BEJMB700G17-inch CRT Monitor

@ LG Electronics Inc.& January 10, 2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. To whom it may concern: We, the undersigned, hereby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to the application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Sincerely, General Manager of New York Office LG Electronics Inc.

February 12, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS INC. FCC ID: BEJMB700G Gentlemen: Transmitted herewith, on behalf of LG Electronics Inc. is an application for certification of the following 17–inch color monitor: FCC ID: BEJMB700G MODEL: MB700G TRADE NAMES: LG  EUT TYPE: 17-inch Color Monitor Attached are the applicant’s authorization letter, measurement report (test data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Mr. Yeong Hur, EMC Engineer LG Electronics Inc.

© 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G

© 2002 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G © 2002 PCTEST Lab 17” Color Monitor NVLAP Lab Code: 100431-0 LG Electronics Inc. FCC ID: BEJMB700G

© 2002 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 66606660--B Dobbin Road B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290TEL (410) 290--6652 6652 •• FAX (410) 290 FAX (410) 290--66546654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE LG Electronics Inc. – DID DIVISION Dates of Tests: February 19-20, 2002 642, Jinpyung-dong, Kumi-city, Test Report S/N: B.220212065.BEJ Kyoungsangbuk-do, 730-360 KOREA Test Site: PCTEST Lab., MD U.S.A. Attn: Mr. Yeong Hur, EMC Engineer FCC ID BEJMB700G APPLICANT LG ELECTRONICS INC. Rule Part(s): FCC Part 15 Subpart B Equipment Class: Class B Peripheral Device (JBP) Standard(s): EN55022: 1998 (CISPR 22) EUT Type: 17-inch Color Monitor Max. Resolution(s): 1280 x 1024 Non-interlaced @ 64kHz/60Hz Trade Name(s): LG ® Model(s): MB700G This equipment has been shown to be in compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992. (Grant Note: #19) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Lab Code 100431-0 © 2002 PCTEST Engineering Laboratory, Inc. FCC Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 1 2.1 INTRODUCTION (SITE DESCRIPTION) 2 3.1 PRODUCTION INFORMATION 3 4.1 DESCRIPTION OF TESTS (CONDUCTED) 4 4.3 DESCRIPTION OF TESTS (RADIATED) 5 5.1 LIST OF SUPPORT EQUIPMENT 6 6.1 TEST DATA (CONDUCTED) 7 7.1 TEST DATA (RADIATED) 8 8.1 SAMPLE CALCULATIONS 9 9.1 ACCURACY OF MEASUREMENT 10 10.1 LIST OF TEST EQUIPMENT 11 11.1 TEST SOFTWARE USED 12 12.1 CONCLUSION 13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: TEST SETUP PHOTOGRAPHS ATTACHMENT H: EXTERNAL PHOTOGRAPHS ATTACHMENT I: INTERNAL PHOTOGRAPHS ATTACHMENT J: USER’S MANUAL Test Report S/N: B.220212065.BEJ FCC Class B Dates of Tests: February 19-20, 2002 Certification © 2002 PCTEST Lab 17” Color Monitor 1 LG Electronics Inc. FCC ID: BEJMB700G MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Applicant Name: LG ELECTRONICS INC. Address: 642, Jinpyung-dong, Kumi-city, Kyoungsangbuk-do, 730-360 KOREA Contact Person: Yeong Hur, EMC Engineer Product Engineering Dept., Safety & EMC Team • FCC ID: BEJMB700G • Equipment Class: B Digital Device / Peripheral (JBP) • EUT Type: 17-inch Color Monitor • Trade Name(s): LG ® • Model(s): MB700G • Max. Resolution: 1280 x 1024 Non-interlaced @ 64kHz/60Hz • Frequency Range: H-Sync: 30kHz – 70kHz V-Sync: 50Hz – 160Hz • Cable(s): Shielded D-Sub (with ferrite on one end) • Power Cord: Unshielded • Rule Part(s): FCC Part 15 Subpart B • Test Procedure(s): ANSI C63.4 (1992) • Dates of Tests: February 19-20, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: B.220212065.BEJ Test Report S/N: B.220212065.BEJ FCC Class B Dates of Tests: February 19-20, 2002 Certification © 2002 PCTEST Lab 17” Color Monitor 2 LG Electronics Inc. FCC ID: BEJMB700G 2.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from LG Electronics Inc. 17- inch Color Monitor FCC ID: BEJMB700G. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure 1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: B.220212065.BEJ FCC Class B Dates of Tests: February 19-20, 2002 Certification © 2002 PCTEST Lab 17” Color Monitor 3 LG Electronics Inc. FCC ID: BEJMB700G 3.1 Product Information 3.2 Equipment Description The Equipment Under Test (EUT) is the LG Electronics Inc. (LG Model: FB775G) 17-inch Color Monitor FCC ID:BEJMB700G. Maximum Resolution(s): 1280 x 1024 Non-interlaced @64kHz/60Hz Frequency Range(s): H-Sync: 30kHz – 70kHz V-Sync: 50Hz – 160 Hz Pixel Pitch: 0.27 mm Power Supply: AC 100-240V 50/ 60Hz 2.0A Power Cord: Unshielded AC power cord Port(s)/Input Connector(s): 15-pin D-Sub type VGA signal connector Cable(s): Shielded D-Sub (with ferrite on one end) Dimensions (WxHxD): 39.1 x 45.0 x 41.6 cm Weight (Net): 19.0 kg Suppression Devices: No m…
