BEJQ50941GHOUSEHOLD COOKTOP

OWNER'S MANUAL COOKTOP Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH CBIS3618B MFL54169112 Rev.XX_MMDDYY www.lg.com Copyright © 2010-2018 LG Electronics Inc. All Rights Reserved. TABLE OF CONTENTS 2 3IMPORTANT SAFETY INSTRUCTIONS 3READ ALL INSTRUCTIONS BEFORE USE 3WARNING STATEMENTS 6CAUTION STATEMENTS 8PRODUCT OVERVIEW 8Product Features 9INSTALLATION 9Before Installing 13Installing the Cooktop 16 OPERATION 16Introduction to Induction Cooking 16Cookware 19Control Panel 31 SMART FUNCTIONS 31LG ThinQ Application 34 MAINTENANCE 34Care and Cleaning 36 TROUBLESHOOTING 36Before Calling for Service 39 LIMITED WARRANTY 39USA 43CANADA 3IMPORTANT SAFETY INSTRUCTIONS ENGLISH IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety Messages Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what may happen if the instructions are not followed. WARNING STATEMENTS WARNING • To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this product, follow basic precautions, including the following: Installation • Be sure your appliance is properly installed and grounded by a qualified technician in accordance with the National Electrical Code ANSI/NFPA No. 70, latest edition in the United States, and all local code requirements. Install only per installation instructions. • The safety aspects of this appliance comply with accepted technical standards. • Never modify or alter the construction of an appliance such as removal of panels, wire covers or any other permanent part of the product. • Remove all tape and packaging wrap before using the appliance. Destroy the carton and plastic bags after unpacking the appliance. Never allow children to play with packaging material. • The installation and connection of the new appliance must only be carried out by qualified personnel. Operation • Know how to disconnect the electrical power to the appliance at the circuit breaker or fuse box in case of an emergency. Mark the breaker or fuse for ease of identification and swift action if necessary. • Never use your appliance for warming or heating a room. • Persons with a pacemaker or similar medical device should exercise caution using or standing near an induction unit while it is in operation, as the electromagnetic field may affect the working of the pacemaker or similar medical device. It would be advisable to consult your doctor or the pacemaker or medical device manufacturer about your particular situation. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the safety alert symbol and either the word WARNING or CAUTION. These words mean: WARNING You may be killed or seriously injured if you do not follow instructions. CAUTION You may be injured or cause damage to the product if you do not follow instructions. 4IMPORTANT SAFETY INSTRUCTIONS • DO NOT touch cooking zones or areas near these surfaces. Cooking zones may be hot from residual heat even though they are dark in color. Areas near the cooking zones may become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials touch these areas until they have had sufficient time to cool. • Never wear loose fitting or hanging garments while using this appliance. • Always turn off all controls when cooking is completed. • Do not use water or flour on grease fires. Smother the fire with a pan lid, or use baking soda, a dry chemical or foam-type extinguisher. • Use only dry pot holders. Moist or damp pot holders on hot surfaces may result in burns from steam. Do not let pot holders touch hot surface units. Do not use a towel or other bulky cloth instead of a pot holder. • Do not heat unopened food containers. A buildup of pressure may cause the container to burst and result in injury. • Flammable materials should not be stored near or on the cooking surface. This includes paper, plastic and cloth items, such as cookbooks, plasticware and towels, as well as flammable liquids. Do not store explosives, such as aerosol cans, on or near the appliance. Flammable materials may explode and result in fire or property damage. • Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. • Never place combustible items on the cooktop. • Never keep any combustible items or aerosol cans in a drawer located under the cooktop. • When heating fat or grease, watch it closely. Fat or grease may catch fire if allowed to become too hot. • Overheated fats and oils catch fire quickly. You should supervise cooking when preparing foods in fat or oil. • Use a deep fat thermometer, if possible, to prevent overheating fat beyond the smoking point. • If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. Do not reuse your cooktop until the glass surface has been replaced. • When using the cooktop, never use aluminum foil, products wrapped in aluminum foil, or deep-frozen food in aluminum cookware. • This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safely. • Young children should be supervised to ensure that they do not play with the appliance. • Accessible parts may become hot during use. Young children should be kept away. • Items of interest to children should not be stored in cabinets above a cooktop or on the backsplash of a cooktop – children climbing on the cooktop to reach items could be seriously injured. • Children should not be lef…

Text truncated - open the document above for the full version.

