BEJMR22GAMagic Remote

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: JAB - Part 15 Class B Digital Device
Date of Grant: Jun 28, 2021
Application Purpose: Original Equipment
Date of Application: Jun 28, 2021
Equipment Note: Magic Remote
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Magic Remote User Information Model Name : MR22GA 목 차 1.리모콘의개요및제원 (1)개요 (2)제원 2.주의사항 3.고객지원 Korean 한국어 1.리모콘의개요및제원 (1)개 요 -매직 리모컨의사용 방법은TV 매뉴얼을참조하세요. 이 리모컨은사용자가댁내에서리모컨을무선 마우스처럼사용하여 TV를 제어할 수 있는 제품으로써, 기존 적외선 리모컨이육안상에위치한 제품을 제어했던반면에 댁내10m 이내에서방향에 상관없이제어 할 수 있는2.4 GHz대RF 리모컨이다. (음성인식지원) (2)제 원 구분내 용 모델명MR22GA 무선 사양 및 주파수BluetoothLE / 2.400 GHz ~ 2.4835 GHz 채널40 채널 전원 DC 3V 알카라인AA 1.5 V건전지2개 사용 동작 온도0 °C ~ 40 °C 2.주의 사항 (1)건전지를 교체한 후에는 리모컨 사용법에 따라 페어링 후에 사용 한다. (2)건전지를 교체 후에 리모컨이 정상 동작하지 않는 경우, 페어링 설정을 다시 해 주세요 . (3)장기간 리모컨을 사용하지 않는 경우, 건전지를 제거해 두는 것이 좋다. ( 4)건전지를 분해하거나, 열을 가해서는 안 된다. (5)건전지를 떨어뜨리거나, 케이스가 손상될 정도로 극심한 충격을 줘서는 안 된다. ( 6)건전지를 물에 넣어서는 안 된다. (7)건전지를 거꾸로 삽입시 폭발의 위험이 있다. ( 8)지정된 장소에 사용한 건전지를 폐기 한다. ( 9)건전지 뚜껑을 열면, 라벨을 확인할 수 있습니다. 3.고객지원 TV 매뉴얼의 서비스 연락처를 참조하세요. [KC 인증 마크 및 인증번호] 상호명: 엘지전자(주) 인증번호: MSIP-CRM-LGE-MR22GA 제조연월: 2020. 제조자 /제조국가: 엘지전자(주)/대한민국 기자재의 명칭/모델명: 특정소출력 무선기기(무선데이터통신시스템용 무선기기)/MR22GA A/S 정보: (주) 엘지전자서비스 Tel : 1544-7777 홈페이지: www.lgeservice.co.kr Table of Contents 1. Overview and specification of the remote control (1) Overview (2) Specification 2. Precautions 3. Customer Support English 1. Overview and Specifications for the Remote Control (1) Overview - Instructions for using the Premium Magic Remote control are in the TV manual. this remote uses RF(Radio Frequency) instead of IR (InfaRed light). this remote will operate within 10m of the tv and does not require it be pointed at the tv.(voice recognition support) (2) Specifications "This device can be operated in at least one Member State without infringing applicable requirements on the use of radio spectrum" CategoriesDetails Model No. MR22GA Range of frequency 2.400 GHz ~ 2.4835 GHz Output Power(Max.)7dBm (EIRP) Channel40 channels Power source AA 1.5 V, 2 alkaline batteries are used Operational temperature range 0 °C ~ 40 °C 2. Precautions (1) After replacement of the battery, use the remote control following pairing in accordance with user manual. (2) If the unit does not operate after replacement of battery, reattempt pairing in accordance with the user manual. (3) If the remote controller is not being used for prolonged period of time, it is recommended you remove the battery from the unit. (4) Do not dismantle or exert heat to the battery. (5) Do not drop battery or exert extreme impact that may even cause the case to be damaged. (6) Do not immerse the battery in water. (7) There is danger of explosion if a the battery is inserted reversely. (8) Properly dispose of used batteries. (9) Open the battery cover to find the label. 3. Customer Support Refer to the contact number for services provided in the TV Manual. Federal Communications Commission(FCC) Statement Federal Communications Commission(FCC) Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected -Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation of the device. You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment and For indoor use only, use outdoors or in other modes not covered by this manual may violate the FCC regulation and violate the user authority to use the product. FCC RF Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End users must follow the specific operating instructions for satisfying RF exposure compliance. Industry Canada Statement [English] Industry Canada Statement (For Canada) This device complies with Industry Canada’s licence-exempt RSS Stadard(s). Operation is subject to the following two conditions: (1)This device may not cause interference. (2)This device must accept any interference, including interference that may cause undesired operation of the device. Avis d'industriecanada Cetappareilestconformeaux normesCNR d’IndustrieCanada applicables aux dispositifs exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1)l’appareil ne doit pas produire de brouillage; 2)l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. IC Radiation Exposure Statement (For Canada) This equipment complies with IC radiation exposure limits set forth for an Uncontrolled environmen…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Agent Authorization Letter Date : Nov. 9, 2017 Rev : 2.3 HACS-F004 FCC Agent Authorization Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 2.3 Fixed Typo “Agent” 11/09/2017 QM LG Electronics USA HACS-F004 FCC Agent Authorization Letter Rev : 2.3 DATE : June 18, 2021 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To whom it may concern: Subject : FCC Agent Authorization Letter for FCC ID : BEJMR22GA We, the undersigned, hereby authorize HCT CO., LTD. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by HCT CO., LTD. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). We recognize that we are still responsible for the terms and conditions outlined in the HCT America Client Services Agreement. This authorization is valid until further written notice from the applicant. Sincerely, Signed by: (Name / Title) Kyung-Su Han / Director, NA Regulatory and Environmental Affairs (Email Address) [email protected] (Phone number) 1-201-266-2215 (Address) LG Electronics USA, 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632

