BEJLSI1100Portable Wireless Local Loop Telephone (PCS)

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jul 16, 2002
Application Purpose: Original Equipment
Date of Application: Jul 16, 2002
Equipment Note: Portable Wireless Local Loop Telephone (PCS)
Frequency Range: 1851.25000000 - 1908.75000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CDMA Fixed Wireless Telephone User Guide Model: LSI-1100 LGE CDMA Fixed Wireless Telephone LSI-1100 2 REVISED HISTORY DATE ISSUE CONTENTS OF CHANGES REMARK 2002/06/3 ISSUE1 Initial Release LGE CDMA Fixed Wireless Telephone LSI-1100 3 Blank Page For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. To maintain compliance with FCC RF exposure requirements, maintain a 2.54 cm. separation distance between the user’s body and the phone, including the antenna. WARNING! Read this information before using your phone LGE CDMA Fixed Wireless Telephone LSI-1100 4 CONTENTS Highlights ................................................................................................................................... 6 1. Important Information.................................................................................................... 7 1.1 Safety Information ....................................................................................................... 7 1.2 Optimal Phone Performance ....................................................................................... 7 1.3 Care and Service......................................................................................................... 8 2. Introduction...................................................................................................................... 9 2.1 Front View of the Telephone ....................................................................................... 9 2.2 LCD Display...............................................................................................................10 2.3 Installation ................................................................................................................. 11 2.4 Installation Steps ....................................................................................................... 13 3. Basic Operation............................................................................................................. 17 3.1 Making a Call.............................................................................................................17 3.2 Redialing Last Outgoing Number .............................................................................. 17 3.3 Receiving a Call......................................................................................................... 18 3.4 Signal Strength .......................................................................................................... 18 3.5 Missed Call Message ................................................................................................ 18 4. List of Menu State......................................................................................................... 19 4.1 Volume / Ring............................................................................................................... 20 4.1.1 Ring Volume..................................................................................................... 20 4.1.2 Key Volume....................................................................................................... 20 4.1.3 Ear Volume....................................................................................................... 20 4.1.4 Ring Select....................................................................................................... 21 4.2 Additional feature .........................................................................................................21 4.2.1 Wake-up Time................................................................................................... 21 4.2.2 Minute Alert....................................................................................................... 21 4.2.3 Set Rx call mode (not applicable in the Voice only model)..................................... 22 4.2.4 Backlight........................................................................................................... 22 4.2.5 Own number..................................................................................................... 22 4.3 Dial features ................................................................................................................. 22 4.3.1 Hot Line.............................................................................................................. 22 4.3.2 Hot Line Time .................................................................................................... 23 4.3.3 Auto Time-out .................................................................................................... 23 4.3.4 Speed Dial (enable / disable) ............................................................................ 23 4.3.5 Key-tone Length ................................................................................................ 24 4.4 Security Features ......................................................................................................... 24 4.4.1 Lock Mode Set.......................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

. July 9, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS, INC. FCC ID: BEJLSI1100 Part 24 Certification Gentlemen: Submitted herewith, on behalf of LG ELECTRONICS, Inc., is an application for Part 24 Certification of the Portable Wireless Local Loop Telephone (PCS). Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), antenna specifications (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned.

Cover Letter(s)

November 12, 2004 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21045 Attn: Martin Perrine In re: BEJLSI1100 TC# 228224 Request for additional information Dear Martin: This letter is in response to your request for additional information dated September 13, 2004 and our subsequent meeting requesting additional time to respond to your questions and letter filed October 12, 2004. Please find attached the power measurements performed by LGE on the recent production units. Also attached is the measurements performed by PCTEST Lab on the WLL model LSI1100. Please note that the power measured by PCTEST agrees to the measurements performed by LGE and the power is within the allowable tolerance for production units. Regarding to your questions, please find the following responses. 1. The final highest AGC/power setting allowed is +21.5dBm 2. The final max. conducted average power measured is +21.7dBm 3. The expected and actual measured tolerance max. power is 21.5dBm +0.8/-0.4 dB We trust this response is satisfactory to your questions. Please also note that these LGE WLL phones will not be sold or marketed in the United States. If you have any questions regarding this matter, please do not hesitate to contact me or PCTEST Lab. Sincerely, Daniel Kim General Manager LG Electronics USA, Inc. Encl. LG Electronics Inc. 2000 Millbrook Dr. Lincolnshire, IL 60069 U.S.A. Tel.: (847) 941-8373

External Photos

© 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJLSI1100 (Model: LSI-1100) Fixed Wireless Telephone (PCS CDMA)