LG Electronics USA, Inc. 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632, United States August 16, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: I, the undersigned, hereby authorize LG Electronics H&A EMC Standard Lab and here after referred to as LG H&A EMC Lab, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by LG H&A EMC Lab on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing LG H&A EMC Lab as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter LG Electronics USA, Inc. 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632, United States that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely yours, (Sign) Name/Title : Sung Soo Kim / Director Company Name : LG Electronics USA, Inc.

Applicant Declaration Applicant Declaration Rev:0.0 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632, United States Grantee Code BEJ FCC ID BEJQ50941G Authorized Contact Name Sung Soo Kim Contact Email [email protected] Contact Phone 201-266-2215 I , the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in ac cordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in ac cepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made i n t his application, the Applicant is responsible for: (1 ) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c )if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensur e t hat production units of this equipment will continue to comply with the FCC’s technical requirements. d)in ac cordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsibl e par ty and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in ac cordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements . (1 ) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. S ee 47C FR 1.2002(b) for the definition of a “party” for these purposes. g)t he Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions . Li nk to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date: 2022-08-16 Print Name: Sung Soo Kim Title: Director *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

LG Electronics USA, Inc. 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632, United States August 16, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Request of Confidentiality for FCC ID : BEJQ50941G To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA, Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics 4 - Short-Te r m 5 External Photos 6 Internal Photos 7 Te s t-Setup Photos 8 User’s Manual LG Electronics USA, Inc. 111 Sylvan Avenue, North Building, Englewood Cliffs, NJ 07632, United States The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely yours, (Sign) Name/Title : Sung Soo Kim / Director Company Name : LG Electronics USA, Inc.

EXTERNAL PHOTOGRAPHS (CBIS3618B) < Top View > < Bottom View > < Front Side View > < Rear Side View > < Left Side View > < Right Side View >

Test Report No. : CW011252-220802001 LG(59)-EMC-RPT-040 1 / 4 It is not allowed to copy this report even partly without the approval of LG Electronics. APPENDIX G : LABEL INFORMATION Test Report No. : CW011252-220802001 LG(59)-EMC-RPT-040 2 / 4 It is not allowed to copy this report even partly without the approval of LG Electronics. < Front side > Test Report No. : CW011252-220802001 LG(59)-EMC-RPT-040 3 / 4 It is not allowed to copy this report even partly without the approval of LG Electronics. < Bottom side > (Technical card) Test Report No. : CW011252-220802001 LG(59)-EMC-RPT-040 4 / 4 It is not allowed to copy this report even partly without the approval of LG Electronics. < Box label >

INTERNAL PHOTOGRAPHS (CBIS3618B) < Machine Section > < Top plate (front) > < Top plate (rear) > < IH core plate > < Bottom plate > < PCB Section > < TFT LCD PCB (front) > < TFT LCD PCB (rear) > < Main(interface) PCB (front) > < Main(interface) PCB PCB (rear) > < Inverter 4B PCB (front) > < Inverter 4B PCB (rear) > < Inverter 2B PCB (front) > < Inverter 2B PCB (rear) > < Noise filter PCB (front) > < Noise filter PCB (rear) > < Power(SMPS) PCB (front) > < Power(SMPS) PCB (rear) > < Power Key PCB (front) > < Power Key PCB (rear) > < Wi-Fi module PCB (front) > < Wi-Fi module PCB (rear) >

