CDMA Fixed Wireless Telephone User Guide Model: LSP-300 LGE CDMA Fixed Wireless Telephone LSP-300 3 REVISED HISTORY DATE ISSUE CONTENTS OF CHANGES REMARK 2001/02/19 ISSUE1 Initial Release LGE CDMA Fixed Wireless Telephone LSP-300 4 Blank Page LGE CDMA Fixed Wireless Telephone LSP-300 5 CONTENTS Highlights......................................................................................................................................7 1. Important Information.......................................................................................................8 1.1 Safety Information...........................................................................................................8 1.2 Optimal Phone Performance.........................................................................................8 1.3 Care and Service............................................................................................................9 2. Introduction.......................................................................................................................10 2.1 Front View of the Telephone.........................................................................................10 2.2 LCD Display.................................................................................................................11 2.3 Installation.....................................................................................................................12 2.4 Installation Steps..........................................................................................................14 3. Basic Operation................................................................................................................15 3.1 Making a Call................................................................................................................15 3.2 Redialing Last Outgoing Number.................................................................................15 3.3 Receiving a Call............................................................................................................16 3.4 Signal Strength.............................................................................................................16 3.5 Missed Call Message...................................................................................................16 4. List of Menu State............................................................................................................17 4.1 Volume / Ring..................................................................................................................17 4.1.1 Ring Volume.........................................................................................................17 4.1.2 Key Volume..........................................................................................................18 4.1.3 Ear Volume..........................................................................................................18 4.1.4 Ring Type 4.2 Additional Feature.........................................................................................................24 4.2.1 Wake-up time.....................................................................................................19 4.2.2 Minute alert..........................................................................................................20 4.2.3 Set Rx call mode..................................................................................................20 4.2.4 SIO baud rate.......................................................................................................20 4.2.5 Own Number..........................................................................................................2 4.3 Dialing features..................................................................................................................19 4.4.1 Hot line...............................................................................................................19 4.4.2 Hot line time.......................................................................................................20 4.4.3 Auto time-out........................................................................................................20 4.4.4 Speed dialing........................................................................................................20 4.4.5 Keytone length.....................................................................................................20 LGE CDMA Fixed Wireless Telephone LSP-300 6 4.5 Security Features............................................................................................................22 4.5.1 Set Lock mode.......................................................................................................23 4.5.2 Clear calls..............................................................................................................23 4.5.3 Clear memory.........................................................................................................23 4.5.4 Emergency call......................................................................................................23 4.5.5 Restrict call............................................................................................................23 4.5.5.1 Restriction set.....................................................................................................23 4.5.5.2 Permit Memory..................................................................................................23 4.5.5.3 Deny Memory....................................................................................................23 4.5.6 New Code 5. Features while in a Call..................................................................................................25 5.1 Ear Volume..........................................................................................................…

Text truncated - open the document above for the full version.

LGE CDMA Fixed Wireless Telephone LSP-300 42 10. Speaker phone This function is a convenient feature which enables you to call using speaker phone button in on-hook state. 11. General Information Main Unit Item LSP-300 Tx Frequency Digital : 824 ~ 849 MHz Rx Frequency Digital : 869 ~ 894 MHz Channel Bandwidth 1.25 MHz Tx Power Digital : 23.0 dBm Conducted Rx Sensitivity -104 ~ -25dBm Size 160 X 215 X 76 (L X W X H) Below 809(with battery, Ni-MH) Weight(g) Below 748 (without battery) Operating Temperature 0 ~ 50 AC/DC Adapter Item SMPS Type Description Input Voltage AC 100 ~ 250V / 0.3A, 15W Input Frequency 50 / 60Hz Output Voltage 9.6V(DC), 1A Battery Item Description Capacity 6V Ni-MH 1500mAh Talk duration time 2 Hours Standby duration time 24 Hours Charging duration time Trickle, 24 Hours