Cover Letter(s)

Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 1 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC FCC Confidentiality Request Letter Date : Nov. 09, 2017 Rev : 3.0 HACS-F003 FCC Confidentiality Request Letter HCT America LLC ([email protected]) 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848, Fax: +1.510.933.8849 Page 2 of 2 This document is electronically controlled. Hard copy documents are uncontrolled. Please check all hard copies against the controlled electronic copy to ensure validity. This document is the confidential property of HCT America LLC. It may not be forwarded or reproduced in whole or in part without written permissions from HCT America LLC REVISION TABLE Rev Description of Change Date Approved 1.0 Original Release(Obsolete) 06/14/2012 QM 2.0 Updated template(Obsolete) 10/01/2012 QM 2.1 Updated address(Obsolete) 01/10/2014 QM 2.2 Updated address 11/18/2016 QM 3.0 Updated LTC and STC Confidentiality table 11/09/2017 QM LG Electronics USA HACS-F003 FCC Confidentiality Request Letter Rev : 3.0 DATE : June 18, 2021 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD SUBJECT: Request for Confidentiality for FCC ID: BEJMR22GA We hereby request confidential treatment of the information accompanying this application as outlined below: LONG-TERM AND SHORT-TERM CONFIDENTIAL LIST LONG-TERM CONFIDENTIAL Exhibit Description 1 Block Diagram 2 Operational Description 3 Parts List 4 Schematics SHORT-TERM CONFIDENTIAL (180 DAYS) 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signed by: (Name / Title) Kyung-Su Han / Director, NA Regulatory and Environmental Affairs (Email Address) [email protected] (Phone number) 1-201-266-2215 (Address) LG Electronics USA, 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632

