BEJTLVUW3IU-WTelematics

TLVUW3IU -W (Online Connectivity Unit) LG Electronics Inc. FCCID: BEJTLVUW3IU-W What is the OCU(Online Connectivity Unit)  The OCU stands for Online Connectivity Unit  It’s a telematics device that LGE is developing for the Volkswagen vehicles.  It is a small box installed deep inside passenger cars, and in charge of wireless communications in GSM, WCDMA and LTE network  It provides voice and data call functions and various onl ine services requested by VW GNSS Antenna Connector Power, CAN, Audio and other data connector GSM/WCDMA/LTE Antenna Connector WCDMA/LTE DRx Antenna Connector Product Image/ Function Product Image Function • Emergency Call • Mobile Online Services • Positioning/Dead Reckoning-GPS, GLONASS, Galileo, BeiDou and QZSS Telematics product supporting Emergency Call/LTE se rvice Specification Supporting Bands WCDMA B5LTE FDD B5/B7 Modem Chip Qualcomm MDM9240 GNSS GPS, GLONASS, Galileo, BeiDou and QZSS Bluetooth No WiFi No Size 145mm x 88mm x 38mm Weight 340g Power DC 12V , 2A Specification Dimension 52.95 38.8 15.5 14.5 26.2 30.75 45.45 17.9 145mm 88mm 38 The OCU3 Features • Call Services - Emergency Call- Automatic Collision Notification Call- Information Call- Road Side Assistance Call • Remote Function Services - Honking And Flashing- Speed Alert- Vehicle Disabling- Battery Charge Management- Departure Time Programming- Door Lock / Unlock- Pre-Trip Climatisation- Trip Statistics- Vehicle Status • Geo-Fencing • POI Address Import • Vehicle Health Report • Vehicle Tracking Major Services Concept GNSS Safety & Security Services Oriented Telematics Terminal Emergency Call Automatic Collision Notification Call Road Side Assistance Call Vehicle Tracking OCU Equipped Vehicles LGE Internal Use Only Block Diagram Confidential Notice FCCChanges or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditio ns: (1) This device may not cause harmful interference, and (2) this device must acce pt any interference received, including interferenc e that may cause undesired operation.This equipment has been tested and found to comply with the limits for a Class B digital dev ice, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasona ble protection against harmful interference in a re sidential installation. This equipment generates uses and can radiate radio frequency ener gy and, if not installed and used in accordance wit h the instructions, may cause harmful interference to radio communications. However, ther e is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interf erence by one or more of the following measures: -Reorient or relocate the receiving antenna.-Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connec ted. -Consult the dealer or an experienced radio/TV tech nician for help. This device complies with FCC radiation exposure li mits set forth for an uncontrolled environment. Thi s device should be installed and operated with minimum distance 20cm between the rad iating element of this device and the user. Frequency Band Acceptable antenna peak gain (incl. cable att.) (dBi) (ERP or EIRP Limit(FCC) - Max tune-up conducted power) 824-849MHz(B5) 10.9 2500-2570MHz (B7) 9.5 • Acceptable antenna peak gain (incl. cable att.) = ERP or EIRP L imit(FCC) - Max tune-up conducted power The maximum antenna gain including cable att. must not exceed t he table below.

Rev 1/26/2023 LG Electronics USA 111 Sylvan Avenue North Building Englewood Cliffs New Jersey United States 07632 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03/22/2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code: BEJ LG Electronics USA (“the applicant”) certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0023476120 Name: LG Electronics USA Address: 111 Sylvan Avenue North Building Englewood Cliffs New Jersey United States 07632 Contact Person: Heejae Cho Tel.: 201-470-2696 Email: [email protected] Sincerely, LG Electronics USA Heejae Cho

