Block diagram for E50 (NVT) Crystal ： RB14318067 ; HLX-U-F(alternate) Regulation ： 14.31818MHz+/- 30PPM Analog (R/G/B) ADC Scaler LVDS TX D-SUB Pane 60MHz~87.5MHz(22”/23”) 146.25MHz(22”/23”) TMDS RX MCU OSD SSC B l 5V 1.8V EEPROM 39.1MHz~61.9MHz(20”) 108.0MHz(20”) MCU OSD SSC SDA/SCL Key 5V 28 68MHz Flash ROM EEPROM system SDA/SCL 3.3V y Crystal 14.318MHz 28 . 68MHz system 3.3V Re g ulato r 1.8V Ada 5V 12V DC/DC converter ready g 3.3V apter 12V converter LED Drive r Panel LED stringPanel LED string

Power of Attorney Federal Communication Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 We, Company: LG Electronics U.S.A., Inc. Address: 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 Would like to inform you that we nominated Audix Technology (Shanghai) Co., Ltd, Mr. Byron Kwo to act on behalf of our LG Electronics Inc. to apply FCC ID for the LCD Monitors with LG brand. Kind Regards, Place, date Signature 2010-03-05 Jae Cheon Lee ________________ ________________

Statement FCC ID: BEJE1950SV Data: Mar 05, 2010 We LG Electronics U.S.A., Inc. declare under our own responsibility that the product LCD Monitor to which this declaration refers conforms with all electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marked. 2010.03.05 [Data] [Name and Signature of person responsible]

FIGURE 1 LCD MONITOR (M/N: E1950SV) GENERAL APPEARANCE (FRONT VIEW) F IGURE 2 LCD MONITOR (M/N: E1950SV) G ENERAL APPEARANCE (BACK VIEW) FIGURE 3 LCD MONITOR (M/N: E1950SV) LABEL F IGURE 4 LCD MONITOR (M/N: E1950SV) P ORT VIEW FIGURE 5 LCD MONITOR (M/N: E1950SV) D-SUB CABLE #1 F IGURE 6 LCD MONITOR (M/N: E1950SV) D-SUB CABLE #2 FIGURE 7 LCD MONITOR (M/N: E1950SV) POWER CORD FIGURE 8 LCD MONITOR (M/N: E1950SV) ADAPTER #1 (GENERAL APPEARANCE) F IGURE 9 LCD MONITOR (M/N: E1950SV) ADAPTER #1 (POWER PORT) FIGURE 10 LCD MONITOR (M/N: E1950SV) ADAPTER #1 (LABEL) FIGURE 11 LCD MONITOR (M/N: E1950SV) ADAPTER #1 (COVER REMOVED) FIGURE 12 LCD MONITOR (M/N: E1950SV) ADAPTER #1 (MAIN BOARD – COMPONENT SIDE) F IGURE 13 LCD MONITOR (M/N: E1950SV) ADAPTER #1 (MAIN BOARD – SOLDERED SIDE) FIGURE 14 LCD MONITOR (M/N: E1950SV) ADAPTER #2 (GENERAL APPEARANCE) F IGURE 15 LCD MONITOR (M/N: E1950SV) ADAPTER #2 (POWER PORT) FIGURE 16 LCD MONITOR (M/N: E1950SV) ADAPTER #2 (LABEL) FIGURE 17 LCD MONITOR (M/N: E1950SV) ADAPTER #2 (COVER REMOVED) FIGURE 18 LCD MONITOR (M/N: E1950SV) ADAPTER #2 (MAIN BOARD – COMPONENT SIDE) F IGURE 19 LCD MONITOR (M/N: E1950SV) ADAPTER #2 (MAIN BOARD – SOLDERED SIDE)

Label Location Information Refer to the below red arrow: (For example)

FIGURE 1 LCD MONITOR (M/N: E1950SV) COVER REMOVED FIGURE 2 LCD MONITOR (M/N: E1950SV) KEY BOARD (COMPONENT SIDE) F IGURE 3 LCD MONITOR (M/N: E1950SV) K EY BOARD (SOLDERED SIDE) FIGURE 4 LCD MONITOR (M/N: E1950SV) MAIN BOARD (COMPONENT SIDE) F IGURE 5 LCD MONITOR (M/N: E1950SV) M AIN BOARD (SOLDERED SIDE) FIGURE 6 LCD MONITOR (M/N: E1950SV) CHIP & CRYSTAL ON MAIN BOARD F IGURE 7 LCD MONITOR (M/N: E1950SV) LCD PANEL LABEL FIGURE 8 LCD MONITOR (M/N: E1950SV) DISPLAY BOARD (COMPONENT SIDE) F IGURE 9 LCD MONITOR (M/N: E1950SV) D ISPLAY BOARD (SOLDERED SIDE) FIGURE 10 LCD MONITOR (M/N: E1950SV) DEBUG 2 1 3 4 5