External Photos

FCC ID: BEJMR22GA , IC: 2703H-MR22GA HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 7 EXTERNAL PHOTOGRAPHS FCC ID: BEJMR22GA , IC: 2703H-MR22GA HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 7 ■ EXTERNAL PHOTO FCC ID: BEJMR22GA , IC: 2703H-MR22GA HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 7 ■ EXTERNAL PHOTO FCC ID: BEJMR22GA , IC: 2703H-MR22GA HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 7 ■ EXTERNAL PHOTO FCC ID: BEJMR22GA , IC: 2703H-MR22GA HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 7 ■ EXTERNAL PHOTO FCC ID: BEJMR22GA , IC: 2703H-MR22GA HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 7 ■ EXTERNAL PHOTO FCC ID: BEJMR22GA , IC: 2703H-MR22GA HCT CO., LTD. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383, Rep. of KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 7 ■ EXTERNAL PHOTO

ID Label/Location Info

MR22GA Label size, position MR21GA Label size SIZE : 15.5 X 30.5 MR22GA Label position Label position

Internal Photos

Test Report

HCT Co., Ltd. 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, 17383 KOREA Tel. +82 31 645 6300 Fax. +82 31 645 6401 F-TP22-03 (Rev. 04) Page 2 of 18 TE S T R E P O R T E M I T e s t f o r F C C C e r t i f i c a t i o n REPORT NO. HCT-EM-2106-FC004 DATE OF ISSUE June 22, 2021 FCC ID. BEJMR22GA Applicant LG Electronics Inc. 222, LG-ro, Jinwi-myeon, Pyeontaek-si, Gyeonggi-do, 17709, KOREA Product Name Model Name Magic Remote MR22GA Date of Test June 08, 2021 to June 09, 2021 Test Standard Used FCC CFR 47 PART 15 Subpart B Class B ANSI C63.4-2014 Test Results Refer to the present document Manufacturer LG Electronics Inc. The result shown in this test report refer only to the sample(s) tested unless otherwise stated. This test results were applied only to the test methods required by the standard. This laboratory is not accredited for the test results marked *. The contents marked ** is information provided by the customer. F-TP22-03 (Rev. 04) Page 3 of 18 Report No. HCT-EM-2106-FC004 REVISION HISTORY The revision history for this test report is shown in table. Revision No. Date of Issue Description 0 June 22, 2021 Initial Release The above Test Report is the accredited test result by (KS Q) ISO/IEC 17025 and KOLAS(Korea Laboratory Accreditation Scheme), which signed the ILAC-MRA. (KOLAS Accreditation No. KT197) If this report is required to confirmation of authenticity, please contact to www.hct.co.kr F-TP22-03 (Rev. 04) Page 4 of 18 Report No. HCT-EM-2106-FC004 CONTENTS 1. GENERAL INFORMATION5 1.1 Description of EUT 5 1.2 Tested System Details 5 1.3 Cable Description 6 1.4 Noise Suppression Parts on Cable. (I/O Cable) 6 1.5 Test Facility 7 1.6 Calibration of Measuring Instrument 7 1.7 Measurement Uncertainty 7 2. DESCRIPTION OF TEST8 2.1 Measurement of Conducted Emission 8 2.2 Measurement of Radiated Emission 9 2.3 Configuration of Tested System 10 3. PRELIMINARY TEST11 3.1 Conducted Emission 11 3.2 Radiated Emission 11 4. EMISSION TEST SUMMARY12 4.1 Conducted Emission 12 4.2 Radiated Emission Below 1 ㎓ 13 4.3 Radiated Emission Above 1 ㎓ 15 5. CONCLUSION17 6.APPENDIX A. TEST SETUP PHOTOGRAPHS18 F-TP22-03 (Rev. 04) Page 5 of 18 Report No. HCT-EM-2106-FC004 1. GENERAL INFORMATION 1.1 Description of EUT The EUT is Magic Remote. FCC ID BEJMR22GA Model Name MR22GA Product Name Magic Remote Frequency Range Bluetooth: 2 402 ㎒to 2 480 ㎒ Power Supply Normal voltage: DC 3.0 V Extreme