BEJRD2130Dual-Mode Single-Band Cellular Phone

LG-RD2130 User Guide CDMA PHONE Contents Introduction Highlights Important Information Check Accessories Before You Start FCC RF EXPOSURE INFORMATION Chapter 1. Getting Started Cautions Phone Overview On screen Icons Chapter 2. Basic Functions Turning the Phone On and Off Making a Call Correcting Dialing Mistakes Receiving Calls Emergency Dialing Speed Dialing Phone Book Features Chapter 3. Menu Features General Guidelines to MENU Access and Settings Names Messages Call History Profiles Setting Planner System Chapter 4. Book Features Names Chapter 5. Message Features Write Message Inbox Outbox Voice Mail Archive Draft Templates Erase Messages Settings Chapter 6. Functions used during a call Scratch pad Mute Voice Privacy Send my number Short DTMF Chapter 7. Accessories Appendix Installation Appendix RF Exposure Statement Chapter 1. Getting Started Cautions z Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference. z Keep your phone in a safe place when not in use. z Only use the batteries, antennas, and chargers provided by LG. Using the wrong accessories could void your warranty. z Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty. z Do not hold the antenna while the phone is in use. z Do not use the phone in designated “no cellular phone use” areas. z Do not expose the phone to high temperature or humidity. z Avoid getting your phone wet. If the phone gets wet, turn the power off immediately and remove the battery pack. If the phone is mal-functional, return it to the dealer for service. z Avoid shock or impact on the phone. Phone Overview Function Key Descriptions Lamp The light goes on when you use the power key to turn on the phone and when there are incoming calls and messages. LCD screen Displays messages & indicator icons. END/PWR Used to turn power on/off. This key disconnects a call. Using this key, you can also exit out of a menu back to the phone’s standby display without changing the setting. SEND Allows user to place or answer calls. Mouse Key This mouse key allows quick access to text and voice mail notification messages. Profiles, R- World, and RingTone menu. And these keys are used to scroll through the memory locations and menu items. Alphanumeric Keypad These keys enable you to enter numbers and characters and choose menu items. Soft Keys The current operation of a soft key is defined by the word at the bottom of the display. Soft Keys 2 : If you press this key once in a menu, you can go back one level and if you press and hold the key in a menu, you can go back to the standby display. Side Keys These keys enable you to adjust keybeep volume (in standby mode) and earpiece volume (in a call status). Star/Pound Key - In the standby status, set the manner mode by pressing the [ * ]button. (for 2 seconds) - In the standby status, set the lock function by pressing the [ # ]button. (for 2 seconds) Clear Key This key erase character and In the standby status, you can go MyMenu On screen Icons The phone screen displays several onscreen icons and onscreen icons appears when the phone is power on. Icons Descriptions Displays the strength of the signal received by the phone and current signal strength is indicated as the number of bars displayed on the screen. No service The phone is not receiving a system signal. In use A call is in progress. No icon indicates the phone is in standby mode. Digital indicator Digital service is available. Analog indicator Analog service is unavailable Indicates that a text message or voice mail has been received Roaming The phone is outside of its home service area. Charge level Indicates battery charge level. D Chapter 2. Basic Functions Turning the Phone On and Off Turning the Phone On 1. Install a charged battery pack or connect the phone to an external power source such as the cigarette lighter adapter or car kit. 2. Press [END/PWR] for a few seconds until the red light on the top of the phone flashes. z Fully extend the antenna for the best performance. <Note> Like any other radio device, avoid any unnecessary contact with the antenna while your phone is on. Turning the Phone Off 1. Press and hold until display screen will be turned off, and then release the key. 2. Protect the antenna by pushing it back into the phone, if extended. Making a Call When you make a call, follow these simple steps: 1. Make sure the phone is turned on. z If not, press [END/PWR]. 2. Enter the phone number with area code, if needed. 3. Press [SEND]. z If the phone is locked, enter the lock code. z “Call Failed” indicates that the call did not go through. 4. Press [END/PWR] to disconnect the call. Correcting Dialing Mistakes If you make mistakes in dialing a number, press [CLR] key once to erase the last entered digit or hold down [CLR] for at least two second to delete all digits, or simply press soft key 2 [BACK] to exit dialing state. Receiving Calls 1. When the phone rings, open cellcase or If cellcase is open, press any key (except [END/PWR], [5][6], [3((]) to answer. z If you press the key [END/PWR], Side Keys ([(][(]) once when you receive a call, you can hold the present call and ring sound or vibration stops. If you press the [END/PWR] key, Side Keys ([(][(]) twice, the present call is terminated. 2. Press [END/PWR] to disconnect the call. In call waiting mode, the present call is on hold as you answer another incoming call. This service is provided by your service provider. When the call waiting function is activated, your phone will beep to let you know if you have an incoming call. Your phone may also display the incoming caller’s identification. Dialing a call from Phone Book You can place a call from any memory location either by speed dialing or by pressing [SEND] while looking up the memory location. One-Touch Dialing : One-touch dialing is a convenient feature which enables you to dial frequently…

Text truncated - open the document above for the full version.

