Car AVN User Manual Model Name : LC7F 1) The Infotainment system provides Infotainment in your car, using the latest technology. See your dealer to have the system or software updated and upgraded. 2) The radio can be easily used by registering up to 25 FM or AM with the PRESET button[1 to 5] per every 5 pages. 3) The Infotainment system can play the USB storage device or iPod/iPhone products. 4) The Bluetooth phone connection function allows for the use of wireless hands-free Phone calls, as well as a phone music player. In addition, the WiFi function is provided. 5) Connect a portable music player to the auxiliary sound input to enjoy the rich sound of the Infotainment system. (2) Specifications *Product ItemCategories Specifications Specification Product NameFaceplate RADIO ASM-RECEIVER ModelLC7F DimensionsRefer to image Weight1.48kg(Base) / 1.52kg(XM, DAB) Power sourceDC 12V Operational temperature range -30 °C ~ 80 °C 1. Overview and Specifications (1) Overview *RF specifications [ BT ] ItemSpecificationsUnit Frequency2400 ~2483.5MHz Modulation TypeGFSK, Π/4-DQPSK, 8-DPSK BT PowerPower class 2 Datarate1 ~ 3Mbps channel spacing1MHz BT versionBT 3.0 [ WiFi ] ItemSpecificationsUnit StandardIEEE 802.11 a/b/g/n Frequency 2.4G2400 ~ 2484MHz 5G5G~6GGHz Bandwidth20MHz Datarate 802.11 b1, 2, 5.5, 11Mbps 802.11 g6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11 a (5G)6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11 n (2.4G / 5G) 6.5, 13, 19.5, 26, 39, 52, 58.5, 65Mbps Modulation DSSS / OFDM ModeAP, Station, Peer to Peer 2. Component 3. Operation Item (#No.)Description (1) DisplayDisplay for Play/Reception/Menu state and information. (2) HOME button Press this button to enter the home menu. (3)/(6) Seek button Press this button to seek the station or media contents. (4) POWER button Press and hold this button to turn the power on/off. Press this button to turn the mute function on/off. (5) Volume knob Rotate the Volume knob to adjust the volume. (7) Phone button Press this button to access the Phone screen. (If there is no connected phone, it will be displayed Bluetooth device management screen.) *Tap *Press & Hold *Fling/Swipe *Pinch & Spread *Rotate Users can rotate the Volume knob on the faceplate. *Push Users can press on the center of the rotary-push knob to mute volume. (8) Interactions | Rotary Knob (9) Touch Gestures 4. Precautions 1) Always operate the vehicle in a safe manner. Do not become distracted by the vehicle while driving and always be fully aware of all driving conditions. Do not change settings or any functions. Pull over in a safe and legal manner before attempting such operations. To promote safety, certain functions are disabled unless the parking brake is on. 2) To reduce the risk of electric shock, do not remove the cover or back of this product. There are no user-serviceable parts inside. Refer servicing to qualified service personnel. 3) To reduce the risk of fire or electric shock, do not expose this product to dripping or splashing water, rain, or moisture. 4) When driving your vehicle, be sure to keep the volume of the unit low enough to allow you to hear sounds coming from the outside. 5) Do not drop it and avoid heavy impacts at anytime. 6) The driver should not watch the monitor while driving. If the driver watches the monitor while driving, it may lead to carelessness and cause an accident. Declaration of Conformity Hereby, LG Electronics European Shared Service Center B.V., declares that this device is compliant with the essential requirements and other relevant provisions of Directive 1999/5/EC. The complete Declaration of Conformity may be requested through the following postal address: LG Electronics European Shared Service Center B.V. European Standard Team Krijgsman 1 1186 DM Amstelveen The Netherlands or can be requested at our dedicated DoC website: http://www.lg.com/global/support/cedoc/cedoc# This device is a 2.4 GHz and 5 GHz wideband transmission system, intended for use in all EU member states and EFTA countries, with indoor use restriction for 5GHz band. (5150 – 5250MHz) This device should be installed and operated with minimum distance 20 cm between the device and your body. And this phrase is for the general statement for consideration of user environment. <FCC Warning Statements> FCC Part 15.19 Statements: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Part 15.105 statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Part 15.21 statement Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. RF Exposure Statement The antenna(s) must be installed such that a minimum separation distance of at least 20 cm is maintained between the…

Text truncated - open the document above for the full version.

