BEJRD2030Dual-Mode Cellular Phone (AMPS/CDMA)

LG Electronics USA, Inc.

Click to zoom

Application Details

Equipment Class: TNE - Licensed Non-Broadcast Transmitter Held to Ear
Date of Grant: Jul 30, 2002
Application Purpose: Original Equipment
Date of Application: Jul 30, 2002
Equipment Note: Dual-Mode Cellular Phone (AMPS/CDMA)
Frequency Range: 824.70000000 - 848.31000000
Company: LG Electronics USA, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

7. Operating Manual LG-RD2030 User Guide CDMA PHONE For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 1.5 cm. from the body. To maintain compliance with FCC RF exposure requirements, use only belt-clips, holsters or similar accessories that maintain a 1.5 cm. separation distance between the user’s body and the back of the phone, including the antenna, whether extended or retracted. The use of belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. WARNING! Read this information before using your phone Contents Introduction Highlights Important Information Check Accessories Before You Start FCC RF EXPOSURE INFORMATION Chapter 1. Getting Started Cautions Phone Overview On screen Icons Chapter 2. Basic Functions Turning the Phone On and Off Making a Call Correcting Dialing Mistakes Receiving Calls Using Quick Mode Call Waiting Mute Redialing Calls Adjusting the Volume Power Save Mode Signal Strength Emergency Dialing Mini Display Speed Dialing Caller ID Phone Book Features Chapter 3. Menu Features General Guidelines to MENU Access and Settings Sound Call History Utility&Fun Scheduler Display Features System Security Chapter 4. Book Features Phone Book Chapter 5. Message Features Voice Send Msg New Text Old Text Erase All Setting Chapter 6. Functions used during a call Mute Memo Voice Privacy Chapter 7. Accessories Chapter 1. Getting Started Cautions l Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference. l Keep your phone in a safe place when not in use. l Only use the batteries, antennas, and chargers provided by LG. Using the wrong accessories could void your warranty. l Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty. l Do not hold the antenna while the phone is in use. l Do not use the phone in designated “no cellular phone use” areas. l Do not expose the phone to high temperature or humidity. l Avoid getting your phone wet. If the phone gets wet, turn the power off immediately and remove the battery pack. If the phone is mal-functional, return it to the dealer for service. l Avoid shock or impact on the phone. Phone Overview Function Key Descriptions Lamp The red light goes on when you use the power key to turn on the phone and when there are incoming calls and messages. LCD screen Displays messages & indicator icons. END/PWR Used to turn power on/off. This key disconnects a call. Using this key, you can also exit out of a menu back to the phone’s standby display without changing the setting. SEND Allows user to place or answer calls. Mouse Key This mouse key allows quick access to text and voice mail notification messages. calendar, outgoing call log, phonebook Find name. Cellcase Close the active cellcase to the terminate a call in progress. Open the active cellcase to answer an incoming call. Soft Keys The current operation of a soft key is defined by the word at the bottom of the display. Soft Keys 2 : If you press this key once in a menu, you can go back one level and if you press and hold the key in a menu, you can go back to the standby display. Side Keys These keys enable you to adjust keybeep volume (in standby mode) and earpiece volume (in a call status). Scroll Keys These keys are used to scroll through the memory locations and menu items. - In the standby status, set the manner mode by pressing the button. (for 2 seconds) - In the standby status, set the lock function by pressing the button. (for 2 seconds) Alphanumeric Keypad These keys enable you to enter numbers and characters and choose menu items. Clear Key On screen Icons The phone screen displays several onscreen icons and onscreen icons appears when the phone is power on. Icons Descriptions Displays the strength of the signal received by the phone and current signal strength is indicated as the number of bars displayed on the screen. No service The phone is not receiving a system signal. In use A call is in progress. No icon indicates the phone is in standby mode. Digital indicator Digital service is available. Analog indicator Analog service is unavailable Indicates that a text message or voice mail has been received Roaming The phone is outside of its home service area. Charge level Indicates battery charge level. D Chapter 2. Basic Functions Turning the Phone On and Off Turning the Phone On 1. Install a charged battery pack or connect the phone to an external power source such as the cigarette lighter adapter or car kit. 2. Press [END/PWR] for a few seconds until the red light on the top of the phone flashes. <Note> Like any other radio device, avoid any unnecessary contact with the antenna while your phone is on. Turning the Phone Off 1. Press and hold until display screen will be…

Text truncated - open the document above for the full version.

