BEJMG370ACellular/PCS GSM Phone

Turning Your Phone On and Off 1.Hold down the [END] key until the phone switches on. 2.To switch the phone off, hold down the [END] key until the power-off image displays. Menu and Options Your phone offers a set of functions that allow you to customize it. These functions are arranged in menus and sub-menus, accessed via the left and right soft keys. The label on the bottom of the display screen immediately above the soft keys indicates their current function. Entering Text You can enter alphanumeric characters by using the phone’s keypad. To change modes, press the key. T9 Mode This mode allows you to enter words with only one keystroke per letter. Each key on the keypad has more than one letter. The T9 mode automatically compares your keystrokes with an internal linguistic dictionary to determine the correct word, thus requiring far fewer keystrokes than the traditional ABC mode. ABC Mode This mode allows you to enter letters by pressing the key labeled with the required letter once, twice, three or four times until the letter is displayed. 123 Mode (Numbers Mode) Type numbers using one keystroke per number. Symbol Mode This mode allows you to enter special characters by pressing key. Making a Call 1.Enter a phone number including the area code. 2.Press the [SEND] key to call the number. 3.When finished, press the [END] key. Answering a Call 1.When the phone rings and the phone icon flashes on the screen, press the [SEND] key or the left soft key to answer. 2.End the call by pressing the [END] key. Note ] After the call ends, the phone will go back to standby mode. Making an international call 1.Press and hold the key for the international prefix. The ‘+’ character automatically selects the international access code. 2.Enter the country code, area code, and the phone number. 3.Press [send] key to call the number. MG370 USER GUIDE This manual may differ from the phone depending on the phone software version and service provider used. How to set the tone Ringtone 1.Press the left soft key [Menu] and select [Settings - Profiles] using the up/down navigation keys. 2.Select [Personalise] and choose Ringtones menu. 3.Press the left soft key [OK] and then you can set the desired ringtone. Tip ›If you want to change your ringer to vibrate, select Vibrate mode or press and hold the upper navigation key. Ringtone/Keypad/Message/Call alert tones and volumes You can select Ringtone/Keypad/Message/Call alert tones and volumes. You can change the sound that will occur when a key is pressed, or volume level. [Menu - Settings - Profiles - Personalise] Installing the SIM Card When you subscribe to a cellular network, you are provided with a plug-in SIM card loaded with your subscription details, such as your PIN, any optional services available and many others. Important! ] The plug-in SIM card and its contacts can be easily damaged by scratches or bending, so be careful when handling, inserting or removing the card. Keep all SIM cards out of the reach of small children. Illustrations Open battery cover Insert your SIM Close the battery cover Charge your battery 5 4 3 21 Installing the SIM Card and Charging the Battery Search New contact Speed dials Copy all Delete all Memory status Information You can Search for contacts in Phonebook. Note: Instant searching is available by inputting the initial letter of the name you want to search. You can add phonebook entries by using this menu. Assign contacts to any of keys and . You can copy all entries from SIM card memory to Phone memory. You can delete all entries from SIM card memory or Phone memory. You can check free space and memory usage. ›Service dial numbers:Access the list of service numbers assigned by service provider safely. ›Own numbers:You can save and check your own numbers in SIM card. ›Business card:This option allows you to create your own business card featuring your name, mobile phone number and so on. Contacts Menu 2 You can check the record of missed, received, and dialed calls only if the network supports the Calling Line Identification (CLI) within the service area. The number and name (if available) are displayed together with the date and time at which the call was made. You can also view call durations. Call history Menu 3 Quick feature reference This section provides brief explanations of features on your phone. New message Inbox Drafts Outbox Sent Voice mail Templates Settings This menu includes functions related to SMS (Short Message Services). This menu includes functions related to SMS (Short Message Services). You will be alerted when you have received a message. This menu shows the preset message list. This menu allows to view the message which is about to be sent or has failed to be sent. This menu allows you to view the messages which have already been sent, including time and content. This menu provides you with a quick way of accessing your voice mailbox (if provided by your network). There are pre-defined messages in the list. You can view and edit the template messages or create new messages. This