BEJLX535Tri-Mode Dual-Band Cellular PCS Phone (AMPS/ CDMA)

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jun 10, 2004
Application Purpose: Original Equipment
Date of Application: Jun 10, 2004
Equipment Note: Tri-Mode Dual-Band Cellular PCS Phone (AMPS/ CDMA)
Frequency Range: 1851.25000000 - 1908.75000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

- 1 - LG- LX535 User Guide Ver. 0.1 2004.05.03 - 2 - Unlocking Your Phone............................................................................. 4 View of Phone ......................................................................................... 4 Installing and Removing the Battery....................................................... 5 Turning Your Phone On and Off ............................................................. 5 Main Menu .............................................................................................. 5 Power Save Mode .................................................................................... 5 Menu Navigation ..................................................................................... 6 Entering Characters Using the Keypad(T9) ............................................ 6 Display Icons ........................................................................................... 7 Antenna.................................................................................................... 7 Signal Strength ........................................................................................ 8 Battery Capacity ...................................................................................... 8 Using the AC Adapter.............................................................................. 8 Using Your Phone.........................................................................................................................................8 Placing a Call........................................................................................... 8 Roaming With Your Sprint PCS Phone TM ............................................... 9 Calling Experience .................................................................................. 9 Correcting Dialing Mistakes ................................................................. 10 In Call Options....................................................................................... 11 Incoming Call Notification.................................................................... 11 Answering Calls .................................................................................... 12 Displaying Your Sprint PCS Phone Number(phone book – not functioning) ........................................................................................... 12 Setting the Ring Volume to Vibrate ....................................................... 13 Getting the Most From Sprint PCS Service................................................................................................13 New Massage Alerts .............................................................................. 13 Retrieving Page/Text Messages............................................................. 13 Page/Text Message Storage ................................................................... 15 Roaming on to Other Service Providers................................................ 15 (Call History- not functioning) .............................................................. 15 Page/Text Messages............................................................................... 15 Erasing Page/Text Messages ................................................................. 16 Sounds ................................................................................................... 16 Adjusting the Volume ............................................................................ 16 Selecting Ring Types for Voice Calls .................................................... 16 - 3 - Tone Length ........................................................................................... 17 Display Menu .............................................................................................................................................18 Security .................................................................................................. 18 Locking Your Phone .............................................................................. 19 Unlocking Your Phone........................................................................... 19 Changing the Lock Code ....................................................................... 19 Answering Your Phone with the Hands-Free Car Kit ........................... 20 - 4 - Unlocking Your Phone If you received your Sprint PCS LX535 in the mail, you may need to unlock it before making calls. 1. Press the [ END] Switch for 2~3 secs. 2. Highlight Unlock and press [ OK ] . 3 3 3 . . . Enter your four-digit lock code. For security purposes, the code will not be visible as you type. Note: If you can’t recall your lock code, try using the last four digits of your Social Security number, the last four digits of your Sprint PCS Phone Number or 0000. View of Phone 1. [END] Switch: Lets you power the phone on or off. 2. Antenna: Fised antenna provides optimum reception for 1900 MHz frequencies. 3. Power On Indicator: Illuminates red when the phone powers on or when you receive incoming calls. Flashes red when you have messages of scheduled alarms. 4. Headset Jack: Provides connection for an optional headsat. 5. Volume Control Keys: Adjust the Ring Volume in the Main Menu or the Voice Volume during a call. The keys also scroll through mouths in the Calendar or pages in the MiniBrowser. 6. Mouse Key: Allows quick and easy scrolling through the menus. 7. OK: Lets you place a call, receive a call, end a call or select menu options. 8. CLR: Lets you clear an entry or back-up in the menu. - 5 - Installing and Removing the Battery To install the battery, insert the bottom of the battery into the opening on the back of the phone. Then, push the battery down until the latch clicks. To remove the battery, press down on the latch and remove the battery from the phone. Turning Your Phone On and Off To turn your phone on, move the On/Off Switch (near the antenna) to the ON position. …

Text truncated - open the document above for the full version.