AFFIDAVIT FOR ESN PROTECTION OF CELLULAR MOBILE TELEPHONES We hereby certify that the LGE Handheld Portable Cellular Telephone(FCC ID: BEJRD2130) is so designed that it complies with all the requirements for ESN protection specified in section 22.919 of the FCC Rules. A) The transmitter in service has a unique ESN. B) The ESN host component is permanently attached to a main circuit board of the mobile transmitter and the integrity of the unit operating software cannot be altered. The ESN is plated from fraudulent contact and tampering. The ESN is encoded using multiplication by a polynomial and the ESN data programmed in the memory with other information. C) The ESN is factory-set and cannot be altered, transferred, removed or otherwise able to be manipulated. Cellular mobile equipment is specifically designed such that any attempt to remove, tamper with, or change the ESN chip, its logic system, or firmware originally programmed by the manufacturer will render the mobile transmitter inoperative. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE Tel : 82-2-850-3850 Fax : 82-2-850-3861 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE March 22. 2003 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Subject : LG Electronics Inc.. FCC ID: BEJRD2130 FCC E911 Requirements Per 522.921 Gentlemen: LG Electronics, Inc. hereby certifies that the analog cellular telephone(FCC ID : BEJRD2130), using the Automatic A/B Roaming–intelligent Retry method, meets the E911 requirements specified in Section 522.921 of the FCC Rules, This procedure recognizes when a “9-1-1” call is made and, at such time, will override any programming in the mobile unit that determines the handling of a non-911 call and permit the call to he handled by other analog carriers. Should you any have questions or comments concerned the above, please contact the undersined. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc.

March 22. 2003 Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 In re : LG Electronics Inc.. FCC ID: BEJRD2130 Dual-Mode Single Band Analog/CDMA Phone (AMPS & CDMA) Part 22 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, LG Electronics, Inc. hereby requests confidentiality of the Block Diagram, Schematics, Technical Description, Operational Description Parts List and Tune-Up Procedure for the above-referenced Type Acceptance application. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. Considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. considers this information to be of benefit to its competitors, such that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, E.S.Park Research Engineer CDMA Handset Lab LG Electronics Inc. Tel : 82-2-850-3850 Fax : 82-2-850-3861 [email protected] 459-9, Kasan-dong,Kemchun-ku Seoul 153-023, Korea LG Electronics Inc. LGE

TCB Q and A.txt From: Mike Kuo Sent: Tuesday, May 20, 2003 9:54 PM To: CLIENT ADVOCATES Cc: Steve Cheng; Thu Chan Subject: LG Electronics USA, FCC ID:BEJRD2130, AN03T2736 FCC Part 22 portion: Question #1: Please provide occupied BW plots. Reply: attached please find additional BW plots. Question #2: Please provide modulation limiting with voice modulation. Reply: Since this device doesn’t have test mode to program the EUT to v oice only mode, and the fact that voice signal in voice + sat configura tion is the same quality with a additional sat signal on, so engineerin g rationale has been made to use voice + sat to substitute the voice on ly plot. Question #3: Please indicate the limits for audio frequency response on page 14 of test report. Reply : attached please find revised test report. SAR Portion of Test report : Question #4: Please justify measurement uncertainty value stated in sec tion 1.3 of test report. Such value does not agree with the informatio n given in section 7 of test report. Reply: attached please find revised SAR test report Question #5: What is the liquid depth during the SAR evaluation ? Reply: 15cm. Report has been modified and included such information. Question #6: In accordance with Probe calibration file and compare the conversion factor used during the SAR evaluation. Head conversion fact or was used for body worn SAR evaluation. Such procedures do not compl y with OET 65 Supplement C, Appendix D:" a field probe must be calibrat ed in tissue media with the target dielectric parameters ..." Please prov ide probe calibration file with body conversion factor for 835MHz and r edo the body worn SAR . Reply: SAR evaluation for body worn operation with probe calibrated wit h body conversion factor has been made. Please refer to the revised SA R test report. Question #7: The SAR test report contains such symbols can not be displ ayed ( ?? Mark showed ). Please provide SAR test report which can be r Page 1 TCB Q and A.txt ecognized ( English version ). Reply: Please refer to revised SAR test report. Question #8: Page 3 section 1 of SAR test report, the max. RF output po wer is listed as 0.398W ERP (26dBm/AMPS ) and 0.316W(25dBm/CDMA ). Suc h information does not match with FCC Part 22 test report. The 26dBm/A MPS and 25dBm/CDMA shall be listed as Max. conducted output power which was measured during SAR and Part 22 tests. The Max. ERP as reported i n FCC Part 22 test report is 21.56dBm/AMPS and 20.66dBm/CDMA. Please m ake necessary correction on the SAR test report. Reply : Please refer to revised SAR test report. Administrative issues: Question #9: The request for confidentiality letter listed the document name can not be associated with file submitted. Please review the fil es that you submitted and modify the request for confidentiality letter which agree with the file names. Reply: Please refer to revised request for confidentiality letter. Question #10: There is no User manual provided. Please provide user ma nual and make sure the body worn operation is addressed in the user man ual. ( The service manual did provided but contains technical informat ion which is normally not avaliable to the end user.) Reply: attached please find revised user manual with body worn warning statement to address RF exposure complaince. Best Regards Mike Kuo Page 2

REPORT NO: 03I1899-1 DATE: APRIL 15, 2003 FCC ID: BEJRD2130 EUT: DUAL-MODE SINGLE-BAND CELLULAR PHONE Page 37 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 8. APENDIX 8.1. EXTERNAL & INTERNAL PHOTOS REPORT NO: 03I1899-1 DATE: APRIL 15, 2003 FCC ID: BEJRD2130 EUT: DUAL-MODE SINGLE-BAND CELLULAR PHONE Page 38 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document.

PROPOSED FCC ID LABEL AND LOCATION LG ELECTRONICS INC. This device complies with Part 22 of the FCC Rules. FCC ID Label

REPORT NO: 03I1899-1 DATE: APRIL 15, 2003 FCC ID: BEJRD2130 EUT: DUAL-MODE SINGLE-BAND CELLULAR PHONE Page 39 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 03I1899-1 DATE: APRIL 15, 2003 FCC ID: BEJRD2130 EUT: DUAL-MODE SINGLE-BAND CELLULAR PHONE Page 40 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 03I1899-1 DATE: APRIL 15, 2003 FCC ID: BEJRD2130 EUT: DUAL-MODE SINGLE-BAND CELLULAR PHONE Page 41 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. REPORT NO: 03I1899-1 DATE: APRIL 15, 2003 FCC ID: BEJRD2130 EUT: DUAL-MODE SINGLE-BAND CELLULAR PHONE Page 42 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document.

