1/6 User Manual (TL1T22NR, TL1T22NE) FCC ID : BEJTL1T22NR 2/6 1. Product Introduction The TL1T22NRare designed for the automotive industry. They support LTE and WCDMA air Interface standards. The TL1T22NR are based on the Qualcomm MDM9250 wireless chipsets and support the following bands. Table 1. Supported Band Band TL1T22NRTL1T22NE Band B2 G, W, L W, L B4 W, L W, L B5 G, W, L W, L B7 L L B12(B17) L L B26 L B41 L G: GSM / W: WCDMA / L: LTE 1.1 Block Diagram Figure 1.1. TL1T22NR Block diagram Confidential 3/6 1.2 Environmental Specifications The environmental specification for operating and storage of the TL1T22NR are defined in the the table below. Table 2. Environmental Specifications Parameter Temperature Range Operating Temperature -40°C to 90°C (ecall 95°C) Storage Temperature -40°C to +95°C Humidity 95% or less 1.3 Electrical Specifications This section provides details for some of the key electrical specifications of the TL1T22NR embedded modules. 1.3.1 Absolute Maximum Rating and ESD Ratings This section defines the Absolute Maximum and Electrostatic Discharge (ESD) Ratings of the TL1T22NR embedded modules. Warning: If these parameters are exceeded, even momentarily, damage may occur to the device. Table 3. Absolute Maximum Ratings Parameter MinMax Units VBATT Power Supply Input - 18 V VIN Voltage on any digital input or output pin - 18 V ESD Ratings ESD 1) Primary, Diversity antenna pads - Contact 10 kV 1) The ESD Simulator configured with 330pF, 2000Ω. Caution: The TL1T22NR embedded modules are sensitive to Electrostatic Discharge. ESD countermeasures and handling methods must be used when handling the TL1T22NR devices. 4/6 1.3.2 Current Consumption Table 4. TL1T22NR Current Consumption (12.5V) Mode Parameter Typical Max Units LTE Max TX Output /Full RB 450 550 mA WCDMA Max TX Output /Full RB 450 550 mA LTE Idle, Registered 2 4 mA WCDMA Idle, Registered 2 4 mA LTE Sleep Mode, Average Current 0.03 mA WCDMA Sleep Mode, Average Current 0.03 mA 5/6 1.4 Mechanical Specifications 1.4.1 Physical Dimensions and Connection Interface Mechanical structure diagram Trunk variant Size : 160 x 100 x 18mm Weight : Low variant – 300g 6/6 2. RF Specification The specifications for the LTE and WCDMA interfaces are defined. TL1T22NR is designed to be compliant with the standard shown in the table below. Table6. Standards Compliance 3. Warning Statement FCC Warning Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. ‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with minimum distance 20cm between the radiating element of this device and the user. Technology Standards LTE • 3GPP Release 11 WCDMA • 3GPP Release 9 GSM • 3GPP Release 8