Attestation Statements

July 22, 2002 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 In re : LG Electronics Inc.. FCC ID: BEJRD2030 Dual-Mode Cellular Phone (AMPS & CDMA) Part 22 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Electronics, Inc. hereby requests confidentiality of the Block Diagrams attachment, Schematic Diagrams & Circuit Description attachment, Operational Description attachment, and Parts List/Tune-Up Procedure attachment for the above-referenced Type Acceptance application. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3861 Fax : 82-2-850-3855 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE

Cover Letter(s)

July 26, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: LG ELECTRONICS, INC. FCC ID: BEJRD2030 Part 22 Certification Gentlemen: Attached herewith, on behalf of LG ELECTRONICS, INC. is an application for Part 22 Certification of the Dual-Mode Cellular Phone (AMPS/CDMA). Attached is the applicant’s Letter of Authorization, Confidentiality Request, ESN Affidavit, E911 Compliance Statement, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams (confidential), circuit description (confidential), operational description (confidential), parts list & tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: LG ELECTRONICS, INC.

External Photos

ID Label/Location Info

© 2002 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) LG Electronics Inc. 2002-06-25 LG Electronics Inc. LGE Model No. : RD2030 FCC ID : BEJRD2030 S/N : Made in Korea

Internal Photos

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. 6660 — B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220715362.BEJ Test Dates: July 24-25, 2002 Phone Type: Dual-Mode FCC ID: BEJRD2030 Page 1 of 30 © 2002 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: LG Electronics Inc. Dates of Tests: July 24-25, 2002 Communication Terminal Research Lab Test Report S/N: SAR.220715362.BEJ 459-9, Kasan-dong, Keumchun-ku Test Site: PCTEST Lab, Columbia MD USA Seoul 153-023, Korea Attn: Harris Ahn, Principal Engineer FCC ID: BEJRD2030 APPLICANT: LG ELECTRONICS, INC. EUT Type: Dual-Mode Cellular Phone (AMPS/CDMA) Tx Frequency: 824.04 — 848.97 MHz (AMPS) / 824.70 — 848.31 MHz (CDMA) Rx Frequency: 869.04 — 893.97 MHz (AMPS) / 869.70 — 893.31 MHz (CDMA) Max. RF Output Power: 0.401 W ERP AMPS (26.033 dBm) / 26.0 dBm Conducted 0.319 W ERP CDMA (25.033 dBm)/ 25.0 dBm Conducted Max. SAR Measurement: 1.210W/kg AMPS Head SAR; 0.833W/kg AMPS Body SAR; 0.807W/kg CDMA Head SAR; 0.620W/kg CDMA Body SAR Trade Name/Model(s): RD2030 FCC Classification: Non-Broadcast Transmitter held to ear (TNE) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220715362.BEJ PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220715362.BEJ Test Dates: July 24-25, 2002 Phone Type: Dual-Mode FCC ID: BEJRD2030 Page 2 of 30 © 2002 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION .................................................................................................. 3 SAR DEFINITION ................................................................................................. 3 2. SAR MEASUREMENT SETUP .................................................................................. 4 Robotic System ....................................................................................................... 4 System Hardware ................................................................................................... 4 System Electronics .................................................................................................. 4 3. DASY3 E-FIELD PROBE SYSTEM ............................................................................ 5 Probe Measurement System.................................................................................... 5 Probe Specifications ............................................................................................... 5 4. Probe Calibration Process....................................................................................... 6 Dosimetric Assessment Procedure .......................................................................... 6 Free Space Assessment ........................................................................................... 6 Temperature Assessment ........................................................................................ 6 5. PHANTOM & EQUIVALENT TISSUES .................................................................... 7 SAM Phantom ........................................................................................................ 7 Brain & Muscle Simulating Mixture Characterization ............................................. 7 Device Holder for Transmitters............................................................................... 7 6. TEST SYSTEM SPECIFICATIONS ............................................................................. 