ᄌᦝጁᱧ 㧯㨔㨍㨚㨓㨑ޓ㧴㨕㨟㨠㨛㨞㨥 ᄌᦝጁᱧ 㧯㨔㨍㨚㨓㨑ޓ㧴㨕㨟㨠㨛㨞㨥 6[RG0Q559ޓ# 559#559# 559# 5RGEKHKECVKQP5JGGV0Q ޓޓޓ⇟ 0Q ᄌᦝ &CVG ᄌ ᦝ ౝ  %QPVGPVUQH%JCPIG 2003.03.06 Constitution  559

    6ޓJKUURGEKHKECVKQPKUCRRNKECDNGVQ%JKR6[RG#PVGPPCECTTKGFKPVJGEGNNWNCTRJQPGVGTOKPCNQH 5KPING$CPF %&/#  ޓᧄ઀᭽ᦠߪ 5KPING$CPF #/&% ߩ៤Ꮺ㔚⹤┵ᧃᯏߦ៞タࠆࠇߐ %JKR6[RG#PVGPPC ߡ޿ߟߦㆡ↪ޕࠆߔ

  559ޓ#
 5ޓ+WPKVYKNNDGWUGFWPNGUUCP[URGEKCNKVKGUCTGCPPQWPEGF ޕࠆߔ૶↪ࠍන૏ +5ޔࠅ㒢޿ߥ߇⺑᣿ߥ೎.ޓ           ! $CPF Ꮺၞ඙ಽ 6:4: (TGSWGPE[ ๟ᵄᢙ 㨪/*\ 㨪/*\
"  0ޓQOKPCN+ORGFCPEG㧦ǡ ޓၮḰ୯㧦ǡ  #$%  8594ޓQRVKOK\CVKQPKURGTHQTOGFD[OCVEJKPIEKTEWKVKPCEVWCNEGNNWNCTRJQPG ޕࠆߔᦨㆡൻࠅࠃߦ㩙㨹㩋㩧㩂㩨࿁〝ߪ 8594 ߡ޿߅ߦታᯏޓ   #$%     !"#$#$% 8594ޓUCVKUHKGUVJGHQNNQYKPIVCDNGEJCTCEVGTKUVKE/CVEJKPIEKTEWKVUJQYPKP(KIKUWUGF ޕࠆߔ૶↪ࠍߩ߽ߔ␜ߦ KI( ߪ㩙㨹㩋㩧㩂㩨࿁〝ޕࠆߔߣߣߎߔߚḩࠍᕈ.ߩਅ⴫ߪ 8594ޓ (TGSWGPE[$CPF ๟ᵄᢙᏪ 㨪/*\㨪/*\ 8594 6.8nH 1.5pF Fig 3.3.1 Matching circuit  559
&!  #$%     !"#$#$%% 8594ޓKUOGCUWTGFCVUVCPFCTFDQCTFUJQYPKP(KI ޕࠆࠇߐ᷹ቯߡ޿߅ߦᮡḰၮ᧼ߔ␜ߦ KI( ߪ 8594ޓ  '"  ' &   ()  *     !"#$+,-./012&'( (TGSWGPE[$CPF ๟ᵄᢙᏪ 㨪/*\㨪/*\ )CKP 㩃㩨㨼㩧 F$KF$K 1.65 2 3 4.8 117.7 99.6100 35 34.6 3.2 12.2 Fig 3.3.2 Standard board Coaxial cable Antenna SSW0900 Microstrip line Matching circuit GND area 99.6*34.6mm  559  '
&!  %  ( )*3,4-2% ޓ%QQTFKPCVGUCPF/GCUWTGOGPVRNCPGCVTCFKCVKQPRCVVGTPOGCUWTGOGPVCTGFGHKPGFKP(KI C CPF(KI D 4CFKCVKQPRCVVGTPOGCUWTGOGPVKURGTHQTOGFCVOQTGVJCPHTGSWGPEKGUKPENWFKPI VJGJKIJGUVCPFNQYGUVNKOKVHTGSWGPE[QHVJGDCPF ޓ᡼኿㩔㩩㩊㨺㩧ߩ᷹ቯޔߡ޿߅ߦᐳᮡ♽ߣ᷹ቯ㕙ߪ (KI C ෸߮ (KI D ࠅࠃߦቯ⟵ޕࠆࠇߐ᡼኿㩔㩩 ޕࠆߔ᷹ቯߢ๟ᵄᢙߩએ਄ߟ㧞ޔ߻฽ࠍ਄ਅ㒢๟ᵄᢙߩ૶↪Ꮺၞߪ㩊㨺㩧 E2 CW (c) Z Y X Fig 3.4.2(a) Coordinates H CW (a) E1 CW (b) Fig 3.4.2(b) Measurement Plane  559  5(6% 7  5 &8  (6% 7&+ ,-. ޓ9 OKP9%࡮  5
! 7(6% 7 ,-./0 +ޓVKUPGEGUUCT[VQIGPGTCVGPQRTQDNGOQPCPVGPPCCRRGCTCPEGCHVGTNQCFKPIVJGGNGEVTKERQYGT QH9VQVJGHGGFKPIRQKPVCVVJGTQQOVGORGTCVWTGFWTKPIOKPWVGU#PFKVKUPGEGUUCT[VQUCVKUH[ VJGTGSWKTGOGPVUUJQYPKPCPF ޓቶ᷷ߢ㧡ಽ㑆㨻㩧㩍㩏ߩ⛎㔚ὐߦ⹜㛎ᓟޔߟ߆ޕ޿ߥࠄߥߪߡߓ↢ࠍਇౕวߦᄖⷰޔᓟߚߒශടࠍ㔚ജߩ 9 ޕ޿ߥࠄߥߪߡߊߥߐߚḩࠍ㔚᳇⊛ⷐ᳞ߩ  ߮෸  ߽ '"!   9*  ! 12 ' : ! 