BEJF1200Single-Band PCS GSM Phone

Some of contents in this manual may differ from your phone depending on the software of the phone or your service provider. F1200 User Guide 2 Introduction Congratulations on your purchase of the advanced and compact F1200 mobile phone, designed to operate with the latest digital mobile communication technology. This user guide contains important information on the use and operation of this phone. Please read all the information carefully for optimal performance and to prevent any damage to or misuse of the phone. Any changes or modifications not expressly approved in this user’s guide could void your warranty for this equipment. F1200 User Guide Guidelines for safe and efficient use F1200 User Guide 3 Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual. Exposure to radio frequency energy Radio wave exposure and Specific Absorption Rate (SAR) information This mobile phone model T5100 has been designed to comply with applicable safety requirement for exposure to radio waves. This requirement is based on scientific guidelines that include safety margins designed to assure this safety of all persons, regardless of age and health. ● The radio wave exposure guidelines employ a unit of measurement known as the Specific Absorption Rate, or SAR. Tests for SAR are conducted using standardized method with the phone transmitting at its highest certified power level in all used frequency bands. ● While there may be differences between the SAR levels of various LG phone models, they are all designed to meet the relevant guidelines for exposure to radio waves. ● The SAR limit recommended by the International Commission on Non-Ionizing Radiation Protection (ICNIRP), which is 2W/kg averaged over ten (10) gram of tissue. ● The highest SAR value for this model phone tested by IDX for use at the ear is 0.66 W/kg (1g). ● SAR data information for residents in countries/regions that have adopted the SAR limit recommended by the Institute of Electrical and Electronics Engineers (IEEE), which is 1.6 W/kg averaged over one (1) gram of tissue. Guidelines for safe and efficient use Product care and maintenance Warning: Use only batteries, charger and accessories approved for use with this particular phone model. The use of any other types may invalidate any approval or warranty applying to the phone, and may be dangerous. ● Do not disassemble this unit. Take it to a qualified service technician when repair work is required. ● Keep away from electrical appliance such as a TV, radio or personal computer. ● The unit should be kept away from heat sources such as radiators or cookers. ● Do not drop. ● Do not subject this unit to mechanical vibration or shock. ● The coating of the phone may be damaged if covered with wrap or vinyl wrapper. ● Use dry cloth to clean the exterior of the unit. (Do not use solvent such as benzene, thinner or alcohol.) ● Do not subject this unit to excessive smoke or dust. ● Do not keep the phone next to credit cards or transport tickets; it can affect the information on the magnetic strips. ● Do not tap the screen with a sharp object; otherwise, it may damage the phone. ● Do not expose the phone to liquid or moisture. ● Use the accessories like an earphone cautiously. Efficient phone operation To enjoy optimum performance with minimum power consumption please: 4 F1200 User Guide Guidelines for safe and efficient use ● Hold the phone as you speak to any other telephone. While speaking directly into the microphone, angle the antenna in a direction up and over your shoulder. If the antenna is extendable/ retractable, it should be extended during a call. ● If your mobile phone supports infrared, never direct the infrared ray at anyone’s eye. Electronics devices All mobile phones may get interference, which could affect performance. ● Do not use your mobile phone near medical equipment without requesting permission. Avoid placing the phone over the pacemaker, i.e. in your breast pocket. ● Some hearing aids might be disturbed by mobile phones. ● Minor interference may affect TVs, radios, PCs, etc. Road Safety Check the laws and regulations on the use of mobile phones in the areas when you drive. ● Do not use a hand-held phone while driving. ● Give full attention to driving. ● Use a hands-free kit, if available. ● Pull off the road and park before making or answering a call if driving conditions so require. ● RF energy may affect some electronic systems in your motor vehicle such as car stereo, safety equipment. ● When your vehicle is equipped with an air bag, do not obstruct with installed or portable wireless equipment. It can cause serious injury due to improper performance. F1200 User Guide 5 F1200 User Guide 6 Guidelines for safe and efficient use Blasting area Do not use the phone where blasting is in progress. Observe restrictions, and follow any regulations or rules. Potentially explosive atmospheres ● Do not use the phone at a refueling point. Don’t use near fuel or chemicals. ● Do not transport or store flammable gas, liquid, or explosives in the compartment of your vehicle, which contains your mobile phone and accessories. In aircraft Wireless devices can cause interference in aircraft. ● Turn off your mobile phone before boarding any aircraft. ● Do not use it on the ground without crew permission. Children Keep the phone in a safe place out of children’s reach. It includes small parts which if detached may cause a choking hazard. Emergency calls Emergency calls may not be available under all cellular networks. Therefore, you should never depend solely on the phone for emergency calls. Check with your local service provider. Battery information and care ● You do not need to completely discharge the battery before recharging. Unlike other battery systems, there is no memory effect that could compromise the battery’s performance. F1200 User Guide 7 Guidelines for safe and efficient use ● Use only LG batteries an…
