BEJLM680A15-inch LCD Monitor

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Jan 21, 2001
Application Purpose: Original Equipment
Date of Application: Jan 21, 2001
Equipment Note: 15-inch LCD Monitor
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Block Diagram

Cover Letter(s)

January 18, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:LG ELECTRONICS INC. FCC ID: BEJLM680A Gentlemen: Transmitted herewith, on behalf of LG Electronics Inc. is an application for certification of the following 15–inch color LCD monitor: FCC ID:BEJLM680A MODEL:LM680A-UA TRADE NAMES:LG  EUT TYPE:15-inch LCD Monitor Attached is the applicant’s authorization letter, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, schematics and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Yeong Hur, EMC Engineer LG Electronics Inc.

External Photos

ID Label/Location Info

© 2000 PCTEST Lab ATTACHMENT E – FCC ID LABEL & LOCATION FCC ID: BEJLM680A © 2000 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Internal Photos

© 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A © 2000 PCTEST Lab 15” LCD Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJLM680A

Test Report

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road 6660-B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290-6652 TEL (410) 290-6652 •• FAX (410) 290-6654 FAX (410) 290-6654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE LG Electronics Inc. – DID DIVISIONDates of Tests: December 28-29, 2000 184, Kongdan-dong, Kumi,Test Report S/N: B.201227029.BEJ Kyoungsangbuk-do, KOREATest Site: PCTEST Lab., MD U.S.A. Attn: Mr. Yeong Hur , EMC Engineer FCC ID BEJLM680A APPLICANT LG ELECTRONICS INC. Rule Part(s):FCC Part 15 Subpart B Equipment Class:Class B Peripheral Device (JBP) Standard(s):EN55022: 1998 (CISPR 22) EUT Type: 15-inch LCD Color Monitor Max. Resolution(s): 1280 x 1024 Non-interlaced @ 75Hz Trade Name(s): LG ® Model(s): LM680A-UA This equipment has been shown to be in compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 (Note Code: #19, 28). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Lab Code 100431-0 © 2000 PCTEST Engineering Laboratory, Inc. FCC Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1SCOPE 1 2.1INTRODUCTION (SITE DESCRIPTION) 2 3.1PRODUCTION INFORMATION 3 4.1DESCRIPTION OF TESTS (CONDUCTED) 4 4.3DESCRIPTION OF TESTS (RADIATED) 5 5.1LIST OF SUPPORT EQUIPMENT 6 6.1TEST DATA (CONDUCTED) 7 7.1TEST DATA (RADIATED)8 8.1SAMPLE CALCULATIONS 9 9.1ACCURACY OF MEASUREMENT 10 10.1LIST OF TEST EQUIPMENT 11 11.1TEST SOFTWARE USED 12 12.1CONCLUSION 13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL Test Report S/N: B.201227029.BEJFCC Class B Dates of Tests: December 28-29, 2000Certification © 2000 PCTEST Lab15” LCD Color Monitor1 LG Electronics Inc. FCC ID: BEJLM680A MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Applicant Name:LG ELECTRONICS INC. Address:184, Kongdan-dong, Kumi, Kyoungbuk, Korea Contact Person:Yeong Hur, EMC Engineer Product Engineering Dept., Safety & EMC Team • FCC ID:BEJLM680A • Equipment Class:B Digital Device / Peripheral (JBP) • EUT Type:15-inch LCD Color Monitor • Trade Name(s):LG ® • Model(s):LM680A-UA • Max. Resolution:1280 x 1024 Non-interlaced @ 75Hz • Frequency Range:H-Sync: 30kHz – 80kHz V-Sync: 56Hz – 85Hz • Cable(s):Shielded D-Sub w/ ferrite on both ends • Power Cord:Unshielded AC Power Cord w/ ferrite on DC end • Rule Part(s):FCC Part 15 Subpart B • Test Procedure(s):ANSI C63.4 (1992) • Dates of Tests:December 28-29, 2000 • Place of Tests:PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N:B.201227029.BEJ Test Report S/N: B.201227029.BEJFCC Class B Dates of Tests: December 28-29, 2000Certification © 2000 PCTEST Lab15” LCD Color Monitor2 LG Electronics Inc. FCC ID: BEJLM680A 2.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from LG Electronics Inc. 15” LCD Color Monitor FCC ID: BEJLM680A. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure 1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: B.201227029.BEJFCC Class B Dates of Tests: December 28-29, 2000Certification © 2000 PCTEST Lab15” LCD Color Monitor3 LG Electronics Inc. FCC ID: BEJLM680A 3.1 Product Information 3.2 Equipment Description The Equipment Under Test (EUT) is the LG Electronics Inc. (LG Model: LM680A-UA) 15-inch LCD Color Monitor FCC ID: BEJLM680A. Maximum Resolution(s):1280 x 1024 Non-interlaced @ 75Hz Frequency Range(s):H-Sync: 30kHz – 80kHz V-Sync: 56Hz – 85Hz Slot Pitch:0.243mm slot pitch Power Supply:Input: 100-240VAC, 50/60Hz, 1.2A-0.6A, LG Electronics AC adapter (Model: PSCV500107A) Power Cord:Unshielded AC power cord w/ ferrite on DC end Port(s)/Input Connector(s):15-pin D-Sub type VGA connector (4) USB Downstream (1) USB Upstream (1) Audio Port (1) Headph…

Text truncated - open the document above for the full version.

Test Report

Test Setup Photos
