BEJGS155ACellular/PCS GSM Phone

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jan 31, 2010
Application Purpose: Original Equipment
Date of Application: Jan 31, 2010
Equipment Note: Cellular/PCS GSM Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Part 15.21 statement" Change or Modifications that ar e not expressly ap proved by the manufacturer could void the user's authority to operate the equipment. “ Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B di gital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide re asonable protection against harmful interference in a residential installation. This equi pment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer ence will not occur in a particular installati on. if this equipment does cause harmful interference or television reception, which can be determined by turning the equi pment off and on, the user is encouraged to tr y to correct the interference by one or more of the fo llowing measures: - Reorient or relocate the receiving antenna. - Increase the separation betwee n the equipment and receiver. - Connect the equipment into an outlet on a circuit diffe rent from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Part 15 Class B ComplianceThis device and its accessories co mply with part15 of FCC rules. Operation is subject to th e following two conditions: (1) This device & its accessories may not cause harmful interference.(2) This device & its accessories must accept any interference received, including interference that ma y cause undesired operation. Body-worn OperationThis USB modem has bee n tested for typical body-worn operations with the distance of 0.79inches (2.0cm) from the user’s body. To comply with FCC RF exposure requirem ents, a minimum separation distance of 0.79inches(2.05cm) must be ma intained from the user's body. Menu map Organiser 1 Alarm 2 Calendar 3 Memo My stuff 1 Images 2 Sounds 3 Others Games 1 Space ball Profi les 1 General 2 Silent 3 Vibrate only 4 Outdoor 5 Headset Call history 1 All calls 2 Missed calls 3 Dialled calls 4 Received calls 5 Call duration Messaging 1 New message 2 Inbox 3 Drafts 4 Outbox 5 Sent 6 Listen to voicemail 7 Info messages 8 Templates 9 Settings Settings 1 Profi le 2 Date & Time 3 Languages 4 Display 5 Fake call 6 Call 7 Auto keylock 8 Security 9 USB connection 0 Network selection * Reset settings # Memory status Browser 1 Home 2 Bookmarks 3 Enter address 4 History 5 Saved pages 6 Settings 7 Information Tools 1 Torch 2 Calculator 3 Stopwatch 4 Unit converter 5 World clock Connectivity 1 Bluetooth 2 Network 3 USB connection Media 1 Camera 2 MP3 player 3 FM radio Contacts 1 Search 2 New contact 3 Speed dials 4 Groups 5 Copy all 6 Delete all 7 Memory status 8 Information Calls Making a call 1 Key in the number using the keypad. To delete a digit press . 2 Press to initiate the call. 3 To end the call, press . TIP! To enter + when making an international call, press and hold 0. Making a call from your contacts 1 Press to open the address book. 2 Using the keypad, enter the fi rst letter of the contact you want to call. For example, for Offi ce, press 6 three times. 3 To scroll through the contacts and their diff erent numbers use and . 4 Press to initiate the call. Answering and rejecting a call When your phone rings, press Accept or press to answer the call. While your phone is ringing, select Silent to mute the ringing. This is great if you have forgotten to change your profi le to Silent for a meeting. Press or Reject to reject the incoming call. TIP! You can change the settings on your phone to answer your calls in diff erent ways. Press Menu, select Settings and choose Call. Select Answer mode and choose from Any key or send key only. Changing the call settings You can set the menu relevant to a call. Press Menu, select Settings and choose Call. • Call barring – Select when you would like calls to be barred. • Fixed dial number – Choose a list of numbers that can be called from your phone. You’ll need your PIN2 code from your operator. Only numbers included in the fi xed dial list can be called from your phone. Contacts Searching for a contact You can search for a contact in your contacts. 1 Press Contacts and choose Search, select Contacts from the Menu screen or press from the standby screen. 2 Using the keypad enter the fi rst letter of the contact you want to call. For example, for Offi ce, press 6 three times. 3 To scroll through the contacts and their diff erent numbers use and . Messaging Your GS155a includes functions related to SMS (Short Message Service), MMS (Multimedia Message Service) and Bluetooth, as well as the network’s service messages. Sending a message 1 Press Menu, select Messaging and choose New message. 2 Choose Message to send an SMS or MMS. 3 A new message editor will open. Message editor combines SMS and MMS into one intuitive and easy to switch between SMS mode and MMS mode. The default setting of the message editor is SMS mode. 4 Enter your message using either the T9 predictive mode or Abc manual mode. You can switch text input mode by pressing . TIP! You can select your message type as SMS or MMS when you enter a text longer than 2 pages in the message fi eld. 5 Press Options and choose Insert to add an Symbol, Text template, Emoticon, Name&Number. 6 Press Send to. 7 Enter the phone number or press Options and select Contacts or Recent list to open your contacts list. You can add multiple contacts. 8 Press Send. Entering text You can enter alphanumeric characters using the phone’s keypad. For example, storing names in Contacts, writing a message and creating scheduling events in the calendar all require entering text. The following text input methods are available in the phone: T9 predictive mode, ABC manual mode and 123 mode. Note: Some fi elds may allow only one text input mode (e.g. telephone number in address book fi elds). T9 predictive mode T9 predictive mode uses a built-in d…

