Order Number : GETEC-C1-12-281 FCC Part 15 subpart B Test Report Number : GETEC-E3-12-096 Page 1 / 1 EUT Type: LED LCD Monitor FCC ID.: BEJIPS237WY APPENDIX G : USER’S MANUAL www.lg.com OWNER’S MANUAL IPS LED MONITOR IPS237W Please read this manual carefully before operating your set and retain it for future reference. IPS LED MONITOR MODEL ENGLISH 2 ENG ENGLISH TABLE OF CONTENTS CONTENTS 3 LICENSES 4 KEY FEATURES 4 ADVANCED FEATURES OF LG IP- S237W WITH LG SmartShare 5 ASSEMBLING AND PREPAR- ING 5 Unpacking 6 Parts and buttons 7 Setting up the Monitor set 7 - Attaching the Stand Base 8 - Detaching the Stand Base 8 - Mounting on a table 9 - Using the cable holder 11 USING THE MONITOR SET 11 - LG SmartShare 13 - Supported Files for LG SmartShare 14 - Connecting or Disconnecting Wireless Router 20 - Keyboard and Mouse Connection 21 WIRED CONNECTION 21 - D-SUB connection 21 - HDMI connection 22 - Smartphone (MHL) Connection 24 WIRELESS CONNECTION 24 - Wi-Di Connection 28 - Miracast Connection 32 - Using DLNA 33 SOFTWARE UPDATE 34 CUSTOMIZING SETTINGS 35 Customizing Settings 35 - Menu Settings 36 - PICTURE 37 - COLOR 38 - DISPLAY 39 - OTHERS 40 Wi-Fi Setting 41 FUNC. Setting 41 - VOLUME 41 - TRUE COLOR FINDER 42 - SUPER ENERGY SAVING 43 TROUBLESHOOTING 46 SPECIFICATIONS 47 Preset Modes (Resolution) 47 Indicator 48 PROPER POSTURE 48 Proper posture for using the Monitor set. 3 ENG ENGLISH LICENSES LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. 4 ENG ENGLISH KEY FEATURES KEY FEATURES ADVANCED FEATURES OF LG IPS237W WITH LG SmartShare With the LG SmartShare for LG IPS237W, the user environment of the monitor becomes smart.  Miracast function to wirelessly shares the screen of a smartphone or other devices.  Wireless Display (Wi-Di) function to display high-definition screen (720p, 1080p) by connecting a computer to the monitor wirelessly.  Digital Living Network Alliance (DLNA) function to play media contents (picture, video, music) stored in a computer, mobile phone, camera, etc.  Mobile High-definition Link (MHL) function to play video and sound from a smartphone on the monitor by connecting the smartphone to the monitor.  Automatic software update simply by connecting to Internet without user interaction.  Connect a keyboard and a mouse to the monitor and use with the computer or other wireless devices.  Support various DRM technologies, such as HDCP 2.0 and DTCP, for content security.  Crystal clear screen at any angle with the IPS panel that gives you 178 degree wide viewing on up/ down/left/right.  Full HD widescreen with 1920 x 1080 resolution and 16:9 viewing ratio optimized for video, game, Internet and paper work.  Two HDMI ports to provide easy connection to various devices such as VCR, DVD and PC.  Surround speaker to provide live sound.  Stylish ultra-slim bezel and touch buttons. LG _Monit or_C54A 2233 /PU
$POOFD UF E You can enjoy contents from smart devices directly on your monit or screen through SmartShare feature. Please execute Miracast, WiDi , DLNA function of your devices t hat you would like to conne ct to your monito r. Press 'Wi-Fi' button for settings 5 ENG ENGLISH ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.  Do not use any unapproved accessories to ensure the safety and product life span.  Any damages or injuries by using unapproved accessories are not covered by the warranty.  The accessories supplied with your product may vary depending on the model.  Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. CAUTION NOTE Stand BodyStand Base CD(Owner's Manual) / Card D-SUB Cable (This cable is not included in all countries.) ( Depending on the country )( Depending on the country ) Power CordAC-DC AdapterAC-DC Adapter or Two Screws MHL Cable (This cable is not included in all countries.) or 6 ENG ENGLISH ASSEMBLING AND PREPARING Parts and buttons Power Indicator  Lighting On: Turned on  Lighting Off: Turned off Connection panel (See p.11) Button (See p.34) (Power Button) 7 ENG ENGLISH ASSEMBLING AND PREPARING Setting up the Monitor set Attaching the Stand Base 1 Place the Monitor set with the screen side down on a flat and cushioned surface. Lay a foam mat or soft protective cloth on the surface to protect the screen from damage. CAUTION 2 Attach the Stand Body to the monitor. Insert the two Lockers of the Stand Body right into the groove of the monitor head and secure them by pressing the left and right bottom sides. Locker 3 Secure the monitor and the Stand Body with the 2 screws. 4 Attach the Stand Base from the Stand Body by turning the screw to the right with a Coin . Tighten the screws firmly to prevent the monitor from tilting forward. Do not over tighten. CAUTION If you don`t fasten the screw tightly, monitor will fall down and get damaged. WARNING 8 ENG ENGLISH ASSEMBLING AND PREPARING Mounting on a table 1 Lift and tilt the Monitor set into its upright position on a table. Leave a 10 cm (minimum) space from the wall for proper ventilation. 2 Connect the AC-DC Adapter and Power Cord to a wall outlet. 10 cm 10 cm 10 cm 10 cm or 2 Turn the screw to the left, and then pull out the Stand Base from the Stand Body . Detaching the Stand Base 1 Place the monitor with the screen side down on a flat and cushioned surface. 3 Remove 2 screws and pull out the Stand Body from the monitor. Connect the power cable at the back of the monitor to prevent it from being caught in the stand body. CAUTION 9 ENG ENGLISH ASSEMBLING AND PREPARING Using the cable hol…