menu allows you to set features of your network service provider. Messaging Menu 1 Menu tree 1. Messaging 1.1 New message 1.2 Inbox 1.3 Drafts 1.4 Outbox 1.5 Sent 1.6 Voice mail 1.7 Info message 1.8 Templates 1.9 Settings 2. Contacts 2.1 Search 2.2 New contact 2.3 Speed dials 2.4 Copy all 2.5 Memory status 2.6 Information 3. Call history 3.1 All calls 3.2 Missed calls 3.3 Dialed calls 3.4 Received calls 3.5 Call duration 4. SIM services 5. Tools 5.1 Game 5.2 Calendar 5.3 Alarm 5.4 Memo 5.5 Calculator 5.6 Unit converter 5.7 World clock 6. Settings 6.1 Profiles 6.2 Date & Time 6.3 Languages 6.4 Display 6.5 Call 6.6 Security 6.7 Power save 6.8 Network selection 6.9 Reset setttings 6.0 Memory status Please read these simple guidelines. Ignoring them may be dangerous or illegal. Further detailed information is given in this manual. Warning ›For your safety, use ONLY specified ORIGINAL batteries and chargers. ›Switch off the phone …

Text truncated - open the document above for the full version.

LG Electronics Inc. 60-39, Gasan-dong, Gumchon-gu Seoul 153-801, Korea Tel: 82-2-2033-1110, Fax: 82-2-2033-1222 Date: June 13, 2007 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJMG370A To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagrams 2 Operational Description 3 Parts List and Tune Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test Setup Photos SHORT-TERM CONFIDENTIAL 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, E.S.Park Manager Mobile Handset R&D Center Mobile Communications Company LG Electronics Inc.

From: bamba2k [[email protected]] Sent: Wednesday, June 20, 2007 3:01 AM To: 'PCTEST TCB' Cc: 'LGE - Bong Hyo, Han'; 'PCTEST - Gregory Czumak'; 'PCTEST - Randy Ortanez'; 'PCTEST - Steve Liu'; 'PCTEST - Mia Kang'; [email protected] Subject: RE: Questions Regarding FCC ID: BEJMG370A Attachments: MG370a_FCC_SAR-revised-1.pdf; MG370a_Operational description_revised.pdf Page 1 of 3 6/20/2007 Hello Gregory, Thank you for your response. Please refer to the below answer for your comments. If it has no problem, please send to us the grant for BEJMG370A. Thanks. SUNG RYUL KIM Estech Co., Ltd. Rm.1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul , 153-803, Korea TEL : +82-2-867-3201 FAX : +82-2-867-3204 International Test Laboratory for EMC /Safety /Telecom ************* Internet E-mail Confidentiality Disclaimer ***************** This e-mail message may contain privileged or confidential information. If you are not the intended recipient, you may not disclose, use, disseminate, distribute, copy of the message including any attachment in any way. If you received this e-mail message in error, please delete the e-mail with any attachments and notify us at [email protected]. Estech does not accept liability for any errors, omissions, corruption and virus in the contents of this message including any attachment that arise as a result of e-mail transmission. ********************************************************************* From: PCTEST TCB [mailto:[email protected]] Sent: Wednesday, June 20, 2007 7:31 AM To: [email protected] Cc: LGE - Bong Hyo, Han; PCTEST - Gregory Czumak; PCTEST - Randy Ortanez; PCTEST - Steve Liu; PCTEST - Mia Kang Subject: Questions Regarding FCC ID: BEJMG370A To: Mr. Sung-Ryul Kim / ESTECH Co., Ltd. From: Mr. Gregory Czumak / PCTEST TCB RE: FCC ID: BEJMG370A Applicant: LG Electronics Co., Ltd. Correspondence Reference Number: BEJ7543 Confirmation Number: 706180543 Date of Original Email: June 19, 2007 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Please verify that the EUT cannot connect to a pc (through a cable). If it can, then it is also a pc peripheral, subject to either certification of DoC. Î This mobile phone can’t connect to a PC. So, LG doesn’t sell it together with USB cable. 2. Please verify that Class 10 or 12 GPRS operation is not available to the EUT (body SAR was only tested with a 1:8.3 duty cycle). Î This mobile phone doesn’t support GPRS mode. Please find out the revised operational description. 3. Several frequencies listed in the table on p.22/44 of the SAR report are incorrect for the referenced channel number, and do not match the frequencies shown on the corresponding SAR plots. Please correct. Î Please find out the revised SAR test report. The items indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager Page 2 of 3 6/20/2007 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you. Page 3 of 3 6/20/2007

MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 1 of 77 MCCL SAR TEST REPORT Specific Absorption Rate Licensed Transmitter Held to Ear (PCE)FCC Classification : PASSTest Result : Certification §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type : FCC Rule Part(s) : LG Electronics, Inc.Applicant : LG Electronics, Inc.Manufacturer : MG370a, MG375aModel Name(s) : Dual-Band Mobile Handset (GSM850/PCS1900)Equipment Under Test (EUT) : Test Report No : MCCL-3-07-034Date of Issue : June 01, 2007 Issued under the authority of E. S. Park / Technical Manager MCCL Reviewed by S. K. Yoon /Vice Technical Manager MCCL Prepared by C. H. Jeong / Test Engineer MCCL This report may not be reproduced other than in full, except with the prior written approval by MCCL SUMMARY This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in European standard EN50360 : 2001 and had been tested in accordance with the measurement procedures specified in European standard EN50361:2001, IEEE 1528 – Dec. 2003, FCC/OET bulletin 65 Supplement C(2001) , Public notice 02-1438(2002), ANSI IEEE standard C95.1(2005) and C95.3(2002) ※ The test results in this test report apply only to sample(s) tested. MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 2 of 77 MCCL TABLE OF CONTENTS 1. TEST RESULT SUMMARY ··························································································· 3 2. DESCRIPTION OF THE DEVICE UNDER TEST·························································· 4 2.1 Antenna Description·································································································· 4 2.2 Device Description···································································································· 4 3. INTRODUCTION············································································································· 5 4. SAR MEASUREMENT SYSTEM ·················································································· 6 4.1 SAR Measurement Setup························································································· 6 4.2 DASY4 E-Field Probe System·················································································· 7 4.3 Phantom····················································································································9 4.4 Simulating Mixture Characterization·············· ······················· ·················· ·· ············10 4.5 Device Holder for Transmitters··············································································· 11 4.6 Validation Dipole ···································································································· 11 5. SAR MEASUREMENT PROCEDURE········································································· 12 6. DEFINITION OF REFERENCE POINT········································································ 13 6.1 EAR Reference Point······························································································ 13 6.2 Handset Reference Points······················································································ 14 7. TEST CONFIGURATION POSITIONS········································································ 15 7.1 Positioning for Cheek/Touch··················································································· 15 7.2 Positioning for Ear / 15 ° Tilt···················································································· 16 7.3 Body Holster /Belt Clip Configuration······························································· 17 8. MEASUREMENT UNCERTAINTY··············································································· 18 9. EN50360 RF EXPOSURE LIMITS··············································································· 19 10. SYSTEM VERIFICATION··························································································· 20 11. MEASUREMENT RESULTS ····················································································· 22 12. TEST EQUIPMENT····································································································· 26 13. REFERENCES············································································································ 27 APPENDIX A: Validation Test Data ······································································ 28 APPENDIX B: SAR Test Data ··············································································· 32 APPENDIX C: Calibration Certificates ································································· 65 MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 3 of 77 MCCL 1.TEST RESULT SUMMARY Maximum Results Found During SAR Evaluation 1. Head Configuration 2. Body Worn Configuration 3. Measurement Uncertainty 19.2 (k=2, 95% CONFIDENCE LEVEL)Extended Standard Uncertainty 9.6 (k=1) Combine Standard Uncertainty 1.6 W/kg averaged over 1 gram ANSI / IEEE C95.1(2005) - SAFETY LIMIT Spatial Peak Uncontrolled Exposure/General Population 1.6 W/kg averaged over 1 gram ANSI / IEEE C95.1(2005) - SAFETY LIMIT Spatial Peak Uncontrolled Exposure/General Population 1.09FixedRight TouchStandard32.4732.28GSM190836.6 StartCh.MHz Frequency End Mod. Device Test Position Battery SAR (W/kg) Antenna Position Conducted Power (dBm) 0.209Fixed 2.0 [Reart 〕 Standard32.4732.28GSM190836.6 StartCh.MHz Frequency End Mod. Device Test Position Battery SAR (W/kg) Antenna Position Conducted Power (dBm) Eui-Soon ParkResponsible Test Engineer : June 01, 2007 Date of Issue : GSM850: 32.5dBm GSM1900: 29.5dBm Transmit Output Power : …

Text truncated - open the document above for the full version.

MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 45 of 77 MCCL LG Electronics Inc. DUT: MG370a ;Type: Dual-Band Mobile Phone; Serial:IMEI 004401091870000 Communication System: GSM 850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium: Head 837 MHz;(σ= 0.959mho/m; ε r = 55.2; ρ= 1000 kg/m 3 ) Phantom section: Flat Section Test Date: 05/30/2007;Ambient Temp: 22. 9°C;Tissue Temp: 21.8°C Probe: ES3DV3 – SN3066;ConvF(5.84, 5.84, 5.84);Calibrated: 2007-01-23 Sensor-Surface: 4mm (Mechanical Surface Detection) Electronics: DAE3 Sn362; Calibrated: 2006-08-25 Phantom: SAM 835; Type: SAM 4.0; Serial: TP-1066 Measurement SW: DASY4, V4.7 Build 44; Post processing SW: SEMCAD, V1.8 Build 171 Flat Touch, Ch.190, Front, Fixed Ant., Standard Battery Area Scan (61x61x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.074mW/g Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.80V/m; Power Drift = -0.009dB Peak SAR (extrapolated) = 0.094W/kg SAR(1 g) = 0.069mW/g; SAR(10 g) = 0.049mW/g Maximum value of SAR (measured) = 0.074mW/g 0 dB = 0.074mW/g MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 46 of 77 MCCL LG Electronics Inc. DUT: MG370a ;Type: Dual-Band Mobile Phone; Serial:IMEI 004401091870000 Communication System: GSM 850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium: Head 837 MHz;(σ= 0.959mho/m; ε r = 55.2; ρ= 1000 kg/m 3 ) Phantom section: Flat Section Test Date: 05/30/2007;Ambient Temp: 22. 9°C;Tissue Temp: 21.8°C Probe: ES3DV3 – SN3066;ConvF(5.84, 5.84, 5.84);Calibrated: 2007-01-23 Sensor-Surface: 4mm (Mechanical Surface Detection) Electronics: DAE3 Sn362; Calibrated: 2006-08-25 Phantom: SAM 835; Type: SAM 4.0; Serial: TP-1066 Measurement SW: DASY4, V4.7 Build 44; Post processing SW: SEMCAD, V1.8 Build 171 Flat Touch, Ch.190, Rear, Fixed Ant., Standard Battery Area Scan (61x61x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.230mW/g Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.7V/m; Power Drift = -0.197dB Peak SAR (extrapolated) = 0.295W/kg SAR(1 g) = 0.209mW/g; SAR(10 g) = 0.140mW/g Maximum value of SAR (measured) = 0.223mW/g 0 dB = 0.223mW/g MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 47 of 77 MCCL LG Electronics Inc. DUT: MG370a ;Type: Dual-Band Mobile Phone; Serial:IMEI 004401091870000 Communication System: PCS 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium: Head 1880 MHz;(σ= 1.48 mho/m; ε r =53.8; ρ= 1000 kg/m 3 ) Phantom section: Flat Section Test Date: 05/31/2007;Ambient Temp: 22. 