8 Automated Test System Specifications .................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS ................................................. 9 Measurement Procedure......................................................................................... 9 Specific Anthropomorphic Mannequin (SAM) Specifications.................................. 9 8. DEFINITION OF REFERENCE POINTS ................................................................. 10 EAR Reference Point............................................................................................. 10 Handset Reference Points ..................................................................................... 10 9. TEST CONFIGURATION POSITIONS .................................................................. 11 Positioning for Cheek/Touch ................................................................................ 11 Positioning for Ear / 15° Tilt .................................................................................. 12 Body Holster /Belt Clip Configurations ................................................................. 13 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS ................................................... 14 Uncontrolled Environment .......................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.815 mW/g, SAR (10g): 0.589 mW/g LGE Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0991 [824.04MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Right Head Phantom; Cheek/Touch position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 8.48E-2 2.54E-1 4.24E-1 5.94E-1 7.63E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.781 mW/g, SAR (10g): 0.564 mW/g Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0383 [836.49MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Right Head Phantom; Cheek/Touch position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 8.28E-2 2.48E-1 4.14E-1 5.80E-1 7.45E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.07 mW/g, SAR (10g): 0.765 mW/g LGE Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0799 [848.97MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Right Head Phantom; Cheek/Touch position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 1.10E-1 3.30E-1 5.50E-1 7.71E-1 9.91E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.09 mW/g, SAR (10g): 0.676 mW/g LGE Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0991 [824.04MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Right Head Phantom; EAR/15 Degrees Tilt position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 9.81E-2 2.94E-1 4.91E-1 6.87E-1 8.83E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.04 mW/g, SAR (10g): 0.631 mW/g LGE Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0383 [836.49MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Right Head Phantom; EAR/15 Degrees Tilt position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 9.29E-2 2.79E-1 4.65E-1 6.50E-1 8.36E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Right Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.21 mW/g, SAR (10g): 0.862 mW/g LGE Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0799 [848.97MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Right Head Phantom; EAR/15 Degrees Tilt position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 1.27E-1 3.80E-1 6.33E-1 8.86E-1 1.14E+0 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Left Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.917 mW/g, SAR (10g): 0.608 mW/g LGE Dual Mode Model: LG-RD2030 FM Mode, Channel 0991[824.04MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Left Head Phantom; Cheek/Touch position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 9.50E-2 2.85E-1 4.75E-1 6.65E-1 8.55E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Left Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.801 mW/g, SAR (10g): 0.522 mW/g LGE Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0383 [836.49MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Left Head Phantom; Cheek/Touch position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 8.82E-2 2.65E-1 4.41E-1 6.17E-1 7.94E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Left Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 1.02 mW/g, SAR (10g): 0.710 mW/g LGE Dual Mode -- Model: LG-RD2030 FM Mode, Channel 0799 [848.97MHz.]; Standard Battery; Ambient Temp. = 22.1°C / Meas. Tissue Temp.= 22.0°C Conducted Power = 26.0dbm; Left Head Phantom; Cheek/Touch position Test Date--07-24-2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 1.06E-1 3.17E-1 5.28E-1 7.40E-1 9.51E-1 PCTEST Engineering Laboratory, Inc. LGE FCC ID: BEJRD2030 -- FM Head SAR SAM Phantom; Left Hand Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91 mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; A…

Text truncated - open the document above for the full version.