3456 ޓ&KOGPUKQPHQNNQYUVJGHQNNQYKPIHKIWTG ޕ߁ᓥߦਅ࿑ߪᄖᒻኸᴺޓ ޓ(KIޓ&KOGPUKQPᄖᒻኸᴺ 16.4 r 0.25 17.4 r 0.25 1 r 0.1 1 r 0.1 4.8 r 0.15 1.5 r 0.15 2 r 0.2 2 r 0.2 0.2 r 0.1 2KP(GGFKPI 2KP0%  559 5;  (78 5  9 79:;<=/0 Ԙ(KTUVN[NGCXKPICPCPVGPPCVQVJGVGORGTCVWTG6 .1 HQTJQWT ԙ5GEQPFN[VJGCPVGPPCKUNGHVVQVJGVGORGTCVWTGQH6 *1 D[UCOGOGVJQFHQTJQWT E[ENGUQHVJKUQRGTCVKQP TGHGTVQ(KI CTGVQDGTGCRGCVGF㧔4GNCVKXGJWOKFKV[OWUVDG OCKPVCKPGF㧕#HVGTVJGCDQXGE[ENGVGUVVJGCPVGPPCOWUVPQVJCXGCPQWVGTFCOCIGCPFCNUQ KVOWUVRCUUTGSWKTGOGPVUUJQYPKPCPF 6 ᤨ㑆  ࠍ࠽࠹ࡦࠕޓ .1 6 ᤨ㑆  ߢᣇᴺߓหޔᓟߚߒ᡼⟎ߦ᷷ᐲߩ *1 )d(ᆑߩߎޕࠆߔ᡼⟎ߦ᷷ᐲߩ㧔(KI ⹜㛎ᓟޕ ࠆߔ⛽ᜬࠍ㧑 ߪ⋧ኻḨᐲޔߒૉ ࠆߔታᣉߡߒ㄰ࠅ➅ࠍ࡞ࠢࠗࠨ  ߡߒߦ࡞ࠢࠗࠨ  ࠍ ෳᾖ ޕ޿ߥࠄߥ߫ࠇߌߥߐߚḩࠍⷐ᳞੐㗄ࠆࠃߦ  ߮෸  ߟ߆ޔߊߥ߇៊்ߥᄖⷰ⊛߽ߦ &KURNC[ ⴫␜ FKXKUKQP ඙ಽ VGORGTCVWTG ᷷ᐲ 6 .1 .QYGTVGORGTCVWTGE[ENKPI ૐ᷷ %[ENKPI ͠ 6 *1 *KIJGTVGORGTCVWTGE[ENKPI 㜞᷷ %[ENKPI ͠ (KIޓ6GORGTCVWTGE[ENKPIޓ᷷ᐲ %[ENKPI ͠ 6 *1 6 .1 6GOR͠ 㧴㨞㧴㨞㧴㨞㧴㨞 %;%.' 6+/'*1745  559 5
<   ! =  !  >>9>?/0 6JGCPVGPPC UEJCTCEVGTKUVKEUCTGVQDGOGCUWTGFCHVGTNGCXKPIKVKPVJGDCVJHQTJQWTUWPFGT EQPFKVKQPUJQYPDGNQY#HVGTVJGCDQXGVJGCPVGPPCOWUVPQVJCXGCPQWVGTFCOCIGCPFCNUQKVOWUV RCUUTGSWKTGOGPVUUJQYPKPCPF  ߦᕡ᷷ᕡḨᮏߢ᧦ઙߩਅࠍ࠽࠹ࡦࠕޓ៊்ߥᄖⷰ⊛߽ߦ⹜㛎ᓟޕࠆߔ᷹ቯࠍᕈ.ߩߘޔᓟߚߒᤨ㑆᡼⟎ ޕ޿ߥࠄߥ߫ࠇߌߥߐߚḩࠍⷐ᳞੐㗄ࠆࠃߦ  ߮෸  ߟ߆ޔߊߥ߇ 6GORGTCVWTG ᷷ᐲ 4GNCVKXGJWOKFKV[ ⋧ኻḨᐲ 6GUVKPIVKOG ⹜㛎ᤨ㑆 r͠r㧑r㧴㨞 5   7 ! @A9:/0 1ޓRGTCVKPIVGORGTCVWTGTCPIG㧦͠㨪 ͠ 㧑KPTGNCVKXGJWOKFKV[ 9ޓJGPQRGTCVKPIKPVJGCDQXGOGPVKQPGFVGORGTCVWTGTCPIGVJGCPVGPPCOWUVPQVJCXGCPQWVGTFCOCIG CPFCNUQKVOWUVRCUUTGSWKTGOGPVUUJQYPKPCPF ޓേ૞᷷ᐲ⹜㛎▸࿐㧦͠㨪 ͠ ⋧ኻḨᐲޓ㧑 ߌߥߐߚḩࠍⷐ᳞੐㗄ࠆࠃߦ  ߮෸  ߟ߆ޔߊߥ߇៊்ߥᄖⷰ⊛ޔേ૞ᤨߩߢ᷷ᐲ▸࿐ߩ਄⸥ޓ ޕ޿ߥࠄߥ߫ࠇ 5 ' 7 ! BC9:/0 6ޓJG5VQTCIG6GORGTCVWTG6GUVJCUGZRGTKOGPVU ޓ(KTUVCNQYVGORGTCVWTGUVQTCIGVGUVYKNNDGGZCOGF#HVGTNGCXKPICPVGPPCCV͠HQTJQWTU KVYKNNDGKPCTQQOVGORGTCVWTGHQTJQWTU ޓ#JKIJVGORGTCVWTGUVQTCIGVGUVYKNNDGGZCOGF#HVGTNGCXKPIKVCV͠UKOKNCTN[HQTJQWTU KVYKNNDGNGHVKPCTQQOVGORGTCVWTGHQTJQWTU ޓ'CEJGZCOKPCVKQPKURGTHQTOGFWPFGTVJGGPXKTQPOGPVQHQHTGNCVKXGJWOKFKV[ ޓ#HVGTVJGCDQXGVJGCPVGPPCOWUVPQVJCXGCPQWVGTFCOCIGCPFCNUQKVOWUVRCUUTGSWKTGOGPVU UJQYPKPCPF ޕࠆࠇࠄߌಽߦ㜞᷹᷷ቯૐ᷷ߪ᷷ᐲ臣⬿⹜㛎ޓ ޕ߁ⴕߦᓟߚߒᤨ㑆᡼⟎  ߢᏱ᷷ޔᓟߚߒᤨ㑆᡼⟎  ߢ͠ޔߪૐ᷷臣⬿⹜㛎ߕ߹ޓ ޓ㜞᷷臣⬿⹜㛎ߪห᭽ ߦ͠ ߢ ᤨ㑆᡼⟎ߚߒᓟޔᏱ᷷ ߢ ᤨ㑆᡼⟎ߚߒᓟߦⴕޕ߁ ޕ߁ⴕߢਅߩ⋧ኻḨᐲߩ㧑 ߽ࠇߕ޿ߪ⹜㛎 ࠇߌߥߐߚḩࠍⷐ᳞੐㗄ߥ㔚᳇⊛ࠆࠃߦ  ߮෸  ߟ߆ޔߊߥ߇៊்ߥᯏ᪾⊛߮ᄖⷰ෸ޔ⹜㛎ᓟޓ ޕ޿ߥࠄߥ߫  559 5 5#   ! D@/0 ޓ$GHQTGXKDTCVKQPVGUVVJGCPVGPPC UGNGEVTKECNEJCTCEVGTKUVKEPGGFUVQDGOGCUWTGF ޓ#HVGTVJGCDQXGUVGRCPCPVGPPCYKNNDGCVVCEJGFVQCXKDTCVKQPVGUVGSWKROGPV 6ޓJGXKDTCVKQPVGUVYKNNDGECTTKGFQWVHQTJQWTKPVJGFKTGEVKQPUQH:;CPF<WPFGTEQPFKVKQP UJQYPDGNQY ޓ#HVGTVJGCDQXGVJGCPVGPPCOWUVPQVJCXGCPQWVGTFCOCIGCPFCNUQKVOWUVRCUUTGSWKTGOGPVU UJQYPKPCPF ޕࠆߡ┙ߺ⚵ࠍ࠽࠹ࡦࠕߦ⹜㛎ⵝ஻ޔᓟߚߒ᷹ቯࠍᕈ.㔚᳇⊛ߩ࠽࠹ࡦࠕߦ೨ߩ⹜㛎ޓ:; ߩᣇะߦฦޘ ⷐߥ㔚᳇⊛ࠆࠃߦ  ߮෸  ߟ߆ޔߊߥ߇៊்ߥᯏ᪾⊛߮ᄖⷰ෸ޔ⹜㛎ᓟޕࠆߔታᣉࠍᤨ㑆⹜㛎  ޕ޿ߥࠄߥ߫ࠇߌߥߐߚḩࠍ᳞੐㗄 1UEKNNCVKPIHTGSWGPE[ ᝄേ๟ᵄᢙ 5YGGR6ޓKOG ᝹ᒁᤨ㑆 CORNKVWFG ᝄ᏷ 6JGOCZKOWOCEEGNGTCVKQP ᦨᄢടᄕᐲ 㨪*\ ಽOOI  559 ?() 7   EFGH  559 @%: IJKL @ &"<9<%A#$%%(< @
<(%        (TGSWGPE[ )*\ 8594 (TGSWGPE[ …

Text truncated - open the document above for the full version.

SAR Measurement Report Test Date : MAR 14-15, MAY 24, 2003 FCC ID : BEJRD2130 Test Report No: LGE-SAR2003005 LG ELECTRONICS INC. CDMA HANDSETS LABORATORY MOBILE HANDSETS COMPANY 459-9, Kasan-don, Keumchun-ku Seoul 153-023, Korea TEL: +82-2-850-3860 FAX: +82-2-850-3855 www.lge.com - 1/25 - SAR Compliance Test Report APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTIONG: LG ELECTRONICS INC. Dates of tests: MAR 14-15, MAY 24, 2003 Communication Terminal Research Lab Test Site: LG ELECTRONICS, SEOUL Korea 459-9, Kasan-don, Keumchun-ku Seoul 153-023, Korea Attn: J.H. Goo , President Test Device Test Report No. LGE-SAR2003005 Number of Page 59 Contact Person J. H. Goo Responsible Test Engineer E. S. PARK Testing has been Carried out in Accordance with IEEE P1528-200X Draft 6.4 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate(SAR) in the Human Body Due to Wireless Communications Device : Experimental Techniques Application Type Certification FCC Classification Licensed Portable Transmitter held to ear (PCE) FCC Rule Part(s) 2.1093; FCC/OET Bulletin 65 Supplement C (July 2001) Test Results The Tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced recept in full, without written approval of the laboratory. Date and Signatures MAY / 26 / 2003 Report Prepared by Eui - Soon Park Senior Research Engineer Models : LG-RD2130, BD2130 FCC ID : BEJRD2130 Type : Dual-Mode Single-Band Cellular Phone SAR Measurement Report Test Date : MAR 14-15, MAY 24, 2003 FCC ID : BEJRD2130 Test Report No: LGE-SAR2003005 LG ELECTRONICS INC. CDMA HANDSETS LABORATORY MOBILE HANDSETS COMPANY 459-9, Kasan-don, Keumchun-ku Seoul 153-023, Korea TEL: +82-2-850-3860 FAX: +82-2-850-3855 www.lge.com - 2/25 - Table of Contents 1. SUMMARY FOR SAR TEST REPORT 3/25 1.1 Head Configuration 3/25 1.2 Body Worn Configuration 3/25 1.3 Measurement Uncertainty 3/25 2. INTRODUCTION 4/25 3. DESCRIPTION OF THE DEVICE UNDER TEST 5/25 3.1 Antenna Description 5/25 3.2 Device Description 5/25 3.3 Battery Option 5/25 4. TEST CONDITIONS 6/25 4.1 Ambient Conditions 6/25 4.2 RF Characteristics of The Test Site 6/25 4.3 Test Signal, Frequencies, And Output Power 6/25 5. DESCRIPTION OF THE TEST EQUIPMENT 7/25 5.1 Test System Specifications 7/25 5.2 SAR Measurement Setup 7/25 5.3 DASY4 E-Field Probe System 8/25 5.4 Phantom & Equivalent Tissues 10/25 6. DESCRIPTION OF THE TEST PROCEDURE 12/25 6.1 Definition of Reference Point 12/25 6.2 Test Configuration Positions 13/25 6.3 Scan Procedures 16/25 6.4 SAR Averaging Methods 16/25 7. MEASUREMENT UNCERTAINTY 17/25 8. SYSTEM VERIFICATION 18/25 8.1 Tissue Verification18/25 8.2 Test System Validation18/25 9. RESULTS 19/25 10. REFERENCES 25/25 APPENDIX A : Validation Test Data APPENDIX B : SAR Test Setup Photographs APPENDIX C : SAR Test Data APPENDIX D : Calibration Certificates SAR Measurement Report Test Date : MAR 14-15, MAY 24, 2003 FCC ID : BEJRD2130 Test Report No: LGE-SAR2003005 LG ELECTRONICS INC. CDMA HANDSETS LABORATORY MOBILE HANDSETS COMPANY 459-9, Kasan-don, Keumchun-ku Seoul 153-023, Korea TEL: +82-2-850-3860 FAX: +82-2-850-3855 www.lge.com - 3/25 - 1. SUMMARY FOR