lower voltage: DC 2.4 V Extreme upper voltage: DC 3.2 V Manufacturer LG Electronics Inc. Factory Hansung Electronics Co., LTD 1) 49-29, Cheomdangieop 4-ro, Sandong-myeon, Gumi-si, Gyeongsangbuk-do, Korea 2) Kawasan Industri Batik Lippo Cikarang JI.Palemn 1Block Ds-6, Cibatu, Cikarang Selatan, Bekasi, Jawa Barat, Indonesia OHSUNG Electronics CO., LTD. 1) 335-4, Sanho-daero, Gumi-si, Gyeongsangbuk-do, KOREA 2) No.188 Tunpu South Road, Qiushe Economic Development Zone, Tongli Town, Wujiang City, Jiangsu Province, China 3) JI. Selayar Blok D7 Kawasan Industri MM 2100, Mekarwangi, Cikarang Barat 17845 Jawa Barat, Indonesia 4) CERRADA CENTINELA 1719, PARQUE INDUSTRIAL CACHANILLA, MEXICALI, BAJA CALIFORNIA, MEXICO 21394 NOTE. This product is a wireless remote controller, it does not have a port to connect peripherals and has a built-in battery. (DC 3.0 V) 1.2 Tested System Details All equipment descriptions used in the tested system (including inserted cards) are: Device Type Model Name Serial Number Manufacturer Magic Remote MR22GA - LG Electronics F-TP22-03 (Rev. 04) Page 6 of 18 Report No. HCT-EM-2106-FC004 1.3 Cable Description Product Name Port Power Cord Shielded (Y/N) I/O Cable Shielded (Y/N) Length (m) EUT - N/A N/A N/A “(D)” Data Cable, “(P)” Power Cable. 1.4 Noise Suppression Parts on Cable (I/O Cable) Product Name Port Ferrite Bead (Y/N) Location Metal Hood (Y/N) Location EUT - N/A N/A N/A F-TP22-03 (Rev. 04) Page 7 of 18 Report No. HCT-EM-2106-FC004 1.5 Test Facility Test site is located at 74, Seoicheon-ro 578beon-gil, Majang-myeon, Icheon-si, Gyeonggi-do, Rep. of Korea. Those measurement facilities are constructed in conformance with the requirements of ANSI C63.4-2014. The Normalized site attenuations (30 ㎒ to 1 ㎓) and Site validation (1 ㎓ to 18 ㎓) were performed in accordance with the standard in ANSI C63.4-2014 This testing laboratories are accredited and accordance with the recognized international Standard ISO/IEC 17025:2017. (KOLAS, Accreditation No. KT197) 1.6 Calibration of Measuring Instrument The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in ac cordance with the manufacturers recommendations for utilizing calibration equipment, which is traceable to recognized national standards.Espectially, all antenna for measurement is calibrated in accordance with the requirements of C63.5:2017 1.7 Measurement Uncertainty The measurement uncertainties shown below were calculated in accordance with the requirements of ANSI C63.4-2014. All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a 95 % level of confidence. The measurement data shown herein meets or exceeds the U CISPR measurement uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly to specified limits to determine compliance. Test Item Test Site (Chamber) Expanded Uncertainty Radiated Emission (30 ㎒ to 1 ㎓) 3 m Semi Anechoic Chamber #1 4.9 ㏈ Radiated Emission (1 ㎓to 18 ㎓) 3 m Semi Anechoic Chamber #1 4.6 ㏈ F-TP22-03 (Rev. 04) Page 8 of 18 Report No. HCT-EM-2106-FC004 2. DESCRIPTION OF TEST 2.1 Measurement of Conducted Emission The test procedure was in accordance with ANSI C63.4-2014, Clause 7.3 a. The EUT was placed 0.4 meters from the conducting wall of the shielded room with EUT being connected to the power mains through a line impedance stabilization network (LISN). If the EUT is connected to the PC through USB, the AC power-line adapter of the PC is directly connected to a line impedance stabilization network (LI…
