MG230d User manual LG Electronics LGE Property MG230d User manual ( Draft ) 8 For Your Safety Important Information This user guide contains important information on the use and operation of this phone. Please read all the information carefully for optimal performance and to prevent any damage to or misuse of the phone. Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Before You Start Safety Instructions WARNING!To reduce the possibility of electric shock, do not expose your phone to high humidity areas, such as the bathroom, swimming pool, etc. Always store your phone away from heat.Never store your phone in settings that may expose it to temperatures less than 32°F or greater than 104°F, such as outside during extreme weather conditions or in your car on a hot day. Exposure to excessive cold or heat will result in malfunction, damage and/or catastrophic failure. Be careful when using your phone near other electronic devices.RF emissions from your mobile phone may affect nearby in adequately shielded electronic equipment. You should consult with manufacturers of any personal medical devices such as pacemakers and hearing aides to determine if they are susceptible to interference from your mobile phone. Turn off your phone in a medical facility or at a gas station. Never place your phone in a microwave oven as this will cause the battery to explode. IMPORTANT!Please read the TIA SAFETY INFORMATION on page 78 before using your phone. Safety Information Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide. ]Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode. ]Never place your phone in a microwave oven as it will cause the battery to explode. ]Do not dispose of your battery by fire or with hazardous or flammable materials. ]Make sure that no sharp-edged items come into contact with the battery. There is a risk of this causing a fire. ]Store the battery in a place out of reach of children. ]Be careful that children do not swallow any parts such as rubber plugs (earphone, connection parts of the phone, etc.). This could cause asphyxiation or suffocation. 9 For Your Safety ]Unplug the power cord and charger during lightning storms to avoid electric shock or fire. ]When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is activated, you may be seriously injured. ]Do not use a hand-held phone while driving. ]Do not use the phone in areas where its use is prohibited. (For example: aircraft). ]Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom. ]Never store your phone in temperatures less than- 4°F or greater than 122°F. ]Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. There is a risk of this causing a fire. ]Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit boards of the phone. ]Do not use your phone in high explosive areas as the phone may generate sparks. ]Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock. ]Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause fire or electric shock. ]Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone. ]Do not disassemble the phone. ]Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire. ]Only use the batteries, antennas, and chargers provided by LG. The warranty will not be applied to products provided by other suppliers. ]Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty. ]Do not hold or let the antenna come in contact with your body during a call. ]An emergency call can be made only within a service area. For an emergency call, make sure that you are within a service area and that the phone is turned on. 10 For Your Safety FCC RF Exposure Information WARNING!Read this information before operating the phone. In August 1996, the Federal Communications (FCC) of he United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. CAUTION Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call quality, damage the phone, void your warranty and/or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with skin, a minor burn may result. Contact your local dealer for a replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 0.6 inches (1.5cm) between the user’s body and the back of the phone. To comply with FCC RF exposure requirements, a minimum separation distance of 0.6 inches(1.5cm) must be maintained between the user's body and the back of the phone. Third-party belt-clips, holsters, and similar accessories containing metallic components should not be used. Body-worn accessories that cannot maintain 0.6 inches(1.5cm) separation distance between the user's body and the back of the phone, and have not been tested for typical body-worn o…

Text truncated - open the document above for the full version.