Date : Jan. 10, 2014 Rev : 2.1 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 44946 Osgood Rd, Fremont, CA 94539, USA TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Confidentiality Request Letter LG Electronics USA HACS-F003 FCC Confidentiality Request Letter Rev : 2.0 DATE : January 12, 2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD SUBJECT : Request for Confidentiality for FCC ID : BEJLC7F We hereby request confidential treatment of the information accompanying this application as outlined below: LONG-TERM AND SHORT-TERM CONFIDENTIAL LIST LONG-TERM CONFIDENTIAL Exhibit Description 1 Block Diagram 2 Schematics 3 Operational Description 4 SHORT-TERM CONFIDENTIAL (180 DAYS) 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signed by: Company Name : LG Electronics USA. Company Address : 1000 Sylvan Avenue, Englewood Cliffs, New Jersey, United States Contact Person Name/Title (in print) : Jacob Cho / Director, Standards & Compliance

FCC ID: BEJLC7F/ IC: 2703H-LC7F EXTERNAL PHOTOGRAPHS HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 7 FCC ID: BEJLC7F/ IC: 2703H-LC7F ■ EXTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 7 FCC ID: BEJLC7F/ IC: 2703H-LC7F ■ EXTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 7 FCC ID: BEJLC7F/ IC: 2703H-LC7F ■ EXTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 7 FCC ID: BEJLC7F/ IC: 2703H-LC7F ■ EXTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 7 FCC ID: BEJLC7F/ IC: 2703H-LC7F ■ EXTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 7 FCC ID: BEJLC7F/ IC: 2703H-LC7F ■ EXTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 7

0700 MISP-CRM-LGE-LC7F FCC ID : BEJLC7FIC : 2703H-LC7F 5mm [LC7F ID Location] ID location ID location

FCC ID: BEJLC7F/ IC:2703H-LC7F INTERNAL PHOTOGRAPHS HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 7 FCC ID: BEJLC7F/ IC:2703H-LC7F ■ Antenna INTERNAL PHOTO BT Antenna HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 7 FCC ID: BEJLC7F/ IC:2703H-LC7F ■ INTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 7 FCC ID: BEJLC7F/ IC:2703H-LC7F ■ INTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 7 FCC ID: BEJLC7F/ IC:2703H-LC7F ■ INTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 7 FCC ID: BEJLC7F/ IC:2703H-LC7F ■ INTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 7 FCC ID: BEJLC7F/ IC:2703H-LC7F ■ INTERNAL PHOTO HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 7