9°C;Tissue Temp: 21.8°C Probe: ES3DV3 – SN3066;ConvF(4.6, 4.6, 4.6);Calibrated: 2007-01-23 Sensor-Surface: 4mm (Mechanical Surface Detection) Electronics: DAE3 Sn362; Calibrated: 2006-08-25 Phantom: SAM 1800; Type: SAM 4.0; Serial: TP-1244 Measurement SW: DASY4, V4.7 Build 44; Post processing SW: SEMCAD, V1.8 Build 171 Flat Touch, Ch.661, Front, Fixed Ant., Standard Battery Area Scan (61x61x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.124mW/g Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.00V/m; Power Drift = 0.005dB Peak SAR (extrapolated) = 0.172W/kg SAR(1 g) = 0.114mW/g; SAR(10 g) = 0.073mW/g Maximum value of SAR (measured) = 0.121mW/g 0 dB = 0.121mW/g MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 48 of 77 MCCL LG Electronics Inc. DUT: MG370a ;Type: Dual-Band Mobile Phone; Serial:IMEI 004401091870000 Communication System: PCS 1900; Frequency: 1880 MHz;Duty Cycle: 1:8.3 Medium: Head 1880 MHz;(σ= 1.48 mho/m; ε r =53.8; ρ= 1000 kg/m 3 ) Phantom section: Flat Section Test Date: 05/31/2007;Ambient Temp: 22. 9°C;Tissue Temp: 21.8°C Probe: ES3DV3 – SN3066;ConvF(4.6, 4.6, 4.6);Calibrated: 2007-01-23 Sensor-Surface: 4mm (Mechanical Surface Detection) Electronics: DAE3 Sn362; Calibrated: 2006-08-25 Phantom: SAM 1800; Type: SAM 4.0; Serial: TP-1244 Measurement SW: DASY4, V4.7 Build 44; Post processing SW: SEMCAD, V1.8 Build 171 Flat Touch, Ch.661, Rear, Fixed Ant., Standard Battery Area Scan (61x61x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.179mW/g Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 11.0V/m; Power Drift = -0.264dB Peak SAR (extrapolated) = 0.264W/kg SAR(1 g) = 0.161mW/g; SAR(10 g) = 0.093mW/g Maximum value of SAR (measured) = 0.177mW/g 0 dB = 0.177mW/g MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 49 of 77 MCCL LG Electronics Inc. DUT: MG370a ;Type: Dual-Band Mobile Phone; Serial:IMEI 004401091870000 Communication System: GSM 850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium: Head 837 MHz;(σ= 0.906mho/m; ε r = 41.7; ρ= 1000 kg/m 3 ) Phantom section: Right Section Test Date: 05/30/2007;Ambient Temp: 22. 9°C;Tissue Temp: 21.8°C Probe: ES3DV3 – SN3066;ConvF(5.96, 5.96, 5.96);Calibrated: 2007-01-23 Sensor-Surface: 4mm (Mechanical Surface Detection) Electronics: DAE3 Sn362; Calibrated: 2006-08-25 Phantom: SAM 835; Type: SAM 4.0; Serial: TP-1066 Measurement SW: DASY4, V4.7 Build 44; Post processing SW: SEMCAD, V1.8 Build 171 Right Head Touch, Ch.190, Fixed Ant., Standard Battery Area Scan (61x61x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 1.18mW/g Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.59V/m; Power Drift = -0.312dB Peak SAR (extrapolated) = 1.72W/kg SAR(1 g) = 1.09mW/g; SAR(10 g) = 0.668mW/g Maximum value of SAR (measured) = 1.19mW/g 0 dB = 1.19mW/g MCCL, 60-39, Kasan-dong, Kumchon-gu, Seoul, Korea Tel:+82 2 2033 1113, Fax:+82 2 2033 1222 Test Report No:MCCL-3-07-034 Page 50 of 77 MCC…

Text truncated - open the document above for the full version.