Text truncated - open the document above for the full version.

Cover Letter(s)

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: January 12, 2010 Fede ral Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJGS155A Equipment Class: P CE: PCS Licensed Transmitter held to ear To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Sch ematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User's Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

Cover Letter(s)

From: 한봉효 Sent: Monday, February 01, 2010 3:40 AM To: PCTEST TCB/CB; HCT - SunHee Kim Subject: Re : Questions Regarding FCC ID: BEJGS155A Importance: High Hello PCTEST TCB, Thank you for your cooperation! Please see the response below and find the attachments. Thank you! Best regards Han. ----- Original Message ----- From: PCTEST TCB/CB To: HCT - SunHee Kim Sent: Saturday, January 16, 2010 3:24 AM Subject: Questions Regarding FCC ID: BEJGS155A To: Ms. Sun-Hee Kim / HCT From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: BEJGS155A Applicant: LG Electronics Inc. Correspondence Reference Number: BEJ0046 Confirmation Number: 1Y1001130046 Date of Original Email: January 15, 2010 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1.The Block Diagram and User’s Manual indicate the existence of a USB interface for the EUT. If this is the case, please provide a JBP test report for this application. → Please find the attachment.(Part15B EMI Test Report) 2.The Operational Description document indicates that the EUT contains GPRS Class 12 multislot capability. Please confirm that this is not implemented in the EUT. → This EUT supports voice call only. 3.The PCS GSM body SAR levels are very low (below 0.1 W/kg). Please verify that the EUT was operating at full power during these tests and that these levels are correct or retest if necessary. → I confirm that the EUT was operating at full power during these tests. As you know, this EUT supports Voice call only, so the body SARs will be lower than PCS head SARs because body SAR is measured with 2cm space. Therefore, I think it's reasonable that the PCS body SAR is very low. The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

External Photos

ID Label/Location Info

Model No: G S 155a FCC ID : BEJ G S 155A S/N :tt GGr LG Electronics Inc. LGE

Internal Photos

Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 12 INTERNAL PHOTOGRAPHS Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ８ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ９ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １０ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １１ of 12 ■ INTERNAL PHOTO Report No.: HCTR1001FR09 FCC ID: BEJGS155A DATE: January 13, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １２ of 12 ■ INTERNAL PHOTO