FCC ID: BEJLC7F / IC:2703H-LC7F RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f² ) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna HCT CO., LTD 1 of 5 FCC ID:BEJLC7F / IC:2703H-LC7F 3. RESULTS (BT BAND) 3- 1. BT BAND Max Peak output Power at antenna input terminal (dBm) 3.5100 Max Peak output Power at antenna input terminal (mW) 2.244 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2402.0 Antenna Gain(typical) ( dBi) 3.04 Antenna Gain(numeric) 2.01372 Power density at prediction frequency (mW/cm²) 0.000899 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 4.RESULTS (DTS BAND) 4- 1. DTS (802.11b BAND) Max Peak output Power at antenna input terminal (dBm) 21.58 Max Peak output Power at antenna input terminal (mW) 143.880 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2412.000 Antenna Gain(typical) ( dBi) 3.04 Antenna Gain(numeric) 2.01372 Power density at prediction frequency (mW/cm²) 0.057641 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 6401 www.hct.co.kr 2 of 5 FCC ID:BEJLC7F / IC:2703H-LC7F 4- 2. DTS (802.11g BAND) Max Peak output Power at antenna input terminal (dBm) 25.42 Max Peak output Power at antenna input terminal (mW) 348.337 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2412.0000 Antenna Gain(typical) ( dBi) 3.04 Antenna Gain(numeric) 2.01372 Power density at prediction frequency (mW/cm²) 0.139550 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 4- 3. DTS (802.11n_20MHz BAND) Max Peak output Power at antenna input terminal (dBm) 25.08 Max Peak output Power at antenna input terminal (mW) 322.107 Prediction distance (cm) 20.000 Prediction frequency (MHz) 2412.00 Antenna Gain(typical) ( dBi) 3.04 Antenna Gain(numeric) 2.01372 Power density at prediction frequency (mW/cm²) 0.129042 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 6401 www.hct.co.kr 3 of 5 FCC ID:BEJLC7F / IC:2703H-LC7F 5.RESULTS (UNII 1 BAND) 5- 1. 802.11a BW(5180 MHz ~ 5240 MHz) Max Peak output Power at antenna input terminal (dBm) 15.21 Max Peak output Power at antenna input terminal (mW) 33.189 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2412.00 Antenna Gain(typical) ( dBi) 3.92 Antenna Gain(numeric) 2.46604 Power density at prediction frequency (mW/cm²) 0.016283 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 5- 2 802.11n_20MHz BW (5180 MHz ~ 5240 MHz) Max Peak output Power at antenna input terminal (dBm) 15.22 Max Peak output Power at antenna input terminal (mW) 33.266 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2412.00 An tenna Gain(typical) ( dBi) 3.92 Antenna Gain(numeric) 2.46604 Power density at prediction frequency (mW/cm²) 0.016320 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 6401 www.hct.co.kr 4 of 5 FCC ID:BEJLC7F / IC:2703H-LC7F 6.RESULTS (UNII 3 BAND) 6- 1.802.11a BW(5765 MHz ~ 5825 MHz) Max Peak output Power at antenna input terminal (dBm) 19.29 Max Peak output Power at antenna input terminal (mW) 84.918 Prediction distance (cm) 20.0000 Prediction frequency (MHz) 2412.00 Antenna Gain(typical) ( dBi) 5.5 Antenna Gain(numeric) 3.54813 Power density at prediction frequency (mW/cm²) 0.059942 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 6- 2 802.11n_20MHz BW (5765 MHz ~ 5825 MHz) Max Peak output Power at antenna input terminal (dBm) 18.11 Max Peak output Power at antenna input terminal (mW) 64.714 Prediction distance (cm) 20.000 Prediction frequency (MHz) 2412.00 Antenna Gain(typical) ( dBi) 5.50 Antenna Gain(numeric) 3.54813 Power density at prediction frequency (mW/cm²) 0.045680 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 HCT CO., LTD 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Korea TEL : + 82 31 645 6467 FAX : + 82 31 645 6401 www.hct.co.kr 5 of 5