Attestation Statements

June 21, 2004 Federal Communications Commission Authorization and Evaluation Div. Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: LG Electronics Inc. FCC ID: BEJLX535 Request for Short-Term Confidentiality To Whom It May Concern: In accordance with 0.457 and 0.459 of CFR 47, LG Electronics Inc. requests short-term confidentiality for the test setup photos, external photos, internal photos, and user’s manual of the attached test report. These documents contain detailed system and equipment descriptions and related information about the product, which LG Electronics Inc. considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Sincerely,

Attestation Statements

LG Electronics Inc. LG Info Comm U.S.A. Inc. 55 Madison Ave., Suite 180 Morristown, NJ 07960 U.S.A. Tel. : +1-973-401-9109 Feb10, 2004 Federal Communication Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To Whom it may concern: We, The undersigned, Hereby authorize PCTEST Engineering Laboratory Inc. to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents Relating to the matters. Any and all acts carried out by PCTEST Engineering Laboratory Inc. On our behalf shall have the same effect as acts of our own. We also hereby certify that No party to the application is to a denial of benefits, Including FCC benefits, pursuant to Section 5301 of the Anti-Drug ACT of 1988, 21 U.S.C 8539a). Sincerely, Bruce Choi General Manager of New York Office LG Electronics Inc. May 10. 2004 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : LG Electronics Inc.. Tri-band Quad-mode CDMA Phone (Amps/Cellular/PCS/GPS) Part 22, 24 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Electronics, Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams & Circuit Description attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced Type Acceptance application. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE May 10. 2004 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: LG Electronics Inc.. Tri-band Quad-mode CDMA Phone (Amps/Cellular/PCS/GPS) Part 22/24 Certification Gentlemen: We hereby certify that this transmit and receive equipment (FCC ID: BEJLX535) for tri- mode mobile station cellular use is capable of compliance with the TIA/EIA-95-B Mobile Station-Base Station Compatibility Standards for Dual-Mode Spread Spectrum Systems, December 1998. Furthermore, we certify compliance to ANSI/TIA/EIA-553-A-1999, Mobile Station-Land Station Compatibility Specification. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc.

Cover Letter(s)

June 1, 2004 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS, INC. FCC ID: BEJLX535 Part 22/24 Certification Gentlemen: Submitted herewith, on behalf of LG ELECTRONICS, INC., is an application for Part 22/24 Certification of the Tri-Mode Dual-Band Analog/PCS CDMA Phone (AMPS/CDMA). Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: LG ELECTRONICS, INC.

External Photos

ID Label/Location Info

© 2004 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) LG Electronics Inc. 13 04-6-2 2. 983 (f) Equipment Identification: LG Electronics Inc. LGE Model No . LG-LX535 FCC ID : BEJLX535 S/N : Made in Korea

Internal Photos

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.240510298.BEJ Test Dates: May 11-19, 2004 Phone Type: Tri-Mode Dual-Band FCC ID: BEJLX535 Page 1 of 50 © 2004 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: LG ELECTRONICS, INC. Dates of Tests: May 11-19, 2004 2000 Milbrook Drive Test Report S/N: SAR.240510298.BEJ Lincolnshire, IL 60069 Test Site: PCTEST Lab, Columbia MD FCC ID: BEJLX535 APPLICANT: LG ELECTRONICS, INC. EUT Type: Tri-Mode Dual-Band Analog/PCS Phone (AMPS/CDMA) Tx Frequency: 824.04 – 848.97 MHz (AMPS) / 824.70 – 848.31 MHz (CDMA) 1851.25 – 1908.75 MHz (PCS CDMA) Rx Frequency: 869.04 – 893.97 MHz (AMPS) / 869.70 – 893.31 MHz (CDMA) 1931.25 – 1988.75 MHz (PCS CDMA) Max. RF Output Power: 0.511 W ERP AMPS (27.085 dBm) / 26.0 dBm Conducted 0.326 W ERP CDMA (25.133 dBm) / 24.0 dBm Conducted 0.312 W EIRP PCS CDMA (24.931 dBm) / 24.0 dBm Conducted Max. SAR Measurement: 1.220 W/kg AMPS Head SAR; 0.914 W/kg AMPS Body SAR; 0.632 W/kg CDMA Head SAR; 0.603 W/kg CDMA Body SAR; 1.010 W/kg PCS CDMA Head SAR; 0.572 W/kg PCS CDMA Body SAR Trade Name/Model(s): LG-LX535 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype [S/N: #1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. P1528 D1.2 (April 2003). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm between the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters may not contain metallic components. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.240510298.BEJ Test Dates: May 11-19, 2004 Phone Type: Tri-Mode Dual-Band FCC ID: BEJLX535 Page 2 of 50 © 2004 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION................................................................................3 2. SAR MEASUREMENT SETUP............................................................................................4 3. DASY4 E-FIELD PROBE SYSTEM.......................................................................................5 4. PROBE CALIBRATION PROCESS......................................................................................6 5. PHANTOM & EQUIVALENT TISSUES................................................................................7 6. TEST SYSTEM SPECIFICATIONS........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS...............................................................9 8. DEFINITION OF REFERENCE POINTS.............................................................................10 9. TEST CONFIGURATION POSITIONS..............................................................................11 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS................................................................14 11. MEASUREMENT UNCERTAINTIES..................................................................................15 12. SYSTEM VERIFICATION.................................................................................................16 13. SAR TEST DATA SUMMARY.......................................................................................17-47 15. SAR TEST EQUIPMENT..........................................................................................48 16. CONCLUSION..............................................................................................................49 17. REFERENCES.................................................................................................................50 PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.240510298.BEJ Test Dates: May 11-19, 2004 Phone Type: Tri-Mode Dual-Band FCC ID: BEJLX535 Page 3 of 50 © 2004 PCTEST Engineering Laboratory, Inc 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recomm…