ID Label/Location Info

© 2002PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Internal Photos

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. 6660 — B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220617315.BEJ Test Dates: June 20-24, 2002 Phone Type: Portable WLL Telephone FCC ID: BEJLSI1100 Page 1 of 24 © 2002 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: LG ELECTRONICS, Inc. Dates of Tests: June 20-24, 2002 Kumkang Venturetel Bldg. 1108, Bisan-Dong Test Report S/N: SAR.220617315.BEJ Dongan-Gu, Annyang-City, Kyunggi-Do, Test Site: PCTEST Lab, Columbia, MD USA Seoul, KOREA 431-050 Attn: Kevin Lee, Associate Research Engineer FCC ID: BEJLSI1100 APPLICANT: LG ELECTRONICS, INC. EUT Type: Portable Wireless Local Loop Telephone (PCS) Tx Frequency: 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.362W EIRP PCS CDMA (25.581 dBm)/ 23.1 dBm Conducted Max. SAR Measurement: 1.31W/kg PCS CDMA Head SAR Trade Name/Model(s): LSI-1100 FCC Classification: Licensed Base Station for Part 24 (PCB) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220617315.BEJ PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220617315.BEJ Test Dates: June 20-24, 2002 Phone Type: Portable WLL Telephone FCC ID: BEJLSI1100 Page 2 of 24 © 2002 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION .................................................................................................. 3 SAR DEFINITION ................................................................................................. 3 2. SAR MEASUREMENT SETUP .................................................................................. 4 Robotic System ....................................................................................................... 4 System Hardware ................................................................................................... 4 System Electronics .................................................................................................. 4 3. DASY3 E-FIELD PROBE SYSTEM ............................................................................ 5 Probe Measurement System.................................................................................... 5 Probe Specifications ............................................................................................... 5 4. Probe Calibration Process....................................................................................... 6 Dosimetric Assessment Procedure .......................................................................... 6 Free Space Assessment ........................................................................................... 6 Temperature Assessment ........................................................................................ 6 5. PHANTOM & EQUIVALENT TISSUES .................................................................... 7 SAM Phantom ........................................................................................................ 7 Brain & Muscle Simulating Mixture Characterization ............................................. 7 Device Holder for Transmitters............................................................................... 7 6. TEST SYSTEM SPECIFICATIONS ............................................................................. 8 Automated Test System Specifications .................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS ................................................. 9 Measurement Procedure......................................................................................... 9 Specific Anthropomorphic Mannequin (SAM) Specifications.................................. 9 8. DEFINITION OF REFERENCE POINTS ................................................................. 10 EAR Reference Point............................................................................................. 10 Handset Reference Points ..................................................................................... 10 9. TEST CONFIGURATION POSITIONS .................................................................. 11 Positioning for Cheek/Touch ................................................................................ 11 Positioning for Ear / 15° Tilt .................................................................................. 12 Body Holster /Belt Clip Configurations ................................................................. 13 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS ................................................... 14 Uncontrolled Environment ................................................................................... 14 Controlled Environment......................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.895 mW/g, SAR (10g): 0.531 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 0025 [1851.25 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Right Head Phantom, Cheek Touch position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 8.99E-2 2.70E-1 4.50E-1 6.29E-1 8.09E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.327 mW/g, SAR (10g): 0.190 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 0600 [1880.00 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Right Head Phantom, Cheek Touch position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 3.44E-2 1.03E-1 1.72E-1 2.41E-1 3.10E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.423 mW/g, SAR (10g): 0.250 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 1175 [1908.75 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Right Head Phantom, Cheek Touch position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 3.77E-2 1.13E-1 1.89E-1 2.64E-1 3.39E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.29 mW/g, SAR (10g): 0.714 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 0025 [1851.25 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Right Head Phantom, EAR/15 Degree Tilt position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 1.04E-1 3.13E-1 5.22E-1 7.31E-1 9.40E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.774 mW/g, SAR (10g): 0.441 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 0600 [1880.00 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Right Head Phantom, EAR/15 Degree Tilt position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 7.46E-2 2.24E-1 3.73E-1 5.22E-1 6.71E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.799 mW/g, SAR (10g): 0.460 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 1175 [1908.75 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Right Head Phantom, EAR/15 Degree Tilt position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 7.65E-2 2.29E-1 3.83E-1 5.36E-1 6.89E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Left Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.824 mW/g, SAR (10g): 0.478 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 0025 [1851.25 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Left Head Phantom, Cheek Touch position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 8.08E-2 2.42E-1 4.04E-1 5.66E-1 7.27E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Left Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.524 mW/g, SAR (10g): 0.302 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 0600 [1880.00 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Left Head Phantom, Cheek Touch position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 5.39E-2 1.62E-1 2.70E-1 3.77E-1 4.85E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJLSI1100-- PCS CDMA Head SAR SAM Phantom; Left Hand Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.611 mW/g, SAR (10g): 0.345 mW/g LGE Wireless Local Loop Phone Model: LSI-1100/1150 PCS CDMA Mode, Ch; 1175 [1908.75 MHz]; Standard Battery; Ambient Temp. =22.4°C / Meas. Tissue Temp. = 22.2°C Conducted Power = 23.0 dBm; Left Head Phantom, Cheek Touch position Test Date -- 06/21/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SA…

Text truncated - open the document above for the full version.

