BEJRU60SZ10LCD Projection TV

APPENDIX G : FCC ID : BEJRU60SZ10 USER’S MANUAL © Copyright 2002, Zenith Electronics Corporation. Installation and Operating Guide | Warranty Model Number|D60WLCD|LCD TV PAGE 2 206-03726 WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. POWER CORD POLARIZATION: CAUTION:TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND. NOTE TO CABLE/TV INSTALLER: This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical. REGULATORY INFORMATION: This equipment, trade name Zenith, model number, D60WLCD, has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. The responsible party for this device compliance is: Zenith Electronics Corporation 2000 Millbrook Drive Lincolnshire, IL 60069 Digital TV Hotline: 1-847-941-8000 CAUTION: Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation. Unauthorized modification could void the user’s authority to operate this product. 2002 Zenith Electronics Corporation. All rights reserved. WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN PAGE 3 206-03726 Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference. Observing the simple precautions discussed in this booklet can help you get many years of enjoyment and safe operation that are built into your new product. This product complies with all applicable U.S. Federal safety requirements, and those of the Canadian Standards Association. (Continued on next page) 1. Read Instructions All the safety and operating instructions should be read before the product is operated. 2. Follow Instructions All operating and use instructions should be followed. 3. Retain Instructions The safety and operating instructions should be retained for future reference. 4. Heed Warnings All warnings on the product and in the operating instruc- tions should be adhered to. 5. Cleaning Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 6. Water and Moisture Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool. 7. Accessories Carts and Stands Do not place this product on a slippery or tilted surface, or on an unstable cart, stand, tripod, bracket, or table. The product may slide or fall, causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table recom- mended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufac- turer’s instructions, and should use a mounting accessory recommended by the manufacturer. 8. Transporting Product A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 9. Attachments Do not use attachments not recommended by the product manufacturer as they may cause hazards. 10. Ventilation Slots and openings in the cabinet are provided for ventila- tion and to ensure reliable operation of the product and to protect it from overheating, and these openings must not be blocked or covered. The openings should never be blocked by placing the product on a bed, sofa, rug, or other similar surface. This product should not be placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions have been adhered to. 11. Power Sources This product…

Text truncated - open the document above for the full version.

Attn.: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR LCD Projection TV FCC ID: BEJRU60SZ10 MODEL #: D60WLCD Gentlemen This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the schematic diagrams, block diagrams required to be submitted with this application be withheld from public review. These documents contain detailed system and equipment description and related information about the product which LG Electronics Inc. considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, LG Electronics Inc. feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Kyeom Soon Kim March 13, 2002 LG Electronics Inc./General Manager LG Electronics Inc.

Attn.: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 LETTER OF AGENT AUTHORIZATION Dear Sir: We, the undersigned, hereby authorize MET laboratories Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This agreement expires one year from the current date. Sincerely, Kyeom Soon Kim March 13, 2002 LG Electronics Inc. /General Manager LG Electronics Inc.

FCC ID : BEJRU60SZ10 1. External View [ Front ] [ Back ]

APPENDIX B : LabellingRequirements FCC ID : BEJRU60SZ10 Warning Label 1ID Label Warning Label 1 Location ID Label Location Warning Label 2 Warning Label 2 Location

FCC ID : BEJRU60SZ10 APPENDIX F 1. External View 2. Internal View 3. PCB View 3-1. Ballast Board 3-2. Ballast Interface Board 3-3. ChromaBoard 3-4. Control Board 3-5. Digital Board 3-6. Drive Board 3-7. Free amp Board 3-8. Main Board 3-9. Power Board 3-10. Power Filter Board 3-11. Side A/V Board 3-12. Tuner Board EUT Photographs FCC ID : BEJRU60SZ10 1. External View [ Front ] [ Back ] FCC ID : BEJRU60SZ10 2. Internal View FCC ID : BEJRU60SZ10 3-1. Ballast Board FCC ID : BEJRU60SZ10 3-2. Ballast Interface Board FCC ID : BEJRU60SZ10 3-3. ChromaBoard FCC ID : BEJRU60SZ10 3-4. Control Board FCC ID : BEJRU60SZ10 3-5. Digital Board FCC ID : BEJRU60SZ10 3-6. Drive Board FCC ID : BEJRU60SZ10 3-7. Free amp Board FCC ID : BEJRU60SZ10 3-8. Main Board FCC ID : BEJRU60SZ10 3-9. Power Board FCC ID : BEJRU60SZ10 3-10. Power FilterBoard FCC ID : BEJRU60SZ10 3-11. Side A/V Board FCC ID : BEJRU60SZ10 3-12. Tuner Board

Marianne Bosley To:[email protected] Subject:Metrak #12085 FCC ID:BEJRU60SZ10 Hello, Our review engineer has completed his technical review. He has requested the following information: 1. Please indicate the highest frequency used or generated by the digital portion of the EUT, as this determines the proper upper frequency range of measurement. Section 15.33(b) indicates the required upper fequency of investigation. If the digital portion generates a frequency over 108 MHz, then radiated measurements over 1 GHz are required. Your report does not indicate that these were made. If so required, please also submit the additional radiated measurements. Remember that the limit of emissions over 1 GHz is an average limit, however, Section 15.35(b) also requires that peak measurements be made as well. Please let me know if you have any further questions. Regards, Marianne Marianne T. Bosley EMC Administrator 410-354-3300 X 412 [email protected]

Marianne Bosley From:Marianne Bosley Sent:Tuesday, March 19, 2002 11:11 PM To:'[email protected]' Cc:Marianne Bosley Subject:FW: Re : Metrak #12085 FCC ID:BEJRU60SZ10 -----Original Message----- From: ??? To: Marianne Bosley Sent: 3/19/2002 9:12 PM Subject: Re : Metrak #12085 FCC ID:BEJRU60SZ10 Thank you for your cooperation!! The highest frequency of the EUT is 75 MHz. I'm sorry to trouble you. Please let me know, if you need any more information. Best Regards, Jacob ---------- ?? ??? ---------- ??? : Marianne Bosley <[email protected]> ??? : ???? ??? ?????(??)([email protected], 82-2-2630-3077~9) ? ? : 02/3/20 3:47:05 AM ? ? : Metrak #12085 FCC ID:BEJRU60SZ10 Hello, Our review engineer has completed the technical review of your project. He has requested the following: 1. Please indicate the highest frequency used or generated by the digital portion of the EUT, as this determines the proper upper frequency range of measurement. Section 15.33(b) indicates the required upper fequency of investigation. If the digital portion generates a frequency over 108 MHz, then radiated measurements over 1 GHz are required. Your report does not indicate that these were made. If so required, please also submit the additional radiated measurements. Remember that the limit of emissions over 1 GHz is an average limit, however, Section 15.35(b) also requires that peak measurements be made as well. Please let me know if your have any questions. Have a good day. Regards, Marianne Marianne T. Bosley EMC Administrator 410-354-3300 X 412 [email protected]

FCC ID : BEJRU60SZ10 APPENDIX E : 1. Radiated Emission 2. Conducted Emission Test Set-up Photographs FCC ID : BEJRU60SZ10 1. Radiated Emission FCC ID : BEJRU60SZ10 2. Conducted Emission
