www.lg.com OWNER’S MANUAL LCD MONITOR LCD MONITOR MODEL E2722PY Please read this manual carefully before operating your set and retain it for future reference. ENGLISH 1 This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. On Safety Use only the power cord supplied with the unit. In case you use another power cord, make sure that it is certified by the applicable national standards if not being provided by the supplier. If the power cable is faulty in any way, please contact the manufacturer or the nearest authorized repair service provider for a replacement. The power supply cord is used as the main disconnection device. Ensure that the socket-outlet is easily accessible after installation. Operate the display only from a power source indicated in the specifications of this manual or listed on the display. If you are not sure what type of power supply you have in your home, consult with your dealer. Overloaded AC outlets and extension cords are dangerous. So are frayed power cords and broken plugs. They may result in a shock or fire hazard. Call your service technician for replacement. As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the unit is turned off. Do not Open the Display: There are no user serviceable components inside. There are Dangerous High Voltages inside, even when the power is OFF. Contact your dealer if the display is not operating properly. To Avoid Personal Injury : Do not place the display on a sloping shelf unless properly secured. Use only a stand recommended by the manufacturer. Do not drop an object on or apply impact to the product. Do not throw any toys or objects on the product screen. It can cause injury to human, problem to product and damage the display. To Prevent Fire or Hazards: Always turn the display OFF if you leave the room for more than a short period of time. Never leave the display ON when leaving the house. Keep children from dropping or pushing objects into the display's cabinet openings. Some internal parts carry hazardous voltages. Do not add accessories that have not been designed for this display. When the display is to be left unattended for an extended period of time, unplug it from the wall outlet. In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very dangerous. It can cause electric shock. Important Precautions 2 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool. Displays are provided with ventilation openings in the cabinet to allow the release of heat generated during operation. If these openings are blocked, built-up heat can cause failures which may result in a fire hazard. Therefore, NEVER: Block the bottom ventilation slots by placing the display on a bed, sofa, rug, etc. Place the display in a built-in enclosure unless proper ventilation is provided. Cover the openings with cloth or other material. Place the display near or over a radiator or heat source. Do not rub or strike the Active Matrix LCD with anything hard as this may scratch, mar, or damage the Active Matrix LCD permanently. Do not press the LCD screen with your finger for a long time as this may cause some afterimages. Some dot defects may appear as Red, Green or Blue spots on the screen. However, this will have no impact or effect on the display performance. If possible, use the recommended resolution to obtain the best image quality for your LCD display. If used under any mode except the recommended resolution, some scaled or processed images may appear on the screen. However, this is characteristic of the fixed-resolution LCD panel. Leaving a fixed image on the screen for a long time may cause damage to the screen and cause image burn-in. Make sure to use a screen saver on the product. Burn-in and related problems are not covered by the warranty on this product. Do not shock or scratch the front and sides of the screen with metallic objects. Otherwise, it may cause damage to the screen. Make sure the panel faces forward and hold it with both hands to move. If you drop the product, the damaged product can cause electric shock or fire. Contact an authorized the service center for repair. Avoid high temperatures and humidity. For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing reflections from surrounding light and bright surfaces. Important Precautions 3 On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching. Do not clean with a wet cloth or spray water or other liquids directly onto the product. An electric shock may occur. (Do not use chemicals such as benzene, paint thinners or alcohol) Spray water onto a soft cloth 2 to 4 times, and use it to clean the front frame; wipe in one direction only. Too much moisture may cause staining. On Repacking Do not throw away the carton and packing materials. They make an ideal container in which to transport the unit. When shipping the unit to another location, repack it in its original material. On Disposal Do not dispose of this product with general household waste. Disposal of this product must be carried out in accordance to the regulations of your local …

Text truncated - open the document above for the full version.