LG Electronics Inc. LG Electronics Inc. Communication Terminal R&D Lab. Kumkang venturetelBldg. 12F, 1108, Bisan-Dong, Anyang-City, Kyonggi-Do 431-050 Korea Telephone : 82-31-389-1060 Fax. : 82-31-389-1030 July 11, 20001 Federal Communication Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 U.S.A. In re : LG Electronics Inc. FCC ID : BEJLSP300 PCS CDMA WLL Terminal Part22 Certification Request for Confidentiality Gentleman, In accordance with 0.459 of CFR47, LG Electronics Inc. Hereby requests confidentiality of Block Diagrams attachment, Schematic Diagram & circuit Description attachment, Antenna Specifications attachment, Operational Description attachment, and Parts List / Tune-Up Procedure attachment for the above-referenced application. These documents contain detailed system and equipment Description and related information about the product which LG Electronics Inc.to the general public. Since This design is a basic from which future technological products will evolve, LG electronics Inc. Considers this information to be a benefit to its competitors anunfair advantage in the market. Sincerely Yours, Kevin Lee / Approval Engineer Research & Supporting Group. Communication Terminal R&D Lab. LG Electronics Inc. LG Electronics Inc. LG Electronics Inc. July 11, 20001 Federal Communication Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 U.S.A. To Whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. On our behalf shall have the same effect as acts of our own. We also hereby certify that No party to the application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug ACT of 1988, 21 U.S.C 853(a). Sincerely, Bruce Choi General Manager of New York Office LG Info Comm U.S.A. Inc. LG Info Comm U.S.A. Inc. 55 Madison Ave., Suite 180 Morristown, NJ 07960 U.S.A. Tel; 973-401-9109 LG Electronics Inc. LG Electronics Inc. Communication Terminal R&D Lab. Kumkang venturetelBldg. 12F, 1108, Bisan-Dong, Anyang-City, Kyonggi-Do 431-050 Korea Telephone : 82-31-389-1060 Fax. : 82-31-389-1030 July 11, 20001 Federal Communication Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 U.S.A. SUBJECT :LG ELECTRONICS INC. FCC ID : BEJLSP300 Users Manual RF Exposure Warning Statement Gentleman, LG electronics Inc. hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the users manual. If you have any further questions regarding this matter, Please do not hesitate to contact to me or PCTEST engineering Laboratory Inc.at(410)290-6652. Sincerely Kevin Lee / Approval Engineer Research & Supporting Group. Communication Terminal R&D Lab. LG Electronics Inc.

October 16, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: LG Electronics Inc. FCC ID: BEJLSP300 731 Confirmation No.: EA101928 Correspondence Reference No.: 20750 Request for Tech. Info.: 09/26/2001 Dear Joe: Transmitted herewith, on behalf of LG Electronics Inc., is an amendment in response to the request for technical information dated September 26, 2001. 1. Please find the attached revised cover letter stating the correct maximum SAR level of 1.0287 W/kg. 2. We used a conductivity value of 1.1 S/m, which is higher than the one listed in supplement C. This is an overestimation and will lead to a higher SAR value. 3. Please find the attached RF warning statement. 4. Please find the attached operational description and the revised page 1 of the test report with the correct maximum power. Please find the revised compliance statement indicating the correct power rating of .231 W ERP. Please find the revised page 42 of the user’s manual indicating the proper conducted value of 23.0 dBm. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: LG Electronics Inc.

. October 16, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS, INC. FCC ID: BEJLSP300 Part 22 Certification Gentlemen: Submitted herewith, on behalf of LG ELECTRONICS, Inc., is an application for Part 22 Certification of the following Single-Band CDMA WLL Phone: FCC ID: BEJLSP300 TRADE/MODEL(s): LGE BEJLSP300 EUT TYPE: Single-Mode CDMA WLL Phone Tx Freq. Range(s): 824.70 — 848.31 MHz (CDMA) Rx Freq. Range(s): 869.64 — 893.37 MHz (CDMA) Max. RF Output Power: 0.231 W CDMA (23.633 dBm) Max. Peak SAR: 1.0287 mW/g CDMA Body SAR Attached is the applicant’s Letter of Authorization, Confidentiality Request, User’s Manual RF Warning page, User’s Manual Location of RF Warning page statement, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune- up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned.

November 14, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Joe Dichoso SUBJECT: LG Electronics Inc. FCC ID: BEJLSP300 731 Confirmation No.: EA101928 Correspondence Reference No.: 20955 Request for Tech. Info.: 10/17/2001 Dear Joe Transmitted herewith, on behalf of LG Electronics Inc., is an amendment provided in response to the request for technical information dated October 17, 2001. 1. In regards to Tim’s email, please find attached the Z Scan liquid depth data. 2. Please find attached the Data taken during a retest of the unit in 15cm of liquid. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us.