Rev 1/26/2023 LG Electronics USA 111 Sylvan Avenue North Building Englewood Cliffs New Jersey United States 07632 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-23-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: LG Electronics USA certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Heejae Cho BEJTLVUW3IU-W Rev 1/26/2023 LG Electronics USA 111 Sylvan Avenue North Building Englewood Cliffs New Jersey United States 07632 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 03-22-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: LG Electronics USA certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Heejae Cho BEJTLVUW3IU-W

LG Electronics USA, Inc. 111 Sylvan Avenue North Building Englewood Cliffs New Jersey United States 07632 Date: 03/24/2023 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Request of Confidentiality FCC ID: BEJTLVUW3IU-W To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA, Inc.. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give LG Electronics USA, Inc.. temporary confidentiality of commercially sensitive information prior to product release. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description 5 Tune-up Procedure SHORT-TERM 6 Internal Photos 7 External Photos 8 Test-Setup Photos 9 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Contact Name: Heejae Cho Title: Director, Regulatory and Environmental Affairs

LG Electronics USA, Inc. 111 Sylvan Avenue North Building Englewood Cliffs New Jersey United States 07632 Date: 03/24/2023 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Letter of Authorization We, the undersigned, hereby authorize Geunki Son of Dt&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: BEJTLVUW3IU-W including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of Dt&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from LG Electronics USA, Inc.. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Contact Name: Heejae Cho Title: Director, Regulatory and Environmental Affairs

FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 1 FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 2 FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 3 FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 4 <Port> FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 5 <External Antenna> <External Antenna> FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 6 <External Antenna + Cable>

FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 1 FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 2 FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 3 FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 4 FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. View 5 <Internal Antenna>

FCC ID: RF feature(Mode) Tune-up Max power(dBm) ANT Gain (dBi) Cable loss between transmitter and antenna(dB) Duty Factor(dB) Adjusted EIRP to tune-up max(dBm) Maximum power density (mW/cm 2 ) Requirement (mW/cm 2 ) LTE Band 7 2 500.00 ~ 2 570.00 23.50 1.77 9.04 NA 16.23 0.008 4 1.000 0 LTE Band 5 824.00 ~ 849.00 23.50 1.94 4.35 NA 21.09 0.025 6 0.549 0 WCDMA 850 826.40 ~ 846.60 23.50 1.94 4.35 NA 21.09 0.025 6 0.550 0 ~~~~~~~~~~ ▪ S = - Note = / ( 4 X 20 2 X π ) = mW/cm 2 Electric Field strength (V/m) Magnetic field strength (A/m) Power Density (mW/cm 2 ) Averaging time (minutes) 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19 / f *180 / f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1,500 f / 1500 30 1,500 ~ 100,000 1.0 30 Conclusion : Note2: EIRP(Adjusted EIRP to Tune- up Max) = Tune-u p power(dBm) + Antenna gain(dBi) + Cable loss(dB) + Duty factor(dB) EIRP / ( 4 R 2 π ) 16.230 0.008 BEJTLVUW3IU-W MPE Calculation Frequency range (MHz) Note1: Please refer to the tune-up procedure for tu ne-up max. The EUT will only be used with a separation of 20 c entimeters or greater between the antenna and the b ody of the user. The exposure condition of this device is compliant with FCC The MPE sample calculation for this exposure is sho wn below. R= Distance to the center of the radiation of the a ntenna(20cm) EIRP= Equivalent Isotropic Radiated Power(mW)S= Maximum power density(mW/cm 2 ) ▪ Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz)