PCTEST TCB From: 김성열 [[email protected]] Sent: Thursday, January 25, 2007 8:13 AM To: [email protected] Cc: [email protected]; [email protected] Subject: 답장:FW: FW: Questions Regarding FCC ID: BEJMG230D Attachments: MG230d_revised_SAR test report.pdf; MG230d_test setup photos_revised.pdf Page 1 of 3 1/25/2007 Hello Gregory, Please refer to the below answers for your comments. If it doesn't has any problem, please send us the grant for it. Thanks and regards. Sung Ryul Kim. --------------- Original Message --------------- 보낸사람 : [email protected] 받는사람 : [email protected] 참조 : 받은날자 : Thu, 25 Jan 2007 22:0:24 +0900 (KST), Thu, 25 Jan 2007 22:00:19 +0900 제목 : FW: FW: Questions Regarding FCC ID: BEJMG230D -----Original Message----- From: "Sung Ryul Kim"<[email protected]> To: [email protected] Cc: Sent: 07-01-25(목) 18:47:24 Subject: FW: Questions Regarding FCC ID: BEJMG230D SUNG RYUL KIM Estech Co., Ltd. Rm.1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea TEL : +82-2-867-3201 FAX : +82-2-867-3204 International Test Laboratory for EMC /Safety /Telecom ************* Internet E-mail Confidentiality Disclaimer ***************** This e-mail message may contain privileged or confidential information. If you are not the intended recipient, you may not disclose, use, disseminate, distribute, copy of the message including any attachment in any way. If you received this e-mail message in error, please delete the e-mail with any attachments and notify us at [email protected] . Estech does not accept liability for any errors, omissions, corruption and virus in the contents of this message including any attachment that arise as a result of e-mail transmission. ********************************************************************* From:PCTEST TCB [mailto:[email protected]] Sent: Thursday, January 25, 2007 7:39 AM To: [email protected] Cc: LGE - Bong Hyo, Han; PCTEST - Andrea Zaworski; PCTEST - Channy Park; PCTEST - Gregory Czumak; PCTEST - Gregory Snyder; PCTEST - Randy Ortanez; PCTEST - Steve Liu Subject: Questions Regarding FCC ID: BEJMG230D To: Mr. Sung-Ryul Kim / ESTECH Co., Ltd. From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: BEJMG230D Applicant: LG Electronics Co., Ltd. Correspondence Reference Number: BEJ7047 Confirmation Number: 701230047-48 Date of Original Email: January 24 , 2007 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Please confirm if there is a ferrite on the serial I/O cable used in the Part 15B tests. This should always be clearly reported. --> Yes, when we test the device, used the serial I/O cable with a ferrite. This cable is provided by LG. 2. Please submit SAR test set up photos. --> Please see the attached report. 3. The z-axis plot for 1900 MHz Body SAR does not appear to correspond to the actual SAR level measured. Please address. --> Please see the attached report. 4. Please correct the following typos: on pp.3 and 4 of the SAR report, the transmit output power Page 2 of 3 1/25/2007 for GSM850 is listed as 32.5 dBm, instead of 31.5 dBm. --> Please see the attached report. The items indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notif y the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. 새로운 기부문화의 씨앗, 해피빈 Page 3 of 3 1/25/2007

Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned Report Number : ESTF150701-005 , Web : www. estech. co. kr Page 1 of 11 Report NumberESTF150701-005 Manufacturer Country of origin Applicant Product 10-Jan-07 GSM Phone MG230d NONE LG Electronics Inc. KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2006 , ANSI C 63.4 2003 2007-1/8 ~ 2007-1/9 OK, Pass = Passed, Fail = Failed, N/A = not applicable LG Electronics Inc. 459-9, Kasan-dong, Keumchun-ku, Seoul 153-023, Korea 82-2-2033-3847 Measurement facility registration number Engineer M.J.Song Manager Engineer J.M.Yang 94696 (Signature) (Signature) 3 4 5 6 8 8 8 9 10 10 10 11 Appendix 1. Spectral diagram Report Number : ESTF150701-005 , Web : www. estech. co. kr Page 2 of 11 5. Measurement of radiated emission ............................................................... 5.1 Measurement e quipment ........................................................................... Contents 1. Laboratory Information ................................................................................. 2. Description of EUT ....................................................................................... 3. Test Standards ............................................................................................. 4. Measurement condition ................................................................................. 5.2 Environmental conditions ........................................................................ 5.3 Test data ............................................................................................. ... 6. Measurement of conducted emission ............................................................ 6.1 Measurement e quipment ........................................................................... 6.2 Environmental conditions ........................................................................... 6.3 Test data ................................................................................................ 2. Description of EUT 2.1 Summary of Equipment Under Test Product name : Model Number : MG230d Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 6-Dec-06 2.2 General descriptions of EUT Report Number : ESTF150701-005 , Web : www. estech. co. kr Page 4 of 11 GSM Phone NONE LG Electronics Inc. KOREA INPUT:AC100~240V , 50/60Hz 150-100mA Output:DC 5.2V,0.8A 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Kor e (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report. ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150701-005 , Web : www. estech. co. kr Page 3 of 11 4.3 EUT and Support equipment Equipment Name Remark (FCC ID) GSM PhoneEUT NOTE PC Printer Adapter Adapter 4.4 Cable Connecting NameI/O portI/O portLength Shielded Note PcSerialCOM2Yes Note PcUSBUSB2Yes Note PcDC Power-2No PrinterDC Power-2No PPT(Latitude D400) TW-04U917-70161- 326-30BH Dell Asia Pacific Sdn. GSM Phone C6414JTH18M149P2 Manufacturer Cable Standard LG Electronics Inc. Report Number : ESTF150701-005 , Web : www. estech. co. kr Page 7 of 11 Remark Start EquipmentEnd Equipment Printer Name S/NModel Name MG230dNONE Hewlett Packard Adapter HP-OQ065B83 CN-0N2765-47890- 441-0249 Adapter Hipro Electronics(Dongguan)Co. ,Ltd. C6409-60152C1H14BYOKOGAWA 3. Test Standards Test Standard : FCC PART 15 (2006) Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report N…
