BEJLSP3600PCS CDMA WLL Phone

LSP-3600 USER GUIDE Please read this manual carefully before operating your set. Retain it for future reference. 1. Important Information4 1.1 Safety Instruction4 1.2 Optimal Phone Performance4 1.3 Care and Service5 1.4 Safety Information6 2. Introduction9 2.1 Front View of the Phone9 2.2 LCD Display 10 2.3 Installation11 2.4 Installation Steps14 3. Basic Operations15 3.1 Making a Call 15 3.2 Redialing Last Number15 3.3 3 way call conferencing15 3.4 Call Waiting16 3.5 Volume Control16 3.6 Receiving a Call16 3.7 Lock Mode16 3.8 Entering and Editing Information17 4. Menu Tree 21 4.1 Names25 4.2 Messages27 4.3 Call History32 4.4 Sound35 4.5 Display37 4.6 Settings38 4.7 Organiser46 4.8 Games48 5. Speaker Phone 50 6. Troubleshooting 51 7. General Information 52 7.1 Main Unit 52 7.2 AC/DC Adapter 52 7.3 Battery 53 FCC RF Exposure Information54 Contents 3 Contents Congratulations on your subscription to the LSP-3600 Fixed Wireless phone. This phone has been designed to operate on the IS-2000 Air Protocol over the 1.9GHz band. And the phone has the advanced user interface similar to mobile phone. It has greatly enhanced voice clarity and provides various advanced features. Key phone features: ᶀ Wide view, Graphic, Backlit Display. ᶀ Polyphonic Ring tones: A choice of 15 melodies and 5 bell sounds available. ᶀ Large Phonebook with 500 entries. ᶀ Speed Dialling for upto 99 numbers. ᶀ 3 Way call conferencing. ᶀ Enhanced SMS features - Group SMS, T9 Dictionary. ᶀ Hands free Speaker Phone. ᶀ Receiver Off-Hook tone. ᶀ Adjustable Ringer Volume, Earpiece Volume, Key Volume, Speaker Volume. ᶀ A Menu driven interface with prompts for easy operations. ᶀ USB and Serial Connectivity for internet access. ᶀ Organiser: Scheduler, Alarm, Memo, Calculator, World Clock with DST, Stopwatch. ᶀ Games: Fortress and Mole. ᶀ Fast charging battery. Highlights Highlights 2 - Consult the Authorized LGE Dealer for assistance of an experienced radio/TV technician. ᶀ Use battery, antenna and AC/DC power adapter provided by LGE. Using parts made by any other manufacturer may invalidate the warranty. ᶀ Only authorized personnel should service the phone and its accessories. Faulty installation or service can be dangerous and may invalidate the warranty. ᶀ Do not use the phone in any designated “cellular phone use” area. ᶀ Avoid using the phone in high temperature or humidity. ᶀ Avoid spilling any liquid on the phone. If the phone gets wet, turn the power off immediately. If the phone doesn ᴗ t work, please contact the service provider immediately. ᶀ Avoid shock or impact. ᶀ We recommend you to charge the backup battery before initial use. The backup battery may be discharged during delivery. 1.3 Care and Service Before cleaning, always unplug the phone from the wall outlet and remove the antenna (or disconnect the antenna cable). Do not use liquid or aerosol cleaners; use a damp cloth for cleaning. If the phone doesn’t work, do not attempt to disassemble it; contact the phone service agent for assistance. If any of the following conditions exist, unplug the phone from the wall plug, remove the battery and call the qualified engineer. - The power supply cord is damaged or frayed. - Liquid has spilled into the phone. - The phone has been exposed to rain or water. - The phone has been dropped or damaged. - The phone does not function normally even after following the operating instructions. Important Information Important Information 5 Important Information Important Information 4 1.1 Safety Instruction WWAARRNNIINNGG // CCAAUUTTIIOONN To reduce the risk of fire or electric shock, do not expose this phone to rain or moisture. Do not use this phone in swimming pools or other water bodies. 1.2 Optimal Phone Performance ᶀ Do not hold the antenna when operating the phone, or operate the phone when someone is within four inches (ten centimeters) of the antenna. Both cases affect the call quality and may cause the phone to operate at a higher power level than required. ᶀ For the best call quality, keep the antenna free from obstructions and position the antenna upright. ᶀ Do not use the phone if the antenna is damaged. Replace the damaged antenna immediately by a qualified technician. Use only a manufacturerapproved antenna. Non-approved antennas, modifications or attachments may impair call quality and damage the phone. ᶀ RF energy may affect improperly installed or inadequately shielded personal medical devices such as pace-makers or hospital monitors. Consult the manufacturer of any personal medical devices to determine whether they are adequately shielded from external RF energy. Turn your phone OFF in health care centers if any regulations posted in the area instruct you to do so. Hospitals or health care centers may be using equipment that may be sensitive to external RF energy. ᶀ If this phone causes harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Place the radio or television farther away from the phone. - Connect the equipment to an outlet on a circuit different from that to which the phone is presently connected. 4 Important Information 7 WWAARRNNIINNGG ᶀ For safety, use only an adapter approved by LG. LG does not bear responsibility for any faults that may arise due to non- conformation to this guide. Example: LSP-3600 (LG Power Adapter Source: DC 5V / 1A) ᶀ Do not, in any way, cause a short-circuit. It may start a fire or the phone may explode causing injury. ᶀ Do not create a sudden impact on the battery by throwing it. Do not dispose off batteries by putting them in a fire. They may explode or catch fire due to the electrolyte within. 1.4 Safety Information CCAAUUTTIIOONN ᶀ Do not use the phone with a car battery. It may cause electric shock, fire, breakdown or transformation. ᶀ Avoid using the phone in high tem…

