Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Part 15.21 statement " Change or Modifications that are not expressly approved by the manufacturer could void the user's authority to operate the equipment. “ LGCM Installation Guide Installing the LG Connection Manager S/W 1. Run setup.exe 2. You will then see the Ericsson Wireless Module Install shield Wizard, and follow the instructions to proceed with installation. 3. When the follow screen appears, click the “Next >” button. 4. When the follow screen appears, select the “I accept the terms of the license agreement” and click the “Next > “ button. 5. It is installing. 6. When the installation is complete, press the [Finish] button and the installation message window will disappear.
LUM900D PCI Express Mini Card User Manual LG Electronics Confidential 1. Production Overview 2 LG Electronics Confidential LG Electrics LUM900D and HSPA PCI Express Mini Card are high‐speed packet access (HSPA) Mobile Broadband Modules. The modules support data services through HSPA, UMTS, EDGE, GPRS, and data message service. 1.1 Production Feature •Powered by ICERA E300™ chipset •Theoretical peak downlink rate of 14.4 Mbps (S/W upgradable to 21Mbps) •Theoretical peak uplink rate of 5.75 Mbps •Tri‐band HSPA and Rx Diversity •Quad‐band GSM/GPRS /EDGE 850/900/1800/1900 MHz (LUM900D) •Support Receive Equalization and Type i –improves performance in noisy & highly mobile environ •System interface : USB 2.0 (1) 4 LG Electronics Confidential PinNameTypeDescription 1NCNot Connect 23.3 VauxPWR+3.3V Power Supply 3NCNot Connect 4GNDPWRGround 5NCNot Connect 6NCNot Connect 7NCNot Connect 8UIM PWROUSIM Interface, USIM VCC Supply 9GNDPWRGround 10UIM_DATAI/OUSIM Interface, USIM IO 11NCNot Connect 12UIM_CLKOUSIM Interface, USIM Clock 13NCNot Connect 14UIM_RESETOUSIM Interface, USIM Reset 15GNDGNDGround 16NCNot Connect 17NCNot Connect 18GNDPWRGround 19NCNot Connect 20W_DISABLE#I/PUWireless Disable , Internal Pull‐up 21GNDPWRGround 22PERST#ISystem Reset 23NCNot Connect 243.3VauxPWR+3.3V Power Supply 25NCNot Connect 26GNDPWRGround 27GNDPWRGround 2.2 Pin Descriptions 5 LG Electronics Confidential PinNameTypeDescription 28NCNot Connect 29GNDPWRGround 30NCNot Connect 31NCNot Connect 32NCNot Connect 33NCNot Connect 34GNDPWRGround 35GNDPWRGround 36USB_D‐I/OUSB Data Negative 37GNDPWRGround 38USB_D+I/OUSB Data Positive 393.3VauxPWR+3.3V Power Supply 40GNDPWRNot Connect 413.3VauxPWR+3.3V Power Supply 42LED_WWAN#OLED Driver, Max 9mA 43GNDPWRNot Connect 44NCNot Connect 45NCNot Connect 46NCNot Connect 47NCNot Connect 48NCNot Connect 49NCNot Connect 50GNDPWRGround 52NCNot Connect 523.3VauxPWR+3.3V Power Supply 6 LG Electronics Confidential 2.3 Signal Descriptions 2.3.1 Power Supply Power Rail Voltage Tolerance Normal (max)Peak (max) 3.3Vaux ± 9%TBD2,750 Power is provided to the LUM850T / LUM900T through Power pins that range from 3.0V to 3.6V. (1)(1) (1) In case of the VCC is +3.3V Definitions: Peak –The highest averaged current value over any 100‐microsecond period Normal –The highest averaged current value over any 1‐second period Note: For Peak, the value of “100‐microsecond period” was derived as follows: The period of time that the current is to be measured and averaged over must be less than a single GPRS slot time. This enables measurement of the average peak current within a single GPRS slot. There are 4.6 milliseconds/GPRS frame and eight slots per GPRS frame = 575 microseconds/slot. The 100‐microsecond period < 575‐microsecond period. 2.3.2 USB Interface The USB interface is compliant with the High Speed USB 2.0 specifications. The USB interface is powered directly from host interface 3.3Vaux supply. 