Report No.: HCT-R-1501-F007 Model: LC7F Page of 61 F-01P-02-014 (Rev.00) FCC ID: BEJLC7F/ IC: 2703H-LC7F HCT Co.Ltd. Version TEST REPORT NO. DATE DESCRIPTION HCT-R-1501-F007 January 12, 2015 - First Approval Report Report No.: HCT-R-1501-F007 Model: LC7F Page of 61 F-01P-02-014 (Rev.00) FCC ID: BEJLC7F/ IC: 2703H-LC7F HCT Co.Ltd. Table of Contents 1. GENERAL INFORMATION .......................................................................................................................... 2. EUT DESCRIPTION ..................................................................................................................................... 3. TEST METHODOLOGY ............................................................................................................................... 3.1 EUT CONFIGURATION ...................................................................................................................... 3.2 EUT EXERCISE .................................................................................................................................. 3.3 GENERAL TEST PROCEDURES ...................................................................................................... 3.4 DESCRIPTION OF TEST MODES ..................................................................................................... 4. INSTRUMENT CALIBRATION..................................................................................................................... 5. FACILITIES AND ACCREDITATIONS ......................................................................................................... 5.1 FACILITIES ......................................................................................................................................... 5.2 EQUIPMENT ....................................................................................................................................... 6. ANTENNA REQUIREMENTS ...................................................................................................................... 7. SUMMARY TEST OF RESULTS ................................................................................................................. 7.1 FCC Part ............................................................................................................................................. 7.2 IC Part ................................................................................................................................................. 8. TEST RESULT ......................................................................................................................................... 8.1 DUTY CYCLE (802.11b/g/n) .......................................................................................................... 8.2 6dB BANDWIDTH (802.11b/g/n) ................................................................................................... 8.3 99% BANDWIDTH (802.11b/g/n) ................................................................................................... 8.4 OUTPUT POWER(802.11b/g/n) ..................................................................................................... 8.5 POWER SPECTRAL DENSITY (802.11b/g/n) ............................................................................... 8.6 OUT OF BAND EMISSIONS AT THE BAND EDGE/ CONDUCTED SPURIOUS EMISSIONS ... 8.7 RADIATED MEASUREMENT ......................................................................................................... 8.7.1 RADIATED SPURIOUS EMISSIONS. .................................................................................. 8.7.2 RECEIVER SPURIOUS EMISSIONS ................................................................................... 8.7.3 RADIATED RESTRICTED BAND EDGES .......................................................................... 8.8 POWERLINE CONDUCTED EMISSIONS ..................................................................................... 9. LIST OF TEST EQUIPMENT ................................................................................................................... 9.1 LIST OF TEST EQUIPMENT(Conducted Test) ............................................................................ 9.2 LIST OF TEST EQUIPMENT(Radiated Test) ................................................................................ Report No.: HCT-R-1501-F007 Model: LC7F Page of 61 F-01P-02-014 (Rev.00) FCC ID: BEJLC7F/ IC: 2703H-LC7F HCT Co.Ltd. 1. GENERAL INFORMATION Applicant: LG Electronics Inc. Address: 222 LG-ro Jinwi-myeon, Pyeongtaek-si, Gyeonggi-do 451-713, Korea FCC ID: BEJLC7F IC: 2703H-LC7F EUT Type: Faceplate RADIO ASM-RECEIVER FCC/ IC Model name(s): LC7F Date(s) of Tests: October 20, 2014 ~ January 09, 2015 Place of Tests: HCT Co., Ltd. 74,Seoicheon-ro 578beon-gil,Majang-myeon, Icheon-si, Gyeonggi-do, Korea. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION EUT Type Faceplate RADIO ASM-RECEIVER FCC/ IC Model Name LC7F Power Supply DC 12.0 V Frequency Range TX : 2412 MHz~2462 MHz RX : 2412 MHz~2462 MHz Max. RF Output Power Peak Wi-Fi 802.11b(21.58 dBm) / Wi-Fi 802.11g (25.42dBm) / Wi-Fi 802.11n (25.08 dBm) Average Wi-Fi 802.11b(15.52 dBm) / Wi-Fi 802.11g (17.15 dBm) / Wi-Fi 802.11n (17.05 dBm) Modulation Type DSSS/CCK(802.11b), OFDM(802.11g, 802.11n) Antenna Specification Manufacturer: AMOTECH Antenna type: Chip Antenna Peak Gain : 3.04 dBi Report No.: HCT-R-1501-F007 Model: LC7F Page of 61 F-01P-02-014 (Rev.00) FCC ID: BEJLC7F/ IC: 2703H-LC7F HCT Co.Ltd. 3. TEST METHODOLOGY FCC KDB 558074 D01 DTS Meas Guidance v03r02 dated June 05, 2014 entitled “Guidance for Performing Compliance Measurements on Digital Transmission Systems(DTS) Operating Under §15.247” and the measurement procedure described in the American National Standard for Testing Unlicensed Wireless Devices(ANSI C63.4-2003) were used in the measurement. 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF fie…