RF Exposure Info

1900MHz Brain Dipole Validation SAM Phantom; Flat Section; Probe:ET3DV6 - SN1677; ConvF(5.30,5.30,5.30) Med. Parameters 1900 MHz Brain: σ = 1.43 mho/m ε r = 41.0 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 10.1 mW/g, SAR (10g): 5.22 mW/g 1900MHz Brain Dipole Validation (D1900V2 S/N: 502) Frequency: 1900 MHz; Antenna Input Power: 250 [mW]; Ambient Temp. = 22.4°C / Meas. Tissue Temp. = 22.2°C PCTEST Brain Tissue Simulating Liquid [06/21/2002] SAR Tot [mW/g] 9.87E-1 2.96E+0 4.93E+0 6.91E+0 8.88E+0 PCTEST Engineering Laboratory, Inc.

Test Report

PCTEST PT. 24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 24.220617314.BEJ Test Dates: June 20-24, 2002 EUT Type: Portable WLL Telephone FCC ID: BEJLSI1100 Page 1 of 17 © 2002 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 Certification LG ELECTRONICS, Inc. Dates of Tests: June 20-24, 2002 Kumkang Venturetel Bldg. 1108, Bisan-Dong Test Report S/N: 24.220617314.BEJ Dongan-Gu, Annyang-City, Kyunggi-Do, Test Site: PCTEST Lab, Columbia MD Seoul, KOREA 431-050 Attn: Kevin Lee, Associate Research Engineer Bruce Choi, General Manager FCC ID BEJLSI1100 APPLICANT LG ELECTRONICS, INC. Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §24(E), §2 EUT Type: Portable Wireless Local Loop Telephone (PCS) Model: LSI-1100 Tx Frequency Range: 1851.25MHz — 1908.75MHz (PCS CDMA) Rx Frequency Range: 1931.25MHz — 1988.75MHz (PCS CDMA) Max. RF Output Power: 0.362W EIRP PCS CDMA (25.581 dBm) Max. SAR Measurement: 1.31W/kg PCS CDMA Head SAR Emission Designator(s): 1M25F9W This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220617314.BEJ PCTEST PT. 24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 24.220617314.BEJ Test Dates: June 20-24, 2002 EUT Type: Portable WLL Telephone FCC ID: BEJLSI1100 Page 2 of 17 © 2002 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-7 6.1 EQUIVALENT ISOTROPIC RADIATED POWER 8 7.1 RADIATED MEASUREMENTS 9-11 8.1 FREQUENCY STABILITY 12-13 9.1 PLOTS OF EMISSIONS 14 10.1 LIST OF TEST EQUIPMENT 15 11.1 SAMPLE CALCULATIONS 16 12.1 CONCLUSION 17 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 24.220617314.BEJ Test Dates: June 20-24, 2002 EUT Type: Portable WLL Telephone FCC ID: BEJLSI1100 Page 3 of 17 © 2002 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: LG ELECTRONICS, INC. Address: Kumkang Venturetel Bldg. 1108, Bisan-Dong Dongan-Gu, Annyang-City, Kyunggi-Do, Seoul, KOREA 431-050 Attention: Kevin Lee, Associate Research Engineer Bruce Choi, General Manager • FCC ID: BEJLSI1100 • Quantity: Quantity production is planned • Emission Designators: 1M25F9W • Tx Freq. Range: 1851.25 — 1908.75 MHz (PCS CDMA) • Rx Freq. Range: 1931.25 — 1988.75 MHz (PCS CDMA) • Max. Power Rating: 0.362W EIRP PCS CDMA (25.581 dBm) • FCC Classification(s): Licensed Portable Transmitter Held to Ear (PCE) • Equipment (EUT) Type: Portable Wireless Local Loop Telephone (PCS) • Modulation(s): PCS CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E) • Dates of Tests: June 20-24, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 24.220617314.BEJ PCTEST PT. 24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 24.220617314.BEJ Test Dates: June 20-24, 2002 EUT Type: Portable WLL Telephone FCC ID: BEJLSI1100 Page 4 of 17 © 2002 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at a 3-meter test range (see Figure2). The equipment under test is placed on a wooden turntable 3-meters from the receive antenna. The receive antenna height and turntable rotations were adjusted for the highest reading on the receive spe…

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)

[email protected]201-470-2696Fax: 201-816-2003

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Non-Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652Fax: 410-290-6654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
1	24E	1.85 GHz - 1.91 GHz	362.00 mW	1M25F9W	2.5000000000 ppm

Confidentiality

Long Term

Grant Notes

Output is EIRP. Device has been tested for SAR compliance. End-users must be informed of the operating requirements for satisfying RF exposure compliance. The highest reported SAR value is: Head: 1.31 W/kg.