RF Exposure Info

MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No: MCCL-3-10-001 Page 1 of 76 MCCL SAR TEST REPORT Specific Absorption Rate Issued under the authority of E. S. Park / Technical Manager MCCL Reviewed by J. S. Jang /Vice Technical Manager MCCL This report may not be reproduced other than in full, except with the prior written approval by MCCL December 07, 2009Date of Sample Receipt : January 09, 2010 Pre-Production Sample [S/N: #1] Date of Issue : Test Device Serial No. : §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Standards : PASSTest Result : Licensed Portable Transmitter Held to Ear (PCE)Device Category : LG Electronics, Inc. Certification Applicant : Application Type : LG Electronics, Inc.Manufacturer : GS155aModel Name(s) : Cellular/PCS GSM PhoneProduct : Test Report No : MCCL-3-10-001 SUMMARY This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI / IEEE C95.1(2005) and had been tested in accordance with the measurement procedures specified in FCC/OET bulletin 65 Supplement C (2001) , ANSI / IEEE 1528 – Dec. 2003 and in applicable Industry Canada Radio Standards specifications (RSS) ※ The test results in this test report apply only to sample(s) tested. Prepared by C. H. Jeong / Test Engineer MCCL MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No: MCCL-3-10-001 Page 2 of 76 MCCL TABLE OF CONTENTS 1. TEST RESULT SUMMARY ········································································································3 2. DESCRIPTION OF THE DEVICE UNDER TEST·························································· 4 2.1 Antenna Description·································································································· 4 2.2 Device Description···································································································· 4 3. INTRODUCTION············································································································· 5 4. SAR MEASUREMENT SYSTEM ·················································································· 6 4.1 SAR Measurement Setup·························································································6 4.2 DASY4 E-Field Probe System·················································································· 7 4.3 Phantom···················································································································· 9 4.4 Brain & Muscle Simulating Mixture Characterization ···········································10 4.5 Device Holder for Transmitters··············································································· 11 4.6 Validation Dipole ···································································································· 11 5. SAR MEASUREMENT PROCEDURE········································································· 12 6. DEFINITION OF REFERENCE POINT········································································ 13 6.1 EAR Reference Point······························································································ 13 6.2 Handset Reference Points······················································································ 14 7. TEST CONFIGURATION POSITIONS········································································ 15 7.1 Positioning for Cheek/Touch··················································································· 15 7.2 Positioning for Ear / 15 ° Tilt···················································································· 16 7.3 Body Holster /Belt Clip Configuration······························································· 17 8. MEASUREMENT UNCERTAINTY··············································································· 18 9. ANSI/IEEE C95.1–2005 RF EXPOSURE LIMITS ····················································· 19 10. SYSTEM VERIFICATION··························································································· 20 11. RF CONDUCTED POWER ····················································································· 22 11.1 Procedures Used To Establish Test Signal··································································· 22 12. MEASUREMENT RESULTS ····················································································· 23 13. TEST EQUIPMENT····································································································· 25 14. REFERENCES············································································································ 26 APPENDIX A: Validation Test Data······································································ 27 APPENDIX B: SAR Test Data··············································································· 33 APPENDIX C: Calibration Certificates································································· 54 MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1114, Fax:+82 2 2033 1222 Test Report No: MCCL-3-10-001 Page 3 of 76 MCCL 1.TEST RESULT SUMMARY Maximum Results Found During SAR Evaluation 1. Head Configuration 2. Body Worn Configuration 3. Measurement Uncertainty 1.6 W/kg averaged over 1 gram ANSI / IEEE C95.1(2005) - SAFETY LIMIT Spatial Peak Uncontrolled Exposure/General Population 1.6 W/kg averaged over 1 gram ANSI / IEEE C95.1(2005) - SAFETY LIMIT Spatial Peak Uncontrolled Exposure/General Population Eui-Soon ParkResponsible Test Engineer : January 09, 2010 Date of Issue : GSM850: 32.5 dBm PCS1900: 29.5 dBm Transmit Output Power : 869.20 ~ 893.80 MHz (GSM850) 1930.20 ~ 1989.80 MHz (PCS1900) Rx Frequency : Cellular/PCS GSM PhoneEUT Type : 60-39, Kasan-Dong, Kumchon-Gu, Seoul 153-801, Korea.Address of Test Site : 824.…

Text truncated - open the document above for the full version.