Report No.: DRTFCC2303-0024 FCC ID: BEJTLVUW3IU-W This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-230(06)210316 Pages: 2 / 74 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2303-0024 Mar. 08, 2023 Initial issue SeungMin Gil JaeJin Lee Report No.: DRTFCC2303-0024 FCC ID: BEJTLVUW3IU-W This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-230(06)210316 Pages: 3 / 74 Table of Contents 1. GENERAL INFORMATION ........................................................................ 5 2. INTRODUCTION ........................................................................................ 6 2.1. EUT DESCRIPTION ............................................................................................................ 6 2.2. TESTING ENVIRONMENT .................................................................................................. 6 2.3. MEASURING INSTRUMENT CALIBRATION ...................................................................... 6 2.4. MEASUREMENT UNCERTAINTY ....................................................................................... 6 2.5. TEST FACILITY ................................................................................................................... 6 3. DESCRIPTION OF TESTS ......................................................................... 7 3.1. ERP & EIRP (Effective Radiated Power & Equivalent Isotropic Radiated Power) ......... 7 3.2. PEAK TO AVERAGE RATIO ............................................................................................... 9 3.3. OCCUPIED BANDWIDTH ................................................................................................. 10 3.4. BAND EDGE EMISSIONS AT ANTENNA TERMINAL ...................................................... 11 3.5. SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL ............................ 11 3.6. UNDESIRABLE EMISSIONS ............................................................................................ 13 3.7. FREQUENCY STABILITY ................................................................................................. 14 4. LIST OF TEST EQUIPMENT ................................................................... 15 5. SUMMARY OF TEST RESULTS .............................................................. 16 6. SAMPLE CALCULATION ........................................................................ 17 7. TEST DATA .............................................................................................. 18 7.1. CONDUCTED OUTPUT POWER ...................................................................................... 18 7.1.1. LTE Band 5 ................................................................................................................ 18 7.1.2. LTE Band 7 ................................................................................................................ 19 7.2. OCCUPIED BANDWIDTH ................................................................................................. 20 7.3. PEAK TO AVERAGE RATIO ............................................................................................. 20 7.4. BAND EDEG EMISSIONS (Conducted) ........................................................................... 20 7.5. SPURIOUS AND HARMONICS EMISSIONS (Conducted) .............................................. 20 7.6. ERP & EIRP ...................................................................................................................... 21 7.6.1. LTE Band 5 ................................................................................................................ 21 7.6.2. LTE Band 7 ................................................................................................................ 22 7.7. UNDESIRABLE EMISSIONS (Radiated) .......................................................................... 23 7.7.1. LTE Band 5 ................................................................................................................ 23 7.7.2. LTE Band 7 ................................................................................................................ 24 7.8. FREQUENCY STABILITY ................................................................................................. 25 7.8.1. LTE Band 5 ................................................................................................................ 25 7.8.2. LTE Band 7 ................................................................................................................ 26 8. TEST PLOTS ........................................................................................... 27 8.1. OCCUPIED BANDWIDTH ................................................................................................. 27 8.1.1. LTE Band 5 ................................................................................................................ 27 8.1.2. LTE Band 7 ................................................................................................................ 31 8.2. PEAK TO AVERAGE RATIO ............................................................................................. 35 Report No.: DRTFCC2303-0024 FCC ID: BEJTLVUW3IU-W This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-230(06)210316 Pages: 4 / 74 8.2.1. LTE Band 5 ................................................................................................................ 35 8.2.2. LTE Band 7 ................................................................................................................ 39 8.3. BAND EDGE EMISSIONS(Conducted) ............................................................................ 43 8.3.1. LTE Band 5 ................................................................................…

Text truncated - open the document above for the full version.