Text truncated - open the document above for the full version.

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. DUT: LG-LX535; Type: LG Tri Mode Phone; Serial: #1; Conducted Power: 26.0 dBm Communication System: AMPS; Frequency: 836.49 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.89 mho/m, ε r = 40.02, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 05-12-2004; Ambient Temp: 23.5°C; Tissue Temp: 20.8°C Probe: ES3DV2 - SN3022; ConvF(6.1, 6.1, 6.1); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Galtronics antenna, Slide In, Touch, Ch.0383, Ant.Out, Standard Battery Area Scan (51x151x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 24 V/m Peak SAR (extrapolated) = 0.639 W/kg SAR(1 g) = 0.494 mW/g; SAR(10 g) = 0.359 mW/g 0 dB = 0.551mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: LG-LX535; Type: LG Tri Mode Phone; Serial: #1; Conducted Power: 26.0 dBm Communication System: AMPS; Frequency: 848.97 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.89 mho/m, ε r = 40.02, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 05-12-2004; Ambient Temp: 23.5°C; Tissue Temp: 20.8°C Probe: ES3DV2 - SN3022; ConvF(6.1, 6.1, 6.1); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Galtronics antenna, Slide In, Tilt, Ch.0799, Ant.Out, Standard Battery Area Scan (51x151x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 30.7 V/m Maximum value of SAR (measured) = 0.889 mW/g SAR(1 g) = 0.768 mW/g; SAR(10 g) = 0.516 mW/g 0 dB = 0.889mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: LG-LX535; Type: LG Tri Mode Phone; Serial: #1; Conducted Power: 26.0 dBm Communication System: AMPS; Frequency: 836.49 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.89 mho/m, ε r = 40.02, ρ = 1000 kg/m 3 ) Phantom section: Left Section Test Date: 05-11-2004; Ambient Temp: 23.4°C; Tissue Temp: 21.2°C Probe: ES3DV2 - SN3022; ConvF(6.1, 6.1, 6.1); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Galtronics antenna, Slide In, Touch, Ch.0383, Ant.In, Standard Battery Area Scan (51x111x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 23.7 V/m Peak SAR (extrapolated) = 0.703 W/kg SAR(1 g) = 0.478 mW/g; SAR(10 g) = 0.339 mW/g 0 dB = 0.543mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: LG-LX535; Type: LG Tri Mode Phone; Serial: #1; Conducted Power: 26.0 dBm Communication System: AMPS; Frequency: 848.97 MHz;Duty Cycle: 1:1 Medium: 835 Muscle ( σ = 0.98 mho/m, ε r = 55.26, ρ = 1000 kg/m 3 ) Phantom section: Left Section Test Date: 05-11-2004; Ambient Temp: 23.4°C; Tissue Temp: 21.2°C Probe: ES3DV2 - SN3022; ConvF(6.1, 6.1, 6.1); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Galtronics antenna, Slide In, Tilt, Ch.0799, Ant.In, Standard Battery Area Scan (51x111x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 34.4 V/m Peak SAR (extrapolated) = 1.88 W/kg SAR(1 g) = 1.22 mW/g; SAR(10 g) = 0.764 mW/g 0 dB = 1.47mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: LG-LX535; Type: LG Tri Mode Phone; Serial: #1; Conducted Power: 26.0 dBm Communication System: AMPS; Frequency: 836.49 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.89 mho/m, ε r = 40.02, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 05-12-2004; Ambient Temp: 23.5°C; Tissue Temp: 20.8°C Probe: ES3DV2 - SN3022; ConvF(6.1, 6.1, 6.1); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Galtronics antenna, Slide Out, Touch, Ch.0383, Ant.Out, Standard Battery Area Scan (51x151x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 10.3 V/m Maximum value of SAR (measured) = 0.154 mW/g SAR(1 g) = 0.139 mW/g; SAR(10 g) = 0.103 mW/g 0 dB = 0.154mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: LG-LX535; Type: LG Tri Mode Phone; Serial: #1; Conducted Power: 26.0 dBm Communication System: AMPS; Frequency: 836.49 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.89 mho/m, ε r = 40.02, ρ = 1000 kg/m 3 ) Phantom section: Right Section Test Date: 05-12-2004; Ambient Temp: 23.5°C; Tissue Temp: 20.8°C Probe: ES3DV2 - SN3022; ConvF(6.1, 6.1, 6.1); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 Galtronics antenna, Slide Out, Tilt, Ch.0383, Ant.Out, Standard Battery Area Scan (51x151x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.81 V/m Maximum value of SAR (measured) = 0.077 mW/g SAR(1 g) = 0.065 mW/g; SAR(10 g) = 0.044 mW/g 0 dB = 0.077mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: LG-LX535; Type: LG Tri Mode Phone; Serial: #1; Conducted Power: 26.0 dBm Communication System: AMPS; Frequency: 836.49 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.89 mho/m, ε r = 40.…

Text truncated - open the document above for the full version.

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. DUT: Dipole 835 MHz; Type: D835V2; Serial: 406 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: 835 Brain ( σ = 0.89 mho/m, ε r = 40.02, ρ = 1000 kg/m 3 ) Phantom section: Flat Section; Space: 1.5 cm Test Date: 05-11-2004; Ambient Temp: 23.4°C; Tissue Temp: 21.2°C Probe: ES3DV2 - SN3022; ConvF(6.1, 6.1, 6.1); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 835 MHz Dipole Validation Area Scan (61x121x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Input Power = 24.0 dBm (250 mW) SAR(1 g) = 2.35 mW/g; SAR(10 g) = 1.52 mW/g Target SAR(1g) = 2.375 mW/g; Deviation = -1.05 % 0 dB = 2.76mW/g PCTEST ENGINEERING LABORATORY, INC. DUT: Dipole 1900 MHz; Type: D1900V2; Serial: 502 Communication System: CW; Frequency: 1900 MHz;Duty Cycle: 1:1 Medium: 1900 Brain ( σ = 1.37 mho/m, ε r = 40.7, ρ = 1000 kg/m 3 ) Phantom section: Flat Section; Space: 2.0 cm Test Date: 05-13-2004; Ambient Temp: 23.8°C; Tissue Temp: 21.8°C Probe: ES3DV2 - SN3022; ConvF(5, 5, 5); Calibrated: 9/23/2003 Sensor-Surface: 3mm (Mechanical Surface Detection) Electronics: DAE3 Sn455; Calibrated: 1/6/2004 Phantom: SAM 12b; Type: SAM 4.0; Serial: TP:1197 Measurement SW: DASY4, V4.2 Build 44; Postprocessing SW: SEMCAD, V1.8 Build 112 1900 MHz Dipole Validation Area Scan (41x51x1): Measurement grid: dx=15mm, dy=15mm Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Input Power = 20.0 dBm (100 mW) SAR(1 g) = 3.71 mW/g; SAR(10 g) = 1.86 mW/g Target SAR(1g) = 3.97 mW/g; Deviation = -6.54 % 0 dB = 4.85mW/g

RF Exposure Info

LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535 LGE FCC ID: BEJLX535 EUT Photographs © 2004 PCTEST Lab. Tri-Mode Dual-Band Analog/PCS Phone Model: LG-LX535

RF Exposure Info

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)

[email protected]201-470-2696Fax: 201-816-2003

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652Fax: 410-290-6654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
4	24E	1.85 GHz - 1.91 GHz	312.00 mW	1M25F9W	2.5 ppm

Confidentiality

Long Term

Grant Notes

Output is ERP for Part 22 and EIRP for Part 24. SAR compliance for body-worn operating configuration is based on a separation distance of 1.5 cm from the back of the unit and the body of the user. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. Belt clips or holsters must not contain metallic components. The highest reported SAR values under this FCC ID: are Part 22 - Head: 1.22 W/kg; Body-worn: 0.914 W/kg; Part 24 - Head: 1.01 W/kg; Body-worn: 0.572 W/kg.
