BEJLSTD400Dual-Band CDMA WLL Terminal

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCB - PCS Licensed Transmitter
Date of Grant: Dec 09, 2002
Application Purpose: Original Equipment
Date of Application: Oct 09, 2002
Equipment Note: Dual-Band CDMA WLL Terminal
Frequency Range: 1851.25000000 - 1908.75000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. This device was tested for typical operations with the antenna of the device kept 2.5 cm. from the body. To maintain compliance with FCC RF exposure requirements, maintain a 2.5 cm. separation distance between the user’s body and the device, including the antenna. WARNING! Read this information before using your phone LGE CDMA Fixed Wireless Terminal LST-D400 Item Tx Frequency Rx Frequency Channel Bandwidth 17. General Information Description 1850 - 1910 MHz 1930 - 1990 MHz 1.25 MHz 7.1 LST-D4OO 0 Main Unit Frequency Stability Tx Power *I50 Hz 24dBm Weight(g) I Rx Power Level I -104 - -25 dBm 620g ( w/o battery ) / 800g ( w/ battery ) Size I 210 x 150 x 63 mm I Item Input Voltage Description 1 OOV - 280V AC Input Frequency Output Voltage 50 / 60 Hz 12V( DC) / 2A I Talk duration time I 2 Hours I Item Capacity ~ Description 8.4V NiMH Standby duration time Charging duration time I Talk duration time 11 Hour I 24 Hours Within 24 Hours I Standby duration time I 12 Hours I Item Capacity I Charaina duration time I Within 24 Hours I Description 8.4V NiMH Note : Talk duration time was measured at sector power -90dBm with 9600bps in Mobile test equipment. Standby duration time was measured at sector power -75dBm with Slotted mode(Slot Cycle Index 2) 29

Cover Letter(s)

October 10, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS, INC. FCC ID: BEJLSTD400 731 Confirmation No.: EA852416 Dual-Band CDMA WLL Terminal Gentlemen: During the Part 22/24 filing of the above referenced FCC ID, we encountered an error after the 731 form. We were unable to input the EUT transmitting frequency ranges, RF output power, frequency tolerance, and emission designator required for the grant. The required information is as follows: Tx Frequency Output Frequency Emission Rule Parts Range Watts Tolerance Designator 22.901(d) 824.70 — 848.31 0.362 2.5 ppm 1M25F9W 24(E) 1851.25 — 1908.75 0.337 2.5 ppm 1M25F9W If you have any questions or require additional information, please do not hesitate to contact us. cc: LG ELECTRONICS, INC.

Cover Letter(s)

. October 9, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS, INC. FCC ID: BEJLSTD400 Part 22/24 Certification Gentlemen: Submitted herewith, on behalf of LG ELECTRONICS, Inc., is an application for Part 22/24 Certification of the Dual-Band CDMA Wireless Local Loop Terminal. Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. Cc: LG Electronics, Inc.

External Photos

© 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal © 2002 PCTEST Lab LGE FCC ID: BEJLSTD400 (Model: LST-D400) Dual-Band CDMA Wireless Local Loop Terminal

