BEJP999DWCellular/PCS GSM/EDGE and AWS WCDMA Phone with WLAN and Bluetooth

LG Electronics Inc. LGE LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: March 23, 2011 PCTEST TCB/CB Div. of PCTEST En gineering Lab., Inc.gg, 6660-B Dobbin Road, Columbia, MD 21045 SUBJECT: LG Electronics USA FCC ID: BEJP999DWFCC ID: BEJP999DW To whom it may concern: We LG Electronics USA confirm that the purpose of the power reduction for Mobile hotspotWe, LG Electronics USA, confirm that the purpose of the power reduction for Mobile hotspot is to meet LG internal SAR limit. When Mobile hotspot mode is activated, power reduction is applied until Mobile hotspot is deactivated by the user with no exception. Should you have any questions or comments concerning the above, please contact the undersigned. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA

LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632 Date: November 25, 2010 Fe deral Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: BEJ P999DW Eq uipment Class: JBP: Part 15 Class B Computing Device Peripheral To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram PERMANENT 2 Operational Descriptions 3 External Photos 4 Internal Photos 5 Test-Setup Photos SHORT-TERM 6 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Jae Cheon(J.C.) Lee General Manager LG Electronics USA LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs, NJ 07632

LG Electronics USA FCC ID: BEJP999DW Model: P999DW External Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 1 of 4 © 2010 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS LG Electronics USA FCC ID: BEJP999DW Model: P999DW External Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 2 of 4 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW External Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 3 of 4 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW External Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 4 of 4 © 2010 PCTEST Engineering Laboratory Inc.

Model No: P999DW FCC ID : BEJP999DW S/N : Made in Korea LG Electronics Inc. LGE

LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 1 of 10 © 2010 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 2 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 3 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 4 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 5 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 6 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 7 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 8 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 9 of 10 © 2010 PCTEST Engineering Laboratory Inc. LG Electronics USA FCC ID: BEJP999DW Model: P999DW Internal Photos EUT Type: 850/1900 GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with BT and WLAN Page 10 of 10 © 2010 PCTEST Engineering Laboratory Inc.

