M4300 <1> M4300 User Guide WE SHOULD INFORM USER THAT THIS MANUAL CAN HAVE SOME DIFFERENCES FROM PHONE DEPENDING ON PHONE S/W AND SERVICE PROVIDER. <2> M4300 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 8 Guidelines for safe and efficient use . . . . . . . . . . 9 M4300 features . . . . . . . . . . . . . . . . . . . . . . . 14 Parts of the phone . . . . . . . . . . . . . . . . . . . . . 14 Display information . . . . . . . . . . . . . . . . . . . . . 19 Getting started . . . . . . . . . . . . . . . . . . . . . . . 20 Installing the SIM card and the handset battery . . . . 20 Charging the battery . . . . . . . . . . . . . . . . . . . . 22 Disconnecting the adapter . . . . . . . . . . . . . . . . . 23 Turning your phone on and off . . . . . . . . . . . . . . 24 Turning your phone ON . . . . . . . . . . . . . . . . . . . 24 Turning your phone OFF . . . . . . . . . . . . . . . . . 24 Access codes . . . . . . . . . . . . . . . . . . . . . . . . 24 PIN code . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 PIN2 code . . . . . . . . . . . . . . . . . . . . . . . . . . 25 PUK code . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 PUK2 code . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Security code . . . . . . . . . . . . . . . . . . . . . . . . 25 Barring password . . . . . . . . . . . . . . . . . . . . . . 25 General functions . . . . . . . . . . . . . . . . . . . . . . 26 Making and answering calls . . . . . . . . . . . . . . . 26 Making a call . . . . . . . . . . . . . . . . . . . . . . . . 26 Making a call using the send key . . . . . . . . . . . . . 26 Making an international call . . . . . . . . . . . . . . . . 26 Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . 26 Making a call from the phonebook . . . . . . . . . . . . 27 Adjusting the volume . . . . . . . . . . . . . . . . . . . . 27 Answering a call . . . . . . . . . . . . . . . . . . . . . . 27 Switching quickly to Vibrate only mode . . . . . . . . . 28 Signal strength . . . . . . . . . . . . . . . . . . . . . . . 28 Entering text . . . . . . . . . . . . . . . . . . . . . . . . . 28 Changing the text input mode . . . . . . . . . . . . . . . 29 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 In call menu . . . . . . . . . . . . . . . . . . . . . . . . . 32 During a call . . . . . . . . . . . . . . . . . . . . . . . . . 32 Multiparty or conference calls . . . . . . . . . . . . . . 34 Making a second call . . . . . . . . . . . . . . . . . . . . 34 Ending a multiparty call . . . . . . . . . . . . . . . . . . 35 Menu tree . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Selecting functions and options . . . . . . . . . . . . . 38 Special . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 My Media . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Games & more . . . . . . . . . . . . . . . . . . . . . . . . 40 Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 External Memory . . . . . . . . . . . . . . . . . . . . . . 40 Call register . . . . . . . . . . . . . . . . . . . . . . . . . 43 Missed calls . . . . . . . . . . . . . . . . . . . . . . . . . 43 Contents M4300 <3> Received calls . . . . . . . . . . . . . . . . . . . . . . . 43 Dialled calls . . . . . . . . . . . . . . . . . . . . . . . . . 44 Delete recent calls . . . . . . . . . . . . . . . . . . . . . 44 Call charges . . . . . . . . . . . . . . . . . . . . . . . . . 44 Call duration . . . . . . . . . . . . . . . . . . . . . . . . . 44 Call costs . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 GPRS information . . . . . . . . . . . . . . . . . . . . . . 46 Call duration . . . . . . . . . . . . . . . . . . . . . . . . . 46 Data volume . . . . . . . . . . . . . . . . . . . . . . . . . 46 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 47 New message . . . . . . . . . . . . . . . . . . . . . . . . 47 Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Mailbox . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Sent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Drafts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Listen to voice mail . . . . . . . . . . . . . . . . . . . . . 54 Info message . . . . . . . . . . . . . . . . . . . . . . . . 54 Read . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Templates . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Text template . . . . . . . . . . . . . . . . . . . . . . . . 55 Multimedia template . . . . . . . . . . . . . . . . . . . . 56 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Text message . . . . . . . . . . . . . . . . . . . . . . . . 57 Multimeadia message . . . . . . . . . . . . . . . . . . . 58 Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Voice mail centre . . . . . . . . . . . . . . . . . . . . . . 59 Info message . . . . . . . . . . . . . . . . . . . . . . . . 59 Push message . . . . . . . . . . . . . . . . . . . . . . . . 60 t-zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Add new . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Caller groups . . . . . . . . . . . . . . . . . . . . . . . . 64 Speed dial . . . . . . . . . . . . . . . . . . . . . . . . . . 64 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Default memory . . . . . . . . . . . . . . . . . . . . . . . 6…

Text truncated - open the document above for the full version.