RF Exposure Info

© 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA) © 2002 PCTEST Lab LGE FCC ID: BEJRD2030 (Model: RD2030) Dual-Mode Cellular Phone (AMPS/CDMA)

RF Exposure Info

835MHz Brain Dipole Validation SAM Phantom; Flat Section; Probe:ET3DV6 - SN1677; ConvF(6.70,6.70,6.70) Med. Parameters 835 MHz Brain: σ = 0.91mho/m ε r = 42.1 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 2.51 mW/g, SAR (10g): 1.63 mW/g 835MHz Brain Dipole Validation (D835V2 S/N: 406) Frequency: 835 MHz; Antenna Input Power: 250 [mW]; Ambient Temp. = 22.1°C / Meas. Tissue Temp. = 22.0°C PCTEST Brain Tissue Simulating Liquid [07/24/2002] SAR Tot [mW/g] 2.61E-1 7.77E-1 1.31E+0 1.82E+0 2.34E+0 PCTEST Engineering Laboratory, Inc.

Test Report

PCTEST Engineering Lab., Inc. SUBJECT:Modulation CharacteristicsTest Report No.:22.220715385.BEJ FCC Part 22Test Date:07.24.2002 EUT:LGE Dual-Band Cellular Phone Model:RD2030 FCC ID:BEJRD2030 REFERENCE:1 kHz = 0 dB Modulation Limiting 0 2000 4000 6000 8000 10000 12000 14000 -35-30-25-20-15-10-50 Audio Input Level (dBV) Deviation (Hz) LGE Dual-Band Cellular Phone FCC ID: BEJRD2030 PCTEST Engineering Lab., Inc. SUBJECT:Modulation CharacteristicsTest Report No.:22.220715385.BEJ FCC Part 22Test Date:07.24.2002 EUT:LGE Dual-Band Cellular Phone Model:RD2030 FCC ID:BEJRD2030 REFERENCE:1 kHz = 0 dB Frequency Response of Audio Low Pass Filter -90.0 -80.0 -70.0 -60.0 -50.0 -40.0 -30.0 -20.0 -10.0 0.0 10.0 FREQUENCY (Hz) LEVEL (dB) Relative to 1kHz 10k1k 100k LGE Dual-Band Cellular Phone FCC ID: BEJRD2030 PCTEST Engineering Lab., Inc. SUBJECT:Modulation CharacteristicsTest Report No.:22.220715385.BEJ FCC Part 22Test Date:07.24.2002 EUT:LGE Dual-Band Cellular Phone Model:RD2030 FCC ID:BEJRD2030 REFERENCE:1 kHz = 0 dB Transmitter Audio Frequency Response -60.00 -50.00 -40.00 -30.00 -20.00 -10.00 0.00 10.00 20.00 FREQUENCY (Hz) LEVEL (dB) Relative to 1kHz 100 1k 10k 100k LGE Dual-Band Cellular Phone FCC ID: BEJRD2030