FCC ID: BEJP999DW Report No.: HCTE1012FE18-1 Date: January 12, 2011 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 2 of 17 TABLE OF CONTENTS PAGE 1. GENERAL INFORMATION 1.1 Product description 3 1.2 Related submittal(s)/Grant(s) 3 1.3 Tested system details 4 1.4 Cable description 5 1.5 Noise suppression parts on cable. (I/O cable) 5 1.6 Test methodology 6 1.7 Test facility 6 1.8 Frequency Range of Radiated Measurements 6 2. SYSTEM TEST CONFIGURATION 2.1 Configuration of tested system 7 3. PRELIMINARY TEST 3.1 Conducted Emission test 8 3.2 Radiated Emission test 8 4. CONDUCTED AND RADIATED EMISSION TESTS SUMMARY 4.1 Conducted Emission test 9 4.2 Radiated Emission test 14 5. FIELD STRENGTH CALCULATION 15 6. TEST EQUIPMENT 16 7. CONCLUSION 17 ATTACHMENT: TEST SETUP PHOTOGRAPHS FCC ID: BEJP999DW Report No.: HCTE1012FE18-1 Date: January 12, 2011 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 3 of 17 1. GENERAL INFORMATION 1.1 Product Description Equipment Under Test (E.U.T) is Cellular/PCS GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with Bluetooth and WLAN, Model: P999DW manufactured by LG Electronics Inc. Its basic purpose is used for communications. Model (s) P999DW Additional Model LG-P999DW, LG-P999, P999 FCC ID BEJP999DW E.U.T Type Cellular/PCS GSM/GPRS/EDGE and AWS WCDMA/HSPA Phone with Bluetooth and WLAN TX Frequency 824.20 ㎒ to 848.80 ㎒ (GSM 850) 1 850.20 ㎒ to 1 909.80 ㎒ (GSM 1 900) 1 711.25 ㎒ to 1 753.75 ㎒ (AWS) RX Frequency 869.20 ㎒ to 893.80 ㎒ (GSM 850) 1 930.20 ㎒ to 1 989.80 ㎒ (GSM 1 900) 2 111.25 ㎒ to 2 153.75 ㎒ (AWS) 1.2 Related Submittal(s) / Grant(s) Original submittal only. FCC ID: BEJP999DW Report No.: HCTE1012FE18-1 Date: January 12, 2011 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 4 of 17 1.3 Tested System Details All equipment descriptions used in the tested system (including inserted cards) are: Device Type Manufacturer Model Number/ Serial Number FCC ID / DoC Connected To Cellular/PCS GSM/ GPRS/EDGE and AWS WCDMA/HSPA Phone with Bluetooth and WLAN LG Electronics Inc P999DW BEJP999DW Notebook PC TV monitor Notebook PC SAMSUNG NT-R519 ZLA693AS900033M DoC E.U.T Notebook PC adaptor DELTA (JIANG SU) ADP-60ZH D AD-6019R DA44-00242A - Notebook PC Mouse Microsoft Intellimouse optical USB and PS/2 compatible 3902B008 DoC Notebook PC TV monitor LG Electronics Inc W2261VP-PF 912NDDM0C242 - E.U.T USB cable - - - Notebook PC E.U.T HDMI cable - - - E.U.T TV monitor Headset - - - E.U.T SD card (2 GB) SANDISK - - E.U.T FCC ID: BEJP999DW Report No.: HCTE1012FE18-1 Date: January 12, 2011 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 5 of 17 1.4 Cable Description * The marked "(D)" means the data cable and "(P)" means the power cable. 1.5 Noise Suppression Parts on Cable. (I/O cable) Product Name Port Ferrite Bead (Y/N) Location Metal Hood (Y/N) Location Headset jack N - Y E.U.T End USB data N - Y Both End Cellular/PCS GSM/ GPRS/EDGE and AWS WCDMA/HSPA Phone with Bluetooth and WLAN HDMI N - Y Both End Notebook PC USB (Mouse) Y Notebook PC End Y Notebook PC End Product Name Port Power Cord Shielded (Y/N) I/O Cable Shielded (Y/N) Length (m) Headset jack - N (D)1.0 USB data Y Y (P,D)1.2 Cellular/PCS GSM/ GPRS/EDGE and AWS WCDMA/HSPA Phone with Bluetooth and WLAN HDMI N Y (D)1.8 Notebook PC USB (Mouse) - Y (D)1.8 FCC ID: BEJP999DW Report No.: HCTE1012FE18-1 Date: January 12, 2011 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 6 of 17 1.6 Test Methodology Both Conducted and Radiated testing was performed according to the procedures in ANSI C63.4/2003. Radiated testing was performed at an antenna to E.U.T distance of 3 m 1.7 Test Facility The 10 m semi anechoic chamber used to collect the radiated data is located at the 105-1, Jangam-Ri, Majang-Myeon, Icheon-Si, Kyoungki-Do, South Korea, and the conducted measurement facility used to measure the conducted data are located at San 136-1, Ami-Ri Bubal-Eup, Icheon-Si, Kyoungki-Do, 467-701, South Korea. Those measurement facilities are constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. Detailed description of test facilities was submitted to the Commission and accepted dated Sep. 03, 2010 (Registration Number: 90661) 1.8 Frequency Range of Radiated Measurements An unintentional radiator, including a digital device, the spectrum shall be investigated from the lowest radio frequency signal generated or used in the device, without going below the lowest frequency for which a Radiated Emission limit is specified, up to the frequency shown in the following table Highest frequency generated or used in the device or on which the device operates or tunes (㎒) Upper frequency of measurement range (㎒) Below 1.705 30 1.705 to 108 1 000 108 to 500 2 000 500 to 1 000 5 000 Above 1 000 5 th harmonic of the highest frequency or 40 ㎓, whichever is lower FCC ID: BEJP999DW Report No.: HCTE1012FE18-1 Date: January 12, 2011 HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8539 FAX: +82 31 639 8535 www.hct.co.kr Page 7 of 17 2. SYSTEM TEST CONFIGURATION 2.1 Configuration of Test System Power Line Conducted test : E.U.T was connected to LISN via Notebook PC adaptor. Preliminary Power Line Conducted Emission tests were performed by using the procedure in ANSI C63.4/2003 7.2.3 to determine the worst operating conditions. Radiated Emission test : Preliminary Radiated Emission tests were performed by using the procedure in ANSI C63.4/2003 8.3.1.1 to determine the worst operating condition. Final Radiated Emission t…
