BEJKT610PCS GSM/ EDGE Phone with Bluetooth

KT610 USER GUIDE This document is the user guide for the LG KT610 3G Video Mobile Phone. All rights for this document are reserved by LG Electronics. Copying, modifying and distributing this document without the consent of LG Electronics are prohibited. ENGLISH 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the Eur opean Dir ective 2002/9 6/EC. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. 3. The correct disposal of your old appliance will help prevent potential negative consequences for the environment and human health. 4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop wher e y ou pur cha sed the product. Disposal of your old appliance Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. " Part 15.105 statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. if this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help. LIMITED WARRANTY STATEMENT 1. WHAT THIS WARRANTY COVERS: LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and conditions: (1) The limited warranty for the product extends for ONE (1) year beginning on the data of purchase of the product. (2) The limited warranty extends on to the original purchaser of the product and is not assignable or transferable to any subsequent purchaser/end user. (3) This warranty is good only to the original purchaser of the product during the warranty period as long as it is in the U.S., including Alaska, Hawaii, U.S. Territories and Canada. (4) The external housing and cosmetic parts shall not be covered under these limited warranty terms. (5) Upon request from LG, the consumer must provide information to reasonably prove the date of purchase. (6) The customer shall bear the cost of shipping the product to the Customer Service Department of LG. LG shall bear the cost of shipping the product back to the consumer after the completion of service under this limited warranty. 2. WHAT THIS WARRANTY DOES NOT COVER: (1) Defects or damages resulting from use of the product in other than its normal and customary manner. (2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair, misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused by shipping blown fuses spills of food or liquid. (3) Breakage or damage to antennas unless caused directly by defects in material or workmanship. (4) That the Customer Service Department at LG was net notified by consumer of the alleged defect or malfunction of the product during the applicable limited warranty period. (5) Products which have had the serial number removed or made illegible. (6) The limited warranty is in lieu of all other warranties, express or implied either in fact or by operations law, statutory or otherwise, including, but limited to any implied warranty of marketability or fitness for a particular use. (7) Damage resulting from use of non-LG approved accessories. (8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to normal customer use. (9) Products operated outside published maximum ratings. 3 (10) Products used or obtained in a rental program. (11) Consumables (such as fuses). 3. STATE LAW RIGHTS: No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, RISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of imitation of incidental or consequential damages or limitations on how long an implied warranty lasts; so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 4. HOW TO GET WARRANTY SERVICE: To obtain warranty service, please call the following web address: www.lgeservice.com 8 For Your Safety Important Information This user guide contains important information on the use and operation of this phone. Please read all the information carefully for optimal performance and to prevent any damage to or misuse of the ph…

Text truncated - open the document above for the full version.