Test Report

PCTEST PT. 22REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.220715385.BEJ Test Dates: July 24-25, 2002 Phone Type: Dual-Mode FCC ID: BEJRD2030 Page 1 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE FCC Part 22 Certification LG Electronics Inc. Dates of Tests: July 24-25, 2002 Communication Terminal Research Lab Test Report S/N: 22.220715385.BEJ 459-9, Kasan-dong, Keumchun-ku Test Site: PCTEST Lab, Columbia MD USA Seoul 153-023, Korea Attn: Harris Ahn, Principal Engineer FCC ID BEJRD2030 APPLICANT LG ELECTRONICS, INC. Classification: Non-Broadcast Transmitter held to ear (TNE) FCC Rule Part(s): §22(H), §22.901(d), §2 EUT Type: Dual-Mode Cellular Phone (AMPS/CDMA) Model: RD2030 Tx Frequency Range: 824.04MHz — 848.97MHz (AMPS) / 824.70 — 848.31MHz (CDMA) Rx Frequency Range: 869.04MHz — 893.97MHz (AMPS) / 869.70 — 893.31MHz (CDMA) Max. RF Output Power: 0.401 W ERP AMPS (26.033 dBm) / 0.319 W ERP CDMA (25.033 dBm) Max. SAR Measurement: 1.210W/kg AMPS Head SAR; 0.833W/kg AMPS Body SAR; 0.807W/kg CDMA Head SAR; 0.620W/kg CDMA Body SAR Emission Designator(s): 40K0F8W / 40K0F1D (AMPS), 1M25F9W (CDMA) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220715385.BEJ PCTEST PT. 22REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.220715385.BEJ Test Dates: July 24-25, 2002 Phone Type: Dual-Mode FCC ID: BEJRD2030 Page 2 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 3 2.1 INTRODUCTION 4 3.1 INSERTS 5 4.1 DESCRIPTION OF TESTS 6-8 5.1 EFFECTIVE RADIATED POWER OUTPUT 9-10 6.1 RADIATED MEASUREMENTS 11-16 7.1 FREQUENCY STABILITY 17-20 8.1 PLOTS OF EMISSIONS 21 9.1 LIST OF TEST EQUIPMENT 22 10.1 SAMPLE CALCULATIONS 23 11.1 CONCLUSION 24 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST/TUNE UP PROCEDURE ATTACHMENT M: USER’S MANUAL ATTACHMENT N: SAR MEASUREMENT REPORT ATTACHMENT O: SAR TEST DATA ATTACHMENT P: SAR TEST SETUP PHOTOGRAPHS ATTACHMENT Q: DIPOLE VALIDATION ATTACHMENT R: PROBE CALIBRATION PCTEST PT. 22REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.220715385.BEJ Test Dates: July 24-25, 2002 Phone Type: Dual-Mode FCC ID: BEJRD2030 Page 3 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. §2.1033 General Information Applicant Name: LG ELECTRONICS INC. Address: 459-9, Kasan-dong, Keumchun-ku Seoul 153-023, Korea Attention: Harris Ahn, Principal Engineer Communication Terminal Research Lab • FCC ID: BEJRD2030 • Quantity: Quantity production is planned • Emission Designators: 40K0F8W / 40K0F1D (AMPS), 1M25F9W (CDMA) • Tx Freq. Range: 824.04 — 848.97 MHz (AMPS) 824.70 — 848.31 MHz (CDMA) • Rx Freq. Range: 869.04 — 893.97 MHz (AMPS) 869.70 — 893.31 MHz (CDMA) • Max. Power Rating: 0.401 W ERP AMPS (26.033 dBm) 0.319 W ERP CDMA (25.033 dBm) • FCC Classification(s): Non-Broadcast Transmitter held to ear (TNE) • Equipment (EUT) Type: Dual-Mode Cellular Phone (AMPS/CDMA) • Modulation(s): AMPS / CDMA • Frequency Tolerance: ± 0.00025% (2.5 ppm) • FCC Rule Part(s): §22(H), §22.901(d), §2 • Dates of Tests: July 24-25, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: 22.220715385.BEJ PCTEST PT. 22REPORT FCC CERTIFICATION Reviewed By: Quality Manager Test Report S/N: 22.220715385.BEJ Test Dates: July 24-25, 2002 Phone Type: Dual-Mode FCC ID: BEJRD2030 Page 4 of 24 © 2002 PCTEST ENGINEERING LABORATORY, INC. 2.1 INTRODUCTION These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highes…

Text truncated - open the document above for the full version.

Contact Information

Applicant

David Kim(Team leader, LGEUS NA Policy & Regulatory Affairs)

[email protected]201-470-2696Fax: 201-816-2003

Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

6660-B Dobbin Road · Columbia, Maryland · United States

Non-Technical Contact

PCTEST Engineering Lab., Inc.Randy Ortanez

[email protected]410-290-6652

Test Firm

PCTEST Engineering Laboratory, Inc.Randy Ortanez

[email protected]410-290-6652Fax: 410-290-6654

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
3	22.901(d)	824.7 MHz - 848.31 MHz	319.00 mW	1M25F9W	2.5 ppm

Confidentiality

Long Term

Grant Notes

Output is ERP. SAR compliance for body-worn operating configurations is limited to the specific configuration testing for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.5 cm. separation between the device, including its antenna whether extended or retracted, and the user�s body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values are � Head: 1.21 W/kg: Body-worn: 0.833 W/kg.
