Applicant: Telian Corp. FCC ID : NPQI170 TUNE-UP PROCEDURE There are no user accessible adjustments or tuning in this GSM phone. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process as special equipment is required to perform such adjustments.
1 PRODUCT SPECIFICATION SEKWANGProvider SKA703-0000AAPart No. MGQ3180 (I170)Model Name TELIANCustomer INTENNAProduct Name No.: SEKWANG 2007-4 Date : 2007. 4. 09 ApprovedChecked CheckedSubmitted SEKWANG 2 -Table of Contents - 1. Product History ---------------------------------------------3 2. Electrical Feature -------------------------------------------- 4 2.1 Frequency Band 2.2 Impedance 2.3 Matching circuit 2.4 VSWR 2.5 Directive ness 2.6 Maximum Power 3. Environment Test --------------------------------------------6 3.1 Operating Temperature Test 3.2 Temperature Cycling Test 3.3 Corrosion Resistance test 4. Electric Performance Data ------------------------------------- 8 4.1 Smith-Chart & VSWR 4.2 3D Gain Data 3 1. Product History 19 17 18 20 21 22 25 24 23 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 임시승인원 07.04.09 1 RemarkChangesDataNo. 4 2. Electrical Feature 2.1 Frequency Band 2.2 Impedance 2.2.1 Input Impedance - R =50Ω 2.2.2 Measuring Method By using Network Analyzer, connect the antenna installed handset to the reflection point of Analyzer and measure the impedance value within the designated frequency band. 2.3 Matching circuit Matching Circuit is composed in free space of 2.1 frequency band while satisfying customer’s requirements. Figure 2.3.1 Matching circuit 1710MHz ~ 1785MHz Rx 1710MHz ~ 1785MHz Tx DCS1800 1805MHz ~ 1880MHz Rx 1710MHz ~ 1785MHz Tx GSM900 1930MHz ~ 1990MHz 1850MHz ~ 1910MHz 869MHz ~ 894MHz 824MHz ~ 849MHz RxTxRxTx FREQUENCY PCSGSM850BAND 5 2.4 VSWR Impedance Matching optimization is performed under the below mentioned environment. 2.4.1. Free Space Environment 2.4.2 Measuring Method Connect (soldering) 50Ω semi-rigid coaxial cable to the 50Ω spot in handset. To minimize the loss of transmission, semi-rigid coaxial cable is used. Including PCB, the handset shouldn’t be different from the one, which will be used for mass production. Specification should be the same for all frequency bands. Free Space means that Handset is put on the surface o...
DEMC#DR50110705W Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 1 of 24 683-3, Yubang-Dong, Yongin-Si, Kyunggi-Do, Korea. 449-080 Tel: +82-31-321-2664 Fax: +82-31-321-1664 http://www.digitalemc.com SAR TEST REPORT Dates of Tests: May 25~28, 2007 Test Report S/N:DR50110705W Test Site : DIGITAL EMC CO., LTD. FCC ID APPLICANT FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) EUT Type: GSM850/PCS1900 Dual Band GPRS Terminal with Bluetooth Equipment Model Name i170 Add Name MGQ3180C Brand Name Very Kool Test Device Serial No.: Identical prototype TX Frequency Range: 824.20 ~848.80 MHz (GSM850) 1850.20 ~ 1909.80 MHz (PCS1900) RX Frequency Range: 869.2 ~893.8 MHz (GSM850) 1930.2 ~ 1989.8 MHz (PCS1900) Max. RF Output Power: 0.456 W ERP GSM850 (26.59dBm) 0.981 W EIRP PCS1900 (29.92dBm) Max. SAR Measurement: 0.558 mW/g GSM850 Head SAR // 0.515 mW/g GSM850 GPRS Body SAR 0.839 mW/g PCS1900 Head SAR // 0.833 mW/g PCS1900 GPRS Body SAR Application Type: Certification Rule Part(s): §2.1093; FCC/OET Bulletin Supplement C[July 2001] Data of issue: May 30, 2007 Tested by : Reviewed by : Sun-Kyu Ryu (Engineer) Harvey Sung (Chief Engineering Director) This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-2003. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NPQI170 Telian Corporation DEMC#DR50110705W Copyright ○ c 2007, DIGITAL EMC Co., Ltd. Page 2 of 24 1. INTRODUCTION ............................................