Multimedia 46 M u l t i m e d i a ] Random play:You can play music tracks in a random order. ] Loop:You can repeatedly play music, either a specific track or all tracks. ] Equaliser:You can enhance or diminish frequencies during music playback. ] Add to track list:You can add the playing music track to a new or saved track list. ] Use tone - Set as ringing tone:You can set the music track as the ringing tone for the current profile. - Assign to contact:You can set the music track as ringing tone for a contact. ] Play in background:You can leave Music player on in the background when using other applications. ] View details:You can view detailed info about the currently playing track. ] Additional details:You can view a web page for more info about the currently playing tack. RecorderMenu 6.3 You can record speech or sound. You can record a phone call by selecting Recorder during the call. 1. Press the left soft key [Options] and select Settings to select the recording quality and default memory for your sound clips. 2. Press the left soft key [Options] and select Record sound clip to start recording. When a recording is started, the recording time appears on the LCD. 3. When you finish the recording, press the right soft key [Stop]. The recorded file is automatically saved in Sound clipsfolder in My stuff. Tip ] You can also press to leave music playback on in the background when making a call or using another application. Note ] Obey all local laws governing the recording of phone calls. Both parties of the call hear a tone every 5 seconds during recording. 47 M u l t i m e d i a 4. To play the sound clip after recording, press. 5. You can listen to previously recorded sound clips by selecting Go to My stuff. CameraMenu 6.4 In this application, you can take photos or record videos. You can switch between camera and video recorder using the up/down navigation keys. To take photos: 1. The viewfinder shows you the image to be captured. 2. To zoom in/out, press the right/left navigation key. 3. Using the left soft key [Options], the followings are available. ] Capture:Select this to take a photo. ] Show toolbar:After selecting this, you can switch between Imageand Videomodes, activate night or sequence mode, or switch between main and secondary camera using the . ] Video mode:Switches to Videomode. ] Use secondary camera:Select this to use the secondary camera. ] Night mode:You can activate/deactivate the night mode. ] Sequence mode:You can take multiple photos in one go by selecting On.(Shortcut: Press to activate the sequence mode in preview.) ] Self-timer:To take a photo automatically after a short time delay to, for example, include yourself in the photo. Select the delay time and press the left soft key [Activate]. Note ] To save the phone’s battery, Camerawill go into standby mode if the camera hardware cannot be activated or if no keys are pressed for one minute. To continue taking photos or recording videos, press . Multimedia 48 M u l t i m e d i a ] Go to My stuff:To view images and videos saved on the phone or memory card. ] Adjust:You can adjust the brightness, contrast, white balance and colour tone. ] Settings:You can set the desired environment to take photos or record videos. After setting the desired environment, press the right soft key [Back]. - Image • Image quality: You can adjust the image quality. • Show captured image: Select Noto take one photo immediately after another. This way, your photos do not remain on the display after you take them, and the camera is ready for use again. • Resolution (Camera 1): Select the desired resolution for the external camera by pressing . • Resolution (Camera 2): Select the desired resolution for the internal camera by pressing . • Default image name: To key in the default name for your new photos, scroll to Text and press . Key in the name and press . • Memory in use: Select where to save your photos. ] Help:Use this option to get to know the phone feature. ] Exit:Exits the application. <Short-cut keys> :To activate night mode and take photos when lighting is dim and the camera needs a long exposure time. :To edit brightness settings. : To activate sequence mode and take 6 photos in one go. Press to take the photos. : To edit contrast settings. Note ] The better the image quality, the more memory the photo uses and the fewer photos you can save on your phone or memory card. 49 M u l t i m e d i a 4. To take a photo, press . Photos are automatically saved in Imagesfolder in My stuff. To record videos: 1. Press the down navigation keys to switch to video recorder. The viewfinder shows you the image to be recorded. 2. To zoom in/out, press the right/left navigation key. 3. Using the left soft key [Options], the followings are available. ] Record:Select this to record a video. ] Show toolbar:After selecting this, you can switch between Imageand Videomodes, activate night mode, or switch between main and secondary camera using the . ] Image mode:Switches to Imagemode. ] Use secondary camera:Select this to use the secondary camera. ] Night mode:You can activate/deactivate the night mode. ] Mute: You can record a video without voice recorded. ] Go to My stuff:To view other videos saved on the phone or memory card. ] Adjust:You can adjust the brightness, contrast, white balance and colour tone. ] Settings:You can set the desired environment to take photos or record videos. After setting the desired environment, press the right soft key [Back]. - Video • Length: Select between Maximumand Short. • Resolution (Camera 1): Select the desired resolution for the external camera by pressing . • Resolution (Camera 2): Select the desired resolution for the internal camera by pressing . Tip ] To send the video clip in a multimedia message, select Shortto reduce the size of the video. Multimedia 50 M u l t i m e d i a • Default video name: To key in the default name for your new videos, scroll to Text and press . Key in the name and press. • Memory in …

Text truncated - open the document above for the full version.

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: March 17, 2008 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJKT610 Equipment Class: PCE: PCS Licensed Transmitter held to ear To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Daniel Kim General Manager LG Electronics USA

From: SunHee Kim Sent: Wednesday, March 26, 2008 7:40 AM To: PCTEST TCB Subject: Re: Questions Regarding FCC ID: BEJKT610 Dear Gregory, Thank you for your comments. We attached the revised documents and replies are embedded below your questions. Please let us know if this is insufficient or if more coordination is necessary. Thank you! Best Regards, Sun-Hee Kim *--- Discretion policies for e-mail message ---* In case you are an unintended recipient of this email message, be aware this message may contain confidential and classified information that is critical for conducting businesses. If this message and its attachment files are not directed to you, you are not authorized to reveal, use, publish, distribute, copy or trust this message or attachment without intended recipient’s authorization. In case you received this message by chance or in error, please return by forwarding the message and its attachments to the sender. HCT ----- Original Message ----- From: PCTEST TCB Sent: Wednesday, March 26, 2008 4:16 AM Subject: Questions Regarding FCC ID: BEJKT610 To: Ms. Sun-Hee Kim / HCT From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: BEJKT610 Applicant: LG Electronics Inc. Correspondence Reference Number: BEJ80219 Confirmation Number: 803190219-21 Date of Original Email: March 25, 2008 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Please specify the detector function (i.e., peak or average) used to generate the RF conducted bandedge and RF conducted spurious emission plots on pp. 12 and 27-28 of the Bluetooth test report. A peak detector should be used. If it was not, please re- perform these measurements with a peak detector and submit the new data. ==> As you can see on the upper left side of test plots, all measurements were performed with a peak detector mode and max hold. We indicated the detector function in the report on page 12 and 36 for your request. <File name: KT610 BT Test Report_Rev.2> 2. Please resubmit the Bluetooth Block Diagram, listing the values of all clocks/oscillators, as required. ==> Please check the attachment file. <File name: KT610_BT_Block Diagram_Rev.1> 3. Various values in the data table on p.44/53 of the Bluetooth report are in the wrong places- please correct the table and resubmit. ==> Please review the corrected BT Test Report on p. 44. <File name: KT610 BT Test Report_Rev.2> 4. Please correct the following typo in Section 10.2 of the SAR report (p.20/57): the Target SAR Value, from the dipole cal report, should be 38.0, and not 39.7. This also affects the deviation value. ==> Please review the revised Target and deviation values on p. 20 of 57. <File name: KT610_SAR Report_Rev.1> The items indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Quality Manager Senior Certification Engineer PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited.

Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １ of 8 G. EXTERNAL PHOTOGRAPHS Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ２ of 8 ■ EXTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ３ of 8 ■ EXTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ４ of 8 ■ EXTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ５ of 8 ■ EXTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ６ of 8 ■ EXTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ７ of 8 ■ EXTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ８ of 8 ■ EXTERNAL PHOTO

LG Electronics Inc. LGE Model No: KT610 FCC ID : BEJ KT610 S/N :Made in Korea Note: The FCC ID label shown will be r eadily visible at the time of purchase. ※ FCC ID label form

Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １ of 22 INTERNAL PHOTOGRAPHS Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ２ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ３ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ４ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ５ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ６ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ７ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ８ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ９ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １０ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １１ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １２ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １３ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １４ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １５ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １６ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １７ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １８ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr １９ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ２０ of 22 ■ INTERNAL PHOTO Report No.: HCT-SAR08-0305 FCC ID: BEJKT610 DATE: March 9, 2008 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr ２１ of 22 ■ INTERNAL PHOTO GCGP   LG Confidential 1 ※ The distance between antennas ※ The distance between antennas Main antenna BT antenna GPS antenna 8.5Cm

Report No.: HCT-SAR08-0306 FCC ID: BEJKT610 Date of Issue: Mar.10, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8565 FAX : +82 31 639 8525 www.hct.co.kr 2 of 57 Table of Contents 1. INTRODUCTION..........................................................................................................................................３ 2. DESCRIPTION OF DEVICE .........................................................................................................................４ 3. DESCRIPTION OF TEST EQUIPMENT ......................................................................................................５ 3.1 SAR MEASUREMENT SETUP ....................................................................................................５ 3.2 DASY E-FIELD PROBE SYSTEM ................................................................................................６ 3.3 PROBE CALIBRATION PROCESS ..............................................................................................７ 3.4 SAM Phantom .............................................................................................................................９ 3.5 Device Holder for Transmitters .....................................................................................................９ 3.6 Brain & Muscle Simulating Mixture Characterization ..................................................................１０ 3.7 SAR TEST EQUIPMENT ..........................................................................................................１１ 4. SAR MEASUREMENT PROCEDURE .....................................................................................................１２ 5. DESCRIPTION OF TEST POSITION .......................................................................................................１３ 5.1 HEAD POSITION .....................................................................................................................１３ 5.2 Body Holster/Belt Clip Configurations ........................................................................................１４ 6. MEASUREMENT UNCERTAINTY ...........................................................................................................１５ 7. ANSI/ IEEE C95.1 - 2005 RF EXPOSURE LIMITS ..................................................................................１５ 8. 3G MEASUREMENT PROCEDURES .....................................................................................................１５ 8.1 Procedures Used To Establish Test Signal .................................................................................１５ 8.2 SAR Measurement Conditions for CDMA2000 1x ......................................................................１５ 9. SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas .........................１５ 9.1 SAR Evaluation Considerations ................................................................................................１５ 10. SYSTEM VERIFICATION .......................................................................................................................１５ 10.1 Tissue Verification ..................................................................................................................１５ 10.2 System Validation ...................................................................................................................１５ 11. SAR TEST DATA SUMMARY .................................................................................................................１５ 11.1 Measurement Results (GSM1900 Head SAR Touch) ................................................................１５ 11.2 Measurement Results (GSM1900 Head SAR Tilt) ....................................................................１５ 11.3 Measurement Results (GSM1900 Body SAR) ..........................................................................１５ 12. CONCLUSION ........................................................................................................................................１５ 13.REFERENCES ........................................................................................................................................１５ Attachment 1. – SAR Test Plots....................................................................................................................１５ Attachment 2. – Dipole Validation Plots........................................................................................................１５ Attachment 3. – Probe Calibration Data.......................................................................................................１５ Attachment 4. – Dipole Calibration Data......................................................................................................１５ Report No.: HCT-SAR08-0306 FCC ID: BEJKT610 Date of Issue: Mar.10, 2008 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8565 FAX : +82 31 639 8525 www.hct.co.kr 3 of 57 1. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices. The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017. The measurement pro…