Text truncated - open the document above for the full version.

LG Electronics Inc. 60-39, Gasan-dong, Gumchon-gu Seoul 153-801, Korea Tel: 82-2-2033-1110, Fax: 82-2-2033-1222 Date: June 28, 2007 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJLSP3600 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram CONFIDENTIAL 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM CONFIDENTIAL 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, E.S.Park Manager Mobile Handset R&D Center Mobile Communications Company LG Electronics Inc.

Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics Inc. 60-39, Gasan-dong, Gumchon-gu, Seoul, 153-023, Korea 82-2-2033-3847 Measurement facility registration number Engineer J.H.Kim Manager Engineer J.M.Yang 94696 (Signature) (Signature) Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2006 , ANSI C 63.4 2003 20-Jun-07 LSP-3600 NONE LG Electronics Inc. KOREA Report Number : ESTF150706-005 , Web : www. estech. co. kr Page 1 of 11 Report NumberESTF150706-005 Manufacturer Country of origin Applicant Product 21-Jun-07 CDMA FIXED WIRELESS TERMINAL 3 4 5 6 8 8 8 9 10 10 10 11 Appendix 1. Spectral diagram 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ Report Number : ESTF150706-005 , Web : www. estech. co. kr Page 2 of 11 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.3 Test data ............................................................................................. ... 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150706-005 , Web : www. estech. co. kr Page 3 of 11 2. Description of EUT 2.1 Summary of Equipment Under Test Product name : Model Number : LSP-3600 Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 15-May-07 Report Number : ESTF150706-005 , Web : www. estech. co. kr Page 4 of 11 CDMA FIXED WIRELESS TERMINAL NONE LG Electronics Inc. KOREA Supplied from Note PC 3. Test Standards Test Standard : FCC PART 15 (2006) Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150706-005 , Web : www. estech. co. kr Page 5 of 11 4. Measurement Condition 4.1 EUT Operation. 4.2 Configuration and Peripherals * The EUT was in the following operation mode during all testing * The operational conditions of the EUT was determined by the manufacturer according to the typical use of the EUT with respect to the expected hightest level of emission. * Connect the EUT to Note PC. * Install sync program to Note PC. * Transferred "H" character data between the phone and note pc during the test. Report Number : ESTF150706-005 , Web : www. estech. co. kr Page 6 of 11 4.3 EUT and Support equipment Equipment Name Remark (FCC ID) CDMA FIXED WIRELESS TERMINAL EUT Adapter P…