Regulatory Information cont. FCC Compliance Statement This equipment has been tested and found to comply within the limits of a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception (which can be determined by turning the equipment on and off), the user is encouraged to try to correct the interference by using one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and the receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's (or your) authority to operate the equipment. Only peripherals (digital input/output devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to this monitor. Operation with non-certified peripherals is likely to result in interference to radio and TV reception. Only shielded signal cables may be used with this System. Canadian DOC Notice This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. TCO Displays 5.0 Congratulations, Your display is designed for both you and the planet! This display carries the TCO Certified label. This ensures that the display is designed for minimal impact on the climate and natural environment, while offering all the performance expected from top of the line electronic products. TCO Certified is a third party verified program, where every product model is tested by an accredited independent test laboratory. TCO Certified represents one of the toughest certifications for displays worldwide. Some of the Usability features of the TCO Displays 5.0 requirements: Visual Ergonomics Good visual ergonomics in order to improve the working environment for the user and to reduce sight and strain problems. Important parameters are: • Light levels without color tint, Uniform color and luminance, Wide color gamut • Calibrated color temperature and gamma curve • Wide luminance level, Dark black levels, Low motion blur Electrical Safety • Product fulfills rigorous safety standards 1 NOTICE The regulations are applied only to the products with the ID LABEL indicating specific requirements. NOTICE The regulations are applied only to the products with the ID LABEL indicating specific requirements. NOTICE The following information is for the models certified by TCO. If you want to know the specification of the purchased product, see the label attached on the back of the product. Regulatory Information cont. 2 Emissions • Low alternating electric and magnetic fields emissions • Low acoustic noise emissions Some of the environmental features of the TCO Displays 5.0 requirements: • The brand owner demonstrates corporate social responsibility and has a certified environmental management system (EMAS or ISO 14001) • Very low energy consumption both in on-and standby mode • Restrictions on chlorinated and brominated flame retardants, plasticizers and polymers • Restrictions on heavy metals such as cadmium, mercury and lead (RoHS compliance) • Both product and product packaging is prepared for recycling • The brand owner offers take-back options The requirements included in this label have been developed by TCO Development in co-operation with scientists, experts, users as well as manufacturers all over the world. Since the end of the 1980s TCO has been involved in influencing the development of IT equipment in a more user-friendly direction. Our labeling system started with displays in 1992 and is now requested by users and IT-manufacturers all over the world. For more information, please visit: www.tcodevelopment.com Information for Environmental Preservation LGE. announced the 'LG Declaration for a Cleaner Environment' in 1994, and this ideal has served as a guiding managerial principle ever since. The Declaration is a foundation that has allowed us to undertake environmentally friendly activities in careful consideration of economic, environmental, and social aspects. We promote activities for environmental preservation, and we specifically develop our products to embrace the concept of environment-friendly. We minimize the hazardous materials contained in our products. For example, there is no cadmium to be found in our monitors. Information for recycling This monitor may contain parts which could be hazardous to the environment. It is important that this monitor be recycled after use. LGE. handles all waste monitors through an environmentally acceptable recycling method. There are several take-back and recycling systems currently in operation worldwide. Many parts will be reused and recycled, while harmful substances and heavy metals are treated by an environmentally friendly method. If you want to find out more information about our recycling program, please contact your local LG vendor or a corporate representative of LG. We set our vision and policies on a cleaner world by selecting the issue of the global environment as a task for corporate improvement. Please visit our website for more information about our ‘green’ policies. http://www.lg.com/global/sustainability/environment/take-back- recycling.jsp English Informationen zur Erhaltung der…

Text truncated - open the document above for the full version.

AHTHORIZATION LETTER LG Electronics USA FCC ID: BEJE2722PYB Date: May 10, 2012 To whom it may concern: We, the undersigned, hereby authorize Cerpass Technology (Suzhou) Co., Ltd. of China to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by Cerpass Technology (Suzhou) Co., Ltd. within the scope of this authorization shall have the same effects as our own. This authorization shall expire 2 weeks from original data. If you have any questions regarding the authorization, please don’t hesitate to contact me. Thank you. Yours Sincerely, Christopher/ Sr. Manager LG Electronics USA

LG Electronics USA Date: May 10, 2012 Federal Communications Commission Authorization and Evaluation Division FCC ID: BEJE2722PYB Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1 Schematics 2 Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Christopher/ Sr. Manager LG Electronics USA

LCD Monitor (Model name: E2722PYB) Exterior Photograph: 1.5m 2.0m 1.5m 1.8m

LCD Monitor (Model name: E2722PYB) FCC ID

LCD Monitor (Model name: E2722PYB) Inside photo:

CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1205021 Cerpass Technology (Suzhou) Co., Ltd Issued Date : May 09, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 1 of 19 FCC TEST REPORT According to 47 CFR, Part 2, Part 15 and CISPR PUB. 22 Applicant : LG Electronics USA Address : 1000 Sylvan Avenue Englewood Cliffs New Jersey United States Equipment : LCD Monitor Model No. : E2722PYB FCC ID : BEJE2722PYB
The test result refers exclusively to the test presented test model / sample.
Without written approval of Cerpass Technology Corp. the test report shall not be reproduced except in full.
The test report must not be used by the clients to claim product certification approval by NVLAP or any agency of the Government. CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1205021 Cerpass Technology (Suzhou) Co., Ltd Issued Date : May 09, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 2 of 19 Contents 1. Summary of Test Procedure and Test Result ........................................................................................... 5 2. Test Configuration of Equipment under Test ............................................................................................ 6 2.1. Manufacturer ....................................................................................................................................6 2.2. Feature of Equipment under Test .....................................................................................................6 2.3. Test Manner ......................................................................................................................................6 2.4. Description of Support Unit ..............................................................................................................7 2.5. General Information of Test ..............................................................................................................8 2.6. Measurement Uncertainty ................................................................................................................8 3. Test of Conducted Emission ...................................................................................................................... 9 3.1. Test Limit ..........................................................................................................................................9 3.2. Test Procedures ................................................................................................................................9 3.3. Typical test Setup .......................................................................................................................... 10 3.4. Measurement equipment ............................................................................................................... 10 3.5. Test Result and Data ...................................................................................................................... 11 4. Test of Radiated Emission ........................................................................................................................ 13 4.1. Test Limit ....................................................................................................................................... 13 4.2. Test Procedures ............................................................................................................................. 14 4.3. Typical test Setup .......................................................................................................................... 14 4.4. Measurement equipment ............................................................................................................... 15 4.5. Test Result and Data (30MHz ~ 1000MHz) ................................................................................... 16 4.6. Test Result and Data (1000MHz ~ 18000MHz) ............................................................................. 18 CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1205021 Cerpass Technology (Suzhou) Co., Ltd Issued Date : May 09, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 3 of 19 History of this test report
ORIGINAL.  Additional attachment as following record: Attachment No. Date Description CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1205021 Cerpass Technology (Suzhou) Co., Ltd Issued Date : May 09, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 4 of 19 FCC TEST REPORT According to 47 CFR, Part 2, Part 15 and CISPR PUB. 22 Applicant : LG Electronics USA Address : 1000 Sylvan Avenue Englewood Cliffs New Jersey United States Equipment : LCD Monitor Model No. : E2722PYB FCC ID : BEJE2722PYB I HEREBY CERTIFY THAT : The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4 – 2003 and the energy emitted by this equipment was passed CISPR PUB. 22 and FCC Part 15 in both radiated and conducted emission class B limits. Testing was carried out on May 08, 2012 at Cerpass Technology Corp. Signature Miro Chueh/ Technical director CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1205021 Cerpass Technology (Suzhou) Co., Ltd Issued Date : May 09, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 5 of 19 1. Summary of Test Procedure and Test Result Test Item Normative References Test Result Conducted Emission ANSI C63.4@2003 FCC Part 15 Subpart B PASS Radiated Emission ANSI C63.4@2003 FCC Part 15 Subpart B PASS CERPASS TECHNOLOGY (SUZHOU)CO., LTD Report No.: SEFD1205021 Cerpass Technology (Suzhou) Co., Ltd Issued Date : May 09, 2012 TEL: +86-512-6917-5888 FAX: +86-512-6917-5666 Page No. : 6 of 19 2. Test Configuration of Equipment under Test 2.1. Manufacturer LG Electronics Nanjing Display Co.,Ltd. No.346,Yaoxin Road Economic & Technical Development Zone Nanjing China 2.2. Feature of Equipment under Test LCD Monitor Model No: E2722PYB VGA Cable Shielded, 1.5m VGA Cable …

Text truncated - open the document above for the full version.

LCD Monitor (Model name: E2722PYB) Front View of Conducted Emission Test Back View of Conducted Emission Test Front View of Radiated Emission Test (30MHz ~ 1000MHz) Back View of Radiated Emission Test (30MHz ~ 1000MHz) Front View of Radiated Emission Test (1000MHz ~ 18000MHz) Back View of Radiated Emission Test (1000MHz ~ 18000MHz)
