Application Details
- Equipment Class
- DSS - Part 15 Spread Spectrum Transmitter
- Date of Grant
- Dec 19, 2007
- Application Purpose
- Original Equipment
- Date of Application
- Dec 17, 2007
- Equipment Note
- Cellular/ PCS GSM/ EDGE Phone with Bluetooth
- Frequency Range
- 2402.00000000 - 2480.00000000
- Company
- LG Electronics USA, Inc.
- Country
- United States
Documents & Files
Select a file to view
Users Manual
Attestation Statements
Cover Letter(s)
External Photos
ID Label/Location Info
Internal Photos
Test Report
Test Setup Photos
Document Text Content (7 documents)
Cover Letter(s)
OPERATIONAL DESCRIPTION Ubitag V2.2 FCC ID SEATAG22 The Ubitag V2.2 is a wireless device intended to be used for the real-time location of objects within buildings. It transmits ultra-wideband (UWB) pulses which are picked up by a network of basestations (Ubisensors) placed inside the building, allowing the 3D position of the tag to be found. The use of UWB technology enables greater positioning accuracy within buildings than other wireless technologies, because it is much less susceptible to multipath interference effects. Applications of the system include healthcare, workplace productivity, security, retail management and manufacturing. The Ubitag V2.2 is a composite device consisting of an ultra-wideband transmitter, a conventional radio transceiver operating in the range 2402.5-2480.5MHz, and associated digital circuitry. It is never the case that both the ultra-wideband transmitter section of the device and the conventional radio transceiver section of the device are active simultaneously. Both the ultra-wideband transmitter and the conventional radio transceiver utilise permanently attached antennas that are integral to the device.
Cover Letter(s)
APPLICANT: Ubisense Limited FCC ID: SEATAG22 Report#: W:\U\Ubisense_SEA\2096AUT7\SEATAG22_15_517_TestReport.DOC Page 1 of 20 FCC PT 15.517 & PT 15.249 COMPOSITE DEVICE Pt 15.517 UWB TEST REPORT APPLICANT Ubisense Limited ADDRESS St Andrew’s House, 90 St. Andrew’s Road Chesterton, Cambridge CB4 1DL England FCC ID SEATAG22 MODEL NUMBER UBITAG7022 PRODUCT DESCRIPTION UWB Tag DATE SAMPLE RECEIVED May 22, 2007 DATE TESTED May 22, 2007 TESTED BY Mario de Aranzeta APPROVED BY Mario de Aranzeta TIMCO REPORT NO. SEATAG22_15_517_TestReport.pdf TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 Email: [email protected] Email: [email protected] HTTP://WWW.TIMCOENGR.COM Certificate # 0955-01 APPLICANT: Ubisense Limited FCC ID: SEATAG22 Report#: W:\U\Ubisense_SEA\2096AUT7\SEATAG22_15_517_TestReport.DOC Page 2 of 20 TABLE OF CONTENTS ATTESTATION STATEMENT....................................................................................... 3 REPORT SUMMARY................................................................................................... 4 TEST ENVIRONMENT AND TEST SETUP ................................................................... 4 DUT DESCRIPTION ................................................................................................... 5 EMC EQUIPMENT LIST ............................................................................................. 6 TEST PROCEDURES ................................................................................................. 7 OPERATIONAL RESTRICTIONS.................................................................................. 9 ULTRA-WIDEBAND 10 dB BANDWIDTH .................................................................. 10 FIELD STRENGTH SPURIOUS EMISSIONS (below 960 MHz) .................................... 11 RADIATED...
Contact Information
Applicant
David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)
Technical Contact
PCTEST Engineering Laboratory, Inc.Randy Ortanez
[email protected]410-290-6652
Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.40 mW |