Test Report No. : CW011252-220802001 LG(59)-EMC-RPT-040 1 / 85 It is not allowed to copy this report even partly without the approval of LG Electronics. TEST REPORT CERTIFICATION OF COMPLIANCE Date of Issue: August 10, 2022 Test Report No: CW011252-220802001 Test Site: LG Electronics H&A EMC Standard Lab. Applicant: LG Electronics USA, Inc. 111 Sylvan Avenue North Building Englewood Cliffs, NJ 07632 Product Type: HOUSEHOLD COOKTOP Brand Name(s): LG Model Name : CBIS3618B Equipment Class: Industrial, Scientific and Medical equipment Regulation: FCC Part 18 Test Procedure: MP-5: 1986 Date of Receipt: Aug. 1. 2022 Date of Test: Aug. 2. 2022 ~ Aug. 5. 2022 FCC ID: BEJQ50941G This device has been verified to comply with the applicable requirements in the FCC Part 18 and was tested in accordance with the measurement procedures specified in MP-5: 1986. I assure full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Note 1: This report apply only to the specific sample(s) tested under stated test conditions. Note2: This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. Tested by: Reviewed by: Jang Hoseong / Test Engineer H&A EMC Standard Lab., LG Electronics Inc. Kim Tae Yul / Technical Manager H&A EMC Standard Lab., LG Electronics Inc. LG Electronics H&A EMC Standard Lab. 170, Seongsanpaechong-ro, Seongsan – Gu, Changwon-si, Gyeongsangnam-do, 51533, Republic of Korea Tel: + 82 55 260 3966 Test Report No. : CW011252-220802001 LG(59)-EMC-RPT-040 2 / 85 It is not allowed to copy this report even partly without the approval of LG Electronics. CONTENTS Page 1. GENERAL INFORMATION ..................................................................................................... 3 1.1 CLIENT INFORMATION........................................................................................................ 3 1.2 TEST FACILITY ................................................................................................................ 3 2. PRODUCT INFORMATION ..................................................................................................... 4 2.1 DESCRIPTION OF EUT. ...................................................................................................... 4 3. DESCRIPTION OF TESTS ...................................................................................................... 5 3.1 TEST CONDITION. ............................................................................................................ 5 3.2 AUXILIARY EQUIPMENT / CABLE LIST ..................................................................................... 5 3.3 TEST SYSTEM LAYOUT ...................................................................................................... 6 4. SUMMARY OF TEST RESULTS .............................................................................................. 7 5. CONDUCTED EMISSION ....................................................................................................... 8 5.1 OPERATING ENVIRONMENT ................................................................................................. 8 5.2 TEST SET-UP .................................................................................................................. 8 5.3 MEASUREMENT UNCERTAINTY ............................................................................................. 9 5.4 LIMIT ........................................................................................................................... 9 5.5 TEST EQUIPMENT ............................................................................................................ 9 5.6 TEST DATA FOR CONDUCTED EMISSION ................................................................................ 10 6. RADIATED EMISSION ......................................................................................................... 50 6.1 OPERATING ENVIRONMENT ............................................................................................... 50 6.2 TEST SET-UP ................................................................................................................ 50 6.3 MEASUREMENT UNCERTAINTY ........................................................................................... 51 6.4 LIMIT ......................................................................................................................... 52 6.5 TEST EQUIPMENT .......................................................................................................... 52 6.6 TEST DATA FOR RADIATED EMISSION .................................................................................... 53 8. RECOMMENDATION & CONCLUSION ................................................................................... 85 Test Report No. : CW011252-220802001 LG(59)-EMC-RPT-040 3 / 85 It is not allowed to copy this report even partly without the approval of LG Electronics. 1. General Information 1.1 Client Information The EUT has been tested by request of: Applicant: LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building Englewood Cliffs, NJ 07632 Manufacturer: LG Electronics Inc Address 170, Seongsanpaechong-ro, Seongsan-gu, Changwon-si, Gyeongsangnam-do, 51533, Republic of KOREA Name of contact: Sung Soo.Kim Telephone: 201-266-2215 1.2 Test facility We are the accredited EMC laboratory by RRA(KOREA). We certify that the above products had performed test on our laboratory and it was confirmed to comply with FCC requirement. The site are constructed in conformance with the requirements of CISPR publication 16/ANSI C63.4 The test was performed accordance to the procedures from FCC/OET MP-5. Name and Address: LG Electronics H&A EMC Standard Lab. 170, Seongsanpaechong-ro, Seongsan-gu, Changwon…

Text truncated - open the document above for the full version.

TEST SET UP PHOTOGRAPHS (CBIS3618B) - Conducted Emission - Radiated Emission (Magnetic Field, Below 30 MHz)