ID Label/Location Info

© 2002PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Internal Photos

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. 6660 — B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.220926499.BEJ Test Dates: Sept. 26, 2002 Phone Type: Dual-Band CDMA WLL FCC ID: BEJLSTD400 Page 1 of 22 © 2002 PCTEST Engineering Laboratory, Inc. APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: LG ELECTRONICS, Inc. Dates of Tests: September 26, 2002 Kumkang Venturetel Bldg. 1108, Bisan-Dong Test Report S/N: SAR.220926499.BEJ Dongan-Gu, Annyang-City, Kyunggi-Do, Test Site: PCTEST Lab, Columbia MD Seoul, KOREA 431-050 Attn: Kevin Lee, Associate Research Engineer Bruce Choi, General Manager FCC ID: BEJLSTD400 APPLICANT: LG ELECTRONICS, INC. EUT Type: Dual-Band CDMA Wireless Local Loop Terminal Tx Frequency: 824.70 — 848.31 MHz (CDMA) / 1851.25 — 1908.75 MHz (PCS CDMA) Rx Frequency: 869.70 — 893.31 MHz (CDMA) / 1931.25 — 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.362 W ERP CDMA (25.583 dBm) / 24.0 dBm Conducted 0.337 W EIRP PCS CDMA (25.281 dBm) / 24.0 dBm Conducted Max. SAR Measurement: 0.94W/kg CDMA Body SAR / 1.07W/kg PCS CDMA Body SAR Trade Name/Model(s): LST-D400(F) FCC Classification: Licensed Non-Broadcast Station Transmitter (TNB) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: Identical prototype This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220926499.BEJ PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.220926499.BEJ Test Dates: Sept. 26, 2002 Phone Type: Dual-Band CDMA WLL FCC ID: BEJLSTD400 Page 2 of 22 © 2002 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION ................................................................................................... 3 SAR DEFINITION.................................................................................................... 3 2. SAR MEASUREMENT SETUP .................................................................................. 4 Robotic System ....................................................................................................... 4 System Hardware .................................................................................................... 4 System Electronics................................................................................................... 4 3. DASY3 E-FIELD PROBE SYSTEM............................................................................. 5 Probe Measurement System .................................................................................... 5 Probe Specifications................................................................................................ 5 4. Probe Calibration Process ....................................................................................... 6 Dosimetric Assessment Procedure........................................................................... 6 Free Space Assessment............................................................................................ 6 Temperature Assessment ......................................................................................... 6 5. PHANTOM & EQUIVALENT TISSUES .................................................................... 7 SAM Phantom ......................................................................................................... 7 Brain & Muscle Simulating Mixture Characterization .............................................. 7 Device Holder ........................................................................................................ 7 6. TEST SYSTEM SPECIFICATIONS ............................................................................. 8 Automated Test System Specifications..................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS .................................................. 9 Measurement Procedure ......................................................................................... 9 Specific Anthropomorphic Mannequin (SAM) Specifications .................................. 9 8. DEFINITION OF REFERENCE POINTS .................................................................. 10 EAR Reference Point ............................................................................................. 10 Handset Reference Points ..................................................................................... 10 9. TEST CONFIGURATION POSITIONS ................................................................... 11 Positioning for Cheek/Touch ................................................................................. 11 Positioning for Ear / 15° Tilt................................................................................... 12 Body Holster /Belt Clip Configurations.................................................................. 13 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS ................................................... 14 Uncontr…

Text truncated - open the document above for the full version.

RF Exposure Info

SAR Data Report 02092613 Start : 26-Sep-02 04:09:54 pm End : 26-Sep-02 04:17:17 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : LGE Model Number : LST-D400 Serial Number : 1 Frequency : 835.89 MHz Transmit Pwr : 0.250 W Antenna Type : Helical Antenna Posn. : Fixed Measurement Data: Phantom Name : SAM FLAT2 Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 56.200 Tissue Conductivity : 0.990 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT002 Probe Type : E Fld Triangle Frequency : 1900 MHz Tissue Type : Muscle Calibrated Dielectric : 53.900 Calibrated Conductivity : 1.480 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 4.500 Probe Sensitivity : 3.000 2.995 2.653 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: CDMA Mode CH-363 Body CF=1; Amb. Temp= 22.2 'C; Liq. Temp=22.0 'C Area Scan - Max Peak SAR Value at x=0.0 y=-18.0 = 0.88 W/kg Zoom Scan - Max Peak SAR Value at x=1.0 y=-19.0 z=0.0 = 1.44 W/kg Max 1g SAR at x=1.0 y=-19.0 z=0.0 = 0.94 W/kg Max 10g SAR at x=0.0 y=-19.0 z=0.0 = 0.61 W/kg 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2 1.3 1.4 1.5 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:1.0 y:-19.0 1g SAR Values 0.944 0.926 0.907 0.889 0.870 0.852 0.833 0.815 0.796 0.778 0.759 SAR Data Report 02092609 Start : 26-Sep-02 03:00:09 pm End : 26-Sep-02 03:07:33 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : LGE Model Number : LST-D400 Serial Number : 1 Frequency : 1825.25 MHz Transmit Pwr : 0.250 W Antenna Type : Helical Antenna Posn. : Fixed Measurement Data: Phantom Name : SAM FLAT2 Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 55.200 Tissue Conductivity : 1.500 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT002 Probe Type : E Fld Triangle Frequency : 1900 MHz Tissue Type : Muscle Calibrated Dielectric : 53.900 Calibrated Conductivity : 1.480 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 4.500 Probe Sensitivity : 3.000 2.995 2.653 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: PCS Mode CH-25 Body CF=1; Amb. Temp= 22.2 'C; Liq. Temp=22.0 'C Area Scan - Max Peak SAR Value at x=1.0 y=19.0 = 0.93 W/kg Zoom Scan - Max Peak SAR Value at x=1.0 y=18.0 z=0.0 = 1.93 W/kg Max 1g SAR at x=1.0 y=19.0 z=0.0 = 1.07 W/kg Max 10g SAR at x=1.0 y=19.0 z=0.0 = 0.60 W/kg 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:1.0 y:18.0 1g SAR Values 1.071 1.038 1.006 0.973 0.941 0.908 0.876 0.844 0.811 0.779 0.746