Report No.: DRTFCC2303-0023 FCC ID: BEJTLVUW3IU-W This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-210(12)210316 Pages: 2 / 28 Test Report Version Test Report No. Date Description Revised by Reviewed by DRTFCC2303-0023 Mar. 08, 2023 Initial issue SeungMin Gil JaeJin Lee Report No.: DRTFCC2303-0023 FCC ID: BEJTLVUW3IU-W This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-210(12)210316 Pages: 3 / 28 Table of Contents 1. GENERAL INFORMATION ........................................................ 4 2. INTRODUCTION ........................................................................ 5 2.1. EUT DESCRIPTION .......................................................................................................... 5 2.2. TESTING ENVIRONMENT ............................................................................................... 5 2.3. MEASURING INSTRUMENT CALIBRATION .................................................................. 5 2.4. MEASUREMENT UNCERTAINTY .................................................................................... 5 2.5. TEST FACILITY ................................................................................................................ 5 3. DESCRIPTION OF TESTS ......................................................... 6 3.1. ERP & EIRP (Effective Radiated Power & Equivalent Isotropic Radiated Power) .... 6 3.2. PEAK TO AVERAGE RATIO ............................................................................................ 8 3.3. OCCUPIED BANDWIDTH (99 % Bandwidth) ............................................................... 10 3.4. SPURIOUS EMISSIONS AT ANTENNA TERMINAL ..................................................... 11 3.5. BAND EDGE EMISSIONS AT ANTENNA TERMINAL .................................................. 12 3.6. RADIATED SPURIOUS EMISSIONS ............................................................................. 13 3.7. FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ..................... 14 4. LIST OF TEST EQUIPMENT .................................................. 15 5. SUMMARY OF TEST RESULTS ............................................. 16 6. EMISSION DESIGNATOR AND SAMPLE CALCULATION .... 17 7. TEST DATA ............................................................................ 18 7.1. CONDUCTED OUTPUT POWER ................................................................................... 18 7.2. PEAK TO AVERAGE RATIO .......................................................................................... 19 7.3. OCCUPIED BANDWIDTH (99 % Bandwidth) ............................................................... 19 7.4. SPURIOUS MISSIONS AT ANTENNA TERMINAL ........................................................ 19 7.5. BAND EDGE EMISSIONS AT ANTENNA TERMINAL .................................................. 19 7.6. EFFECTIVE RADIATED POWER ................................................................................... 20 7.7. RADIATED SPURIOUS EMISSIONS ............................................................................. 21 7.8. FREQUENCY STABILITY / VARIATION OF AMBIENT TEMPERATURE ..................... 22 7.8.1. FREQUENCY STABILITY (WCDMA850) .................................................................. 22 8. TEST PLOTS ........................................................................... 23 8.1. PEAK TO AVERAGE RATIO ........................................................................................ 23 8.2. OCCUPIED BANDWIDTH (99 % Bandwidth) ............................................................. 24 8.3. SPURIOUS EMISSIONS AT ANTENNA TERMINAL ................................................... 25 8.4. BAND EDGE EMISSIONS AT ANTENNA TERMINAL ................................................. 27 Report No.: DRTFCC2303-0023 FCC ID: BEJTLVUW3IU-W This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-210(12)210316 Pages: 4 / 28 1. GENERAL INFORMATION Equipment Class PCS Licensed Transmitter (PCB) Product Name Telematics Model Name T LVUW 3IU-W Add Model Name - FVIN(Firmware Version Identification Number) X500 EUT Serial Number 212VICL329171 Power Supply DC 12 V Antenna Information Antenna Type: Shark pin Antenna (Model : 5WA.035.507 B 041) Antenna gain(including connected cable loss between transmitter and antenna): -2.41 dBi Antenna gain: 1.94dBi Cable loss: 4.35 dB Mode Tx Frequency (MHz) Emission Designator Conducted output power ERP Max power (dBm) Max power (W) Max power (dBm) Max power (W) WCDMA850 826.4 ~ 846.6 4M12F9W 22.85 0.193 16.78 0.048 Report No.: DRTFCC2303-0023 FCC ID: BEJTLVUW3IU-W This test report is prohibited to copy or reissue in whole or in part without the approval of Dt&C Co., Ltd. TRF-RF-210(12)210316 Pages: 5 / 28 2. INTRODUCTION 2.1. EUT DESCRIPTION The Equipment Under Test (EUT) supports 850 WCDMA and multi band LTE. 2.2. TESTING ENVIRONMENT Ambient Condition ▪ Temperature +21 °C ~ +22 °C ▪ Relative Humidity 40 % ~ 44 % 2.3. MEASURING INSTRUMENT CALIBRATION The measuring equipment, which was utilized in performing the tests documented herein, has been calibrated in accordance with the manufacturer's recommendations for utilizing calibration equipment, which is traceable to recognized national standards. 2.4. MEASUREMENT UNCERTAINTY The measurement uncertainties shown below were calculated in accordance with requirements of ANSI C63.4-2014. All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a 95 % level of confidence. Parameter Measurement uncertainty Radiated Disturbance (Below 1 GHz) 4.8 dB (The confidence level is about 95 %, k = 2) Radiated Disturbance (1 GHz ~ 18 GHz) 5.0 dB (The confidence level is about 95 %, k = 2) Radiated Disturbance (Above 18 GHz) 5.2 dB (The confidence level is about 95 %, k = 2) 2.5…