7 LG Electronics Confidential 2.3.3 Control Signal Interface Power is provided to the LUM850T / LUM900T through Power pins that range from 3.0V to 3.6V. Notes: 1. Applies to PERST# and W_DISABLE#. 2. As measured at the card connector pad. SymbolParameterConditionsMinMaxUnitsNotes +3.3VauxSupply Voltage3.3‐9%V2 V IH Input High Voltage2.03.6V1 V IL Input Low Voltage‐0.50.8V1 I IN Input Leakage Current0V to 3.3V‐10+10μA1 I LKG Output Leakage Current0V to 3.3V‐50+50μA1 2.3.4 USIM Interface The USIM interface pins provide the connections necessary to interface to a USIM socket located on host system. Voltage levels over this interface comply with 3GPP standards. 2.3.5 Antenna Interface The modem has two connecters for antenna interface. The one is for Main antenna and the other is for Diversity antenna(AUX). The connector type is UF.L and the path is assumed to be 50 ohms. 3. RF Specifications 8 LG Electronics Confidential 3.1 UMTS Technical Data Power Class Class 3 (+24dBm) Frequency BandBand V(850)BAND IV (900)BAND II (1900)BAND I (2100) Frequency Range (MHz) TX: 824‐849 RX: 869‐894 TX: 880‐915 RX: 925‐960 TX:1850‐1910 RX: 1930‐1990 TX:1920‐1980 RX: 2110‐2170 Duplex Spacing45MHz45MHz80MHz190MHz Advanced ReceiverType 3 Maximum Downlink Speed 384 kbps (Packet‐Switched) Maximum Uplink Speed 384 kbps (Packet‐Switched) Features FDD intra‐frequency cell reselection FDD inter‐frequency cell reselection Inter‐RAT(3G <‐> 2G) cell reselection Inter‐RAT Cell Change Order(3G <‐> 2G) Maximum Downlink Speed14Mbps Maximum Uplink Speed5.7Mbps HSDPA CategoriesCategory 10 HSUPA CategoriesCategory 6 3.2 HSPA Technical Data 9 LG Electronics Confidential 3.3 GSM Performance and Technical Characteristics ParameterGSM 850E‐GSM 900GSM 1800GSM 1900 Frequency Range (MHz) TX: 824‐849 RX: 869‐894 TX: 880‐915 RX: 925‐960 TX: 1710‐1785 RX: 1805‐1880 TX:1850‐1910 RX: 1930‐1990 Duplex spacing45MHz45MHz95MHz80MHz Channel Spacing 200kHz Number of channels 123 Carriers x 8 (TDMA) 175 Carriers x 8 (TDMA) 374 Carriers x 8 (TDMA) 299 Carriers x 8 (TDMA) Modulation GMSK 8‐PSK Power Class GSM Power Class 4(2W) : 850 / 900MHz (27dBm) GSM Power Class 1(1W) : 1800 / 19000MHz (26dBm) EDGE Power Class E2 3.4 GSM Features Supported ME SIM Lock Network 40 possible codes supported Network Subset 30 possible codes supported Service Provider 40 possible codes supported SIM / USIM 1 possible codes supported SIM Application Toolkit USIM Application Toolkit Supported(Release 99) Supported(Release 99) USSDSending USSD supported; No MMI is provided. Speech CodingNot applicable 10 LG Electronics Confidential GPRS ReleaseR99 Data Rates Multislot class 12 supported (Customer configurability to support Multi‐slot Class 10) GPRS Coding Schemes : CS‐1, CS‐2, CS‐3, CS‐4 Mode of OperationClass B Network Modes Network Mode 1 Network Mode 2 Network Mode 3 IP ConnectivityPDP type IP is supported IPv4 SMS over GPRSMobile Originated and Mobile Terminated QoSSupport for all 4 classes (AT Command level) QoS Negotiation PDP Context PDP Context description edited via supplied Wizard o…
Text truncated - open the document above for the full version.
LG Electronics USA 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 Date: Aug. 04, 2009 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. SunHee Kim of HCT Co., Ltd and hereafter referred to as HCT, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. SunHee Kim of HCT Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing HCT as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jae Cheon(J.C.) Lee General Manager LG Electronics USA REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.
LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: February 1, 2010 Fe deral Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJLUM900D Equipment Class: PCB: PCS License d Tr ansmitter To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure PERMANENT 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electroni cs USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632
Request for Modular Approval FCC ID: BEJLUM900D Item Requirements EUT 1 The final device is designed for mobile or fixed operation. ( Below is example statement ) This Modem module will be installed in a host product where the transmitting antenna can provide 20cm separation distance to the body of user. This module is sold to OEM and will only be installed by OEM or OEM authorized installer. Install this module in a portable configuration is not allowed unless proper equipment authorization has obtained. 2 The maximum antenna gain to allow compliance with RF exposure requirements is listed on the Grant of Certification for the module. The antenna gain including cable loss must not exceed -3.68dBi in Cellular band and -2.04dBi in PCS band, for purposes of 2.1043 and 2.1091. Above MPE estimate is based upon the measured peak conducted output power. MPE estimate is submitted via separate RF exposure attachment. 3 The licensed module must have a FCC ID label on the module itself. That FCC ID label must be visible through a window on the final device or it must be visible when an access panel, door or cover is easily removed. If not, a second label must be placed on the outside of the final device that contains the following text: Contains “FCC ID: BEJLUM900D” Please refer to the FCC ID label format. Labeling instruction has been provided in the OEM installation instruction. 4 The Grant should include the following words in the device description or grant notes: “modular transmitter” or “transmitter module”. Modular approval is requested for this application.
Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 1 of 7 EXTERNAL PHOTOGRAPHS Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 2 of 7 ■ EXTERNAL PHOTO Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 3 of 7 ■ EXTERNAL PHOTO Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 4 of 7 ■ EXTERNAL PHOTO Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 5 of 7 ■ EXTERNAL PHOTO Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 6 of 7 ■ EXTERNAL PHOTO Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 7 of 7 ■ EXTERNAL PHOTO
※ FCC ID Label Form Note: The FCC ID label shown will be readily visible at the time of purchase. FCC ID: BEJLUM `WWk Model: LUM- `WWk
Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 1 of 3 INTERNAL PHOTOGRAPHS Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 2 of 3 ■ INTERNAL PHOTO Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 3 of 3 ■ INTERNAL PHOTO
FCC ID:BEJLUM900D HCT CO., LTD SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8565 FAX : + 82 31 639 8525 www.hct.co.kr 1 of 3 RF Exposure Statement 1. LIMITS According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength (V/m) Magnetic field Strength (A/m) Power density (mW/cm²) Averaging time (minutes) 0.3 - 1.34....................................... 1.34 - 30....................................... 30 - 300....................................... 300 - 1500.................................... 1500 - 100.000................................. 614 824/f 27.5 ............... ............... 1.63 2.19/f 0.073 ............... ............... *(100) *(180/ f²) 0.2 f/1500 1.0 30 30 30 30 30 F = frequency in MHz * = Plane-wave equivalent power density 2. MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG/4πR² S = Power density P = power input to antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna FCC ID: BEJLUM900D HCT CO., LTD SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8565 FAX : + 82 31 639 8525 www.hct.co.kr 2 of 3 2-1. GSM850 BAND Max Peak output Power at antenna input terminal (dBm) 32.720 Max Peak output Power at antenna input terminal (mW) 1629.296 Prediction distance (cm) 20.000 Prediction frequency (MHz) 848.800 Antenna Gain(typical) (dBi) -1.03 Antenna Gain(numeric) 0.444 Power density at prediction frequency (mW/cm²) 0.14392 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 0.566 2-2. GSM1900 BAND Max Peak output Power at antenna input terminal (dBm) 28.93 Max Peak output Power at antenna input terminal (mW) 826.03795 Prediction distance (cm) 20.00000 Prediction frequency (MHz) 1850.2 Antenna Gain(typical) (dBi) -1.03 Antenna Gain(numeric) 0.65464 Power density at prediction frequency (mW/cm²) 0.10758 MPE limit for uncontrolled exposure at prediction frequency (mW/cm²) 1.00000 FCC ID: BEJLUM900D HCT CO., LTD SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8565 FAX : + 82 31 639 8525 www.hct.co.kr 3 of 3 3. RESULTS The power density level at 20 cm is 0.14392 mW/cm², which is below the uncontrolled exposure limit of 0.566 mW/cm² at 848.8 MHz for GSM850 band. The power density level at 20 cm is 0.10758 mW/cm², which is below the uncontrolled exposure limit of 1.0 mW/cm² at 1850.2 MHz for GSM1900 band.
FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR04 Date of Issue: February 02, 2010 EUT Type: Cellular/ PCS GSM/ EDGE Module FCC ID: BEJLUM900D Page 2 of 39 Table of Contents 1. GENERAL INFORMATION ........................................................................................................................... 3 2. INTRODUCTION ........................................................................................................................................... 4 2.1. EUT DESCRIPTION............................................................................................................................ 4 2.2. MEASURING INSTRUMENT CALIBRATION .................................................................................... 4 2.3. TEST FACILITY .................................................................................................................................. 4 3. DESCRIPTION OF TESTS ........................................................................................................................... 5 3.1 Effective Radiated Power/Equivalent Isotropic Radiated Power................................................... 5 3.2 Peak- to- Average Ratio ..................................................................................................................... 6 3.3 Occupied bandwidth. ......................................................................................................................... 7 3.4 Spurious and Harmonic Emissions at Antenna Terminal. ............................................................. 8 3.5 Radiated Spurious and Harmonic Emissions ................................................................................. 9 3.6 Frequency stability / variation of ambient temperature ............................................................... 10 4. LIST OF TEST EQUIPMENT .......................................................................................................................11 5. SUMMARY OF TEST RESULTS ................................................................................................................ 12 6. SAMPLE CALCULATION ........................................................................................................................... 13 7. TEST DATA ................................................................................................................................................. 14 7.1 Conducted Output Power ................................................................................................................ 14 7.2 Peak-to-Average Ratio ..................................................................................................................... 15 7.3 Occupied Bandwidth........................................................................................................................ 16 7.4 Conducted Spurious Emissions ..................................................................................................... 17 7.4.1 Band Edge .............................................................................................................................. 17 7.5 Effective Radiated Power Output (GSM) ........................................................................................ 18 7.6 Equivalent Isotropic Radiated Power (GSM) ................................................................................. 19 7.7 Radiated Spurious Emissions......................................................................................................... 20 7.7.1 Radiated Spurious Emissions (GSM850)............................................................................. 20 7.7.2 Radiated Spurious Emissions (GSM1900)........................................................................... 21 7.8 Frequency stability / variation of ambient temperature ............................................................... 22 7.8.1 FREQUENCY STABILITY (GSM850) ..................................................................................... 22 7.8.2 FREQUENCY STABILITY (GSM1900) ................................................................................... 23 8. TEST PLOTS............................................................................................................................................... 24 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR04 Date of Issue: February 02, 2010 EUT Type: Cellular/ PCS GSM/ EDGE Module FCC ID: BEJLUM900D Page 3 of 39 MEASUREMENT REPORT 1. GENERAL INFORMATION Applicant Name: LG Electronics, Inc. Address:60-39, Gasan-dong, Gumchon-gu, Seoul 153-023, Korea FCC ID: BEJLUM900D Application Type: Certification FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §22, §24, §2 EUT Type: Cellular/ PCS GSM/ EDGE Module Model(s): LUM-900D Tx Frequency: 824.20 - 848.80 MHz (GSM850) 1 850.20 - 1 909.80 MHz (GSM1900) Rx Frequency: 869.20 - 893.80 MHz (GSM850) 1 930.20 - 1 989.80 MHz (GSM1900) Max. RF Output Power: 1.253 W ERP GSM850 (30.98 dBm) / 0.337 W EIRP GSM1900 (25.27 dBm) 0.601 W ERP EDGE850 (27.79 dBm) / 0.288 W EIRP EDGE1900 (24.60 dBm) Emission Designator(s): 247KGXW (GSM850) 244KGXW (GSM1900) 251KG7W (GSM850 EDGE) 247KG7W (GSM1900 EDGE) Antenna Specification Manufacturer: ACE Antenna Co., Ltd. Antenna type: Fixed Antenna Peak Gain: -1.03 dBi Date(s) of Tests: January 14, 2010 ~ January 18, 2010 FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1002FR04 Date of Issue: February 02, 2010 EUT Type: Cellular/ PCS GSM/ EDGE Module FCC ID: BEJLUM900D Page 4 of 39 2. INTRODUCTION 2.1. EUT DESCRIPTION The LG Electronics, Inc. LUM-900D Cellular/ PCS GSM/ EDGE Module consists of GSM850, GSM1900, GPRS12, EDGE. 2.2. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipme…
Text truncated - open the document above for the full version.
Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 1 of 3 TEST SETUP PHOTOGRAPHS MEID Number: A00000016703A5 Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 2 of 3 ■ Test Setup Photo Report No.: HCTR1002FR04 FCC ID: BEJLUM900D DATE: February 02, 2010 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page 3 of 3 ■ Test Setup Photo
San 136-1, Ami-ri , Bubal-eup, Icheon-si · Kyoungki- do · South Korea
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 4 | 24E | 1.85 GHz - 1.91 GHz | 324.00 mW | 247KG7W | 2.5 ppm |