RF Exposure Info

File: 02-04-2002.cal Date: 04-Feb-02 01:20:16 pm Probe Name: PCT002 Frequency:835 MHz Comment:PCTEST TEM CAL Amp 1 Setting: 20.000 Amp 2 Setting: 20.000 Amp 3 Setting: 20.000 0.0 0.2 0.4 0.6 0.8 1.0 1.2 050100150200250300350 Ch 0 Ch 1 Ch 2 Sum Degrees (x10) Voltage (in mV) File: 02-04-2002.cal2 Date: 04-Feb-02 03:18 :09 pm Probe Name: PCT002 Frequency:1900 MHz Comment:PCTEST TEM CAL Amp 1 Setting:20.000 Amp 2 Setting:20.000 Amp 3 Setting:20.000 0.0 0.2 0.4 0.6 0.8 1.0 1.2 050100150200250300350 Ch 0 Ch 1 Ch 2 Sum Degrees (x10) Voltage (in mV) Conversion Factor Assessment for IDX SAR Measurement System S/N: PCT002 835 MHz Brain ε r = 40.7 ± 5% σ = 0.89 ± 5% mho/m Conversion Factor = 5.8 ± 7% (k=2) 1900 MHz Brain ε r = 40.2 ± 5% σ = 1.41 ± 5% mho/m Conversion Factor = 4.7 ± 7% (k=2) Probe calibration 1900 MHz Brain (WG 1900) 0 1 2 3 4 5 6 7 8 0510152025303540 z in mm SAR in mW/cm^3 / W Analytical Measurements Probe Calibration 835 MHz Brain (WG 835) 0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 0510152025303540 z in mm SAR in (mW/cm^3)/W Analytical Measurements

RF Exposure Info

SAR Data Report 02092601 Start : 26-Sep-02 8:28:58 am End : 26-Sep-02 8:40:37 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : Validation Frequency : 835 MHz Transmit Pwr : 0.250 W Antenna Type : Dipole Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Brain Tissue Dielectric : 40.560 Tissue Conductivity : 0.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT002 Probe Type : E Fld Triangle Frequency : 835 MHz Tissue Type : Brain Calibrated Dielectric : 40.700 Calibrated Conductivity : 0.890 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 5.800 Probe Sensitivity : 3.597 3.474 3.049 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: 835 MHz Validation Amb. Temp= 22.2 'C; Liq. Temp=22.1 'C Area Scan - Max Peak SAR Value at x=2.0 y=-5.0 = 2.10 W/kg Zoom Scan - Max Peak SAR Value at x=2.0 y=-3.0 z=0.0 = 3.30 W/kg Max 1g SAR at x=2.0 y=-3.0 z=0.0 = 2.21 W/kg Max 10g SAR at x=2.0 y=-4.0 z=0.0 = 1.38 W/kg Validation Results at 0.25 W: Peak Nominal = 3.5, Error: -5.71 % 1g Nominal = 2.4, Error: -7.03 % 10g Nominal = 1.6, Error: -10.78 % 0 1 2 3 4 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:2.0 y:-3.0 1g SAR Values 2.21 2.07 1.94 1.80 1.67 1.53 1.39 1.26 1.12 0.99 0.85 SAR Data Report 02092602 Start : 26-Sep -02 9:28:43 am End : 26-Sep -02 9:35:10 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : Validation Frequency : 1900 MHz Transmit Pwr : 0.250 W Antenna Type : Dipole Measurement Data: Phantom Name : SAM-FLAT Phantom Type : Uniphantom Tissue Type : Brain Tissue Dielectric : 41.110 Tissue Conductivity : 1.420 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT002 Probe Type : E Fld Triangle Frequency : 1900 MHz Tissue Type : Brain Calibrated Dielectric : 40.200 Calibrated Conductivity : 1.410 Calibrated Density : 1.000 Probe Offset : 2.400 mm Conversion Factor : 4.700 Probe Sensitivity : 3.000 2.995 2.653 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 100 Samples NIDAQ Gain: 5 Comments: 1900 MHz Validation CF=1; Amb. Temp= 21.3 'C; Liq. Temp=21.0 'C Area Scan - Max Peak SAR Value at x=0.0 y=0.0 = 8.78 W/kg Zoom Scan - Max Peak SAR Value at x=0.0 y=0.0 z=0.0 = 15.80 W/kg Max 1g SAR at x=1.0 y=1.0 z=0.0 = 9.19 W/kg Max 10g SAR at x=1.0 y=1.0 z=0.0 = 4.80 W/kg Validation Results at 0.25 W: Peak Nominal = 18.0, Error: -12.32 % 1g Nominal = 9.9, Error: -7.40 % 10g Nominal = 5.1, Error: -6.34 % 0 2 4 6 8 10 12 14 16 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:0.0 y:0.0 1g SAR Values 9.19 8.67 8.15 7.63 7.11 6.59 6.07 5.54 5.02 4.50 3.98