Text truncated - open the document above for the full version.

1 ANTENNA SPECIFICATION Product : Shark pin antenna Model Name : 5WA.035.507 B 041 Date : 2019. 1. 14. 2 Table of Contents Page 1.Model Name ------------------------------------------------------------------------------- 3 2 . Antenna Type ----------------------------------------------------------------------------- 3 3 . Electrical Performance Data ---------------------------------------------------- 3 ~ 7 3 1.Model Name 5WA.035.507 B 041 2.Antenna Type - Shark pin Antenna 3.Electric Performance Data 3.1 Specification Sheet Freq.[MHz]Eff.[%]Avg.[dBi] Peak[dBi]Eff.[%]Avg.[dBi] Peak[dBi]Eff.[%]Avg.[dBi] Peak[dBi] 61713.39-8.73-3.635.96 -12.25-7.219.35-7.13-3.44 703 51.89-2.8519.1-10.41-5.8760.99-2.151.02 74663.42-1.981.959.11 -10.41-5.0872.53-1.391.98 78752.73-2.781.639.41 -10.26-5.7862.14-2.071.68 834 51.77-2.861.9111.03-9.57-5.4762.8-2.021.94 89453.56-2.712.0412.1-9.17-3.3865.67-1.832.12 96054.56-2.63216.42-7.85-1.7770.99-1.492.08 151015.97-7.97-1.5529.59-5.29-0.7245.55-3.410.33 155021.14-6.750.6328.68-5.42-0.7949.83-3.030.71 157517.48-7.58-0.7230.73-5.12-0.7348.21-3.170.69 171028.18-5.52.2147-3.280.775.18-1.242.38 185026.49-5.771.8546.3-3.342.1172.79-1.382.85 192021.15-6.751.0439.37-4.051.0460.53-2.181.61 199019.71-7.050.3337.24-4.290.3256.95-2.441.89 217023.2-6.342.5540.47-3.930.9163.67-1.962.62 230019.95-71.7937.17-4.31.1357.12-2.431.88 236018.75-7.271.636.48-4.380.9655.23-2.582.1 250018.06-7.431.1833.13-4.80.5251.19-2.911.7 269014.63-8.351.5829.97-5.231.0344.59-3.511.77 Electronic Specification Theta-Pol(H) Phi-Pol(V) PwrSum 4 3.2 Radiation Pattern 3.2.1 H-PLANE 1. 617Mhz ~ 960Mhz 2. 1427Mh z ~ 1575Mhz 3. 1710Mhz ~ 2170Mhz 5 4.2500Mhz ~ 2900Mhz 6 3.2.2 V-PLANE 1. 617Mhz ~ 960Mhz 2. 1427Mhz ~ 1575Mhz 3. 1710Mhz ~ 2170Mhz 7 4. 2500Mhz ~ 2900Mhz

FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. Test Setup photographs EUT Position: X-axis EUT Position: Y-axis EUT Position: Z-axis FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. Test Setup Photo of Radiated Measurement (Below 1GHz) FCC ID: BEJTLVUW3IU-W Copyright Ⓒ 2023, Dt&C Co., Ltd. Test Setup Photo of Radiated Measurement (Above 1GHz)