LG Electronics U.S.A., Inc. FCC ID: BEJE1950SV 1 Equipment Description The Equipment Under Test (EUT) is the LG Electronics U.S.A., Inc. LCD Monitor. General Specification LG Electronics U.S.A., Inc. FCC ID: BEJE1950SV 2 EUT Operating Conditions a. Setup the EUT and Peripherals as shown in Sec. 3.2 of the test report. b. Turn on the power of all equipment and the EUT. c. Set the contrast & brightness of EUT to maximum. d. PC system ran the self-test program “EMC Test” by windows XP and sent “H” characters to EUT through graphic card, the EUT’s screen displayed and filled with “H” pattern by its resolution (Via D-Sub Input). e. Repeat above procedure from c to d for difference test mode. f. The other peripherals devices were driven and operated during the test. g. The test modes are as follows: Adapter Test Mode ADS-24NP-12-1 12024G D-Sub 640*480@60Hz D-Sub 1024*768@60Hz D-Sub 1360*768@60Hz DSA-36W-12 1 24 D-Sub 640*480@60Hz D-Sub 1024*768@60Hz D-Sub 1360*768@60Hz

LG Electronics U.S.A., Inc. FCC ID: BEJE1950SV Page 1 of 29 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F10026 Prepared For : LG Electronics U.S.A., Inc. 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632, United States Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai 200233, China Tel: +86-21-64955500 Fax: +86-21-64955491 Report No. : ACI-F10026 Date of Test : Mar 01 – 02, 2010 Date of Report : Mar 10, 2010 Application for FCC Certificate On Behalf of LG Electronics U.S.A., Inc. LCD Monitor Model No.: E1950SV Serial No.: 001NDCR8C715 FCC ID : BEJE1950SV LG Electronics U.S.A., Inc. FCC ID: BEJE1950SV Page 2 of 29 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F10026 TABLE OF CONTENTS Page 1 SUMMARY OF STANDARDS AND RESULTS .......................................................................... 4 1.1 Description of Standards and Results ......................................................................................... 4 2 GENERAL INFORMATION .......................................................................................................... 5 2.1 Description of Equipment Under Test ........................................................................................ 5 2.2 Peripherals .................................................................................................................................. 6 2.3 Description of Test Facility ........................................................................................................ 7 2.4 Measurement Uncertainty .......................................................................................................... 7 3 CONDUCTED EMISSION TEST .................................................................................................. 8 3.2 Block Diagram of Test Setup ..................................................................................................... 8 3.3 Conducted Emission Limit [FCC Part 15 Subpart B 15.107(a)] ................................................ 9 3.4 Test Configuration ...................................................................................................................... 9 3.5 Operating Condition of EUT .................................................................................................... 10 3.6 Test Procedures ........................................................................................................................ 10 3.7 Test Results .............................................................................................................................. 11 4 RADIATED EMISSION TEST ..................................................................................................... 18 4.1 Test Equipment ......................................................................................................................... 18 4.2 Block Diagram of Test Setup ................................................................................................... 18 4.3 Radiated Emission Limit [FCC Part 15 Subpart B 15.109(a)] ................................................. 19 4.4 Test Configuration .................................................................................................................... 19 4.5 Operating Condition of EUT .................................................................................................... 20 4.6 Test Procedures ........................................................................................................................ 20 4.7 Test Results .............................................................................................................................. 21 5 DEVIATION TO TEST SPECIFICATIONS .............................................................................. 28 6 DEBUG DESCRIPTION ............................................................................................................... 29 LG Electronics U.S.A., Inc. FCC ID: BEJE1950SV Page 3 of 29 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F10026 TEST REPORT FOR FCC CERTIFICATE Applicant : LG Electronics U.S.A., Inc. Manufacturer : LG Electronics Nanjing Display Co., Ltd. EUT Description : LCD Monitor (A) Model No. : E1950SV (B) Serial No. : 001NDCR8C715 (C) Power Supply : 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 15 SUBPART B CLASS B OCTOBER 2009 AND ANSI C63.4-2003 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart B (Class B) and ICES-003, Issue 4 February 2004 (CISPR 22:2002) limits both radiated and conducted emissions. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. This report shows that the EUT (M/N: E1950SV; S/N: 001NDCR8C715) which was tested in 3m anechoic chamber Mar 01 – 02, 2010 is technically compliance with the FCC official limits also. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report contains data that are not covered by the NVLAP accreditation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. Date of Test : Mar 01 – 02, 2010 Date of Report : Mar 10, 2010 Producer : KATHY WANG / Assistant Review : DIO YANG / Deputy Assistant Manager Signatory : SAMMY CHEN / Assistant Manager LG Electronics U.S.A., Inc. FCC ID: BEJE1950SV Page 4 of 29 Audix Technology (Shanghai) Co., Ltd. Report No.: ACI-F10026 1 SUMMARY OF STANDARDS AND RESULTS 1.1 Description of Standards and Results The EUT have been tested according to the applicable standards as refere…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test F RONT VIEW B ACK VIEW 2. Radiated Electromagnetic Emission Test F RONT VIEW OF RADIATED EMISSION TEST B ACK VIEW OF RADIATED EMISSION TEST S ETUP WITH MAXIMUM DETECTED EMISSION AT HORIZONTAL POLARIZATION (TEST MODE: D-SUB 640*480@60HZ) (ADAPTER: DSA-36W-12 1 24) SETUP WITH MAXIMUM DETECTED EMISSION AT VERTICAL POLARIZATION (TEST MODE: D-SUB 640*480@60HZ) (A DAPTER: DSA-36W-12 1 24)