Test Report

PCTEST PT. 22/24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22/24.220926498.BEJ Test Dates: Sept. 26, 2002 Phone Type: Dual-Band CDMA WLL FCC ID: BEJLSTD400 Page 1 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 24 & 22 Certification LG ELECTRONICS, Inc. Dates of Tests: September 26, 2002 Kumkang Venturetel Bldg. 1108, Bisan-Dong Test Report S/N: 22/24.220926498.BEJ Dongan-Gu, Annyang-City, Kyunggi-Do, Test Site: PCTEST Lab, Columbia MD Seoul, KOREA 431-050 Attn: Kevin Lee, Associate Research Engineer Bruce Choi, General Manager FCC ID BEJLSTD400 APPLICANT LG ELECTRONICS, INC. Classification: Licensed Non-Broadcast Station Transmitter (TNB) FCC Rule Part(s): §24(E), §22.901(d); §2 EUT Type: Dual-Band CDMA Wireless Local Loop Terminal Model: LST-D400(F) Tx Frequency Range: 824.70 — 848.31MHz (CDMA) / 1851.25MHz — 1908.75MHz (PCS CDMA) Rx Frequency Range: 869.70 — 893.31MHz (CDMA) / 1931.25MHz — 1988.75MHz (PCS CDMA) Max. RF Output Power: 0.362 W ERP CDMA (25.583 dBm) / 0.337 W EIRP PCS CDMA (25.281 dBm) Max. SAR Measurement: 0.94W/kg CDMA Body SAR / 1.07W/kg PCS CDMA Body SAR Emission Designator(s): 1M25F9W (CDMA) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220926498.BEJ PCTEST PT. 22/24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22/24.220926498.BEJ Test Dates: Sept. 26, 2002 Phone Type: Dual-Band CDMA WLL FCC ID: BEJLSTD400 Page 2 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-8 5.1 EFFECTIVE RADIATED POWER OUTPUT 9 6.1 EQUIVALENT ISOTROPIC RADIATED POWER 10 7.1 RADIATED MEASUREMENTS 11-16 8.1 FREQUENCY STABILITY 17-20 9.1 PLOTS OF EMISSIONS 21 10.1 LIST OF TEST EQUIPMENT 22 11.1 SAMPLE CALCULATIONS 23 12.1 CONCLUSION 24 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 22/24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22/24.220926498.BEJ Test Dates: Sept. 26, 2002 Phone Type: Dual-Band CDMA WLL FCC ID: BEJLSTD400 Page 3 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: LG ELECTRONICS, INC. Address: Kumkang Venturetel Bldg. 1108, Bisan-Dong Dongan-Gu, Annyang-City, Kyunggi-Do, Seoul, KOREA 431-050 Attention: Kevin Lee, Associate Research Engineer Bruce Choi, General Manager • FCC ID: BEJLSTD400 • Quantity: Quantity production is planned • Emission Designators: 1M25F9W (CDMA) • Tx Freq. Range: 824.70 — 848.31 MHz (CDMA) 1851.25 — 1908.75 MHz (PCS CDMA) • Rx Freq. Range: 869.70 — 893.31 MHz (CDMA) 1931.25 — 1988.75 MHz (PCS CDMA) • Max. Power Rating: 0.362 W ERP CDMA (25.583 dBm) 0.337 W EIRP PCS CDMA (25.281 dBm) • FCC Classification(s): Licensed Non-Broadcast Station Transmitter (TNB) • Equipment (EUT) Type: Dual-Band CDMA Wireless Local Loop Terminal • Modulation(s): CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): § 24(E), §22.901(d) • Dates of Tests: September 26, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 22/24.220926498.BEJ PCTEST PT. 22/24 REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22/24.220926498.BEJ Test Dates: Sept. 26, 2002 Phone Type: Dual-Band CDMA WLL FCC ID: BEJLSTD400 Page 4 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Measurement Procedure The radiated and spurious measurements were made outdoors at a 3-meter test range (see Figure2). The equipment under test is placed on a wooden turntable 3-meters from the receive an…