SAR TEST REPORT FCC ID BEJRD2130 Date of Test MAR 14-15, MAY 24, 2003 Responsible Test Engineer Eui - Soon Park Measurement Performed by Cheol - Goo Lee EUT Type Dual-mode Single-band Cellular Phone (AMPS / CDMA) Tx Frequency 824.04 – 848.97 MHz (AMPS) 824.820 ~ 848.190 MHz (CDMA) Rx Frequency 869.04 – 893.97 MHz (AMPS) 869.820 ~ 893.190 MHz (CDMA) Max. RF Output Power AMPS - 0.398W (26 dBm) Conducted (21.56 dBm ERP) CDMA - 0.316W (25 dBm) Conducted (20.66 dBm ERP) Maximum Results Found During SAR Evaluation 1.1 Head Configuration Max. SAR Measurement FREQUENCY Power MHz Ch Modulation dBm Battery Device test position Antenna position SAR (W/kg) 848.97 799 AMPS 26 Standard Left Cheek Touch Fixed 0.712 1.2 Body Worn Configuration Max. SAR Measurement FREQUENCY Power MHz Ch Modulation dBm Battery Separation Distance (cm) Antenna position SAR (W/kg) 836.49 383 AMPS 26 Standard 1.5 [w/o Holster] Fixed 0.887 1.3 Measurement Uncertainty Combine Standard Uncertainty 10.2 (k=1) Extended Standard Uncertainty 20.3 (k=2, 95% CONFIDENCE LEVEL) SAR Measurement Report Test Date : MAR 14-15, MAY 24, 2003 FCC ID : BEJRD2130 Test Report No: LGE-SAR2003005 LG ELECTRONICS INC. CDMA HANDSETS LABORATORY MOBILE HANDSETS COMPANY 459-9, Kasan-don, Keumchun-ku Seoul 153-023, Korea TEL: +82-2-850-3860 FAX: +82-2-850-3855 www.lge.com - 4/25 - 2. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable device.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) For localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for safety Levels with Respect to Human Exposure to Radio Frequency Electronic Fields, 3 kHz to 300 GHz. (c) 1992 by the institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSIC95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields – RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radio Frequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD20814.[6] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source…