Test Report

FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1001FR09 Date of Issue: January 13, 2010 EUT Type: Cellular/ PCS GSM Phone FCC ID: BEJGS155A Page 2 of 36 Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 3 2. INTRODUCTION ........................................................................................................................................... 4 2.1. EUT DESCRIPTION............................................................................................................................ 4 2.2. MEASURING INSTRUMENT CALIBRATION .................................................................................... 4 2.3. TEST FACILITY .................................................................................................................................. 4 3. DESCRIPTION OF TESTS ........................................................................................................................... 5 3.1 Effective Radiated Power/Equivalent Isotropic Radiated Power................................................... 5 3.2 Peak- to- Average Ratio ..................................................................................................................... 6 3.3 Occupied bandwidth. ......................................................................................................................... 7 3.4 Spurious and Harmonic Emissions at Antenna Terminal. ............................................................. 8 3.5 Radiated Spurious and Harmonic Emissions ................................................................................. 9 3.6 Frequency stability / variation of ambient temperature ............................................................... 10 4. LIST OF TEST EQUIPMENT .......................................................................................................................11 5. SUMMARY OF TEST RESULTS ................................................................................................................ 12 6. SAMPLE CALCULATION ........................................................................................................................... 13 7. TEST DATA ................................................................................................................................................. 14 7.1 Conducted Output Power ................................................................................................................ 14 7.2 Peak-to-Average Ratio ..................................................................................................................... 14 7.3 Occupied Bandwidth........................................................................................................................ 15 7.4 Conducted Spurious Emissions ..................................................................................................... 15 7.4.1 Band Edge .............................................................................................................................. 15 7.5 Effective Radiated Power Output (E.R.P)(GSM850) ...................................................................... 16 7.6 Equivalent Isotropic Radiated Power (E.I.R.P.) (GSM1900 ) ........................................................ 17 7.7 Radiated Spurious Emissions......................................................................................................... 18 7.7.1 Radiated Spurious Emissions (GSM850 Mode) .................................................................. 18 7.7.2 Radiated Spurious Emissions (GSM1900 Mode) ................................................................ 19 7.8 Frequency stability / variation of ambient temperature ............................................................... 20 7.8.1 FREQUENCY STABILITY (GSM850) ..................................................................................... 20 7.8.2 FREQUENCY STABILITY (GSM1900) ................................................................................... 21 8. TEST PLOTS............................................................................................................................................... 22 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1001FR09 Date of Issue: January 13, 2010 EUT Type: Cellular/ PCS GSM Phone FCC ID: BEJGS155A Page 3 of 36 MEASUREMENT REPORT 1. GENERAL INFORMATION Applicant Name: LG Electronics, Inc. Address:60-39, Gasan-dong, Gumchon-gu, Seoul, 153-023, Korea FCC ID: BEJGS155A Application Type: Certification FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §22, §24, §2 EUT Type: Cellular/ PCS GSM Phone Model(s): GS155a Battery Model Name: Power Rating: Type: LGIP-531A(Standard) 3.7 V, 950 mAh Lithium Ion Battery Tx Frequency:824.20 – 848.80 MHz (GSM850) 1 850.20 – 1 909.80 MHz (GSM1900) Rx Frequency: 869.20 – 893.80 MHz (GSM850) 1 930.20 – 1 989.80 MHz (GSM1900) Max. RF Output Power:1.514 W ERP GSM850 ( 31.80 dBm) / 0.590 W EIRP GSM1900 ( 27.71 dBm) Emission Designator(s): 249KGXW (GSM850), 247KGXW (GSM1900) Antenna Specification Manufacturer: LS Mtron Co., Ltd. Antenna type: Internal Antenna Peak Gain: -0.403 dBi Date(s) of Tests: January 13, 2010 ~ January 05, 2010 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1001FR09 Date of Issue: January 13, 2010 EUT Type: Cellular/ PCS GSM Phone FCC ID: BEJGS155A Page 4 of 36 2. INTRODUCTION 2.1. EUT DESCRIPTION The LG Electronics, Inc. GS155a Cellular/ PCS GSM Phone consists of GSM850 and GSM1900. 2.2. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. 2.3. TEST FACILITY The op…

Text truncated - open the document above for the full version.

Test Setup Photos

MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 1 of 10 MCCL SAR Test Setup Photographs Figure 1 Right Head SAR Test Setup - Cheek Touch Position MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 2 of 10 MCCL Figure 2 Right Head SAR Test Setup - Ear Tilt Position MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 3 of 10 MCCL Figure 3 Left Head SAR Test Setup - Cheek Touch Position MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 4 of 10 MCCL Figure 4 Left Head SAR Test Setup - Ear Tilt Position MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 5 of 10 MCCL Figure 5 Body SAR Test Setup – w/o Holster MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 6 of 10 MCCL Figure 6 Body SAR Test Setup – w/o Holster MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 7 of 10 MCCL Figure 7 DUT Photo MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 8 of 10 MCCL Figure 8 DUT Photo MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 9 of 10 MCCL Figure 9 DUT Photo MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Page 10 of 10 MCCL Figure 10 DUT Photo

Test Setup Photos

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)

[email protected]201-470-2696Fax: 201-816-2003

Technical Contact

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

HCT Co., LTDSang Lee

[email protected]82-31-645-6420Fax: 82-31-645-6401

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	590.00 mW	247KGXW	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operation is based on a separation distance of 2.0 cm between the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters not listed in this filing may not contain metallic components. The highest reported SAR values are: Part 22 - Head: 1.28 W/kg; Body-worn: 0.59 W/kg; Part 24 - Head: 0.31 W/kg; Body-worn: 0.10 W/kg. This device also contains filings that are not operational in U.S. Territories. This filing is only applicable for US operations.