<46> M4300 Listen to voice mail Menu-4-7 This menu provides you with a quick way of accessing your voice mailbox (if provided by your network). Before using this feature, you must enter the voice centre number obtained from your network operator. When new voice message is received, the symbol will be displayed on the screen. Please check with your network provider for details of their service in order to configure the handset correctly. Info message (Network dependent) Menu-4-8 Info service messages are text messages sent by the network to mobile phone users. They provide general information such as weather reports or traffic condi- tions. Each type of information has the number; there- fore, you can contact the service provider as long as you have input the certain number for the information. When you receive an info service message, a popup message will indicate a new message receipt or the info service message will be displayed directly. The following options are available when viewing info serv - ice messages. Read (Menu-4-8-1) 1. Select Read to view the message, it will be displayed on the screen. 2. The message will be shown until another message is reached. Topics (Network dependent) (Menu-4-8-2) • Add new: You can add a new info service message number with its nickname in the phone or in the SIM (if the SIM is available). • View list: You can view the list of all the info service message numbers. Press the left soft key [Options] to edit or delete the info message category. • Active list: You can set whether you will receive each info service message or not using the left soft key [On/Off] in this list. Messages M4300 <47> Messages Templates Menu-4-9 There are pre-defined messages in the list. You can view and edit the template messages or create new messages. Two types of templates are available: Text and Multimedia. Text template (Menu-4-9-1) • Please call me back. • I’m late. I will be there at... • Where are you now? • I am on the way. • Top urgent. Please contact. • I love you. The following options are available. ] View: You can view the selected template. ] Delete: Deletes the selected template. ] Add new: Use this to create new template. ] Send via: ] Edit: Use this to write a new message or edit the selected template message from the text template list. ] Delete all: Deletes all the text templates. Multimedia template (Menu-4-9-2) You can create a multimedia template after pressing the left soft key [Add new]. And the multimedia tem - plates you saved as a template while creating a multi- media message in the Write multimedia message . ] Preview: Select this option to check out the multime- dia message you've created. Each slide is sequen - tially played back automatically. You can also move to another slide from the currently played slide using the left/right navigation keys. To replay the message, press the left soft key [Replay]. ] Save: Saves the message in drafts or as a template. ] Edit subject: ] Add slide: Add a slide before or after the current slide. ] Move to slide: Select this option to move to another slide from the current slide. ] Delete slide: Deletes the current slide. ] Set slide format: You can set the following slide for- mat. - Set timer: Enter the timer in each field using the numeric keypad. <48> M4300 ] T9 dictionary: Select the T9 language for T9 input mode. You can also deactivate the T9 input mode by selecting T9 off. ] Exit: Exits from the Write multimedia message menu. Settings Menu-4-0 Text message (Menu-4-0-1) This menu lets you set up default SMS information. ] Message types: Set the default message type (Text, Voice, Fax, Natl. Paging, X.400, E-mail, ERMES). The network can convert the messages into the selected format. ] Validity period: Set the length of time for which your text messages will be saved at the SMS center while attempts are made to deliver them to the recipient. Possible values are 30 minutes, 1 hour, 6 hours, 12 hours, 1 day, 1 week and the maximum authorised by your network operator. ] Delivery report: Select whether to activate or deac- tivate the report function. When this function is acti - vated, the network informs you whether or not your message has been delivered. ] Reply charging: Allows the recipient of your SMS message to send you a reply via your message cen - tre, if the service is provided by the network. ] SMS centre: Saves or changes the number of your SMS centre when sending text messages. You must obtain this number from your service provider. Multimedia message (Menu-4-0-2) Via this menu, you can set up the default multimedia message information. The following options are available. ] Priority: Set the priority for the multimedia messages you will send. ] Validity period: Set the length of time for which your multimedia messages will be saved in the network server while attempts are made to deliver them to the recipient. Possible values are 1 hour, 12 hours, 1 day, 1 week and the maximum authorised by your network operator. ] Subject: Messages M4300 <49> Messages ] Delivery report: Select whether to activate or deac- tivate the report function. When this function is acti - vated, the network informs you whether or not your message has been delivered. ] Read reply: ] Auto download - On: If you select this, messages are downloaded automatically on receipt. - Off: Requires you to confirm you want to download the message. - Home network only: If you select this, messages are downloaded automatically on receipt in your home network area. And outside your home service area, it requires you to confirm you to download the message. - Reject: If you select this, every message will be rejected on receipt. ] Network settings: If you select the multimedia mes- sage server, you can set the URL for multimedia message server. ] Permitted types: Set the permitted type. Possible val- ues are Personal, Advertisements and Information. 1. Hold down key in standby mode. 2. You can check the following submenus. • Home: You ca…
