001) • Very low energy consumption both in on-and standby mode • Restrictions on chlorinated and brominated flame retardants, plasticizers and polymers • Restrictions on heavy metals such as cadmium, mercury and lead (RoHS compliance) • Both product and product packaging is prepared for recycling • The brand owner offers take-back options The requirements included in this label have been developed by TCO Development in co-operation with scientists, experts, users as well as manufacturers all over the world. Since the end of the 1980s TCO has been involved in influencing the development of IT equipment in a more user-friendly direction. Our labeling system started with displays in 1992 and is now requested by users and IT-manufacturers all over the world. For more information, please visit: www.tcodevelopment.com Information for Environmental Preservation LGE. announced the 'LG Declaration for a Cleaner Environment' in 1994, and this ideal has served as a guiding managerial principle ever since. The Declaration is a foundation that has allowed us to undertake environmentally friendly activities in careful consideration of economic, environmental, and social aspects. We promote activities for environmental preservation, and we specifically develop our products to embrace the concept of environment-friendly. We minimize the hazardous materials contained in our products. For example, there is no cadmium to be found in our monitors. Information for recycling This monitor may contain parts which could be hazardous to the environment. It is important that this monitor be recycled after use. LGE. handles all waste monitors through an environmentally acceptable recycling method. There are several take-back and recycling systems currently in operation worldwide. Many parts will be reused and recycled, while harmful substances and heavy metals are treated by an environmentally friendly method. If you want to find out more information about our recycling program, please contact your local LG vendor or a corporate representative of LG. We set our vision and policies on a cleaner world by selecting the issue of the global environment as a task for corporate improvement. Please visit our website for more information about our ‘green’ policies. http://www.lg.com/global/sustainability/environment/take-back- recycling.jsp English Informationen zur Erhaltung der…

Text truncated - open the document above for the full version.

Cover Letter(s)

AHTHORIZATION LETTER LG Electronics USA FCC ID: BEJD2743PB Date: Mar 31, 2012 To whom it may concern: We, the undersigned, hereby authorize Cerpass Technology (Suzhou) Co., Ltd. of China to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Cerpass Technology (Suzhou) Co., Ltd. within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 weeks from original data. If you have any questions regarding the authorization, please don’t hesitate to contact me. Thank you. Yours Sincerely, Christopher/ Sr. Manager LG Electronics USA

Cover Letter(s)

LG Electronics USA Date: Mar 31, 2012 Federal Communications Commission Authorization and Evaluation Division FCC ID: BEJD2743PB Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Christopher/ Sr. Manager LG Electronics USA

External Photos

LCD Monitor (Model name: D2743PB) Exterior Photograph: Adapter #1: LCAP21A Adapter #2: ADS-40SG-19-3 19032G Adapter #3: ADS-40FSG-19 19032GPG-1 Adapter #4: LCAP26A-C

ID Label/Location Info

LCD Monitor (Model name: D2743PB) FCC ID

Internal Photos

LCD Monitor (Model name: D2743PB) Inside photo:

Test Report

CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1203115 Cerpass Technology (Suzhou) Co., Ltd Issued Date : Mar 31, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 1 of 21 FCC TEST REPORT According to 47 CFR, Part 2, Part 15 and CISPR PUB. 22 Applicant : LG Electronics USA Address : 1000 Sylvan Avenue Englewood Cliffs New Jersey United States Equipment : LCD Monitor Model No. : D2743PB FCC ID : BEJD2743PB  The test result refers exclusively to the test presented test model / sample.  Without written approval of Cerpass Technology Corp. the test report shall not be reproduced except in full.  The test report must not be used by the clients to claim product certification approval by NVLAP or any agency of the Government. CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1203115 Cerpass Technology (Suzhou) Co., Ltd Issued Date : Mar 31, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 2 of 21 Contents 1. Summary of Test Procedure and Test Result ...........................................................................................5 2. Test Configuration of Equipment under Test............................................................................................6 2.1. Manufacturer ....................................................................................................................................6 2.2. Feature of Equipment under Test .....................................................................................................6 2.3. Test Manner ......................................................................................................................................7 2.4. Description of Support Unit ..............................................................................................................9 2.5. General Information of Test ............................................................................................................10 2.6. Measurement Uncertainty ..............................................................................................................10 3. Test of Conducted Emission ....................................................................................................................11 3.1. Test Limit ........................................................................................................................................ 11 3.2. Test Procedures.............................................................................................................................. 11 3.3. Typical test Setup ...........................................................................................................................12 3.4. Measurement equipment................................................................................................................12 3.5. Test Result and Data ......................................................................................................................13 4. Test of Radiated Emission........................................................................................................................15 4.1. Test Limit ........................................................................................................................................15 4.2. Test Procedures..............................................................................................................................16 4.3. Typical test Setup ...........................................................................................................................16 4.4. Measurement equipment................................................................................................................17 4.5. Test Result and Data (30MHz ~ 1000MHz)....................................................................................18 4.6. Test Result and Data (1000MHz ~ 18000MHz)..............................................................................20 CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1203115 Cerpass Technology (Suzhou) Co., Ltd Issued Date : Mar 31, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 3 of 21 History of this test report  ORIGINAL.  Additional attachment as following record: Attachment No. Date Description CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1203115 Cerpass Technology (Suzhou) Co., Ltd Issued Date : Mar 31, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 4 of 21 FCC TEST REPORT According to 47 CFR, Part 2, Part 15 and CISPR PUB. 22 Applicant : LG Electronics USA Address : 1000 Sylvan Avenue Englewood Cliffs New Jersey United States Equipment : LCD Monitor Model No. : D2743PB FCC ID : BEJD2743PB I HEREBY CERTIFY THAT : The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4 – 2003 and the energy emitted by this equipment was passed CISPR PUB. 22 and FCC Part 15 in both radiated and conducted emission class B limits. Testing was carried out on Mar 30, 2012 at Cerpass Technology Corp. Signature Miro Chueh/ Technical director CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1203115 Cerpass Technology (Suzhou) Co., Ltd Issued Date : Mar 31, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 5 of 21 1. Summary of Test Procedure and Test Result Test Item Normative References Test Result Conducted Emission ANSI C63.4@2003 FCC Part 15 Subpart B PASS Radiated Emission ANSI C63.4@2003 FCC Part 15 Subpart B PASS CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1203115 Cerpass Technology (Suzhou) Co., Ltd Issued Date : Mar 31, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 6 of 21 2. Test Configuration of Equipment under Test 2.1. Manufacturer LG Electronics Nanjing Display Co.,Ltd. No.346,Yaoxin Road Economic & Technical Development Zone Nanjing China 2.2. Feature of Equipment under Test LCD Monitor Model No: D2743PB Manufacturer: Lien Chang Electronic Enterprise Co.,Ltd. …

Text truncated - open the document above for the full version.

Test Setup Photos

LCD Monitor (Model name: D2743PB) Front View of Conducted Emission Test Back View of Conducted Emission Test Front View of Radiated Emission Test (30MHz ~ 1000MHz) Back View of Radiated Emission Test (30MHz ~ 1000MHz) Front View of Radiated Emission Test (1000MHz ~ 18000MHz) Back View of Radiated Emission Test (1000MHz ~ 18000MHz)

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)
[email protected]201-470-2696Fax: 201-816-2003

Technical Contact

Cerpass technology(suzhou)co.LtdMiro Chueh
[email protected]0512-69175888

Suzhou · China

Non-Technical Contact

Cerpass technology(suzhou)co.LtdMandy liu
[email protected]0512-69175888

Test Firm

Cerpass Technology (SuZhou) Co., Ltd.Miro Chueh
[email protected]86-0512-69175888Fax: 86-0512-36175666

Technical Specifications

#Rule PartsFrequency RangePower Output
115B--
Confidentiality
Long Term
Grant Notes
Maximum Resolution: 1920X1080 @60Hz
